303-01-14
303-01-14
Basic Motor/Transaxle
REMOVAL AND INSTALLATION (Continued)
15.
CAUTION: Do not lower the
motor/transaxle more than 4 inches (102
mm) or damage to the motor/transaxle
electrical connections may occur.
Lower the motor/transaxle 4 inches (102 mm)
to expose the top of the motor/transaxle frame.
16. NOTE: If installing a new motor/transaxle,
remove the LH and RH bracket bolts.
Disconnect the halfshaft from the
motor/transaxle.
17. Lower the motor/transaxle and remove from the
vehicle.
Installation
1. To install, reverse the removal procedure.
