Ford Transit (2018 year). Manual - part 27

E175474

1.

Lift the handle.

2. Move the seat back backward or

forward to attain the desired position.

3. Release the handle.

Adjusting the Armrest

3

E95256

1

2

1.

Raise the armrest fully.

2. Lower the armrest to the stowed

position.

3. Raise the armrest to attain the desired

position.

POWER SEATS

 (If Equipped)

WARNINGS

Do not adjust the driver seat when
your vehicle is moving.

Do not place cargo or any objects
behind the seat backrest before
returning it to the original position.

The driver seat has removable stop
bolts on the track to enable access
to the vehicle battery.  See

Changing the 12V Battery (page 238).

E138647

Power Lumbar

E138648

REAR SEATS

 (If Equipped)

WARNINGS

Do not use the bench seats as a bed
when your vehicle is moving. Failure
to follow this warning could result in

serious personal injury or death.

Do not place any objects on a folded
seat. Hard objects may become
projectiles in a crash or sudden stop,

which may increase the risk of serious
personal injury.

Note: Rear seat arrangements vary
depending on the vehicle.

Recline Adjustment

 (If Equipped)

WARNINGS

When reclining the seat backrest
forward and backward, take care not
to get your hands caught between

the seat backrest and the frame, catches
or mechanism. Failure to take care may
result in personal injury.

WARNINGS

Make sure that any cargo or objects
are not trapped behind the seat
backrest. Make sure the seatbelts

are not trapped in any way when unfolding
the seat backrest up. Failure of an
occupant to be able to use a trapped
seatbelt increases the risk of serious
personal injury or death.

Make sure that the seat backrest is
fully engaged in its catch. A seat
backrest which is not fully engaged

in its catch could move in the event of an
accident. This may result in serious
personal injury or death.

E172224

With the seat occupied, pull the lever or
strap to recline or raise the seat backrest.

Removing Seats (Passenger
Vehicles)

WARNINGS

Seats can weigh up to 176 lb (80 kg).
Do not attempt to lift or carry a seat
on your own.

Do not use the release handles to lift
or carry the seat.

E173870

1

2

3

1.

Pull the release handle up at an angle
from the floor.

2. While holding the handle in this

position, tilt the top of the seat forward
to release the seat frame rear catches
from the floor.

3. When the rear seat latches are clear of

the floor, release the handle.

4. Pull the seat backward to release the

seat frame front catches.

5. Remove the seat from the vehicle.

Note: Two persons are required to release
the seat handles and remove the seat.

Note: You can only remove seats that have
integral release handles.

Note: The seatback does not fold forward.

Installing the Seats

WARNINGS

Make sure that the floor catches are
free from foreign material before
installing the seats.

Make sure that you securely fasten
the seat catches when installing.
Check the latches are correctly

engaged by checking the red latch
indicators.
