IN CASE OF EMERGENCY

231

6. Insert a small screwdriver or similar tool down

into the gear selector override access hole (at

the right front corner of the gear selector

assembly), and push and hold the override

release lever down.

Gear Selector Override Location

7. Move the gear selector to the NEUTRAL

position.

8. The vehicle may then be started in NEUTRAL.
9. Reinstall the gear selector bezel.

FREEING A STUCK VEHICLE

If your vehicle becomes stuck in mud, sand, or

snow, it can often be moved using a rocking

motion. Turn the steering wheel right and left to

clear the area around the front wheels. Then shift

back and forth between DRIVE (D) and REVERSE

(R), while gently pressing the accelerator. Use the

least amount of accelerator pedal pressure that

will maintain the rocking motion, without spinning

the wheels or racing the engine.

Shifts between DRIVE and REVERSE can only be

achieved at wheel speeds of 5 mph (8 km/h) or

less. Whenever the transmission remains in

NEUTRAL for more than two seconds, you must

press the brake pedal to engage DRIVE or

REVERSE.

NOTE:

Push the ESC OFF button to place the Electronic

Stability Control (ESC) system in “Partial OFF”

mode, before rocking the vehicle

page 176.

Once the vehicle has been freed, push the ESC OFF

button again to restore “ESC On” mode.

CAUTION!



Racing the engine or spinning the wheels may

lead to transmission overheating and failure.

Allow the engine to idle with the transmission

in NEUTRAL for at least one minute after every

five rocking-motion cycles. This will minimize

overheating and reduce the risk of clutch or

transmission failure during prolonged efforts

to free a stuck vehicle.



When “rocking” a stuck vehicle by shifting

between DRIVE/SECOND gear and REVERSE,

do not spin the wheels faster than 15 mph

(24 km/h), or drivetrain damage may result.



Revving the engine or spinning the wheels too

fast may lead to transmission overheating and

failure. It can also damage the tires. Do not

spin the wheels above 30 mph (48 km/h)

while in gear (no transmission shifting occur

ring).

WARNING!

Fast spinning tires can be dangerous. Forces

generated by excessive wheel speeds may

cause damage, or even failure, of the axle and

tires. A tire could explode and injure someone.

Do not spin your vehicle's wheels faster than

30 mph (48 km/h) or for longer than 30 sec

onds continuously without stopping when you

are stuck and do not let anyone near a spinning

wheel, no matter what the speed.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

232

IN CASE OF EMERGENCY

(Continued)

TOWING A DISABLED VEHICLE

This section describes procedures for towing a

disabled vehicle using a commercial towing

service.

This vehicle must be towed with all four wheels OFF

the ground.
If you must use the accessories (wipers,

defrosters, etc.) while being towed, the ignition

must be in the RUN position.
If the key fob is unavailable or the vehicle's battery

is discharged, find Instructions on shifting the

transmission out of PARK in order to move the

vehicle

page 230.

HEEL

RIVE

(AWD) M

ODELS

FCA US LLC requires towing with all four wheels

OFF the ground. Acceptable methods are to tow

the vehicle on a flatbed, or with one end of the

vehicle raised and the opposite end on a towing

dolly.

SAGE

— I

QUIPPED

Your vehicle is equipped with a tow eye that can be

used to move a disabled vehicle.
When using a tow eye, be sure to follow the Tow

Eye Usage Precautions below.

Tow Eye

Tow Eye Usage Precautions

Towing

Condition

Wheels OFF

The Ground

ALL WHEEL

DRIVE

Flat Tow

NONE

NOT ALLOWED

Wheel Lift Or

Dolly Tow

Rear

NOT ALLOWED

Front

NOT ALLOWED

Flatbed

ALL

CAUTION!



Do not use sling type equipment when towing.

Vehicle damage may occur.



When securing the vehicle to a flat bed truck,

do not attach to front or rear suspension

components. Damage to your vehicle may

result from improper towing.

CAUTION!



DO NOT tow this vehicle with ANY of its wheels

on the ground. Damage to the drivetrain will

result.



Front or rear wheel lifts must not be used (if

the remaining wheels are on the ground).

Internal damage to the transmission or power

transfer unit will occur if a front or rear wheel

lift is used when towing.



Towing this vehicle in violation of the above

requirements can cause severe transmission

and/or power transfer unit damage. Damage

from improper towing is not covered under the

New Vehicle Limited Warranty.

CAUTION!



