309-00-10 Exhaust

System 309-00-10

REMOVAL AND INSTALLATION (Continued)

Wagon - 6 cylinder (ULP & SFLPG)

Item

Description

1

M10 Nut assembly

2

Three-way catalytic converter

3

Intermediate muffler assembly

4

Rear muffler assembly

5

Rubber exhaust hanger insulators

6

Nut assembly

G56320 en

309-00-11 Exhaust

System 309-00-11

REMOVAL AND INSTALLATION (Continued)

Ute - 6 cylinder (ULP)

Item

Description

1

M10 Nut assembly

2

Three-way catalytic converter

3

Intermediate muffler assembly

4

Rubber exhaust hanger insulators

5

Rear muffler assembly

6

Nut assembly

G56320 en

309-00-12 Exhaust

System 309-00-12

REMOVAL AND INSTALLATION (Continued)

Ute - 6 cylinder (SFLPG)

Item

Description

1

M10 Nut assembly

2

Three-way catalytic converter

3

Intermediate muffler assembly

4

Nut Assembly

5

Rubber exhaust hanger insulators

6

Rear muffler assembly

7

Nut assembly

G56320 en

309-00-13 Exhaust

System 309-00-13

REMOVAL AND INSTALLATION (Continued)

Ute - 8 cylinder (ULP)

Item

Description

1

M10 Nut assembly

2

Two-way adapter

3

Three-way catalytic converter

4

Intermediate muffler assembly

5

Rubber exhaust hanger insulators

6

Rear muffler assembly

7

Nut Assembly

8

Nut assembly

G56320 en
