307-01-55 Automatic

Transmission 307-01-55

REMOVAL AND INSTALLATION (Continued)

V8 Steering column components

G73102 en

307-01-56 Automatic

Transmission 307-01-56

REMOVAL AND INSTALLATION (Continued)

Gear Shift — Floor Mounted

Removal
1.  Raise the vehicle and disconnect the transmission

shift cable from the lower selector lever.

I6 Floor mount shift components

G73103 en

307-01-57 Automatic

Transmission 307-01-57

REMOVAL AND INSTALLATION (Continued)

V8 Floor mount shift components

2.  Disconnect the four nuts that attach the housing

6.  Remove the whole floor shift housing by lifting

to the floorpan.

vertically

Installation
1.  To install the floor shift housing to the floorpan

reverse the above instructions in order 6, 5, 4.

2.  Place the selector lever in the ‘P’ position.
3.  Raise the vehicle.
4.  Reconnect the four nuts that attach the housing to

the floorpan.

5.  Install the shift cable back onto the lower selector

lever.

6.  Tighten the lock nut to the required torque to 28

Nm.

7.  Lower the vehicle and check transmission

operation in each selector lever detent position.

3.  Lower the vehicle.

8.  Check that the mode light functions correctly. For

4.  Remove the centre console (Refer to section

further information, refer to Section 307-05.

307-05).

5.  Detach the back light bulb/wiring.

G73103 en

307-01-58 Automatic

Transmission 307-01-58

REMOVAL AND INSTALLATION (Continued)

Cross Shaft Seals

Mass Damper / Extension Housing

Special Tool(s)

93 LE (I6)

Selector shift pin remover and

installer

Manual selector shaft seal

remover

Manual selector shaft seal

installer

Removal
1.  Raise the vehicle.
2.  Detach the transmission lever and/or the inhibitor

switch from the cross shaft. For 93LE only the

external cross shaft pin must be removed using

tool 307-467 prior to removing the inhibitor switch.

3.  Carefully remove the seal/s from the case using

special tool 307-365.

Installation

Item

Description

1.  Cover the shaft with plastic tape to prevent

1

Nut  M8

damage to the seal and using special tool

307-366 drive the new seal into the case until it is

2

I6 AutomaticTransmission Extension

flush with the boss. Remove the tape.

Housing

2.  Install the transmission lever and/or inhibitor

3

Extension Housing adapter

switch. For 93LE only install the external cross

4

Support Bracket

shaft pin using tool 307-467 prior to installing the

5

Bolt M10x25

transmission lever.

6

Transmission Support

3.  Lower the vehicle.

7

Lock Nut M10

8

Bolt M10x50

9

Cross Member

10

Bolt M8X46

11

Bolt M10x89
