2001 RANGER ELECTRIC VEHICLE
124-1 POWER MIRRORS
For diagnostic information, refer to
Section 501-09 of the Workshop Manual.
Refer to Location Index, Cell 152, for Component,
Connector, Splice, Ground and Base Part Number
descriptions and locations.
12V (UP)
0V (DOWN)
RD
C200
EXTERIOR
REAR VIEW
MIRROR
SWITCH
SEE PAGE 149-10
FOR SWITCH
TESTING
RIGHT
EXTERIOR
REAR
VIEW
MIRROR
LEFT/
RIGHT
MOTOR
SEE GROUNDS
PAGE 10-10
I/P FUSE
PANEL
PAGE 13-2
32
7.5A
UP/DOWN
MOTOR
M
M
LEFT
EXTERIOR
REAR VIEW
MIRROR
544
VT
543
DG
540
541
DB
542
YE
57
BK
LEFT
AND
RIGHT
MIRROR
SELEC-
TOR
SWITCH
DIRECTIONAL CONTROL SWITCH
SEE POWER
DISTRIBUTION
PAGE 13-2
542
YE
UP
DN
UP
DN
L
R
L
R
L
R
L
R
G200
C500
C509
C509
12V
0V
UP/DOWN SWITCH
C509
956
OG/LG
544
VT
543
DG
C252
C252
542
YE
C200
12V (UP)
0V (DOWN)
12V
(DOWN OR R)
0V (UP OR L)
12V (UP)
0V (DOWN)
12V (UP)
0V (DOWN)
12V (DOWN OR R)
0V (UP OR L)
12V (DOWN OR R)
0V (UP OR L)
12V (L)
0V (R)
12V (L)
0V (R)
12V (L)
0V (R)
12V (L)
0V (R)
C600
542
YE
C600
543
DG
544
VT
HOT AT ALL TIMES
LEFT/
RIGHT
MOTOR
M
M
UP/DOWN
MOTOR
542
YE
C201