The tow eye must only be used for roadside

emergencies. Use with an appropriate device

in accordance with highway code (a rigid bar

or rope) to maneuver the vehicle in prepara

tion for transport via a tow truck.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

IN CASE OF EMERGENCY

233

(Continued)

Tow Eye Warning Label

Front Tow Eye Installation

The front tow eye receptacle is located behind an

access door, located on the right side of the front

fascia/bumper. To install the tow eye, open the

access door using the vehicle key or a small

screwdriver, and thread the tow eye into the

receptacle.
Insert the wheel bolt wrench handle through the

eye and tighten. The tow eye must be fully seated

to the attaching bracket through the lower front

fascia/bumper as shown. If the tow eye is not fully

seated to the attaching bracket, the vehicle should

not be towed.

Front Tow Eye Access Door

Front Tow Eye Installed



The tow eye must not be used to move the

vehicle off the road or where there are obsta

cles.



Do not use the tow eyes for tow truck hookup

or highway towing.



Do not use the tow eye to free a stuck vehicle

page 231.



Damage to your vehicle may occur if these

guidelines are not followed

page 232.

WARNING!

Stand clear of vehicles when pulling with tow

eyes.

CAUTION!



Do not use a chain with a tow eye. Chains may

break, causing serious injury or death.



Do not use a tow strap with a tow eye. Tow

straps may break or become disengaged,

causing serious injury or death.



Failure to follow proper tow eye usage may

cause components to break resulting in

serious injury or death.

WARNING!

-------------------------------------------------------------------------------------------------------------------------------------------------------------

234

IN CASE OF EMERGENCY

Rear Tow Eye Installation

The rear tow eye receptacle is located behind a

access door on the rear fascia/bumper.
To install the tow eye, open the access door using

the vehicle key or a small screwdriver, and thread

the tow eye into the receptacle.
Insert the wheel bolt wrench handle through the

eye and tighten. The tow eye must be fully seated

to the attaching bracket through the lower rear

fascia/bumper. If the tow eye is not fully seated to

the attaching bracket, the vehicle should not be

towed.

Rear Tow Eye Access Door

Rear Tow Eye Installed

ENHANCED ACCIDENT RESPONSE SYSTEM

(EARS)

This vehicle is equipped with an Enhanced

Accident Response System.
This feature is a communication network that

takes effect in the event of an impact

page 201.

EVENT DATA RECORDER (EDR)

This vehicle is equipped with an event data

recorder (EDR). The main purpose of an EDR is to

record data that will assist in understanding how a

vehicle’s systems performed under certain crash

or near crash-like situations, such as an air bag

deployment or hitting a road obstacle

page 204.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

235

SERVICING AND MAINTENANCE

SCHEDULED MAINTENANCE

Your vehicle is equipped with an automatic oil

change indicator system. The oil change indicator

system will remind you that it is time to take your

vehicle in for scheduled maintenance.
Based on engine operation conditions, the oil

change indicator message will illuminate in the

instrument cluster. This means that service is

required for your vehicle. Operating conditions

such as frequent short-trips, trailer tow and

extremely hot or cold ambient temperatures will

influence when the “Change Oil” or “Oil Change

Required” message is displayed. Have your vehicle

serviced as soon as possible, within the next

500 miles (805 km).

An authorized dealer will reset the oil change

indicator message after completing the scheduled

oil change.

NOTE:

Under no circumstances should oil change

intervals exceed 10,000 miles (16,000 km),

12 months or 350 hours of engine run time,

whichever comes first. The 350 hours of engine

run or idle time is generally only a concern for fleet

customers.

NOTE:

The Oil Change Indicator will not illuminate under

these conditions.

Once A Month Or Before A Long Trip:



Check engine oil level.



Check windshield washer fluid level.



Check the tire inflation pressures and look for

unusual wear or damage.



Check the fluid levels of the coolant reservoir,

and brake master cylinder reservoir, and fill as

needed.



Check function of all interior and exterior lights.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

237

Mileage or time passed (whichever comes first)

10,000

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

16,000

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

Check tire condition/wear and adjust pressure, if

necessary, check Tire Service Kit expiration date (if

provided).

•

Check operation of lighting system (headlamps, direction

indicators, hazard warning lights, luggage compartment,

passenger compartment, glove compartment, instrument

panel warning lights, etc.).

•

Check and, if necessary, top up fluid levels (brakes/

hydraulic clutch, windshield washer, engine coolant, etc.).

•

Check engine control system operation (via diagnostic tool).

•

Visually inspect condition of: exterior bodywork, underbody

protection, pipes and hoses (exhaust - fuel system - brakes),

rubber elements (boots, sleeves, bushings, etc.).

•

Check windshield/rear window wiper blade position/wear.

•

Check operation of windshield washer system and adjust

jets if necessary.

•

Check cleanliness of hood and tailgate locks and

cleanliness and lubrication of linkages.

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

238

SERVICING AND MAINTENANCE

Visually check the condition and wear of the front and rear

brakes.

