Ford Ranger EV (2001 year). Manual - part 59

303-03-14

Engine Cooling

REMOVAL AND INSTALLATION

Coolant Pump

Removal

1. If connected, disconnect the vehicle from the

charging station.

2. Disconnect the auxiliary battery ground cable.

CAUTION: Do not remove the radiator

pressure relief cap if the coolant is hot or if
the coolant pump is running.
Turn the radiator pressure relief cap to the first
stop to remove any remaining pressure.

4. Raise and support the vehicle. Refer to

Section

100-02

5. Remove the LH inner fender splash shield.

•

Disconnect the six clips.

6. NOTE: When removing the water pump, it is

preferable to clamp off the coolant lines rather
than letting them drain.
Clamp off and disconnect the coolant lines from
the water pump.

303-03-15

Engine Cooling

REMOVAL AND INSTALLATION (Continued)

7. Disconnect the coolant pump electrical

connector.

8. Remove the coolant pump.

1 Remove the bolt.
2 Remove the pump.

Installation

1. To install, reverse the removal procedure.

•

After installation, bleed the cooling system.
Refer to

Cooling System Drain, Fill and

Bleed

Coolant Pump —Postal Ranger EV

Removal

1. If connected, disconnect the vehicle from the

charging station.

2. Disconnect the auxiliary battery ground cable.

303-03-16

Engine Cooling

REMOVAL AND INSTALLATION (Continued)

CAUTION: Do not remove the radiator

pressure relief cap if the coolant is hot or if
the coolant pump is running.
Turn the radiator pressure relief cap to the first
stop to remove any remaining pressure.

4. Raise and support the vehicle. Refer to

Section

100-02

5. Remove the LH inner fender splash shield.

6. NOTE: When removing the water pump, it is

preferable to clamp off the coolant lines rather
than letting them drain.
Clamp off and disconnect the coolant lines from
the water pump.
