Ford Edge (2018 year). Manual - part 27

Settings

Select setting

911
Assist

Do Not
Disturb

Traction
Ctrl

Max
Speed

Speed
Minder

Volume Limiter

Hold OK to Clear All MyKeys

Clear
MyKeys

Select setting

Distance

Display
Setup

Temper-
ature

Gauge
Display

Tire Pres-
sure

Language

INFORMATION MESSAGES

Note: Depending on your vehicle options
and instrument cluster type, not all of the
messages will display or be available. The
information display may abbreviate or
shorten certain messages.

E144636

Press the OK button to acknowledge and
remove some messages from the
information display. The information
display will automatically remove other

messages after a short time.

You need to confirm certain messages
before you can access the menus.

Active Park

Action

Message

The system requires service due to a malfunction. Contact an

authorized dealer.

Active Park Fault

Adaptive Cruise Control

Action

Message

A radar malfunction is preventing the adaptive cruise control

from engaging.  See Using Adaptive Cruise Control (page

205).

Adaptive Cruise

Malfunction

A condition exists such that the adaptive cruise cannot func-

tion properly.  See Using Adaptive Cruise Control (page

205).

Adaptive Cruise Not

Available

You have a blocked sensor due to bad weather, ice, mud or

water in front of the radar sensor. You can typically clean the
sensor to resolve.  See Using Adaptive Cruise Control (page

205).

Adaptive Cruise Not

Available Sensor

Blocked See Manual

The system has disabled the automatic braking.

Normal Cruise Active

Automatic Braking

Turned Off

A radar malfunction is preventing the adaptive cruise control

from engaging.

Front Sensor Not Aligned

The adaptive cruise has reinstated controls to the driver.

Adaptive Cruise - Driver

Resume Control

Your vehicle speed is too slow to activate the adaptive cruise.

Adaptive Cruise Speed

Too Low to Activate

The adaptive cruise is automatically adjusting the gap

distance and the driver needs to shift the transmission into a

lower gear.

Adaptive Cruise Shift

Down

Adaptive Steering

Action

Message

The adaptive steering system has detected a difference

between steering wheel angle and the desired road wheel

angle. The steering wheel adjusts itself to correct this differ-

ence. This adjustment is part of normal system operation.

Adaptive Steering Initial-

ization

The adaptive steering system is off. It is possible that the

steering wheel may not be straight when the vehicle is driving

straight ahead. If this message persists, see an authorized

dealer.

Adaptive Steering Fault

Service Required

The adaptive steering system integrity cannot be verified. Do

not drive the vehicle and contact an authorized dealer

immediately.

Adaptive Steering Loss

Do Not Drive

Airbag

Action

Message

The system detects a malfunction due to a blocked sensor.

Remove blockage.

Occupant Sensor

BLOCKED Remove

Objects Near Passenger

Seat

Alarm

Action

Message

Alarm triggered due to unauthorized entry.  See Anti-Theft

Alarm (page 75).

Vehicle Alarm To Stop

Alarm, Start Vehicle.

The system requires service due to a malfunction. Contact

an authorized dealer.

Alarm malfunction Service

req'd

All-Wheel Drive

Action

Message

The all-wheel drive system temporarily turns off to protect

itself from overheating.

AWD Temporarily

Disabled

The all-wheel drive system temporarily turns off to protect

itself from overheating or if you are using the temporary spare

tire.

AWD OFF

The all-wheel drive system will resume normal function and

clear this message after driving a short distance with the road

tire re-installed or after the system cools.

AWD Restored

The all-wheel drive system is not operating properly. If the

warning stays on or continues to come on, contact an

authorized dealer.

AWD Malfunction

Service Required

Automatic Engine Shutdown

Action

Message

The engine is getting ready to shut off.

Engine Shuts Off In

{seconds to shut off:#0}

Seconds

The engine has shut off to help increase fuel economy.

Engine Shut Off For Fuel

Economy

The engine is getting ready to shut off. You can press OK on

the left steering wheel button to override the shut down.

Engine Shuts Off in

{seconds to shut off:#0}

Seconds Press Ok to

Override

Automatic High Beam Control

Action

Message

The front camera sensor has reduced visibility. Clean the

windshield.

Front Camera Low Visibility

Clean Screen

The system requires service due to a malfunction. Contact

an authorized dealer.

Front Camera Malfunction

Service Required

The front camera sensor has malfunctioned. Wait a short

period of time for the sensor to cool down.

Front Camera Temporarily

Not Available
