Ford Transit Connect (2016 year). Manual - part 86

Message

Message

Touch this button to adjust settings for:

Sound Settings

Bass

Midrange

Treble

Set Balance and Fade

DSP

Occupancy Mode

Speed Compensated Volume

This allows you to select a category of music you would like to
search for. You can then choose to either seek or scan for the
stations playing that category.

Set Category for
Seek/Scan

This allows you to lock and unlock channels, change or reset your
PIN or unlock all channels. To use this feature, you need your initial
PIN, which is 1234.

Parental Lockout

This feature allows you turn alerts on and off.

Artist / Title / Team
Alerts

SIRIUS requires this number when communicating with you about
your account.

Electronic Serial
Number (ESN)

Touch this button to manually enter the desired satellite channel
number. Touch Enter when you are done

Direct Tune

Note: Your vehicle may not have all these sound settings.

SIRIUS Satellite Radio Information

Note: SIRIUS reserves the unrestricted right
to change, rearrange, add or delete
programming including canceling, moving
or adding particular channels, and its prices,
at any time, with or without notice to you.
Ford Motor Company shall not be
responsible for any such programming
changes.

E142593

SIRIUS satellite radio is a
subscription-based satellite radio service
that broadcasts a variety of music, sports,
news, weather, traffic and entertainment
programming. Your factory-installed
SIRIUS satellite radio system includes
hardware and a limited subscription term
that begins on the date of sale or lease of
your vehicle. See an authorized dealer for
availability.

For more information on extended
subscription terms (a service fee is
required), the online media player and a
list of SIRIUS satellite radio channels, and
other features, please visit
www.siriusxm.com in the United States,
www.sirius.ca in Canada, or call SIRIUS at
1-888-539-7474.

Note: This receiver includes the eCos
real-time operating system. eCos is
published under the eCos License.

Satellite Radio Electronic Serial Number
(ESN)

You need your ESN to activate, modify or
track your satellite radio account. The ESN
is on the System Information Screen (SR
ESN:XXXXXXXXXXXX).

To access your ESN, touch the bottom
left corner of the touchscreen, then
select:

Message

SIRIUS

Options

SIRIUS Satellite Radio Reception Factors and Troubleshooting

Potential reception issues

For optimal reception performance, keep the antenna clear of snow
and ice build-up and keep luggage and other materials as far away
from the antenna as possible.

Antenna obstruc-
tions

Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses,
parking garages, dense tree foliage and thunderstorms can interfere
with your reception.

Terrain

When you pass a ground-based broadcast-repeating tower, a
stronger signal may overtake a weaker one and the audio system
may mute.

Station overload

Your display may show ACQUIRING... to indicate the interference
and the audio system may mute.

Satellite radio
signal interfer-
ence

Troubleshooting tips

Action

Cause

Message

No action required. This
message should disappear
shortly.

Radio requires more than two
seconds to produce audio for
the selected channel.

Acquiring…

If this message does not clear
shortly, or with an ignition key
cycle, your receiver may have
a fault. See an authorized
dealer for service.

There is an internal module or
system failure present.

Satellite antenna fault

SIRIUS system failure

Tune to another channel or
choose another preset.

The channel is no longer avail-
able.

Invalid Channel

Contact SIRIUS at 1-888-539-
7474 to subscribe to the
channel, or tune to another
channel.

Your subscription does not
include this channel.

Unsubscribed Channel

The signal is blocked. When
you move into an open area,
the signal should return.

The signal is lost from the
SIRIUS satellite or SIRIUS
tower to your vehicle antenna.

No Signal

No action required. The
process may take up to three
minutes.

Update of channel program-
ming in progress.

Updating…

Contact SIRIUS at 1-888-539-
7474 to resolve subscription
issues.

Your satellite service is no
longer available.

Questions? Call

1-888-539-7474

Use the channel guide to turn
off the Lock or Skip function on
that station.

All the channels in the selected
category are either skipped or
locked.

None found

Check Channel Guide

No action required.

SIRIUS has updated the chan-
nels available for your vehicle.

Subscription Updated

SIRIUS Satellite Radio Voice
Commands

E142599

If you are listening to SIRIUS
satellite radio, press the voice
button on the steering wheel

controls. You will hear a prompt, you can
then say any of the commands in the
following table.

If you are not listening to SIRIUS
satellite radio, press the voice button
and, after the tones press the voice
button and when prompted say:

Voice command

Sirius

You can then say any of the following
or a similar command:

SAT 1

Voice command

Sports Games

Tune

Help

You can also say the name of any Sirius
station, such as “The Highway” or “Deep
Tracks”, to listen to that station.

CD

E142611

To access, press the lower left corner
on the touchscreen, then select:

Menu Item

CD

Insert your CD then select:

Action and Description

Menu Item

Touch this button to repeat the currently
playing track, all tracks on the disc or switch
the feature off if already on.

Repeat

Touch this button to play the tracks or
entire albums in random order, or switch
the feature off if already on.

Shuffle

Touch this button to hear a brief sampling
of all available tracks.

Scan

Touch this button to see disc information.

More Info

Touch this button to look through all avail-
able CD tracks.

Browse
