MOTORCRAFT PARTS - 3.5L ECOBOOST™

Part Number

Component

FA-1884

Air filter element

FL-500-S

Oil filter

BXT-59

Battery

BXT-65-650

*

SP-534

Spark plugs

FP-68

Cabin air filter

WW-2600 (driver side)

Windshield wiper blade

WW-2206 (passenger side)

WW-1106

Rear window wiper blade

*

This Motorcraft part is designed for vehicles with Intelligent Access.

We recommend Motorcraft replacement parts available at your Ford dealer or at
fordparts.com for scheduled maintenance. These parts meet or exceed Ford Motor
Company’s specifications and are engineered for your vehicle. Use of other parts may
impact vehicle performance, emissions and durability. Your warranty may be void for any
damage related to use of other parts.

If a Motorcraft oil filter is not available, use an oil filter that meets industry performance
specification SAE/USCAR-36.

For spark plug replacement, contact an authorized dealer. Replace the spark plugs at the
appropriate intervals.  See Scheduled Maintenance (page 491).

VEHICLE IDENTIFICATION
NUMBER

The vehicle identification number is
located on the left-hand side of the
instrument panel.

Please note that in the graphic, XXXX is
representative of your vehicle identification
number.

The Vehicle Identification Number contains
the following information:

World manufacturer identifier

A

Brake system, Gross Vehicle
Weight Rating, Restraint Devices
and their locations

B

Make, vehicle line, series, body
type

C

Engine type

D

Check digit

E

Model year

F

Assembly plant

G

Production sequence number

H

VEHICLE CERTIFICATION
LABEL

The National Highway Traffic Safety
Administration Regulations require that a
Safety Compliance Certification Label be
affixed to a vehicle and prescribe where
the Safety Compliance Certification Label
may be located. The Safety Compliance
Certification Label shall be affixed to either
the door hinge pillar, the door latch post,
or the edge of the door near the door latch,
next to the driver's seating position.

TRANSMISSION CODE
DESIGNATION

The transmission code is on the Safety
Compliance Certification Label.  The
following table shows the transmission
code along with the transmission
description.

Code

Description

6

Six-speed automatic transmission 6F35

C

Six-speed automatic transmission 6F55

J

Six-speed automatic transmission 6F50

CAPACITIES AND SPECIFICATIONS - 2.3L ECOBOOST™

Capacities

WARNING

The air conditioning refrigerant system contains refrigerant under high pressure.
Only qualified personnel should service the air conditioning refrigerant system.
Opening the air conditioning refrigerant system can cause personal injury.

Capacity

Item

5.7 qt (5.4 L)

Engine oil (with oil filter)

11.6 qt (11 L)

Engine coolant

Between MIN/MAX on brake fluid reservoir

Brake fluid

2.11 pt (1.0 L)

Rear axle fluid (four-wheel drive)

9.0 qt (8.5 L) *

Automatic transmission fluid

23.7 fl oz (700 ml)

Power Transfer Unit (PTU) fluid (four-
wheel drive)

Fill as required

Windshield washer fluid

18.6 gal (70.4 L)

Fuel tank

2.81 lb (1.276 kg)

A/C refrigerant

7.3 fl oz (215 ml)

A/C refrigerant compressor oil

*Approximate dry fill capacity.  Actual amount may vary during fluid changes.

Specifications

Materials

Specification

Name

WSS-M2C946-A

Recommended motor oil (U.S.):
Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor
Oil
XO-5W30-QSP

WSS-M2C946-A

Recommended Motor oil (Canada):
Motorcraft® SAE 5W-30 Super Premium Motor Oil
CXO-5W30-LSP12

WSS-M2C946-A

Optional motor oil (U.S.):
