Action

Message

See Tire Pressure Monitoring System (page 281).

The system has detected a fault that requires service.  Have
your vehicle checked as soon as possible.

Tire Pressure Monitor
Fault

See Tire Pressure Monitoring System (page 281).

Displays if the system detects a fault with a tire pressure
sensor or the spare tire is in use.

Tire Pressure Sensor
Fault

See Tire Pressure Monitoring System (page 281).
If the warning message remains on after you have checked
the tire pressures, the system has detected a fault that
requires service.  Have your vehicle checked as soon as
possible.

MANUAL CLIMATE CONTROL

E147011

A

E

B

D

C

Fan speed control: Controls the volume of air circulated in your vehicle. Adjust
to select the desired fan speed or switch off. If you switch the fan off, the
windshield may fog up.

A

Recirculated air: Press the button to switch between outside air and
recirculated air. When you select recirculated air, the air currently in the
passenger compartment recirculates. This can reduce the time needed to cool
the interior, when used with A/C, and reduce unwanted odors from entering
your vehicle.

B

Note: Recirculation air may turn off automatically, or be prevented from turning
on in all airflow modes except MAX A/C to reduce risk of fogging. Recirculated
air may also turn on and off automatically in instrument panel or instrument
panel and floor airflow modes during hot weather to improve cooling efficiency.

Temperature control: Controls the temperature of the air circulated in your
vehicle. Adjust to select the desired temperature. If you select MAX A/C, the
system distributes recirculated air through the instrument panel air vents. This
mode is more economical and efficient than normal air conditioning. Turn the
temperature control to maximum heat to turn the auxiliary heater on

C

Air conditioning: Press the button to switch the air conditioning on or off. To
improve air conditioning when starting your vehicle, drive with the windows
open for two to three minutes.

D

Air distribution control: Adjust to select the desired air distribution.

E

Select to distribute air through
the instrument panel air vents.

Select to distribute air through
the instrument panel air vents
and footwell air vents.

Select to distribute air through
the footwell air vents.

Select to distribute air through
the windshield air vents and
footwell air vents.

Select to distribute air through
the windshield air vents. You can
also use this setting to defog or

clear the windshield of a thin covering of
ice. You can also increase the temperature
and fan speed to improve clearing.

HINTS ON CONTROLLING THE
INTERIOR CLIMATE

General Hints

Note: Prolonged use of recirculated air may
cause the windows to fog up.

Note: A small amount of air may be felt
from the footwell air vents regardless of the
air distribution setting.

Note: To reduce humidity build-up inside
your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note: Do not place objects under the front
seats as this may interfere with the airflow
to the rear seats.

Note: Keep the air intakes in front of the
windshield free from obstruction (such as
snow or leaves) to allow the climate control
system to function effectively.

Note: To reduce fogging of the windshield
during humid weather, adjust the air
distribution control to the windshield air
vents position. Increase the temperature
and fan speed and press the A/C button to
improve clearing, if required.

Heating the Interior Quickly

•

Adjust the fan speed to the highest
speed setting.

•

Adjust the temperature control to the
highest setting.

•

Adjust the air distribution control to the
footwell air vents position.

Recommended Settings for
Heating

•

Adjust the fan speed to the second
speed setting.

•

Adjust the temperature control to the
midway point of the hot settings.

•

Adjust the air distribution control to the
footwell and windshield air vents
position.

Cooling the Interior Quickly

•

Adjust the fan speed to the highest
speed setting.

•

Adjust the temperature control to the
MAX A/C position.

•

Adjust the air distribution control to the
instrument panel air vents position.

Recommended Settings for
Cooling

•

Adjust the fan speed to the second
speed setting.

•

Adjust the temperature control to the
midway point of the cold settings.

•

Adjust the air distribution control to the
instrument panel air vents position.

Vehicle Stationary for Extended
Periods During Extreme High
Ambient Temperatures

•

Apply the parking brake.

•

Move the transmission selector lever
to position P or neutral.

•

Adjust the temperature control to the
MAX A/C position.

•

Adjust the fan speed to the lowest
speed setting.

Side Window Defogging in Cold
Weather

•

Adjust the air distribution control to the
instrument panel and windshield air
vents positions.

•

Press the A/C button.

•

Adjust the temperature control to the
desired setting.

•

Adjust the fan speed to the highest
setting.

•

Direct the instrument panel side air
vents toward the side windows.

•

Close the instrument panel vents.

Maximum Cooling Performance in
Instrument Panel or Instrument
Panel and Footwell Positions

•

Adjust the temperature control to the
lowest setting.

•

Press the A/C and recirculated air
buttons.

•

Adjust the fan speed to the highest
setting initially and then adjust it to suit
the desired comfort level.

REAR PASSENGER CLIMATE CONTROLS

E175829

A

B

Fan speed control: Adjusts the volume of air circulated in the vehicle.

A

Temperature and air distribution control: Controls the temperature of the
air circulated in your vehicle. Adjust to select the desired temperature and
distribution. Cool air distributes through the top air vents and warm air distributes
through the rear floor vents.

B
