The headlamps do not turn on with the
wipers:
•

During a single wipe.

•

When using the windshield washers.

•

If the wipers are in intermittent mode.

Note: If you switch the autolamps and the
autowipers on, the headlamps turn on when
the windshield wipers continuously operate.

INSTRUMENT LIGHTING
DIMMER

E231828

Press repeatedly or press and hold until
you reach the desired level.

DAYTIME RUNNING LAMPS

 (If

Equipped)

WARNING

The daytime running lamps system
does not activate the rear lamps and
may not provide adequate lighting

during low visibility driving conditions.
Make sure you switch the headlamps on,
as appropriate, during all low visibility
conditions. Failure to do so may result in a
crash.

The daytime running lamps turn on when:
1.

Switching the ignition on.

2. The lighting control is in the off

position, parking lamps or the
autolamps position, and the sensor
detects daylight.

3. Your vehicle is in drive (D).

Note: Switch the daytime running lamps
on or off by selecting Police Silent Mode in
the information display.  See General
Information (page 79).

Note: In markets where daytime running
lamps are mandated by law, Silent Mode
does not disable the daytime running lamps.

DIRECTION INDICATORS

E163272

•

To operate the left direction indicator,
push the lever down until it stops.

•

To operate the right direction indicator,
push the lever up until it stops.

Note: Tap the lever up or down to make the
direction indicators flash three times.

INTERIOR LAMPS

Note: When you enable Silent Mode or Dark
Car Mode, the courtesy lamps do not turn
on.

The lamps turn on under the following
conditions:
•

You open any door.

•

You press a remote control button.

•

You press the dome lamp button on
the instrument panel.

Front Map Lamps

E163273

Rear Interior Lamps

A

E142455

Dome Lamp

E206739

Press the button to switch the lamps on
or off.

Dome Task Lamp

 (If Equipped)

Note: Prolonged use of the dome task
lamps causes the battery to run out of
charge.

E203953

Night vision red light on.

A

Off.

B

White light on.

C

Your vehicle may be equipped with one or
two red or white dome task lamps in the
headliner. These lamps are between the
driver and passenger seat, or at the rear of
your vehicle.

POWER WINDOWS

WARNINGS

Do not leave children unattended in
your vehicle and do not let them play
with the power windows. Failure to

follow this instruction could result in
personal injury.

When closing the power windows,
verify they are free of obstruction and
make sure that children and pets are

not in the proximity of the window
openings.

E146043

Note:  You may hear a pulsing noise when
just one of the windows is open.  Lower the
opposite window slightly to reduce this
noise.

Press the switch to open the window.

Lift the switch to close the window.

One-Touch Down

Press the switch fully and release it.  Press
again or lift it to stop the window.

One-Touch Up

Lift the switch fully and release it. Press or
lift it again to stop the window.

Resetting One-Touch Up

Start the engine.

1.

Lift and hold the window switch until
the you fully close the door window.
Continue to hold the switch for a few
seconds after you close the window.

2. Release the window switch.

3. Press and hold the window switch until

you fully open the door window.

4. Release the window switch.

5. Lift and hold the window switch until

you fully close the window.

6. Test for correct window operation by

carrying out the one-touch down and
one-touch up features.

Bounce-Back

The window will stop automatically while
closing.  It reverses some distance if there
is an obstacle in the way.

Overriding the Bounce-Back Feature

WARNING

When you override the bounce-back
feature the window will not reverse
if it detects an obstacle. Take care

when closing the windows to avoid
personal injury or damage to your vehicle.

Pull up the window switch and hold within
a few seconds of the window reaching the
bounce-back position.  The window travels
up with no bounce-back protection.  The
window stops if you release the switch
before the window fully closes.
