between 60ºC (140ºF) and 70ºC (150ºF), the thermostat and its sealing function within the
thermostat housing must be checked.

5. 5. INSTALL a new thermostat.

REFER to:

Thermostat

(303-03E Engine Cooling - 2.0L Duratorq-TDCi

(85kW/115PS) - DW/2.0L Duratorq-TDCi (100kW/136PS) - DW/2.0L Duratorq-TDCi
(103kW/140PS) - DW, Removal and Installation).

6. 6. Carry out another road test from step 1 using the same criteria to confirm that the

concern has been rectified.

7. 7. Using the Ford approved diagnostic tool, clear the PCM keep alive memory (KAM)

or electrically erasable programmable read only memory (EEPROM) so that new
drive values can be learnt.

Engine Cooling - 2.2L Duratorq-TDCi
(129kW/175PS) - DW - Radiator Lower
Mounting Repair

S-MAX/Galaxy 2006.5 (02/2006

General Procedures

General Equipment

5 mm drill bit
Cable ties
Flat file

1. On both sides.

2. Secure the radiator and condenser assembly to the front

panel (on both sides).

General Equipment:

Cable ties

3. Raise and support the vehicle.

Refer to:

Lifting

(100-02 Jacking and Lifting, Description

and Operation).

1. General

Equipment:

Flat file

2. General

Equipment:

5 mm drill
bit

8. Torque: 25 Nm

9. Torque: 8 Nm

10. Lower the vehicle.

11. Remove the cable ties securing the radiator and condenser

assembly.

12. On both sides.
