Objects hanging off the seatback.

•

Objects stowed in the seatback map
pocket.

•

Objects placed on the occupant's lap.

•

Cargo interference with the seat

•

Other passengers pushing or pulling on
the seat.

•

Rear passenger feet and knees resting
or pushing on the seat.

The conditions listed above may cause the
weight of a properly seated occupant to
be incorrectly interpreted by the front
passenger sensing system. The person in
the front passenger seat may appear
heavier or lighter due to the conditions
described in the previous list.

E67017

Make sure the front passenger
sensing system is operating
properly.  See Crash Sensors

and Airbag Indicator (page 53).

If the airbag readiness light is lit, do the
following:

The driver and adult passengers should
check for objects lodged underneath the
front passenger seat or cargo interfering
with the seat.

If objects are lodged or cargo is interfering
with the seat, please take the following
steps to remove the obstruction:
•

Pull your vehicle over.

•

Switch your vehicle off.

•

Driver or adult passengers should
check for any objects lodged
underneath the front passenger seat
or cargo interfering with the seat.

•

Remove the obstruction(s) (if found).

•

Restart your vehicle.

•

Wait at least two minutes and verify
that the airbag readiness light in the
instrument cluster is no longer
illuminated.

•

If the airbag readiness light in the
instrument cluster remains illuminated,
this may or may not be a problem due
to the front passenger sensing system.

Do not attempt to repair or service the
system. Take your vehicle immediately to
an authorized dealer.

If it is necessary to modify an advanced
front airbag system to accommodate a
person with disabilities, contact the Ford
Customer Relationship Center.

SIDE AIRBAGS

WARNINGS

Do not place objects or mount
equipment on or near the airbag
cover, on the side of the seatbacks

(of the front seats), or in front seat areas
that may come into contact with a
deploying airbag. Failure to follow these
instructions may increase the risk of
personal injury in the event of a crash.

Do not use accessory seat covers.
The use of accessory seat covers
may prevent the deployment of the

side airbags and increase the risk of injury
in an accident.

Do not lean your head on the door.
The side airbag could injure you as it
deploys from the side of the

seatback.

Do not attempt to service, repair, or
modify the airbag, its fuses or the
seat cover on a seat containing an

airbag as you could be seriously injured or
killed. Contact your authorized dealer as
soon as possible.

WARNINGS

If the side airbag has deployed, the
airbag will not function again. The
side airbag system (including the

seat) must be inspected and serviced by
an authorized dealer. If the airbag is not
replaced, the unrepaired area will increase
the risk of injury in a crash.

The side airbags are located on the
outboard side of the seatbacks of the front
seats. In certain sideways crashes, the
airbag on the side affected by the crash
will be inflated. The airbag was designed
to inflate between the door panel and
occupant to further enhance the protection
provided occupants in side impact crashes.

E152533

The system consists of the following:
•

A label or embossed side panel
indicating that side airbags are fitted
to your vehicle.

•

Side airbags located inside the driver
and front passenger seatbacks.

•

Front passenger sensing system.

E67017

•

Crash sensors and monitoring system
with readiness indicator.  See Crash
Sensors and Airbag Indicator (page
53).

Note: The passenger sensing system will
deactivate the passenger seat-mounted
side airbag if it detects an empty passenger
seat.

The design and development of the side
airbag system included recommended
testing procedures that were developed
by a group of automotive safety experts
known as the Side Airbag Technical
Working Group. These recommended
testing procedures help reduce the risk of
injuries related to the deployment of side
airbags.

SAFETY CANOPY™

WARNINGS

Do not place objects or mount
equipment on or near the headliner
at the siderail that may come into

contact with a deploying curtain airbag.
Failure to follow these instructions may
increase the risk of personal injury in the
event of a crash.

Do not lean your head on the door.
The curtain airbag could injure you
as it deploys from the headliner.

Do not attempt to service, repair, or
modify the supplementary restraint
system or associated components.

Failure to follow this instruction could
result in personal injury or death.

All occupants of your vehicle,
including the driver, should always
properly wear their seatbelts, even

when an airbag supplemental restraint
system is provided. Failure to properly wear
your seatbelt could seriously increase the
risk of injury or death.

