Ford Transit (2018 year). Manual - part 29

Press the element in to use the cigar
lighter. It will pop out automatically.

CUP HOLDERS

WARNINGS

Do not place hot drinks in the cup
holders when your vehicle is moving.

Make sure that cups placed in the
holders do not obstruct your vision
while driving.

OVERHEAD CONSOLE

 (If Equipped)

Overhead Storage Compartments

Overhead Console

WARNING

Do not place heavy objects in the
overhead console. Heavy objects
may become projectiles in a crash or

sudden stop and may increase the risk of
serious injury.

E189357

BOTTLE HOLDER

WARNING

Do not place glass objects in the
bottle holder.

E171160

FRONT DOOR STORAGE
COMPARTMENT

 (If Equipped)

E169150

Turn the retaining clips counterclockwise
to open the storage compartment.

GENERAL INFORMATION

WARNINGS

Extended idling at high engine
speeds can produce very high
temperatures in the engine and

exhaust system, creating the risk of fire or
other damage.

Do not park, idle or drive your vehicle
on dry grass or other dry ground
cover. The emission system heats up

the engine compartment and exhaust
system, creating the risk of fire.

Do not start the engine in a closed
garage or in other enclosed areas.
Exhaust fumes can be toxic. Always

open the garage door before you start the
engine.

Exhaust leaks may result in entry of
harmful and potentially lethal fumes
into the passenger compartment. If

you smell exhaust fumes inside your
vehicle, have your vehicle inspected
immediately. Do not drive if you smell
exhaust fumes.

If you disconnect the battery, your vehicle
may exhibit some unusual driving
characteristics for approximately 5 mi
(8 km) after you reconnect it.  This is
because the engine management system
must realign itself with the engine.  You
can disregard any unusual driving
characteristics during this period.

The powertrain control system meets all
Canadian interference-causing equipment
standard requirements regulating the
impulse electrical field or radio noise.

When you start the engine, avoid pressing
the accelerator pedal before and during
operation. Only use the accelerator pedal
when you have difficulty starting the
engine.

IGNITION SWITCH

E180794

A (off) - The ignition is off.

Note: When you switch the ignition off and
leave your vehicle, do not leave your key in
the ignition. This could cause your vehicle
battery to lose charge.

Note: To switch the engine off when your
vehicle is moving, move the transmission
selector lever to position N. Use the brakes
to bring the vehicle to a safe stop. After your
vehicle has stopped, switch the engine off
and move the transmission selector lever to
position P. Turn the key to position A or B.

B (accessory) - Allows the electrical
accessories such as the radio to operate
while the engine is not running.

Note: Do not leave the ignition key in this
position for too long. This could cause your
vehicle battery to lose charge.

C (on) - All electrical circuits operational.
Warning lamps and indicators illuminate.

D (start) - cranks the engine. Release the
key as soon as the engine starts.

STARTING A GASOLINE
ENGINE

Before starting the engine check the
following:
•

Make sure all occupants have fastened
their seatbelts.

•

Make sure the headlamps and
electrical accessories are off.

•

Make sure the parking brake is on.

•

Make sure the transmission is in park
(P).

When you start the engine, the idle speed
increases, this helps to warm up the
engine. If the engine idle speed does not
slow down automatically, have your
vehicle checked by an authorized dealer.

Note: Do not touch the accelerator pedal.

1.

Fully press the brake pedal.

2. Turn the key to the on position to

switch the ignition on.

3. Turn the key to the start position to

start your vehicle.  Release the key
when the engine starts.

Note: You can only operate the starter for
a limited period of time, for example 10
seconds. The number of start attempts is
limited to approximately six. If you exceed
this limit, the system will not allow you to
try again until a period of time has elapsed,
for example 30 minutes.

Engine Idle Speed after Starting

The speed at which the engine idles
immediately after starting will adjust
automatically to minimize vehicle
emissions and maximize cabin comfort
and fuel economy.

The idle speed will vary depending on
certain factors. These include vehicle
component and ambient temperatures as
well as electrical and climate system
demands.

Cold or Hot Engine

If the engine does not start within 10
seconds, wait for a short period and try
again.

If the engine does not start after three
attempts, wait 10 seconds and follow the
flooded engine procedure.

If you have difficulty starting the engine
when the temperature is below -13°F
(-25°C), press the accelerator pedal to the
mid-way point of its travel and try again.

Flooded Engine

1.

Shift into park (P).

2. Fully depress the accelerator pedal and

hold it there.

3. Start the engine.

Note: If the engine does not start, repeat
the cold or hot engine procedure.

STARTING A DIESEL ENGINE

WARNINGS

Do not use starting fluid, for example
ether, in the air intake system. Such
fluid could cause immediate

explosive damage to the engine and
possible personal injury.

Do not mix diesel with gasoline,
gasohol or alcohol. This could cause
an explosion.

Note: Avoid shutting the engine down after
an extensive idling period. Drive your vehicle
for several miles with the engine at normal
operating temperatures under a moderate
load.
