Ford Ranger EV (2001 year). Manual - part 60

303-03-18

Engine Cooling

REMOVAL AND INSTALLATION (Continued)

2. Remove the radiator cooling fan.

1 Unclip the hose.
2 Remove the two bolts.
3 Disconnect the cooling fan electrical

connector.

4 Remove the radiator fan.

Installation

1. Install the radiator cooling fan.

1 Position the cooling fan.
2 Install the two bolts.
3 Connect the cooling fan electrical connector.
4 Clip the hose in position.

2. Connect the auxiliary battery ground cable.

Cooling System Tubes and Hoses

Removal

CAUTION: Do not remove the radiator

pressure relief cap if the coolant is hot or if
the coolant pump is running.
Turn the radiator pressure relief cap to the first
stop to remove any remaining pressure.

2. Raise and support the vehicle. Refer to

Section

100-02

303-03-19

Engine Cooling

REMOVAL AND INSTALLATION (Continued)

3. Disconnect the front coolant tube rubber hose

connections.

•

Clamp off the hoses to prevent coolant loss.

•

Position a catch pan to collect the coolant.

4. Disconnect the rear coolant tube rubber hose

connections.

•

Clamp off the hoses to prevent coolant loss.

•

Position a catch pan to collect the coolant.

5. Remove the coolant tubes.

1 Remove the eight coolant tube clamp

screws.

2 Remove the tubes.

303-03-20

Engine Cooling

REMOVAL AND INSTALLATION (Continued)

Installation

1. To install, reverse the removal procedure.

•

After installation, bleed the cooling system.
Refer to

Bleed — Cooling System.

Cooling System Tubes and Hoses —Postal Ranger EV

Removal

WARNING: Do not remove the

radiator pressure relief cap if the coolant is
hot or if the coolant pump is running.
Turn the radiator pressure relief cap to the first
stop to remove any remaining pressure.

2. Raise and support the vehicle. Refer to

Section

100-02
