Protected Components

Fuse Rating

Fuse or Relay

Number

Climate control seat module.

30A

1

77

Trailer lighting module.

40A

1

78

Blower motor.

40A

2

79

Wiper motor 2.

25A

1

80

110 volt inverter.

40A

1

81

Not used.

–

82

Not used (spare).

20A

1

83

Starter solenoid.

30A

1

84

Not used.

—

85

Anti-lock brake system pump.

60A

2

87

1

M case fuse.

2

J case fuse.

Passenger Compartment Fuse
Panel

The fuse panel is located under the
instrument panel to the left of the steering
column.

Note: It may be easier to access the fuse
panel if you remove the finish trim piece.

E145984

Protected Components

Fuse Rating

Fuse or Relay

Number

Not used.

—

1

Memory seats.

7.5A

1

2

Lumbar.
Driver seat module logic power.

Driver door unlock.

20A

1

3

Not used (spare).

5A

1

4

Not used (spare).

20A

1

5

Not used (spare).

10A

2

6

Not used (spare).

10A

2

7

Not used (spare).

10A

2

8

Not used (spare).

10A

2

9

Keypad.

5A

2

10

Power liftgate module logic power.
Hands free liftgate module.

Protected Components

Fuse Rating

Fuse or Relay

Number

Not used (spare).

5A

2

11

Climate control module.

7.5A

2

12

Cluster.

7.5A

2

13

Steering column control module.
Smart datalink connector (gateway)
module.

Extended power module.

10A

2

14

Datalink power.

10A

2

15

Not used (spare).

15A

1

16

Not used (spare).

5A

2

17

Push button start switch.

5A

2

18

Extended power module.

7.5A

2

19

Not used (spare).

7.5A

2

20

Humidity and in–car temperature sensor.

5A

2

21

Occupant classification system.

5A

2

22

Delayed accessory (power inverter logic,
moonroof logic, driver window switch
power).

10A

1

23

Central lock/unlock.

20A

1

24

Driver door (window, mirror).

30A

1

25

Driver door module.
Driver door lock indicator.
Driver lock switch illumination.

Front passenger door (window, mirror).

30A

1

26

Front passenger door module.
Front passenger lock indicator.
Front passenger switch illumination
(window, lock).

Protected Components

Fuse Rating

Fuse or Relay

Number

Moonroof.

30A

1

27

Amplifier.

20A

1

28

Not used (spare).

30A

1

29

Not used (spare).

30A

1

30

Not used (spare).

15A

1

31

Global positioning system.

10A

1

32

Center stack display.
Voice control (SYNC).
Radio transceiver module.

Radio.

20A

1

33

Run-start bus (fuse 19, 20, 21, 22, 35, 36, 37,
circuit breaker 38).

30A

1

34

Not used (spare).

5A

1

35

Auto-dimming rear view mirror.

15A

1

36

Heated seat.
Auto high beam/lane departure mirror
module.
Rear heated seat module logic power.

Heated steering wheel module.

20A

1

37

Active front steering wheel.

Rear power windows.

30A

3

38

Rear window switch illumination.

1

Micro 2 fuse.

2

Micro 3 fuse.

3

Circuit breaker.
