Entertainment System — General Information

415-00-23

DIAGNOSIS AND TESTING (Continued)

Test Step

Result/Action to Take

Acronyms

M2

Check that the accessories are on.

Yes

ACC_POS

Check pid’s using data logger.

Go to M3

Are the accessories on?

No

Repair faulty ignition

system and retest.

M3

Check to see if the ICC audio is turned on.

Yes

Is the audio on?

Go to M5

No

Go to M4

M4

Push the ICC audio power button.

Yes

POWER_SW

Check pid’s using data logger.

Go to M5

Does the ICC audio turn on?

No

Go to ICC does not turn

on symptom in the

symptom chart.

M5

Check that the rear speakers mute and a sonar

Yes

REVRS_INP

beeping alert sounds when the vehicle is placed in

No fault. ICC functioning

reverse.

correctly.

Check pid’s using data logger.

No

Does the sonar operate correctly?

Continue

M6

Check that the sonar system / wiring is correct as

Yes

per procedures.

Replace ICC and retest.

Is the system / wiring OK?

No

Repair faulty system /

wiring and retest.

G68759 en

415-01-1 Audio

Unit 415-01-1

SECTION : 415-01 Audio Unit

VEHICLE APPLICATION : 2003.0 BA Falcon
CONTENTS

PAGE

SPECIFICATIONS

 Specifications   ........................................................................................................................415-01-2

DESCRIPTION AND OPERATION

  Audio System   ........................................................................................................................415-01-3

DIAGNOSIS AND TESTING

  Audio System   ........................................................................................................................415-01-4

REMOVAL AND INSTALLATION

  Audio System Security   ..........................................................................................................415-01-5

  Audio Unit   .............................................................................................................................415-01-5

 Amplifier   ................................................................................................................................415-01-5

  Steering Wheel Audio Controls   .............................................................................................415-01-5

 Capacitor   ...............................................................................................................................415-01-5

  Ground Strap   ........................................................................................................................415-01-5

415-01-2 Audio

Unit 415-01-2

SPECIFICATIONS

Torque Specifications

Description

Nm

Intake manifold suppressor bolt

19 - 24

Steering wheel switch screws

1.8 - 2.2

Ground strap belt - engine

40.3 - 54.7

Ground strap belt - chassis

10.2 - 13.8

G73347 en

415-01-3 Audio

Unit 415-01-3

DESCRIPTION AND OPERATION

controls. Suitable audio units are portable cassette

Audio System

players, CD players, DVD or MP3 players.

The audio system consists of the following

For this function to be enabled, an aux jumper

components:

harness available through Ford must be connected.

Audio unit
Amplifier (where fitted)
Steering wheel controls

The audio controls on the steering wheel allows the

driver to control volume, media selection, memory

presets and radio station and CD track seek. The

audio controls are located on the left side of the

steering wheel.
There are 3 audio units available with features as

indicated in the following table.

Feature

Low

Mid

High

Series

Series

Series

AM/FM stereo radio

X

X

X

CD player single disc

X

Vehicles are equipped with 4, 6 or 11 speakers

CD player 6 disc in

X

X

depending on the equipment level. Refer to Section

dash

415-03.

100 watt power output

X

X

The subwoofer amplifier incorporates "thermo

protection" which shuts down the output when the

250 watt power output

X

luggage compartment temperature exceeds 90

°C.

Subwoofer amplifier

X

This automatically protects the unit from internal

Steering wheel remote

X

X

X

damage during times of extreme heat. Should this

control: volume, mode,

situation occur, allow the unit to cool down or open

tuner scan & seek & cd

the deck lid for a short period. The unit will return to

track increment

normal operation after the temperature drops to an

acceptable level.

Speed dependant

X

X

X

volume

Radio Frequency Interference Suppression

Speed dependant bass

X

X

X

The radio ignition interference capacitor reduces

Sound position control

X

X

X

interference transmitted through the radio speakers by

Digital signal

X

the engine ignition and electrical system.

processing (dsp)

studio, stadium, hall
CD compression

X

clock

X

X

Telephone interface

X

X

X

and mute
Navigation audio

X

X

X

interface
Sonar parking audio

X

interface
Auxillary audio input

X

X

X

Output power limiting to

X

X

X

10% thd (total harmonic

distortion)
System diagnostics

X

X

X

Item

Description

1

Interference capacitor attached here

Refer to the owners manual for complete operating

guidelines.
All audio systems include an Auxillary audio input

function, where an external device can be connected

to provide audio functionality via the vehicle audio

G73348 en
