Ford Transit (2018 year). Manual - part 23

Trip computer 1

Trip computer 2

All Values

1

Speed

Trip Odometer

Gear Shifting

Ford EcoMode

Average Fuel

Anticipation

Speed

Information

Distance to E

Trip Timer

Outside Temp.

1

This feature is seen on high level clusters.

Note: The trip computer readings can be
reset independently.  See Trip Computer
(page 97).

Information

Driver Alert

DEF Level

Exhaust Filter

Engine Hours

Engine Hours

Trailer Brake

MyKey

MyKey Info

System Check

Settings

Traction Ctrl

Driver Assist

Auto Exh.Clean

Driver Alert

Tire Monitor

Auto

Power Step

Deploy

Off

Electric

Trailer Brake

Elec.-Hydraulic

Lane Keeping

Navigation info

Display

Choose your applicable setting.

Language

Choose your applicable setting.

Distance

Choose your applicable setting.

Temperature

Display

Compass

Convenience

Calibrate

Autolock

Locks

Autounlock

Global Unlock

Custom Lock

Create MyKey

Create MyKey

MyKey

Always On

Traction Ctrl

User selectable

Choose your applicable setting.

Max Speed

Off

Choose your applicable setting.

Speed Warning

Settings

Off

Volume Limiter

Clear MyKey

Clear MyKeys

System Check

All active warnings will display first if
applicable. The system check menu may
appear different based upon equipment
options and current vehicle status. Use the
up and down arrow buttons to scroll
through the list.  See Information
Messages (page 98).

TRIP COMPUTER

Resetting the Trip Computer

Press and hold OK on the current screen
to reset the respective trip, distance, time
and average fuel consumption information.

All Values

Indicates all the respective trip, distance,
time and average fuel consumption
information.

Average Fuel Consumption

Indicates the average fuel consumption
since the function was last reset.

Distance to Empty

Indicates the approximate distance your
vehicle will travel on the fuel remaining in
the tank. Changes in driving pattern may
cause the value to vary.

Outside Air Temperature

Shows the outside air temperature.

Trip Odometer

Registers the distance traveled of
individual journeys.

Trip Timer

Registers the elapsed time of individual
journeys or the total time since the function
was last reset.

Digital Speedometer

Provides a digital display of the current
vehicle speed.

PERSONALIZED SETTINGS

Measure Units

You can choose personalized settings
using the information display control on
the steering wheel. See Information
Displays (page 94).

To swap between imperial and metric units, scroll to:

Action and Description

Message

Press the OK button.

Display

Choose your applicable setting. Press the OK button.

Measure unit

Swapping between imperial and metric units will affect the
following displays:
•

Average fuel consumption.

•

Distance to empty.

•

Odometer.

•

Outside temperature units.

•

Trip odometer.

•

Digital Speedometer.

INFORMATION MESSAGES

E130248

Press the OK button to acknowledge and
remove some messages from the
information display.  The information
display will automatically remove other
messages after a short period of time.

You need to confirm certain messages
before you can access the menus.

The message indicator
illuminates to supplement some
messages.

The indicator is red or amber depending
on the severity of the condition and it
remains on until the condition is resolved.

A system-specific symbol with a message
indicator may supplement some
messages.

Note:  Depending on your vehicle options
and instrument cluster type, not all of the
messages will display or be available.  The
information display may abbreviate or
shorten certain messages.

Airbag

Action

Message

Have your vehicle checked as soon as possible.

Airbag fault Service now
