E145780

7.

Remove the bulb from the bulb holder.

Install the new bulb in reverse order.

Replacing the License Plate Lamp
Bulb

3

2

1

E72789

1.

Carefully release the spring clip.

2. Remove the lamp.

3. Remove the bulb.

Install the new bulb in reverse order.

BULB SPECIFICATION CHART

Replacement bulbs are specified in the
chart below. Headlamp bulbs must be
marked with an authorized “D.O.T.” for
North America to make sure they have the
proper lamp performance, light brightness,
light pattern, and safe visibility. The correct
bulbs will not damage the lamp assembly
or void the lamp assembly warranty and
will provide quality bulb illumination time.

Trade name

Function

H7LL

*Headlamp high beam (Halogen)

H11LL

*Headlamp low beam (Halogen)

LED

*Side marker lamp - front

W5W

*Park lamp - front

PWY24W

*Turn lamp - front

H11

*Fog lamp - front

LED

*Tail and brake lamp - high series

LED

*Tail and brake lamp - low series

921

Reverse lamp

251

Maintenance

Trade name

Function

LED

*Turn lamp - rear - high series

LED

*Turn lamp - rear - low series

LED

*Side marker lamp - rear

W5W

License plate lamp

W5W or LED**

*Trunk lamp

LED

*High-mount brake lamp

LED

*Side repeater lamp

LED

*Interior lamp

*To replace these bulbs, see your authorized dealer.

To replace all instrument panel bulbs, see your authorized dealer.

**If so equipped.

252

Maintenance

GENERAL INFORMATION

Your Ford or Lincoln authorized dealer has
many quality products available to clean
your vehicle and protect its finishes.

CLEANING PRODUCTS

For best results, use the following products
or products of equivalent quality:

Motorcraft Bug and Tar Remover (ZC-42)

Motorcraft Custom Bright Metal Cleaner
(ZC-15)

Motorcraft Detail Wash (ZC-3-A)

Motorcraft Dusting Cloth (ZC-24)

Motorcraft Engine Shampoo and
Degreaser (U.S. only) (ZC-20)

Motorcraft Engine Shampoo (Canada
only) (CXC-66-A)

Motorcraft Multi-Purpose Cleaner (Canada
only) (CXC-101)

Motorcraft Premium Glass Cleaner
(Canada only) (CXC-100)

Motorcraft Premium Quality Windshield
Washer Fluid (Canada only) [CXC-37-(A,
B, D or F)]

Motorcraft Premium Windshield Wash
Concentrates (U.S. only) (ZC-32-A1 or
ZC-32-B1)

Motorcraft Professional Strength Carpet
& Upholstery Cleaner (ZC-54)

Motorcraft Spot and Stain Remover (U.S.
only) (ZC-14)

Motorcraft Ultra-Clear Spray Glass Cleaner
(ZC-23)

Motorcraft Vinyl Cleaner (Canada only)
(CXC-93)

Motorcraft Wheel and Tire Cleaner
(ZC-37-A)

CLEANING THE EXTERIOR

Wash your vehicle regularly with cool or
lukewarm water and a neutral pH
shampoo, such as Motorcraft® Detail
Wash.

•

Never use strong household detergents
or soap, such as dish washing or
laundry liquid. These products can
discolor and spot painted surfaces.

•

Never wash a vehicle that is “hot to the
touch” or during exposure to strong,
direct sunlight.

•

Dry your vehicle with a chamois or soft
terry cloth towel in order to eliminate
water spotting.

•

Immediately remove items such as
gasoline, diesel fuel, bird droppings and
insect deposits because they can cause
damage to your vehicle’s paintwork
and trim over time. Use Motorcraft Bug
and Tar Remover.

•

Remove any exterior accessories, such
as antennas, before entering a car
wash.

Note: Suntan lotions and insect repellents
can damage any painted surface; if these
substances come in contact with your
vehicle, wash off as soon as possible.

Stripes or Graphics (if equipped)

Do not use a commercial or high-pressure
wand on the surface or edge of stripes and
graphics. This can cause damage to the
film and cause the edge of the film to peel
away from the vehicle surface.

Exterior Chrome

Note: Never use abrasive materials such as
steel wool or plastic pads as they can
scratch the chrome surface.

Note: Do not use chrome cleaner, metal
cleaner or polish on wheels and wheel
covers

253

Vehicle Care

•

Wash your vehicle first, using cool or
lukewarm water and a neutral pH
shampoo, such as Motorcraft Detail
Wash.

•

Use Motorcraft Custom Bright Metal
Cleaner. Apply the product as you
would a wax to clean bumpers and
other chrome parts; allow the cleaner
to dry for a few minutes, then wipe off
the haze with a clean, dry rag.

•

Do not apply cleaning product to hot
surfaces and do not leave cleaning
product on chrome surfaces for a
period of time exceeding that which is
recommended.

•

Using other non-recommended
cleaners can result in severe and
permanent cosmetic damage.

Underbody

Flush the complete underside of your
vehicle frequently. Keep body and door
drain holes free from packed dirt.

Cleaning Plastic Exterior Parts

Use only approved products to clean
plastic parts

•

For routine cleaning, use Motorcraft
Detail Wash.

•

If tar or grease spots are present, use
Motorcraft Bug and Tar Remover.

REPAIRING MINOR PAINT
DAMAGE

Your authorized dealer has touch-up paint
to match your vehicle’s color. Take your
color code (printed on a sticker in the
driver’s door jamb) to your authorized
dealer to ensure you get the correct color.

•

Remove particles such as bird
droppings, tree sap, insect deposits, tar
spots, road salt and industrial fallout
before repairing paint chips.

•

Always read the instructions before
using the products.

WAXING

Regular waxing is necessary to protect your
car's paint from the elements. We
recommend that you wash and wax the
painted surface once or twice a year.

When washing and waxing, park your
vehicle in a shaded area out of direct
sunlight. Always wash your vehicle before
applying wax.

•

Use a quality wax that does not contain
abrasives.

•

Follow the manufacturer’s instructions
to apply and remove the wax.

•

Apply a small amount of wax in a
back-and-forth motion, not in circles.

•

Do not allow wax to come in contact
with any non-body (low-gloss black)
colored trim. The wax will discolor or
stain the parts over time.

•

Roof racks.

•

Bumpers.

•

Grained door handles.

•

Side mouldings.

•

Mirror housings.

•

Windshield cowl area.

•

Do not apply wax to glass areas.

•

After waxing, your car's paint should
feel smooth, and be free of streaks and
smudges.
