Ford Focus Electric (2018 year). Manual - part 57

E223058

Description

Item

Callout

This icon displays when your phone's microphone is
muted. A caller cannot hear you.

Microphone Mute

A

This icon displays when the audio system is muted.

Mute

B

This icon displays when SYNC 3 has received a soft-
ware update. Pressing the icon will show more details
about the new software.

Download

C

This icon displays when the system is connected to
a Wi-Fi network.

Wi-Fi

D

This icon displays when an available Wi-Fi network
is within range.

Wi-Fi in Range

E

This icon displays when your cell phone is roaming.

Roaming

F

This icon displays when you receive a text message
on your phone.

Text Message

G

Description

Item

Callout

This icon displays when 911 Assist is set to off and
your phone is connected to SYNC.

911 Assist Off

H

This icon displays when there is an active Bluetooth
alert.

Bluetooth Alert

I

This icon displays to show an active Bluetooth
connection.

Bluetooth

J

Messages may also appear in the status
bar to provide you with notifications. You
can select the message to view the
associated feature.

Feature Bar

Functions

Feature Bar Item

Allows you to control the media playing in
your vehicle. You can control all audio
features including AM, FM and satellite
radio, CDs, and media streaming over a
Bluetooth device or through a USB
connection.

Audio

Allows you to make calls, receive calls, and
access the phonebook of your connected
device.

Phone

Allows you to see your vehicle's location on
a virtual road map, get driving directions to
your destination and find points of interest
along your route.

Navigation

(If equipped)

Connect and control SYNC 3 compatible
apps running on your iPhone or Android
device. Also, access built-in additional
features such as SiriusXM Traffic and Travel
Link (if equipped).

Apps

You can customize your system with
various settings for the touchscreen display,
feature preferences, and how you want to
interact with your vehicle.

Settings

Cleaning the Touchscreen

You can remove fingerprints with a dry,
clean, soft cloth.

If dirt or fingerprints are still on the screen,
apply a small amount of alcohol to the
cloth and try to clean it again.

Note:  Do not use detergent or any type of
solvent to clean the touchscreen.

Note: Do not pour or spray alcohol onto the
touchscreen.

Using Voice Recognition

Using voice commands allows you to keep
your hands on the wheel and eyes on the
road. The system provides feedback
through audible tones, prompts, questions
and spoken confirmations depending on
the situation and the chosen level of
interaction (voice settings).

The system also asks short questions
(confirmation prompts) when it is not sure
of your request or when there are multiple
possible responses to your request.

When using voice commands, words and
icons may appear in the status bar
indicating the status of the voice command
session.  See Using Voice Recognition
(page 239).

Using the Steering Wheel Controls

Depending on your vehicle and option
package, you can use different controls on
your steering wheel to interact with the
touchscreen system in different ways.

VOL: Control the volume of audio output.

Mute: Mute the audio output.

Voice: Press to start a voice session. Press
again to stop the voice prompt and
immediately begin speaking. Press and
hold to end a voice session.

SEEK NEXT:
•

While in radio mode, press to seek
between memory presets.

•

While in USB, Bluetooth Audio or CD
mode, press to seek between songs or
press and hold to fast seek.

SEEK PREVIOUS:
•

While in radio mode, press to seek
between memory presets.

•

While in USB, Bluetooth Audio or CD
mode, press to seek between songs or
press and hold to fast seek.

PHONE ACCEPT: Press to answer a call
or switch between calls.

PHONE REJECT: Press to end a call or
reject an incoming call.

Note: On some models, SEEK NEXT may
be combined with PHONE REJECT and
SEEK PREVIOUS may be combined with
PHONE ACCEPT.

M:Touch the control repeatedly to switch
between media sources (modes).

See Steering Wheel (page 61).

Using Your Bezel Controls

Depending on your vehicle and option
package, you may also have these controls
on your instrument panel:

•

Power: Switch the audio system on
and off.

•

VOL: Control the volume of playing
audio.

•

Seek and Tune: se as you normally
would in audio modes.

•

Eject: Eject a CD from the audio
system.

•

SOURCE  or MEDIA: Press repeatedly
to advance through available media
modes.

•

SOUND: Press to access the Sound
menu where you can adjust sound and
other audio settings.

•

1-6: Press and hold to store or press to
select an AM, FM or SIRIUS memory
preset.  See Audio System (page 223).

•

DISP: Switch the display on or off. You
can also touch the screen to switch the
display back on.

•

Temperature, fan and climate
control buttons: Control the
temperature, fan speed or settings of
the climate control system.  See
Climate Control (page 94).

911 Assist

WARNINGS

Unless the 911 Assist setting is set on
before a crash, the system will not
dial for help which could delay

response time, potentially increasing the
risk of serious injury or death after a crash.

Do not wait for 911 Assist to make an
emergency call if you can do it
yourself. Dial emergency services

immediately to avoid delayed response
time which could increase the risk of
serious injury or death after a crash. If you
do not hear 911 Assist within five seconds
of the crash, the system or phone may be
damaged or non-functional.

Always place your phone in a secure
location in your vehicle so it does not
become a projectile or get damaged

in a crash. Failure to do so may cause
serious injury to someone or damage the
phone which could prevent 911 Assist from
working properly.

Note: The SYNC 911 Assist feature must be
set on before the incident.

Note: The SYNC 911 Assist feature only
operates in the U.S., Canada or in a territory
in which 911 is the emergency number.

Note: Before setting this feature on, make
sure that you read the 911 Assist Privacy
Notice later in this section for important
information.

Note: If any user sets 911 Assist to on or off,
that setting applies for all paired phones. If
911 Assist is switched off and the phone is
connected to SYNC, an icon displays on the
status bar.

Note: Every phone operates differently.
While SYNC 911 Assist works with most
cellular phones, some may have trouble
using this feature.

If a crash deploys an airbag (excluding
knee airbags and rear inflatable safety
belts [if equipped]) or activates the fuel
pump shut-off, your SYNC-equipped
vehicle may be able to contact emergency
services by dialing 911 through a paired and
connected Bluetooth-enabled phone. You
can learn more about the 911 Assist
feature, by visiting:

Website

www.owner.ford.com
www.syncmyride.ca
www.syncmaroute.ca

For important information about airbag
deployment and the fuel pump shut-off
please see the Supplementary Restrains
and Roadside Emergencies sections of
your owner manual.

To switch 911 Assist on and off please view
the settings information. See Settings
(page 290).

To make sure that 911 Assist works
correctly:
•

SYNC must be powered and working
properly at the time of the incident and
throughout feature activation and use.

•

The 911 Assist feature must be set on
before the incident.
