303-01c-21

Engine — V8 (4V)

303-01c-21

IN-VEHICLE REPAIR (Continued)

5.  Remove the positive crankcase ventilation (PCV)

8.  Remove the four ignition coils.

nylon tube from PCV valve and position the tube

aside.

9.  Separate the engine control wiring harness from

the valve cover studs.

6.  Remove the bolts and the ignition coil cover.

10. Remove the eight bolts, two studs and the valve

7.  Disconnect the four ignition coils.

cover.

Clean and inspect the sealing surfaces.

11. To install, reverse the removal procedure.

NOTE: Apply silicone gasket and sealant in the

locations shown.

G89775 en

303-01c-22

Engine — V8 (4V)

303-01c-22

IN-VEHICLE REPAIR (Continued)

6.  Separate the engine wiring harness from the

Valve Cover — LH

valve cover studs.

Materials
Silicone Gasket and

WSE-M4G323-A4

Sealant

F7AZ-19554-EA or

equivalent

Removal and Installation
1.  Remove the upper intake manifold. For additional

information, refer to Intake Manifold—Upper in

this section.

2.  Remove the engine oil level indicator tube bracket

bolt and position the tube aside.

7.  Remove the bolts, studs and the left valve cover.

Clean and inspect the sealing surfaces.

8.  To install, reverse the removal procedure.

NOTE: Apply silicone gasket and sealant in the

locations shown.

3.  Remove the bolts and the ignition coil cover.
4.  Disconnect the four ignition coils.
5.  Remove the four ignition coils.

Crankshaft Pulley

Special Tool(s)

Remover, Crankshaft Vibration

Damper

303-009 (T58P-6316-D)

Installer, Crankshaft Vibration

Damper

303-102 (T74P-6316-B)

G89775 en

303-01c-23

Engine — V8 (4V)

303-01c-23

IN-VEHICLE REPAIR (Continued)

Materials

Installation

Silicone Gasket and

WSE-M4G323-A4

1.  Apply silicone gasket or LOCKTITE 5900 or

Sealant

equivalent to the Woodruff key slot on the

F7AZ-19554-EA or

crankshaft pulley.

LOCTITE 5900 or

NOTE: The crankshaft pulley must be installed

equivalent

within four minutes after applying the silicone.

Removal
1.  Remove the drive belt. For additional information,

refer to Section 303-05.

2.  Raise and support the vehicle. For additional

information, refer to Section 100-02.

3.  Remove the crankshaft pulley bolt.

2.  Using the special tool, install the crankshaft

pulley.

4.  Using the special tool, remove the crankshaft

pulley.

3.  Install the bolt and washer. Tighten the bolt in four

stages:

Stage 1: Tighten to 90 Nm (66 lb-ft).
Stage 2: Loosen one full turn.
Stage 3: Tighten to 50 Nm (37 lb-ft).
Stage 4: Tighten an additional 85-95 degrees.

G89777 en

303-01c-24

Engine — V8 (4V)

303-01c-24

IN-VEHICLE REPAIR (Continued)

4.  Lower the vehicle.

Installation

5.  Install the drive belt. For additional information,

1.  Apply silicone gasket sealant to outer perimeter

refer to Section 303-05.

surface of crankshaft front seal.

2.  Lubricate the engine front cover and the

Crankshaft Front Oil Seal

crankshaft front oil seal inner lip with clean engine

oil.

Special Tool(s)

Installer, Crankshaft Front Oil

Seal

303-635

Installer, Front Cover Oil Seal

303-335 (T88T-6701-A)

Item

Description

1

Lubricate with engine oil

Remover, Crankshaft Front Oil

2

Seal with silicone gasket sealant

Seal

303-107 (T74P-6700-A)

3.  Using the special tools, install the crankshaft front

oil seal into the engine front cover.

Materials
SAE 5W-20 Premium

WSS-M2C910-A2

Synthetic Blend Motor Oil

10W-30GF2 Engine Oil

orequivalent

Removal
1.  Remove the crankshaft pulley. For additional

information, refer to Crankshaft Pulley in this

section.

2.  Using the special tool, remove the crankshaft front

oil seal.

4.  Install the crankshaft pulley. For additional

information, refer to Crankshaft Pulley in this

section.

Engine Front Cover

Materials
Metal Surface Cleaner

WSE-M5B392-A

F4AZ-19A536-RA or

equivalent
Silicone Gasket and

WSE-M4G323-A4

Sealant

F7AZ-19554-EA or

LOCTITE 5900 or

equivalent
10W-30GF2 Engine Oil

WSS-M2C910-A2

or equivalent
