Ford Ranger EV (2001 year). Manual - part 30





204-02-25

204-02-25

Rear Suspension

REMOVAL AND INSTALLATION (Continued)

4.

Remove the hub.

1

Install Hub Puller, Safety Chain, and Slide
Hammer.

2

Remove the hub.

5.

Remove snap ring.

6.

Remove the wheel bearing using the Wheel
Bearing Removal and Installation Kit or
equivalent.

Installation

1.

Position the wheel bearing.

204-02-26

204-02-26

Rear Suspension

REMOVAL AND INSTALLATION (Continued)

2.

Install the wheel bearing using the Wheel
Bearing Removal and Installation Kit or
equivalent.

3.

Install the snap ring.

4.

Install the halfshaft. Refer to

 Section 205-05

.

5.

Install the hub.

1

Position the hub.

2

Install the hub washer and nut. Tighten the
nut to the specified torque to install the hub
into the bearing and over the halfshaft.

6.

Install the rotor.

1

Position the rotor.

2

Install the retaining clips.

204-02-27

204-02-27

Rear Suspension

REMOVAL AND INSTALLATION (Continued)

7.

Install the caliper

1

Position the caliper.

2

Install the bolts.

8.

Install the wheel.

9.

Lower the vehicle.
