Ford Ranger EV (2001 year). Manual - part 262
2001 RANGER ELECTRIC VEHICLE
150-11
CONNECTOR FACES
-
810 (RD/LG)
516 (YE/BK)
514(YE/RD)
-
523 (RD/PK)
524(PK/BK)
57 (BK)
534(YE/LG)
-
-
-
NOT USED
Brake Pedal Position Switch
Right Front AntiĆLock Brake Sensor
(Low)
Right Front AntiĆLock Brake Sensor
(High)
NOT USED
Right Rear AntiĆLock Brake Sensor
(High)
Right Rear AntiĆLock Brake Sensor
(Low)
Ground
Power (Hot at all Times)
NOT USED
NOT USED
NOT USED
1
2
3
4
5
6
7
8
9
10
11
12
C154
PIN
CIRCUIT
CIRCUIT FUNCTION
ANTIĆLOCK BRAKE CONTROL MODULE
-
-
-
603 (DG)
522 (TN/BK)
521 (TN/OG)
-
601 (LB/PK)
519 (LG/BK)
518 (LG/RD)
70 (LB/WH)
57 (BK)
483 (RD)
NOT USED
NOT USED
NOT USED
ABS Indicator
Left Front AntiĆLock Brake Sensor
(Low)
Left Front AntiĆLock Brake Sensor
(High)
NOT USED
Power (Hot in Run)
Left Rear AntiĆLock Brake Sensor
(Low)
Left Rear AntiĆLock Brake Sensor
(High)
Data Link Connector (DLC)
Ground
ABS Continuous Power
13
14
15
16
17
18
19
20
21
22
23
24
25
PIN
CIRCUIT
CIRCUIT FUNCTION
2
3
4
6
7
16
23
22
21
20
18
17
8
9
2425
1
5
10
11
12
13
1415
19
