Ford F-150 (2018 year). Manual - part 20

ADJUSTING THE STEERING
WHEEL

WARNING

Do not adjust the steering wheel
when your vehicle is moving.

Note:  Make sure that you are sitting in the
correct position.

E180482

1.

Unlock the steering column.

2. Adjust the steering wheel to the desired

position.

E180534

3. Lock the steering column.

Power Tilt and Telescope Steering
Column

 (If Equipped)

E180535

Use the control on the side of the steering
column to adjust the position.

To adjust:
•

Tilt: press the top or bottom of the
control

•

Telescope: press the front or rear of the
control.

Memory Feature

You can save and recall the steering
column position with the memory function.

Pressing the adjustment control during
memory recall cancels the operation.

Easy Entry and Exit Feature

The column moves to the full up and in
position when you switch the ignition off.
It returns to the previous setting when you
switch the ignition on.  You can switch this
feature on or off in the information display.

AUDIO CONTROL

 (If Equipped)

You can operate the following functions
with the control:

E191327

Volume up.

A

Media.

B

Seek up or next.

C

Volume down.

D

Seek down or previous.

E

Media

Press repeatedly to scroll through available
audio modes.

Seek, Next or Previous

Press the seek button to:
•

Tune the radio to the next or previous
stored preset.

•

Play the next or previous track.

Press and hold the seek button to:
•

Tune the radio to the next station up
or down the frequency band.

•

Seek through a track.

VOICE CONTROL

 (If Equipped)

E191328

Mute.

A

Voice recognition.

B

End call.

C

Answer or make a call.

D

See your SYNC information.

CRUISE CONTROL

Type One

E191329

See Using Cruise Control (page 239).

Type Two

E248613

See Using Adaptive Cruise Control
(page 240).

INFORMATION DISPLAY
CONTROL

E191336

See Information Displays (page 111).

HEATED STEERING WHEEL

 (If

Equipped)

See your SYNC information.

ADJUSTING THE PEDALS

 (If

Equipped)

Note: Never use the controls when your feet
are on the accelerator or brake pedals,
especially when the vehicle is moving.

Note: Adjust the pedals only when your
vehicle is in park (P).

Depending on your vehicle and equipment
level, the shape and location of your
power-adjustable pedal control can vary.

•

If your control is vertical, then it is to
the left of the steering column and on
the instrument panel.

•

If your control is horizontal, then it is on
the left side of the steering column.

The Vertical Control

E176213

Farther.

A.

Closer.

B.

The Horizontal Control

A

B

E162916

Farther.

A.

Closer.

B.

Both horizontal and vertical controls
operate the same way:
1.

Press and hold A to move the pedals
away from you.

2. Press and hold B to move the pedals

closer to you.

You can save and recall the pedal positions
with the memory feature.  See Memory
Function (page 150).
