2001 RANGER ELECTRIC VEHICLE

151-21

COMPONENT LOCATION VIEWS

2001 ELECTRIC RANGER
FCS–12887–01 (21 OF 29)

DO NOT USE
THIS  ILLUSTRATION
AND GRID FOR
REPORTING VEHICLE
REPAIR  LOCATIONS

UNDERHOOD (POSTAL 2 OF 4)

1

2

3

4

5

6

7

8

9

10

B

C

D

E

F

A

A

B

C

D

E

F

1

2

3

4

5

6

7

8

9

10

FRONT OF VEHICLE

G104

C1954, C1955
COOLING FAN
RELAY BOX

C1969
CHARGER
INLET

ENGINE
COMPARTMENT
FUSE BOX

C1953
DC/DC TEMP
SENSOR

2001 RANGER ELECTRIC VEHICLE

151-22

COMPONENT LOCATION VIEWS

2001 ELECTRIC RANGER
FCS–12887–01 (22 OF 29)

DO NOT USE
THIS  ILLUSTRATION
AND GRID FOR
REPORTING VEHICLE
REPAIR  LOCATIONS

UNDERHOOD (POSTAL 3 OF 4)

1

2

3

4

5

6

7

8

9

10

B

C

D

E

F

A

A

B

C

D

E

F

1

2

3

4

5

6

7

8

9

10

FRONT OF VEHICLE

C144
HORN

C182
RIGHT FRONT
PARK/TURN
LAMP

C180
LEFT FRONT
PARK/TURN
LAMP

C147
LEFT
HEADLAMP

C155
RIGHT
HEADLAMP

G1998

C1970
RIGHT FRONT
WHEEL SENSOR

G105

C1951
LEFT FRONT
WHEEL SENSOR

C1952
AMBIENT
TEMPERATURE
SENSOR

2001 RANGER ELECTRIC VEHICLE

151-23

COMPONENT LOCATION VIEWS

2001 ELECTRIC RANGER
FCS–12887–01 (23 OF 29)

DO NOT USE
THIS  ILLUSTRATION
AND GRID FOR
REPORTING VEHICLE
REPAIR  LOCATIONS

UNDERHOOD (POSTAL 4 OF 4)

1

2

3

4

5

6

7

8

9

10

B

C

D

E

F

A

A

B

C

D

E

F

1

2

3

4

5

6

7

8

9

10

FRONT OF VEHICLE

C1966
GLYCOL
COOLANT
SENSOR

C1967
COOLING FAN

C164
WINDSHIELD
WASHER PUMP

2001 RANGER ELECTRIC VEHICLE

151-24

COMPONENT LOCATION VIEWS

2001 ELECTRIC RANGER
FCS–12887–01 (24 OF 29)

DO NOT USE
THIS  ILLUSTRATION
AND GRID FOR
REPORTING VEHICLE
REPAIR  LOCATIONS

INSTRUMENT PANEL (POSTAL 1 OF 3)

1

2

3

4

5

6

7

8

9

10

B

C

D

E

F

A

A

B

C

D

E

F

1

2

3

4

5

6

7

8

9

10

FRONT OF VEHICLE

C202
PARKING
BRAKE SWITCH

C219
STEERING COLUMN
CLOCKSPRING

I/P FUSE
PANEL

C2995
ACCELERATION
POSITION SENSOR
(APS)

C210
BRAKE PEDAL
POSITION (BPP)
SWITCH

G200

C903
GRUMMAN
HEADLINER
HARNESS
