Ford F-650/750 (2018 year). Manual - part 12

POWER WINDOWS

 (If Equipped)

WARNINGS

Do not leave children unattended in
your vehicle and do not let them play
with the power windows. They may

seriously injure themselves.

When closing the power windows,
you should verify they are free of
obstructions and make sure that

children and pets are not in the proximity
of the window openings.

E163056

Note: You may hear a pulsing noise when
just one of the windows is open. Lower the
opposite window slightly to reduce this
noise.

Press the switch to open the window.

Lift the switch to close the window.

One-Touch Up or Down

 (If Equipped)

Press or lift the switch fully and release it.
Press or lift it again to stop the window.

Note: The window may disable for up to
five minutes if you cycle it up and down
repeatedly. This helps prevent damage to
the motor. Normal operation resumes once
the motor cools.

Restoring the One-Touch Up Function

You may lose the one-touch function if the
vehicle battery is low.

Note: Perform one-touch up re-calibration
with the door closed. Calibrating with the
door open causes the window to bounce
back continuously.

To reset the function after the battery
recharges:

1.

Pull the switch all the way up.

2. Hold the switch until the glass stops

and continue to hold for two seconds.

3. Press the switch down and operate the

window to the full down position.
One-touch up is now functional.

Bounce-Back

 (If Equipped)

The window stops automatically while
closing. It reverses some distance if there
is an obstacle in the way.

Overriding the Bounce-Back Feature

WARNING

When you override the bounce-back
feature, the window will not reverse
if it detects an obstacle. Take care

when closing the windows to avoid
personal injury or damage to your vehicle.

Pull up the window switch and hold within
two seconds of the window reaching the
bounce-back position. The window travels
up with no bounce-back protection. The
window stops if you release the switch
before the window closes fully.

Window Lock

 (If Equipped)

Press the control to lock or unlock the rear
window controls.

EXTERIOR MIRRORS

Auxiliary Convex Mirrors

E208233

Convex mirrors are a ball-stud design for
precise adjustment to maximize viewing
area.

Power Exterior Mirrors

 (If Equipped)

WARNING

Do not adjust the mirrors when your
vehicle is moving.

E163059

B

A

C

Left–hand mirror.

A

Off.

B

Right–hand mirror.

C

To adjust a mirror:

1.

Rotate the control to select the mirror
you want to adjust.

2. Adjust the position of the mirror.

3. Return the control to the center

position to lock mirrors in place.

Foldaway Exterior Mirrors

For tight parking conditions, you can push
the mirror toward the door window glass.
Before driving, make sure that you fully
engage the mirror in its support when
returning it to its original position.

Power–Folding Mirrors (If Equipped)

E163060

1.

Rotate the control so the dots line up.

2. Pull the control back to fold the mirrors

in or out.

Note: If you repeatedly fold and unfold the
mirrors several times within one minute, the
system may disable to protect the motors
from overheating. It resets to normal
function automatically within three to five
minutes.

You can also fold a mirror manually by
pushing it toward the door window glass.
After you manually adjust the mirror, you
need to reset it.

To reset the power–folding mirror system
and return it to its normal function:
•

Fold the mirror manually by pushing it
toward the door window glass.

•

Use the power–fold control to fold and
unfold the mirror two or three times.
The mirror makes a sound as it resets.

Heated Exterior Mirrors

 (If Equipped)

See Heated Exterior Mirrors (page 74).

Signal Indicator Mirrors

 (If Equipped)

The outer portion of the appropriate mirror
housing blinks when you use the direction
indicator.

Clearance Lamps

 (If Equipped)

The lower, outer part of the mirror housings
light when you switch on the headlamps
or parking lamps.

Telescoping Mirrors

 (If Equipped)

E163061

This feature lets you extend the mirror
about 3 in (76 mm). It is useful when
towing a trailer. You can manually pull out
or push in the mirrors to the desired
position.

PowerScope™ Power Telescoping
Mirrors (If Equipped)

This feature lets you position both mirrors
in or out at the same time. The control is
on the door trim panel.

E163062

B

A

Telescope out.

A

Telescope in.

B

To adjust the mirrors:
•

Press and hold the control.

•

When you position the mirrors in or out,
the motors run as long as you hold the
control. The running motors allow you
to make adjustments as needed.

•

After positioning the mirrors, return the
control to the center position to help
protect the motors from overheating.

INTERIOR MIRROR

 (If Equipped)

WARNING

Do not adjust the mirror when your
vehicle is moving.

Note: Do not clean the housing or glass of
any mirror with harsh abrasives, fuel or other
petroleum or ammonia-based cleaning
products

You can adjust the interior mirror to your
preference. Some mirrors also have a
second pivot point. This lets you move the
mirror head up or down and from side to
side.

Pull the tab below the mirror toward you
to reduce glare at night.

SUN VISORS

Slide-on-rod

 (If Equipped)

E138666

Rotate the sun visor toward the side
window and extend it rearward for extra
shade.
