Ford F-150 (2018 year). Manual - part 37

E142554

Saving a PreSet Position

1.

Switch the ignition on.

2. Adjust the memory features to your

desired position.

3. Press and hold the desired preset

button until you hear a single tone.

Note: A confirmation that you saved a
memory preset appears in the information
display.

You can save up to three preset memory
positions. You can save a memory preset
at any time.

Recalling a PreSet Position

Press and release the preset button
associated with your desired driving
position. The memory features move to
the position stored for that preset.

Note: You can only recall a preset memory
position when you switch the ignition off, or
when you place the transmission in park (P)
or neutral (N) if the ignition is on.

Note: Press any seat or mirror adjustment
switch (or any memory button) during a
memory recall to cancel the operation.

You can also recall a preset memory
position by:
•

Pressing the unlock button on your
intelligent access key fob if you linked
it to a preset position.

•

Unlocking the intelligent driver door
handle if a linked key fob is present.

Note: Using a linked key fob to recall your
memory position when the ignition is off
moves the seat and steering column to the
Easy Entry position.

Linking a PreSet Position to your
Remote Control or Intelligent
Access Key

Your vehicle can save the preset memory
positions for up to three remote controls
or intelligent access (IA) keys.

1.

With the ignition on, move the memory
features to the position you desire.

2. Press and hold the desired preset

button for about five seconds. A tone
sounds after about two seconds.
Continue holding until you hear a
second tone.

3. Within three seconds, press the lock

button on the remote control you are
linking.

To unlink a remote control, follow the
same procedure – except in Step 3, press
the unlock button on the remote control.

Easy Entry and Exit Feature

If you enable the easy entry and exit
feature, it automatically moves the driver
seat position rearward up to 2 in (5 cm)
when you switch the ignition off.  The driver
seat returns to the previous position when
you switch the ignition on.

You can enable or disable this feature in
the information display.  See Information
Displays (page 111).

REAR SEATS

 (If Equipped)

Folding Up the Rear Seat Cushion

The rear seat has a split 60/40 cushion.
You can flip each seat cushion up into a
vertical storage position.

E181250

Rotate the seat cushion up until it locks
into the vertical storage position.

Returning the Seat to the Seating
Position

WARNING

Make sure that cargo or any objects
are not trapped underneath the seat
cushion before returning the seat

cushion to its original position, and that the
seat cushion returns to the full down
position. Failure to do so may prevent the
seat from operating properly in the event
of a crash, which could increase the risk of
serious injury.

E166704

Pull the control on the bottom of the seat
cushion to release the seat cushion from
the storage position.

HEATED SEATS

 (If Equipped)

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

cord injury, medication, alcohol use,
exhaustion or other physical conditions,
must exercise care when using the heated
seat. The heated seat may cause burns
even at low temperatures, especially if
used for long periods of time. Do not place
anything on the seat that insulates against
heat, such as a blanket or cushion. This
may cause the heated seat to overheat.
Do not puncture the seat with pins, needles
or other pointed objects. This may damage
the heating element which may cause the
heated seat to overheat. An overheated
seat may cause serious personal injury.

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

Note: The engine must be running to use
this feature.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

Note: The heated seats may remain on
after you remote start your vehicle, based
on your remote start settings. The heated
seats may also turn on when you start your
vehicle if they were on when you switched
your vehicle off.

Rear Heated Seats

 (If Equipped)

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

cord injury, medication, alcohol use,
exhaustion or other physical conditions,
must exercise care when using the heated
seat. The heated seat may cause burns
even at low temperatures, especially if
used for long periods of time. Do not place
anything on the seat that insulates against
heat, such as a blanket or cushion. This
may cause the heated seat to overheat.
Do not puncture the seat with pins, needles
or other pointed objects. This may damage
the heating element which may cause the
heated seat to overheat. An overheated
seat may cause serious personal injury.

Do not do the following:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

Note: The engine must be running to use
this feature.

The rear seat heat controls are on the rear
of the center console.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

The heated seat module resets at every
ignition run cycle. While the ignition is in
the on position, press the heated seat
switch to enable heating mode. When
activated, they turn off automatically when
you switch off the engine.

CLIMATE CONTROLLED SEATS

(If Equipped)

Heated Seats

WARNING

People who are unable to feel pain
to their skin because of advanced
age, chronic illness, diabetes, spinal

cord injury, medication, alcohol use,
exhaustion or other physical conditions,
must use caution when using the heated
seat. The heated seat may cause burns
even at low temperatures, especially if
used for long periods of time. Do not place
anything on the seat that may block the
heat, such as a blanket or cushion. This can
cause the heated seat to overheat. Do not
puncture the seat with pins, needles or
other pointed objects. This damages the
heating element and can cause the heated
seat to overheat. An overheated seat may
cause serious personal injury.

Note: The heated seats switch on during a
remote start if they are enabled through the
information displays.  See General
Information (page 111).

Note: The heated seats may also switch
on when you start your vehicle if they were
on when you previously switched your
vehicle off.

Note: Do not do the following:

•

Place heavy objects on the seat.

•

Operate the seat heater if water or any
other liquid spills on the seat. Allow the
seat to dry thoroughly.

E146322

Press this symbol to cycle through the
various heat settings and off. More
indicator lights indicate warmer settings.

Ventilated Seats

Note: The ventilated seats switch on during
a remote start if they are enabled through
the information displays.  See General
Information (page 111).

Note: The ventilated seats may also switch
on when you start your vehicle if they were
on when you previously switched your
vehicle off.

Note: Do not do the following:

•

Spill liquid on the front seats. This may
cause the air vent holes to become
blocked and not work properly.

•

Place cargo or objects under the seats.
They may block the air intake causing
the air vents to not work properly.

The ventilated seats only function when
the engine is running.

E224689

Press this symbol to cycle through the
various ventilation settings and off. More
indicator lights indicate higher fan speeds.

If the engine falls below 350 RPM while
the ventilated seats are on, the feature
turns itself off. You need to reactivate it.

Note: To improve comfort, use the
ventilated seats along with the vehicle’s air
conditioning system.
