Ford Police Interceptor Utility (2018 year). Manual - part 17

Window Lock

E144072

Press the control to lock or unlock the rear
window controls. It illuminates when you
lock the rear window controls.

Accessory Delay

You can use the window switches for
several minutes after you switch the
ignition off or until you open either front
door.

EXTERIOR MIRRORS

Power Exterior Mirrors

WARNING

Do not adjust the mirrors when your
vehicle is moving.

E144073

Left-hand mirror.

Adjustment control.

Right-hand mirror.

To adjust your mirrors, switch your vehicle
on (with the ignition in accessory mode or
the engine running) and then:
1.

Select the mirror you want to adjust.
The control lights.

2. Use the adjustment control to adjust

the position of the mirror.

3. Press the mirror control again. The

control light turns off.

Fold-Away Exterior Mirrors

Push the mirror toward the door window
glass. Make sure that you fully engage the
mirror in its support when returning it to its
original position.

Heated Exterior Mirrors

(If Equipped)

See Heated Windows and Mirrors (page
94).

Integrated Blind Spot Mirror

(If

Equipped)

WARNING

Objects in the blind spot mirror are
closer than they appear.

Blind spot mirrors have an integrated
convex mirror built into the upper outboard
corner of the exterior mirrors. They can
assist you by increasing visibility along the
side of your vehicle.

Check the main mirror first before a lane
change, then check the blind spot mirror.
If no vehicles are present in the blind spot
mirror and the traffic in the adjacent lane
is at a safe distance, signal that you are
going to change lanes. Glance over your
shoulder to verify traffic is clear, and
carefully change lanes.

E138665

The image of the approaching vehicle is
small and near the inboard edge of the
main mirror when it is at a distance. The
image becomes larger and begins to move
outboard across the main mirror as the
vehicle approaches (A). The image
transitions from the main mirror and begins
to appear in the blind spot mirror as the
vehicle approaches (B). The vehicle
transitions to your peripheral field of view
as it leaves the blind spot mirror (C).

Blind Spot Information System

(If

Equipped)

See Blind Spot Information System
(page 138).

INTERIOR MIRROR

Manual Dimming Mirror

WARNING

Do not adjust the mirrors when your
vehicle is moving. This could result
in the loss of control of your vehicle,

serious personal injury or death.

Pull the tab below the mirror toward you
to reduce the effect of bright light from
behind.

Automatic Dimming Mirror

(If Equipped)

WARNING

Do not adjust the mirrors when your
vehicle is moving. This could result
in the loss of control of your vehicle,

serious personal injury or death.

The mirror dims to reduce the effect of
bright light from behind. It returns to
normal when the bright light from behind
is no longer present or if you shift into
reverse (R).
