Ford Transit (2018 year). Manual - part 8

E259284

The child safety lock is on the rear side
door.

Left-Hand Side

Turn the key counterclockwise to lock and
clockwise to unlock.

Right-Hand Side

Turn the key clockwise to lock and
counterclockwise to unlock.

PRINCIPLE OF OPERATION

WARNINGS

Always drive and ride with the
seatback upright and the lap belt
snug and low across the hips.

To reduce the risk of injury, make
sure children sit where they can be
properly restrained.

Never let a passenger hold a child on
his or her lap while your vehicle is
moving. The passenger cannot

protect the child from injury in a crash
which may result in serious injury or death.

All occupants of the vehicle,
including the driver, should always
properly wear their seatbelts, even

when an airbag supplemental restraint
system is provided. Failure to properly wear
your seatbelt could seriously increase the
risk of injury or death.

It is extremely dangerous to ride in a
cargo area, inside or outside of a
vehicle. In a crash, people riding in

these areas are more likely to be seriously
injured or killed. Do not allow people to ride
in any area of your vehicle that is not
equipped with seats and seatbelts. Be sure
everyone in your vehicle is in a seat and
using a seatbelt properly.

In a rollover crash, an unbelted
person is significantly more likely to
die than a person wearing a seatbelt.

Each seating position in your vehicle
has a specific seatbelt assembly
which is made up of one buckle and

one tongue that are designed to be used
as a pair. 1) Use the shoulder belt on the
outside shoulder only. Never wear the
shoulder belt under the arm. 2) Never
swing the seatbelt around your neck over
the inside shoulder. 3) Never use a single
belt for more than one person.

WARNINGS

When possible, all children 12 years
old and under should be properly
restrained in a rear seating position.

Failure to follow this could seriously
increase the risk of injury or death.

Seatbelts and seats can become hot
in a vehicle that has been closed up
in sunny weather; they could burn a

small child. Check seat covers and buckles
before you place a child anywhere near
them.

Front and rear seat occupants,
including pregnant women, should
wear seatbelts for optimum

protection in an accident.

All seating positions in this vehicle have
lap and shoulder belts. All occupants of
the vehicle should always properly wear
their seatbelts, even when an airbag
supplemental restraint system is provided.

The seatbelt system consists of:
•

Lap and shoulder seatbelts.

•

Shoulder seatbelt with automatic
locking mode, (except driver seatbelt).

•

Height adjuster at the front outboard
seating positions.

•

Seatbelt pretensioner at the front
outboard seating positions.

E71880

•

Seatbelt warning light and chime.

E67017

•

Crash sensors and monitoring system
with readiness indicator.

The seatbelt pretensioners at the front
seating positions are designed to tighten
the seatbelts when activated. In frontal
and near-frontal crashes, the seatbelt
pretensioners may be activated alone or,
if the crash is of sufficient severity, together
with the front airbags. In side crashes and
rollovers, the seatbelt pretensioners
activate when the Safety Canopy is
activated.

FASTENING THE SEATBELTS

The front outermost and rear safety
restraints in your vehicle are combination
lap and shoulder belts.

E142587

1.

Insert the seatbelt tongue into the
proper buckle (the buckle closest to
the direction the tongue is coming
from) until you hear a snap and feel it
latch.

Note: Make sure that the seatbelt tongue
is properly fastened in the seatbelt buckle.

E142588

2. Press the button to release the seatbelt

tongue.

Using Seatbelts During Pregnancy

WARNING

Always ride and drive with your
seatback upright and properly fasten
your seatbelt. Fit the lap portion of

the seatbelt snugly and low across the
hips. Position the shoulder portion of the
seatbelt across your chest. Pregnant
women must follow this practice. See the
following figure.

E170730

Pregnant women should always wear their
seatbelt.  The lap belt portion of a
combination lap and shoulder belt should
be positioned low across the hips below
the belly and worn as tight as comfort
allows.  The shoulder belt should be
positioned to cross the middle of the
shoulder and the center of the chest.

Seatbelt Locking Modes

WARNINGS

After a crash, have a qualified
technician check all the seatbelts to
make sure the seatbelts including

the automatic locking retractor feature for
child restraints operate properly. We
recommend replacing any system that has
damage or does not operate properly.
Failure to do so can result in personal injury
or death in the event of a sudden stop or
another crash.

You must replace the seatbelt if the
automatic locking retractor or any
other seatbelt function is not

operating correctly. Failure to replace the
seatbelt and retractor assembly could
increase the risk of injury in a crash.

All seatbelts in your vehicle are
combination lap and shoulder belts. The
driver seatbelt has the first type of locking
mode, and the front outermost passenger
and rear seat seatbelts have both types of
locking modes described as follows:

Vehicle Sensitive Mode

This is the normal retractor mode which
allows free shoulder belt length
adjustment to your movements and
locking in response to vehicle movement.
For example, if you brake suddenly or turn
a corner sharply, or your vehicle receives
an impact of approximately 5 mph
(8 km/h) or more, the combination
seatbelts lock to help reduce forward
movement of the driver and passengers.

In addition, the retractor is designed to lock
if you pull the webbing out too quickly. If
the seatbelt retractor locks, slowly lower
the height adjuster to allow the seatbelt
to retract. If the retractor does not unlock,
pull the seatbelt out slowly then feed a
small length of webbing back toward the
stowed position. For rear seatbelts, recline
the rear seat backrest or push the seat
backrest cushion away from the seatbelt.
Feed a small length of webbing back
toward the stowed position.

Automatic Locking Mode

In this mode, the shoulder belt
automatically pre-locks. The seatbelt still
retracts to remove any slack in the
shoulder belt. The automatic locking mode
is not available on the driver seatbelt.

Using Automatic Locking Mode

You should use automatic locking mode
when a child safety seat, except a booster,
is on the front passenger seat or rear seat.
Children 12 years old and under should be
correctly restrained in a rear seating
position whenever possible.  See Child
Safety (page 16).

E142591

1.

Buckle the combination lap and
shoulder belt.

2. Grasp the shoulder portion and pull

downward until you pull the entire
seatbelt out.
