Ford Ranger EV (2001 year). Manual - part 48

211-02-13

211-02-13

Power Steering

REMOVAL AND INSTALLATION (Continued)

Power Steering Gear — Postal Ranger EV

Removal and Installation

1. The power steering gear is the same as the

gasoline powered Ranger. For additional
information, refer to Section 211-02 of the
2001 Ranger Workshop Manual.

211-02-14

211-02-14

Power Steering

REMOVAL AND INSTALLATION (Continued)

Power Steering Pump Hoses — Pressure Hose

Removal

1. Disconnect the pressure hose from the power

steering pump.

2. Raise and support the vehicle. Refer to

 Section

100-02

.

3. Disconnect the pressure hose from the steering

gear.

4. Remove the pressure hose.

1 Remove the clamp bolt.
2 Remove the pressure hose.

211-02-15

211-02-15

Power Steering

REMOVAL AND INSTALLATION (Continued)

Installation

1. To install, reverse the removal procedure.

•

Purge the power steering system of air.
Refer to Section 211-00 of the 2001
Ranger Workshop Manual.

211-02-16

211-02-16

Power Steering

REMOVAL AND INSTALLATION (Continued)

Power Steering Pump Hoses — Pressure Hose - Postal Ranger EV

Removal

1. Disconnect the pressure hose from the power

steering pump.

2. Raise and support the vehicle. For additional

information, refer to

 Section 100-02

.

3. Disconnect the pressure hose from the steering

gear.

4. Remove the pressure hose.

1 Remove the clamp bolt.
2 Remove the pressure hose.
