Ford Falcon. Manual - part 362

415-01-4 Audio

Unit 415-01-4

DIAGNOSIS AND TESTING

Audio System

Refer to Section 415-00.

G73349 en

415-01-5 Audio

Unit 415-01-5

REMOVAL AND INSTALLATION

3.  Remove the steering wheel audio control screws.

Audio System Security

NOTE: Some steering wheels are leather

wrapped and should be protected when removing

 WARNING: All audio systems fitted are

the steering wheel controls.

protected by an electronic security system, which

Remove the steering wheel audio control.

renders it inoperative if removed from its

originally fitted vehicle. Owner provided security

Disconnect the electrical connectors.

cards are not required as the audio system links

to other electronics in that vehicle. All audio units

will be coded when they leave the factory and

re-training can only be carried out by using the

WDS tester.

Audio Unit

1.  See information in Section 413-08 for Audio Unit

removal and installation.

Amplifier

Removal
1.  Remove left hand side interior quarter trim.
2.  Remove 2 rivets.

Installation

3.  Remove amplifier and disconnect wiring.

1.  Reverse the removal procedure.

NOTE: When reinstalling screws set gap between

switch buttons and horn pad to 0.7mm.

Capacitor

Removal
1.  Follow removal procedure shown in figure.

Item

Description

1

Amplifier

2

Rivets

3

Bracket

Installation
1.  Connect wiring to amplifier.

Item

Description

2.  Locate amplifier in position.

1

Interference capacitor attached here

3.  Install 2 rivets.
4.  Refit interior quarter trim.

Installation
1.  Reverse the removal procedure.

Steering Wheel Audio Controls

Ground Strap

Removal
1.  Disconnect the battery ground cable. For

Removal

additional information, refer to Section 414-01.

1.  Disconnect the battery cables. For additional

2.  Remove the steering wheel air bag. For additional

information, refer to Section 414-01.

information, refer to Section 501-20B.

G73356 en

415-01-6 Audio

Unit 415-01-6

REMOVAL AND INSTALLATION (Continued)

2. Remove

bolts

I6

V8

Installation
1.  Reverse the removal procedure, torque to

specifications.

G73356 en

415-02-1 Antenna 415-02-1

SECTION : 415-02 Antenna

VEHICLE APPLICATION : 2003.0 BA Falcon
CONTENTS

PAGE

SPECIFICATIONS

 Specifications   ........................................................................................................................415-02-2

DESCRIPTION AND OPERATION

 Antenna   .................................................................................................................................415-02-3

DIAGNOSIS AND TESTING

 Antenna   .................................................................................................................................415-02-4

GENERAL PROCEDURES

  Antenna Grid Wire Repair   .....................................................................................................415-02-5

REMOVAL AND INSTALLATION

  Antenna — Sedan  .................................................................................................................415-02-6

  Antenna — Wagon  ................................................................................................................415-02-6

  Antenna — Ute   .....................................................................................................................415-02-6

  Antenna Lead — in Cable   .....................................................................................................415-02-6
