2001 RANGER ELECTRIC VEHICLE

150-103

CONNECTOR FACES

1

2

3

4

619 (PK/WH)

-

-

-

Air Bag Crash Sensor Feed

NOT USED

NOT USED

NOT USED

C1967

PIN

CIRCUIT

CIRCUIT FUNCTION

RIGHT PRIMARY CRASH SENSOR

14290

2

3

4

C1969F

14B308

1

2

3

261 (OG/BK)

260 (RD/OG)

57 (BK)

Cooling Fan, Low

Cooling Fan, High

Ground

C1968

PIN

CIRCUIT

CIRCUIT FUNCTION

COOLING FAN

14290

3

1

2

C1969M

57 (BK)

3984(RD)

3404 (YE)

57 (BK)

3404 (YE)

3984(RD)

1

14290

2001 RANGER ELECTRIC VEHICLE

150-104

CONNECTOR FACES

148 (YE/RD)

515 (OG/RD)

361 (RD)

758 (VT/WH)

57 (BK)

VBC Feedback Signal to Interface

Adapter Assembly (IAA) Module

VBC Control from Interface Adapter

Assembly (IAA) Module

VBC Low Side Relay Coil

Blower Motor Ground Reference

Ground

1

2

3

4

5

C1971

PIN

CIRCUIT

CIRCUIT FUNCTION

VARIABLE BLOWER CONTROLLER (VBC)

5

4

1

2

3

1

2

1

2

524(PK/BK)

523 (RD/PK)

Sensor Low to Module

Sensor High to Module

C1970

PIN

CIRCUIT

CIRCUIT FUNCTION

RIGHT FRONT ANTIĆLOCK BRAKE SENSOR

14405

POSTAL

2001 RANGER ELECTRIC VEHICLE

150-105

CONNECTOR FACES

1

2

3051 (BK/YE)

3063 (TN/OG)

Evaporator Temperature Sensor

Evaporator Temperature Sensor

Reference

C1972

PIN

CIRCUIT

CIRCUIT FUNCTION

EVAPORATOR TEMPERATURE SENSOR

14290

1

2

3

4

3232 (VT)

-

-

3222 (PK/LB)

A/C Low Pressure Switch Sensor Signal

NOT USED

NOT USED

A/C Low Pressure Switch

C1973

PIN

CIRCUIT

CIRCUIT FUNCTION

A/C LOW PRESSURE SWITCH

14290

4

2

3

1

1

2

2001 RANGER ELECTRIC VEHICLE

150-106

CONNECTOR FACES

C1980F

10B691

3410 (YE)

C1981

10B691

1197 (LG/BK)

3704(RD/WH)

LOWER FRONT PACK TEMPERATURE SENSOR #3

974(OG)

C1980M

14B309

3410 (YE)

974(OG)

1

2
