Ford Focus Electric (2018 year). Manual - part 26

12 Volt DC Power Point

WARNINGS

Do not plug optional electrical
accessories into the cigar lighter
socket. Incorrect use of the cigar

lighter can cause damage not covered by
the vehicle warranty, and can result in fire
or serious injury.

Do not use a power point for
operating a cigar lighter. Incorrect
use of the power points can cause

damage not covered by the vehicle
warranty, and can result in fire or serious
injury.

Note: After starting your vehicle, you can
use the socket to power 12-volt appliances
with a maximum current rating of 15 amps.

After you switch your vehicle off, the power
supply works only for a maximum of 11
minutes.
Note: Do not insert objects other than an
accessory plug into the power point. This
damages the outlet and can blow the fuse.

Note: Do not hang any accessory from the
accessory plug.

Note: Do not use the power point over the
vehicle capacity of 12 volt DC 180 watt or a
fuse may blow.

Note: Incorrect use of the power point can
cause damage not covered by your
warranty.

Note: Always keep the power point caps
closed when not in use.

Run the vehicle for full capacity use of the
power point.

To prevent the battery from running out of
charge:
•

Do not use the power point longer than
necessary after switching the vehicle
off.

•

Do not leave devices plugged in
overnight or when your vehicle is in park
(P) for extended periods.

Location

You may find power points in the following
locations:
•

On the center console.

•

In the center console.

•

In the cargo area.

CENTER CONSOLE

Stow items in the cupholder carefully as
items may become loose during hard
braking, acceleration or crashes, including
hot drinks which may spill.

Available console features include:

E188648

Cupholder with grips and height
adjuster. To use, flip the
removable inset piece.

A

Storage compartment with
auxiliary power point and media
hub.

B

Parking aid and cardholder.

C

Auxiliary power point.

D

USB port.

E

OVERHEAD CONSOLE

E131605

Press near the rear edge of the door to
open it.

STARTING THE ELECTRIC
MOTOR

Keyless Starting

Note: The system may not function if the
passive key is close to metal objects or
electronic devices, for example keys or a cell
phone.

Note: A valid passive key must be located
inside your vehicle to switch the power on
and start your vehicle.

Note:  Passive keys left inside your vehicle
when locked are disabled.  A message may
appear in the information display indicating
that there is no key detected when you try
to start your vehicle.  Press the unlock
button on the remote control to enable it,
and then start your vehicle.

Power Modes

E166822

The keyless starting system has three
modes:
•

Off: Turns the power off. Without
applying the brake pedal, press and
release the power button once when
your vehicle is in the on mode, or when
your vehicle is on but not moving.

•

On: All electrical circuits are
operational and the warning lamps and
indicators illuminate. Without applying
the brake pedal, press and release the
power button once from off mode.

•

Start: Starts your vehicle. Press the
brake pedal, and then press the power
button for a couple of seconds. The
green ready to drive indicator lamp
illuminates in the instrument cluster
when your vehicle is ready to drive.

Starting Your Vehicle

Before starting your vehicle, check the
following:
•

Make sure all the occupants have
fastened their safety belts.

•

Make sure the headlamps and
electrical accessories are off.

•

Make sure the parking brake is on.

•

Make sure the gearshift lever is in park
(P).

Note: Do not touch the accelerator pedal.

1.

Fully depress the brake pedal.

2. Press the power button.

Note: You will not hear any engine noise.

The system does not function if:
•

The passive key frequencies are
jammed.

•

The key battery has no charge.

If you are unable to start your vehicle,
follow the steps below.

E184385

2

1

1.

Open the floor console storage
compartment lid.

2. Remove the tray.

E184386

3

3. Place the key flat on the symbol at the

bottom of the floor console storage
compartment.

4. With the key in this position, press the

brake pedal, then press the power
button to switch the power on and
start your vehicle.

Fast Restart

The fast restart feature allows you to
restart your vehicle within 10 seconds of
switching it off, even if it does not detect
a valid passive key.

Within 10 seconds of switching your vehicle
off, press the brake pedal and press the
power button. After 10 seconds, you can
no longer start your vehicle if it does not
detect a valid passive key.

Once your vehicle has started, it remains
on until you press the power button, even
if it does not detect a valid passive key. If
you open and close a door while your
vehicle is on, the system searches for a
valid passive key. You cannot start your
vehicle if the system does not detect a
valid passive key within 10 seconds.

SWITCHING OFF THE
ELECTRIC MOTOR

WARNING

Switching off the electric motor
when your vehicle is still moving will
result in a loss of brake and steering

assistance. The steering will not lock, but
higher effort will be required. With the
ignition switched off some electrical
circuits, warning lamps and indicators may
also be off. Failure to follow this warning
could result in serious personal injury or
death.

When your vehicle is not moving and the
electric motor is on or the power is in
accessory mode, press and release the
power button without pressing the brake
pedal. This will shut off the electric motor
and all electrical accessories.