•

Check the front suspension, tie rods and replace if

necessary.

•

Inspect the CV/Universal joints.

•

Visual inspect the condition of the accessory drive belt.

•

Check the tension of the accessory drive belt.

•

Inspect and replace, if required, front end accessory drive

belt, tensioner, and, idler pulley.

•

Inspect and replace PCV valve if necessary.

•

Change engine oil and replace oil filter.

In accordance with Oil Change Indicator System OR Severe Duty Mileage, whichever occurs first.

Inspect the PTU fluid level.

•

Inspect the rear differential fluid level.

•

Replace spark plugs.

•

Replace engine air cleaner filter.

•

Replace brake fluid every two years.

•

Mileage or time passed (whichever comes first)

10,000

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

16,000

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

239

Replace cabin filter.

To be replaced every 12,000 mi (19,000 km).

Flush and replace the engine coolant at 10 years or

150,000 miles (240,000 km) whichever comes first.

•

1. The oil and oil filter replacement must be carried out when indicated by a warning light or message on the instrument panel, or in any case should not exceed 1 year or 10,000 miles

(16,000 km).

2. The spark plug change is distance based only, yearly intervals do not apply. The following are essential to ensure correct operation and prevent serious damage to the engine:



Only use spark plugs of the same make and type which are specially certified for such engines

page 293.



Strictly comply with the spark plug replacement interval given in the Maintenance Plan for spark plug replacement.



Contact an authorized dealer if you have any questions.

3. The engine air cleaner filter should be inspected at every oil change if used in dusty areas.

○ Recommend replacement

• Mandatory service

Mileage or time passed (whichever comes first)

10,000

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

16,000

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

WARNING!



You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have

any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.



Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This could cause

an accident.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

241

HECKING

EVEL

To ensure proper engine lubrication, the engine oil

must be maintained at the correct level. Check the

oil level at regular intervals, such as every fuel

stop. The best time to check the engine oil level is

about five minutes after a fully warmed up engine

is shut off.
Checking the oil while the vehicle is on level ground

will improve the accuracy of the oil level readings.

NOTE:

The dipstick is integral with the cap.
Engine Oil Cap/Dipstick Installation
Install the oil cap/dipstick aligning arrow on the

cap with arrow on the engine cover and then screw

the cap down.

There are four possible dipstick types:



Crosshatched zone.



Crosshatched zone marked SAFE.



Crosshatched zone marked with MIN at the low

end of the range and MAX at the high end of the

range.



Crosshatched zone marked with dimples at the

MIN and the MAX ends of the range.

NOTE:

Always maintain the oil level within the crosshatch

markings on the dipstick.
Adding 1 quart (1 liter) of oil when the reading is at

the low end of the dipstick range will raise the oil

level to the high end of the range marking.

DDING

ASHER

LUID

The windshield washer fluid reservoir is located in

the engine compartment, and the fluid level should

be checked at regular intervals. Fill the reservoir

with windshield washer solvent (not engine

coolant/ antifreeze)

page 240.

AINTENANCE

-F

REE

ATTERY

Your vehicle is equipped with a maintenance-free

battery. You will never have to add water, and

periodic maintenance is not required.

1 — Oil Cap/Dipstick Arrow
2 — Engine Cover Arrow

CAUTION!

Overfilling or underfilling the crankcase will

cause aeration or loss of oil pressure. This could

damage your engine.

WARNING!

Commercially available windshield washer

solvents are flammable. They could ignite and

burn you. Care must be exercised when filling or

working around the washer solution.

WARNING!



Battery fluid is a corrosive acid solution and

can burn or even blind you. Do not allow

battery fluid to contact your eyes, skin, or

clothing. Do not lean over a battery when

attaching clamps. If acid splashes in eyes or

on skin, flush the area immediately with large

amounts of water

page 226.



Battery gas is flammable and explosive. Keep

flame or sparks away from the battery. Do not

use a booster battery or any other booster

source with an output greater than 12 Volts. Do

not allow cable clamps to touch each other.



Battery posts, terminals, and related accesso

ries contain lead and lead compounds. Wash

hands after handling.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

242

SERVICING AND MAINTENANCE

RESSURE

ASHING

Cleaning the engine compartment with a high

pressure washer is not recommended.

VEHICLE MAINTENANCE

An authorized dealer has the qualified service

personnel, special tools, and equipment to

perform all service operations in an expert

manner. Service Manuals are available which

include detailed service information for your

vehicle. Refer to these Service Manuals before

attempting any procedure yourself.

NOTE:

Intentional tampering with emissions control

systems may void your warranty and could result in

civil penalties being assessed against you.

NGINE

Engine Oil Selection

For the proper engine oil selection

page 293.

