Ford Explorer (2018 year). Manual - part 89

AUDIO UNIT - VEHICLES WITH:
SONY AM/FM/CD

WARNING

Driving while distracted can result in
loss of vehicle control, crash and
injury. We strongly recommend that

you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Note: Some features, such as SIRIUS
satellite radio, may not be available in your
location. Check with an authorized dealer.

Note: The touchscreen controls most of
the audio features. See your SYNC
information.

SOUND: Press to access settings for Treble, Midrange, Bass, Fade or Balance.

A

CD slot: Insert a CD.

B

Eject: Press to eject a CD.

C

Vol and Power: Turn to adjust the volume. Press to switch the system on and
off.

D

TUNE: In radio mode, press to search through the radio frequency band. In
SIRIUS mode, press to find the next or previous available satellite radio station.

E

Seek, Fast Forward and Reverse: In radio mode, select a frequency band
and press either button. The system stops at the first station it finds in that
direction. In SIRIUS mode, press to select the next or previous satellite radio
station. If you select a specific category (such as jazz, rock or news), press to
find the next or previous station in the category you select. In CD mode, press
to select the next or previous track. Press and hold to move quickly forward or
backward through the current track.

F

AUDIO UNIT - VEHICLES WITH:
AM/FM/CD/SYNC

WARNING

Driving while distracted can result in
loss of vehicle control, crash and
injury. We strongly recommend that

you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Note: You can operate your audio system
for up to one hour after you switch the
ignition off. Press VOL to operate the
system with the ignition turned off. The
system turns off after one hour.

Note: Some features, such as SIRIUS
satellite radio, may not be available in your
location. Check with an authorized dealer.

Note: Depending on your vehicle options,
your audio system may not be equipped
with a CD player.

SOUND: Press to access settings for Treble, Midrange, Bass, Fade and Balance.
Use the up and down arrow buttons to select the various settings. When you
make your selection, press the left and right arrow buttons to change the
settings. Press OK to set or press MENU to exit. Sound settings can be set for
each audio source independently.

A

MUTE: Press to mute the playing audio.

B

Clock: Press to access the clock setting. Use the center arrow controls to change
the hours and minutes. You can also set the clock by pressing MENU and
scrolling to Clock Settings. If not in phone mode, press to display the clock.

C

MENU: Press to access different audio system features. See Menu Structure.

D

Number block: In radio mode, store and recall your favorite radio stations. To
store a radio station, tune to the station, then press and hold a preset button
until sound returns. In CD mode, select a track. In phone mode, enter a phone
number.

E

Function buttons: Select different functions of the audio system depending
on which mode you are in (such as Radio mode or CD mode).

F

Seek, Fast Forward and Reverse: In radio mode, select a frequency band
and press either button. The system stops at the first station it finds in that
direction. In SIRIUS mode, press to select the next or previous satellite radio
station. If you select a specific category (such as jazz, rock or news), press to
find the next or previous station in the category you select. In CD mode, press
to select the next or previous track. Press and hold to move quickly forward or
backward through the current track.

G

TUNE: In radio mode, turn to search through the radio frequency band. In SIRIUS
mode, turn to find the previous or next available satellite radio station.

H

End phone call: Press to end a phone call.

I

Eject: Press to eject a CD.

J

OK and cursor arrows: Use the up and down arrow buttons to select the
various settings. When you make your selection, press the left and right arrow
buttons to change the settings. Press OK to set or press MENU to exit.

K

CD Slot: Insert a CD.

L

Play/Pause: Press to either play or pause a track when listening to a CD.

M

Answer or make phone call: Press to either answer or make a phone call.

N

Vol and Power: Turn to adjust the volume. Press to switch the system on and
off.

O

PHONE: Press to access the phone features of the SYNC system. See your
SYNC information.

P

MEDIA: Press to open the media source menu. You can press this multiple
times to change to CD or to a SYNC-Media device or scroll through the media
sources using the arrow buttons. Press OK to select a source.

Q

RADIO: Press to listen to the radio or change radio stations. Press the function
buttons below the radio screen to select different radio functions.

R

CD: Press to listen to a CD. Press the function buttons below the radio screen
to select on-screen options of Repeat or Shuffle.

S

Menu Structure

Note: Depending on your system, some
options may appear slightly different.

Press MENU.

Press the up and down arrow buttons to
scroll through the options.

Press the right arrow to enter a menu.
Press the left arrow to exit a menu.

Press OK to confirm a selection.
