POWER WINDOWS

WARNINGS

Do not leave children unattended in
your vehicle and do not let them play
with the power windows. Failure to

follow this instruction could result in
personal injury.

When closing the power windows,
verify they are free of obstruction and
make sure that children and pets are

not in the proximity of the window
openings.

Note: You may hear a pulsing noise when
only one of the windows is open. Lower the
opposite window slightly to reduce this
noise.

Press the switch to open the window.

Lift the switch to close the window.

One-Touch Down

Press the switch fully and release it.  Press
again or lift it to stop the window.

One-Touch Up

Lift the switch fully and release it. Press or
lift it again to stop the window.

Window Lock

Press the control to lock or unlock the rear
window controls.  It illuminates when you
lock the rear window controls.

Bounce-Back

The window will stop automatically while
closing. It will reverse some distance if
there is an obstacle in the way.

Overriding the Bounce-Back Feature

WARNING

If you override bounce-back, the
window does not reverse if it detects
an obstacle. Take care when closing

the windows to avoid personal injury or
damage to your vehicle.

Proceed as follows to override this
protection feature when there is a
resistance, for example in winter:

1.

Close the window twice until it reaches
the point of resistance and let it
reverse.

2. Close the window a third time to the

point of resistance.  The bounce-back
feature is now disabled and you can
close the window manually.  The
window goes past the point of
resistance and you can close it fully.

See an authorized dealer as soon as
possible if the window does not close after
the third attempt.

Resetting the Bounce-Back Feature

WARNING

Bounce-back is off until you reset the
memory. Take care when closing the
windows to avoid personal injury or

damage to your vehicle.

If you have disconnected the battery, you
must reset the bounce-back memory
separately for each window.

1.

Lift and hold the switch until the
window is fully closed.

2. Release the switch.

3. Lift the switch again for one more

second.

4. Press and hold the switch until the

window is fully open.

5. Release the switch.

6. Lift and hold the switch until the

window is fully closed.

7.

Open the window and then try to close
it automatically.

8. Reset and repeat the procedure if the

window does not close automatically.

Accessory Delay

You can use the window switches for
several minutes after you switch the
ignition off or until you open either front
door.

GLOBAL OPENING

You can use the remote control to open
the windows with the ignition off.

Note: To operate this feature, accessory
delay must not be active.

Opening the Windows

You can use the global opening feature to
open the windows only for a short time
after you unlock your vehicle by using the
remote control.

To use the global opening feature:
1.

Press and release the remote control
unlock button.

2. Press the remote control unlock button

again and hold it for approximately
three seconds. Release the control
when the windows begin to open.

3. Press the lock or unlock button on your

remote control to stop the window
opening function.

Note: Contact an authorized Ford dealer to
deactivate this feature.

EXTERIOR MIRRORS

Power Exterior Mirrors

WARNING

Do not adjust the mirrors when your
vehicle is moving. This could result
in the loss of control of your vehicle,

serious personal injury or death.

Left-hand mirror

A

Off

B

Right-hand mirror

C

Press the arrows to adjust the mirror.

Fold-Away Exterior Mirrors

Push the mirror toward the door window
glass.  Make sure that you fully engage the
mirror in its support when returning it to its
original position.

Signal Indicator Mirrors

The outer portion of the appropriate mirror
housing blinks when you activate the turn
signal.

Heated Exterior Mirrors

 (If Equipped)

See Heated Windows and Mirrors (page
108).

Puddle Lamps

 (If Equipped)

The lamps on the bottom part of the mirror
housing light when you use your
transmitter to unlock the doors or when
you open a door.

Integrated Blind Spot Mirrors

 (If

Equipped)

WARNING

Objects in the mirror are closer than
they appear.

Blind spot mirrors have an integrated
convex mirror built into the upper outboard
corner of the exterior mirrors. They are
designed to increase your visibility along
the side of your vehicle.

Check the main mirror first before a lane
change, then check the blind spot mirror.
If no vehicles are present in the blind spot
mirror and the traffic in the adjacent lane
is at a safe distance, signal that you intend
to change lanes. Glance over your shoulder
to verify traffic is clear and carefully
change lanes.

The image of the approaching vehicle is
small and near the inboard edge of the
main mirror when it is at a distance. The
image becomes larger and begins to move
outboard across the main mirror as the
vehicle approaches (A). The image will
transition from the main mirror and begin
to appear in the blind spot mirror as the
vehicle approaches (B). The vehicle will
transition to your peripheral field of view
as it leaves the blind spot mirror (C).

Blind Spot Information System

 (If

Equipped)

See Blind Spot Information System
(page 170).

INTERIOR MIRROR

WARNING

Do not adjust the mirrors when your
vehicle is moving. This could result
in the loss of control of your vehicle,

serious personal injury or death.

Manual Dimming Mirror

Pull the tab below the mirror toward you
to reduce the effect of bright light from
behind.

Note: Your mirror may have multiple pivot
points.

Automatic Dimming Mirror

 (If Equipped)

The mirror dims to reduce the effect of
bright light from behind. It returns to
normal when the bright light from behind
is no longer present or if you shift into
reverse (R).

Do not block the sensors on the front and
back of the mirror.

Note: A rear center passenger or raised rear
center head restraint could prevent light
from reaching the sensor.