To reduce risk of injury, do not
obstruct or place objects in the
deployment path of the airbag.

WARNINGS

If a supplementary restraint system
component has deployed, it will not
function again. Have the system and

associated components inspected as soon
as possible. Failure to follow this
instruction could result in personal injury
or death.

The Safety Canopy deploys during
significant side crashes or when a certain
likelihood of a rollover event is detected
by the rollover sensor. The Safety Canopy
is mounted to the roof side-rail sheet
metal, behind the headliner, above each
row of seats. In certain sideways crashes
or rollover events, the Safety Canopy will
be activated, regardless of which seats are
occupied. The Safety Canopy is designed
to inflate between the side window area
and occupants to further enhance
protection provided in side impact crashes
and rollover events.

E75004

The system consists of the following:
•

Safety Canopy curtain airbags above
the trim panels over the front and rear
side windows identified by a label or
wording on the headliner or roof-pillar
trim.

•

A flexible headliner which opens above
the side doors to allow air curtain
deployment

E67017

· Crash sensors and monitoring
system with a readiness
indicator.  See Crash Sensors

and Airbag Indicator (page 53).

Properly restrain children 12 years old and
under in the rear seats. The Safety Canopy
will not interfere with children restrained
using a properly installed child or booster
seat because it is designed to inflate
downward from the headliner above the
doors along the side window opening.

The design and development of the Safety
Canopy included recommended testing
procedures that were developed by a
group of automotive safety experts known
as the Side Airbag Technical Working
Group. These recommended testing
procedures help reduce the risk of injuries
related to the deployment of side airbags
(including the Safety Canopy).

CRASH SENSORS AND
AIRBAG INDICATOR

WARNING

Modifying or adding equipment to
the front end of the vehicle (including
frame, bumper, front end body

structure and tow hooks) may affect the
performance of the airbag system,
increasing the risk of injury. Do not modify
the front end of the vehicle.

Your vehicle has a collection of crash and
occupant sensors which provide
information to the restraints control
module which deploys (activates) the
front safety belt pretensioners, optional
rear inflatable safety belts, driver airbag,
passenger airbag, seat mounted side
airbags, and the Safety Canopy®. Based
on the type of crash (frontal impact, side
impact or rollover), the restraints control
module will deploy the appropriate safety
devices.

The restraints control module also
monitors the readiness of the above safety
devices plus the crash and occupant
sensors. The readiness of the safety
system is indicated by a warning indicator
light in the instrument cluster or by a
backup tone if the warning light is not
working.  See Instrument Cluster (page
103).  Routine maintenance of the airbag is
not required.

A difficulty with the system is indicated by
one or more of the following:

E67017

The readiness light will not
illuminate immediately after the
ignition is turned on.

•

The readiness light will either flash or
stay lit.

•

A series of five beeps will be heard. The
tone pattern will repeat periodically
until the problem, the light or both are
repaired.

If any of these things happen, even
intermittently, have the supplemental
restraint system serviced at an authorized
dealer immediately. Unless serviced, the
system may not function properly in the
event of a crash.

The fact that the safety belt pretensioners
or front airbags did not activate for both
front seat occupants in a crash does not
mean that something is wrong with the
system. Rather, it means the restraints
control module determined the accident
conditions (crash severity, belt usage)
were not appropriate to activate these
safety devices.
•

The design of the front airbags is to
activate only in frontal and near-frontal
crashes (not rollovers, side impacts or
rear impacts unless the crash causes
sufficient frontal deceleration).

•

The design of the safety belt
pretensioners and optional rear
inflatable safety belts is to activate in
frontal, near-frontal and side crashes,
and in rollovers.

•

The design of the side airbags is to
inflate in certain side impact crashes.
Side airbags may activate in other
types of crashes if the vehicle
experiences sufficient sideways motion
or deformation.

•

The design of the Safety Canopy is to
inflate in certain side impact crashes
or rollover events. The Safety Canopy
may activate in other types of crashes
if the vehicle experiences sufficient
sideways motion or deformation, or a
certain likelihood of rollover.

AIRBAG DISPOSAL

Contact your authorized dealer as soon as
possible. Airbags must be disposed of by
qualified personnel.
