LOCKING AND UNLOCKING

You can use the power door lock control
or the remote control to lock and unlock
your vehicle.

Power Door Locks

 (If Equipped)

The power door lock control is on the driver
and front passenger door panels.

E184784

A

B

Unlock.

A

Lock.

B

Hidden Rear Door Locks

 (If Equipped)

You can manually lock or unlock the rear
doors using the hidden lock knob on the
inside front edge of the rear doors.

E203323

Open the front doors to access the lock
knob. Pull the knob to unlock and push the
knob to lock.

Remote Control

You can use the remote control at any
time.

Unlocking the Doors (Two-Stage
Unlock)

E138629

Press the button to unlock the
driver door.

Press the button again within three
seconds to unlock all doors.  The direction
indicators will flash.

Press and hold both the lock and unlock
buttons on the remote control for three
seconds to change between driver door or
all doors unlock mode. The direction
indicators will flash twice to indicate a
change to the unlocking mode. Driver door
mode only unlocks the driver door when
you press the unlock button once. All door
mode unlocks all doors when you press
the unlock button once. The unlocking
mode applies to the remote control.

Locking the Doors

E138623

Press the button to lock all
doors.  The direction indicators
will flash.

Press the button again within three
seconds to confirm that all the doors are
closed.  The doors will lock again, the horn
will sound and the direction indicators will
flash if all the doors and the liftgate are
closed.

Note: If any door or the liftgate is open, or
if the hood is open on vehicles with an
anti-theft alarm or remote start, the horn
will sound twice and the direction indicators
will not flash.

Independent Liftgate Locking
Feature

 (If Equipped)

This feature allows you to unlock the
liftgate independently of the other doors.

Unlocking

The liftgate unlocks when you pull and
release the liftgate control on the overhead
console with the ignition on.

Note: The liftgate does not unlock when
you unlock all the doors electronically using
the remote control or power door lock
control.

Liftgate Timed Release (If Equipped)

Switch the ignition to the run, start or
accessory position.

Pull and release the liftgate
control on the overhead console.

Note: Only the liftgate unlocks. All other
passenger doors remain in the previous
locking state.

A warning lamp illuminates in the
instrument cluster for 45 seconds. See
Warning Lamps and Indicators (page
75).  You can then open the liftgate using
the exterior liftgate release button.

Once the 45 second timer expires, the
lamp turns off and you can no longer open
the liftgate. Pull and release the liftgate
control on the overhead console again to
restart the timer.

Note: You can also unlock the liftgate by
using the key blade inserted into the liftgate
lock cylinder.

Locking

The liftgate locks when any of the
following occur:
•

You open and close the liftgate after
you pull and release the liftgate control
on the overhead console.

•

The 45 second timer expires.

Locking and Unlocking the Doors
with the Key Blade

Locking with the Key

Turn the top of the key toward the front of
your vehicle.

Unlocking with the Key

Turn the top of the key toward the rear of
your vehicle.

Note: If the child safety locks are on and
you pull the interior handle, you will only
turn off the emergency locking, not the child
safety lock. You can only open the doors
using the external door handle.

Opening a Rear Door From the
Inside

Pull the interior door handle twice to
unlock and open a rear door.  The first pull
unlocks the door and the second pull
opens the door.

Illuminated Entry

 (If Equipped)

The interior lamps and some exterior
lamps illuminate when you unlock the
doors with the remote control.

The lamps turn off if:
•

The ignition is on.

•

You press the remote control lock
button.

•

25 seconds have elapsed.

The lamps do not turn off if:
•

You switch them on with the lighting
control.

•

Any door is open.

Illuminated Exit

 (If Equipped)

The interior lamps and some exterior
lamps illuminate when all doors are closed
and you switch the ignition off.

The lamps will turn off if all the doors
remain closed and:
•

25 seconds have elapsed.

•

You lock your vehicle from the outside.

Battery Saver

If you leave the courtesy lamps, interior
lamps or headlamps on, the battery saver
shuts them off 10 minutes after you switch
the ignition off.

MANUAL LIFTGATE

WARNINGS

It is extremely dangerous to ride in a
cargo area, inside or outside of a
vehicle. In a crash, people riding in

these areas are more likely to be seriously
injured or killed. Do not allow people to ride
in any area of your vehicle that is not
equipped with seats and seatbelts. Make
sure everyone in your vehicle is in a seat
and properly using a seatbelt. Failure to
follow this warning could result in serious
personal injury or death.

Make sure to close and latch the
liftgate to prevent drawing exhaust
fumes into your vehicle. This will also

prevent passengers and cargo from falling
out. If you must drive with the liftgate open,
keep the vents or windows open so outside
air comes into your vehicle. Failure to
follow this warning could result in serious
personal injury.

Note: Be careful when opening or closing
the liftgate in a garage or other enclosed
area to avoid damaging the liftgate.

Note: Do not hang anything, for example a
bike rack, from the glass or liftgate. This
could damage the liftgate and its
components.

Note: Do not leave the liftgate open while
driving. This could damage the liftgate and
its components.

Opening the Liftgate

Manually

E138632

Press the button located in the top of the
liftgate pull cup handle to unlatch the
liftgate, and then pull on the outside
handle.

With the Remote Control

E138630

Press the button twice within
three seconds.

Closing the Liftgate

E155976

A handle is located inside the liftgate to
help with closing.
