2001 RANGER ELECTRIC VEHICLE
150-107
CONNECTOR FACES
3999 (DB/LG)
3001 (PK/OG)
3136 (WH)
3003 (PK/WH)
-
3410 (YE)
570 (BK/WH)
57 (BK)
3006 (PK/LG)
3000 (VT)
3986 (DG)
Auxiliary Contactor Relay Status
Battery Heater #1
Negative Buss Open Control
Emergency Power Off (EPO) Request
From Battery Control Module (BCM)
NOT USED
Inertia Switch +12 Volt Input
Signal Ground
Chassis Ground
Emergency Power Off (EPO) Signal to
Battery Control Module (BCM)
Battery Heater #2
Main Contactor Relay Control
1
2
3
4
5
6
7
8
9
10
11
C1982
PIN
CIRCUIT
CIRCUIT FUNCTION
CONTACTOR BOX
3138 (LB/BK)
295 (LB/PK)
190 (WH/OG)
3706 (DB)
3997 (DG)
3007 (VT/YE)
3991 (TN)
3998 (GY)
3137 (GY/YE)
3705 (LB)
3996 (RD/YE)
3602 (TN/YE)
Current Sensor Control Input
Power (Hot in Run and Start)
Power (Hot At All Times)
Main Current Sensor Output
Emergency Power Off (EPO) to
Traction Inverter Module (TIM)
Battey Heater Present
Precharge Contactor Relay Control
Auxiliary Contactor Relay Control
Charge Contactor Control Input
Auxiliary Current Sensor Output
Auxiliary Current Sensor Return
Main Current Sensor Return
12
13
14
15
16
17
18
19
20
21
22
23
PIN
CIRCUIT
CIRCUIT FUNCTION
8
7
6
5
4
3
2
1
15
14
13
12
11
10
9
23
22
21
20
19
18
17
16
