Trip Computer

Vehicle Settings and Personalization

WARNING LAMPS AND
INDICATORS

The following warning lamps and
indicators alert you to a vehicle condition
that may become serious. Some lamps
illuminate when you start your vehicle to
make sure they work. If any lamps remain
on after starting your vehicle, refer to the
respective system warning lamp for further
information.

Note: Some warning indicators appear in
the information display and operate the
same as a warning lamp but do not
illuminate when you start your vehicle.

Anti-Lock Braking System

If it illuminates when you are
driving, this indicates a
malfunction. Your vehicle

continues to have normal braking without
the anti-lock brake system function. Have
your vehicle checked as soon as possible.

Automatic Regeneration Control

(If Equipped)

E208811

Illuminates when you switch it
off.

Battery

If it illuminates while driving, it
indicates a malfunction. Switch
off all unnecessary electrical

equipment and have the system checked
by an authorized dealer immediately.

Brake System

WARNING

Driving your vehicle with the warning
lamp on is dangerous. A significant
decrease in braking performance

may occur. It may take you longer to stop
your vehicle. Have your vehicle checked as
soon as possible. Driving extended
distances with the parking brake engaged
can cause brake failure and the risk of
personal injury.

E209041

Indicates low brake fluid level or
a brake system malfunction.
Have the system checked

immediately by an authorized dealer.

Check Fuel Cap

Illuminates when you may not
have properly installed the fuel
cap. Continued driving with this

light on may cause the Service engine soon
warning indicator to come on.

Check Suspension

(If Equipped)

E208808

Illuminates when you press the
air suspension dump switch.

Cruise Control

(If Equipped)

E71340

Illuminates when you switch on
this feature. See Using Cruise
Control (page 137).

Diesel Exhaust Fluid

(If Equipped)

E163176

Illuminates with the key in the
ON position, when the fluid is
contaminated or the level falls

below 1.0 gal (3.8 L). Refill the tank or, at
a minimum, add at least 1.0 gal (3.8 L) in
the tank.

Diesel Particulate Filter

(If Equipped)

Illuminates when the soot level in the
diesel particulate filter has reached a point
where it requires operator assistance. See
Diesel Particulate Filter (page 109).

Direction Indicator

Illuminates when you switch on
the left or right direction
indicator or when you switch on

the hazard warning flashers. If the
indicators stay on or flash faster, check for
a burned out bulb.

Door Ajar

Displays when the ignition is on
and any door is not completely
closed.

Electronic Locking Differential

(If

Equipped)

E163170

Illuminates when using the
electronic locking differential.

Engine Oil Pressure

If it illuminates with the engine
running, or when you are driving,
this indicates a malfunction.

Stop your vehicle as soon as it is safe to
do so and switch off the engine. Check the
engine oil level.

Note: Do not resume your journey if it
illuminates despite the level being correct.
Have the system checked by an authorized
dealer immediately.

Exhaust Brake On

(If Equipped)

E171217

The exhaust brake indicator light
illuminates when you switch the
exhaust brake on.

Fasten Seatbelt

E71880

Illuminates and a tone sounds
to remind you to fasten your
seatbelt.

High Beam

Illuminates when you switch on
the high beam headlamps. It
flashes when you use the

headlamp flasher.

Hydromax

E146190

Illuminates to indicate normal
hydromax booster reserve
system activation when the

engine is off and the service brake pedal is
applied. This light may also illuminate
momentarily if the engine is running and
the driver turns the steering wheel fully in
one direction while braking. If the light
remains on while the engine is running, this
indicates inadequate hydraulic booster
pressure or reserve pump system failure.
Stop the vehicle as soon as possible and
seek service immediately by your
authorized dealer.

Low Fuel Level

(If Equipped)

Illuminates when the fuel level
is low or the fuel tank is nearly
empty. Refuel as soon as

possible.

Parking Brake Warning

E208810

Illuminates briefly when you
switch the ignition to the on
position (with the engine off). It

also illuminates when you apply the
parking brake. If the park brake lamp does
not illuminate at these times, seek service
immediately. Vehicles equipped with the
power park parking brake option: If the park
brake warning lamp begins to blink after

setting the parking brake, this may indicate
a failure in the parking brake system. Seek
service from an authorized dealer
immediately. Driving extended distances
with the parking brake engaged can cause
brake failure and the risk of personal injury.

Powertrain Malfunction/Reduced
Power/Electronic Throttle Control

(If Equipped)

Illuminates in the event of a
powertrain fault. Contact an
authorized dealer as soon as

possible.

Service Engine Soon

If it illuminates when the engine
is running this indicates a
malfunction. The On Board

Diagnostics system has detected a
malfunction of the vehicle emission control
system.

If it flashes, engine misfire may be
occurring. Increased exhaust gas
temperatures could damage the catalytic
converter or other vehicle components.
Drive in a moderate fashion (avoid heavy
acceleration and deceleration) and have
your vehicle immediately serviced.

It illuminates when you switch the ignition
on prior to engine start to check the bulb
and to indicate whether your vehicle is
ready for Inspection and Maintenance
(I/M) testing.

Normally, it illuminates until the engine is
cranked and automatically turns off if no
malfunctions are present. However, if after
15 seconds it flashes eight times, this
indicates that your vehicle is not ready for
Inspection and Maintenance (I/M) testing.

See Catalytic Converter (page 103).

Stability Control and Traction
Control Indicator

(If Equipped)

E138639

Illuminates and slowly flashes
when you change the traction
control mode. It illuminates and

rapidly flashes during a traction or stability
control event.

Trailer Anti-Lock Brake System
(ABS)

E209040

Illuminates briefly when you
switch on the ignition, and only
when a PLC trailer or a PLC

diagnostic tool is connected. If the light
fails to illuminate, remains on after you
start the vehicle or continues to flash, have
the system serviced immediately.

Transmission Tow/Haul

(If Equipped)

E161509

Illuminates when you switch on
the tow/haul feature. If the light
flashes steadily, have the system

serviced immediately, damage to the
transmission could occur.

Two Speed Axle

E208809

The Two Speed Axle indicator
comes on when you switch the
low axle range on.

Wait to Start

(If Equipped)

Illuminates when you switch the
ignition on as part of the
pre-start system. Wait until the

wait to start indicator turns off before
attempting to start vehicle.

WARNING

Do not use starting fluid, for example
ether, in the air intake system. Such
fluid could cause immediate

explosive damage to the engine and
possible personal injury.

Water in Fuel

(If Equipped)

Illuminates when the fuel
filter/water separator has a
significant quantity of water in

it.

If the light illuminates when the engine is
running, stop the vehicle as soon as safely
possible, shut off the engine, then drain the
fuel filter/water separator.

Allowing water to stay in the system could
result in extensive damage to, or failure of,
the fuel injection system.

WARNING

Do not drain the water-in-fuel
separator while the engine is running.
Failure to follow this warning may

result in fire, serious injury, death or
property damage.

AUDIBLE WARNINGS AND
INDICATORS

Beltminder Warning

Sounds when a safety belt is unfastened
in an occupied seat and your vehicle is
moving.

Door Ajar

Sounds when a door is not fully closed and
your vehicle is moving.

Headlamps On Warning Chime

Sounds when you remove the key from the
ignition and open the driver's door and you
have left the headlamps or parking lamps
on.

Key in Ignition Warning Chime

Sounds when you open the driver's door
and you have left the key in the ignition
with it in the off or accessory position.

Parking Brake On Warning Chime

Sounds when you have left the parking
brake on and drive your vehicle. If the
warning chime remains on after you have
released the parking brake, have the
system checked by your authorized dealer
immediately.
