Ford Transit (2018 year). Manual - part 77

Quantity

Item

4.8 qt (4.5 L)

Washer system fill capacity.

2.62 lb (1.19 kg)

Air conditioning refrigerant fill capacity - vehicles
with rear air conditioning.

1.76 lb (0.8 kg)

Air conditioning refrigerant fill capacity - vehicles
without rear air conditioning.

9.5 fl oz (280 ml)

Air conditioning refrigerant compressor oil fill capa-
city - vehicles with rear air conditioning.

5.4 fl oz (160 ml)

Air conditioning refrigerant compressor oil fill capa-
city - vehicles without rear air conditioning.

1

Change the automatic transmission fluid and filter at the correct service interval.  See

Scheduled Maintenance (page 454).

2

For complete refill of limited slip differential, add 4.0 fl oz. (118 ml) of Additive Friction

Modifier XL-3 or equivalent meeting Ford Specification EST-M2C118-A.
Note: Ford rear axles contain a synthetic lubricant that does not require changing unless
you submerge the axle in water.

Adding Engine Oil

Quantity

1.0 qt (0.9 L)

The quantity of engine oil required to raise
the indicated level on the dipstick from
minimum to maximum.

Specifications

We recommend that you use Motorcraft
oil and fluids for your vehicle.  Only use
fluid that meets Ford specifications.

Materials

Specification

Name

WSS-M2C946-A

Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor Oil
(U.S.)
Huile moteur de très haute qualité SAE 5W-30 Motorcraft®
(Canada)
XO-5W30-QSP (U.S.)
CXO-5W30-LSP6 (Canada)

WSS-M97B44-D2

Motorcraft® Orange Prediluted Antifreeze/Coolant (U.S.)
Antigel/liquide de refroidissement prédilué orange Motorcraft®
(Canada)
VC-3DIL-B (U.S.)
CVC-3DIL-B (Canada)

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake
Fluid (U.S.)

Specification

Name

Liquide de frein automobile haute performance DOT 4 LV
Motorcraft® (Canada)
PM-20 (U.S. & Canada)

MERCON® LV

Motorcraft® MERCON® LV Automatic Transmission Fluid (U.S.)

WSS-M2C938-A

Liquide pour boîte de vitesses automatique Motorcraft® (Canada)
XT-10-QLVC (U.S.)
CXT-10-LV6 (Canada)

WSS-M2C942-A

Motorcraft® SAE 75W-85 Premium Synthetic Hypoid Gear
Lubricant (U.S.)
Huile synthétique de haute qualité pour engrenages hypoïdes SAE
75W-85 Motorcraft® (Canada)
XY-75W85-QL (U.S. & Canada)

EST-M2C118-A

Motorcraft® Additive Friction Modifier (U.S.)
Additif modificateur de friction (Canada)
XL-3 (U.S.)
CXL-3 (Canada)

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concentrate with
Bitterant (U.S.)
Liquide lave-glace de haute qualité Motorcraft® (Canada)
ZC-32-B2 (U.S.)
CXC-37-A/B/D/F (Canada)

WSH-M17B19-A

Motorcraft® R-134a Refrigerant (U.S.)
Frigorigène R-134a (Canada)
YN-19 (U.S.)
CYN-19-R (Canada)

WSH-M1C231-B

Motorcraft® PAG Refrigerant Compressor Oil (U.S.)
Huile PAG pour compresseur frigorifique Motorcraft® (Canada)
YN-12-D (U.S. & Canada)

ESA-M1C75-B

Premium Long-Life Grease (U.S.)
Première Qualité Graisse de Longue Durée (Canada)
XG-1-E1 (U.S. & Canada)

Motor oils of the recommended viscosity
grade that display the API Certification
Mark for gasoline engines are also
acceptable.  Do not use oil labeled with
API SN service category unless the label
also displays the API certification mark.

Note: Automatic transmissions that require
MERCON® LV transmission fluid should
only use MERCON® LV transmission fluid.

E142732

An oil that displays this symbol conforms
to current engine, emission system and
fuel economy performance standards of
the International Lubricants Specification
Advisory Committee (ILSAC).

Note: Do not use more than 1.1 qt (1 L) of
the alternative engine oil between
scheduled service intervals.

Using oil and fluids that do not meet the
defined specification and viscosity grade
may lead to:
•

Component damage which may not be
covered by the vehicle Warranty.

•

Longer engine cranking periods.

•

Increased emission levels.

•

Reduced engine performance.

•

Reduced fuel economy.

•

Reduced brake performance.

Do not use supplemental engine oil
additives because they are unnecessary
and could lead to engine damage that may
not be covered by the vehicle Warranty.

Alternative Engine Oil for
Extremely Cold Climates

To improve engine cold start performance,
we recommend that you use the following
alternative engine oil where the ambient
temperature reaches -22°F (-30°C) or
below.

Materials

Specification

Name

WSS-M2C953-A1

Engine Oil - SAE 0W-30

E240523

CAPACITIES AND
SPECIFICATIONS - 3.7L

WARNING

The air conditioning refrigerant
system contains refrigerant under
high pressure. Only qualified

personnel should service the air
conditioning refrigerant system. Opening
the air conditioning refrigerant system can
cause personal injury.

Capacities

Quantity

Item

6 qt (5.7 L)

Engine oil fill capacity including the oil filter.

5.5 qt (5.2 L)

Engine oil fill capacity excluding the oil filter.

16.4 qt (15.5 L)

Engine coolant fill capacity - vehicles with an auxil-
iary heater.

14.9 qt (14.1 L)

Engine coolant fill capacity - vehicles without an
auxiliary heater.

13.1 qt (12.4 L)

Automatic transmission fluid fill capacity.

1

2.9 qt (2.72 L)

Rear axle fluid fill capacity - vehicles with limited

slip differential.

2

3.0 qt (2.84 L)

Rear axle fluid fill capacity - vehicles with conven-
tional differential.

4.0 fl oz (118 ml)

Rear axle friction modifier.

25.1 gal (95 L)

Fuel tank fill capacity.

4.8 qt (4.5 L)

Washer system fill capacity.

2.45 lb (1.11 kg)

Air conditioning refrigerant fill capacity - vehicles
with rear air conditioning.

1.76 lb (0.8 kg)

Air conditioning refrigerant fill capacity - vehicles
without rear air conditioning.
