FCC and RSS-210 Industry Canada
Compliance

This device complies with Part 15 of the
FCC Rules and with RSS-210 of Industry
Canada. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.

Note: Changes or modifications to your
device not expressly approved by the party
responsible for compliance can void the
user’s authority to operate the equipment.

This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment. End Users must
follow the specific operating instructions
for satisfying RF exposure compliance. This
transmitter must be at least 8 in (20 cm)
from the user and must not be co-located
or operating in conjunction with any other
antenna or transmitter.

The term “IC:” before the
certification/registration number only
signifies that Industry Canada technical
specifications were met.

 (If Equipped)

12 Volt DC Power Point

WARNING

Do not plug optional electrical
accessories into the cigar lighter
socket. Incorrect use of the cigar

lighter can cause damage not covered by
the vehicle warranty, and can result in fire
or serious injury.

Note: When you switch the ignition on, you
can use the socket to power 12 volt
appliances with a maximum current rating
of 15 amps.

If the power supply does not work after you
switch the ignition off, switch the ignition
on.
Note: Do not hang any accessory from the
accessory plug.

Note: Do not use the power point over the
vehicle capacity of 12 volt DC 180 watts or
a fuse may blow.

Note: Always keep the power point caps
closed when not in use.

Do not insert objects other than an
accessory plug into the power point.  This
damages the power point and may blow
the fuse.

Run the vehicle for full capacity use of the
power point.

To prevent the battery from running out of
charge:
•

Do not use the power point longer than
necessary when the vehicle is not
running.

•

Do not leave devices plugged in
overnight or when you park your vehicle
for extended periods.

Note: Timed power points remain on for 30
minutes if the vehicle is in accessory mode.
If you switch the vehicle off, the timed
power points remain on for 75 minutes.

Locations

Power points may be in the following
locations:
•

On the front of the center console.

•

Inside the center console.

•

On the rear of the center console.

•

In the cargo area.

110 Volt AC Power Point

 (If Equipped)

WARNING

Do not keep electrical devices
plugged in the power point whenever
the device is not in use. Do not use

any extension cord with the 110 volt AC
power point, since it will defeat the safety
protection design. Doing so may cause the
power point to overload due to powering
multiple devices that can reach beyond
the 150 watt load limit and could result in
fire or serious injury.

Note: The power point turns off when you
switch the ignition off, or when the battery
voltage drops below 11 volts.

You can use the power point for electric
devices that require up to 150 watts.  It is
on the rear of the center console.

When the indicator light on the power point
is:
•

On: The power point is working, the
ignition is on and a device is plugged
in.

•

Off: The power point is off, the ignition
is off or no device is plugged in.

•

Flashing: The power point is in fault
mode.

The power outlet temporarily turns off
power when in fault mode if the device
exceeds the 150 watt limit.  Unplug your
device and switch the ignition off.  Switch
the ignition back on, but do not plug your
device back in.  Let the system cool off and
switch the ignition off to reset the fault
mode.  Switch the ignition back on and
make sure the indicator light remains on.

Do not use the power point for certain
electric devices, including:
•

Cathode-ray, tube-type televisions.

•

Motor loads, such as vacuum cleaners,
electric saws and other electric power
tools or compressor-driven
refrigerators.

•

Measuring devices, which process
precise data, such as medical
equipment or measuring equipment.

•

Other appliances requiring an
extremely stable power supply such as
microcomputer-controlled electric
blankets or touch-sensor lamps.

CENTER CONSOLE

Stow items in the cup holder carefully as
items may become loose during hard
braking, acceleration or crashes, including
hot drinks which may spill.

Available console features include:

USB port and SD card.

A

Power point.

B

Cup holder.

C

Terrain control and hill descent
control.

D

AC power point or USB port.

E

Rear climate controls.

F

AC power point.

G

USB smart charger.

H

Rear Seat Armrest

OVERHEAD CONSOLE

Press near the rear edge of the door to
open it.