American Petroleum Institute (API)

Approved Engine Oil

These symbols mean that the oil has been certified

by the API. The manufacturer only recommends API

trademark oils.

The API Starburst trademark certifies

0W-20, 0W-30 and 5W-30 engine oils.

The API Donut trademark certifies 0W-40

and 5W-40 engine oil.

CAUTION!



It is essential when replacing the cables on

the battery that the positive cable is attached

to the positive post and the negative cable is

attached to the negative post. Battery posts

are marked positive (+) and negative (-) and

are identified on the battery case. Cable

clamps should be tight on the terminal posts

and free of corrosion.



If a “fast charger” is used while the battery is

in the vehicle, disconnect both vehicle battery

cables before connecting the charger to the

battery. Do not use a “fast charger” to provide

starting voltage.

CAUTION!

Precautions have been taken to safeguard all

parts and connections however, the pressures

generated by these machines is such that

complete protection against water ingress

cannot be guaranteed.

WARNING!

You can be badly injured working on or around a

motor vehicle. Only do service work for which

you have the knowledge and the proper

equipment. If you have any doubt about your

ability to perform a service job, take your vehicle

to a competent mechanic.

CAUTION!

Do not use chemical flushes in your engine oil as

the chemicals can damage your engine. Such

damage is not covered by the New Vehicle

Limited Warranty.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

243

(Continued)

Materials Added To Engine Oil

The manufacturer strongly recommends against

the addition of any additives (other than leak

detection dyes) to the engine oil. Engine oil is an

engineered product and its performance may be

impaired by supplemental additives.

Disposing Of Used Engine Oil And Oil

Filters

Care should be taken in disposing of used engine

oil and oil filters from your vehicle. Used oil and oil

filters, indiscriminately discarded, can present a

problem to the environment. Contact an

authorized dealer, service station or governmental

agency for advice on how and where used oil and

oil filters can be safely discarded in your area.

NGINE

ILTER

The engine oil filter should be replaced with a new

filter at every engine oil change.
Engine Oil Filter Selection
A full-flow type disposable oil filter should be used

for replacement. The quality of replacement filters

varies considerably. Only high quality Mopar®

certified filters should be used.

NGINE

LEANER

ILTER

For the proper maintenance intervals

page 236.

Engine Air Cleaner Filter Selection
The quality of replacement filters varies

considerably. Only high quality Mopar® certified

filters should be used.

CCESSORY

RIVE

ELT

NSPECTION

When inspecting accessory drive belts, small

cracks that run across ribbed surface of belt from

rib to rib, are considered normal. These are not a

reason to replace belt. However, cracks running

along a rib (not across) are not normal. Any belt

with cracks running along a rib must be replaced.

Also have the belt replaced if it has excessive wear,

frayed cords or severe glazing.

WARNING!

The air induction system (air cleaner, hoses,

etc.) can provide a measure of protection in the

case of engine backfire. Do not remove the air

induction system (air cleaner, hoses, etc.) unless

such removal is necessary for repair or

maintenance. Make sure that no one is near the

engine compartment before starting the vehicle

with the air induction system (air cleaner, hoses,

etc.) removed. Failure to do so can result in

serious personal injury.

WARNING!



Do not attempt to inspect an accessory drive

belt with vehicle running.



When working near the radiator cooling fan,

disconnect the fan motor lead. The fan is

temperature controlled and can start at any

time regardless of ignition mode. You could be

injured by the moving fan blades.



You can be badly injured working on or around

a motor vehicle. Only do service work for which

you have the knowledge and the proper equip

ment. If you have any doubt about your ability

to perform a service job, take your vehicle to a

competent mechanic.

WARNING!

-------------------------------------------------------------------------------------------------------------------------------------------------------------

244

SERVICING AND MAINTENANCE

Accessory Belt (Serpentine Belt)

Conditions that would require replacement:



Rib chunking (one or more ribs has separated

from belt body)



Rib or belt wear



Longitudinal belt cracking (cracks between two

ribs)



Belt slips



“Groove jumping" (belt does not maintain

correct position on pulley)



Belt broken (note: identify and correct problem

before new belt is installed)



Noise (objectionable squeal, squeak, or rumble

is heard or felt while drive belt is in operation)

Some conditions can be caused by a faulty

component such as a belt pulley. Belt pulleys

should be carefully inspected for damage and

proper alignment.

Belt replacement on some models requires the

use of special tools, we recommend having your

vehicle serviced at an authorized dealer.

ONDITIONER

AINTENANCE

For best possible performance, your air conditioner

should be checked and serviced by an authorized

dealer at the start of each warm season. This

service should include cleaning of the condenser

fins and a performance test. Drive belt tension

should also be checked at this time.

Refrigerant Recovery And Recycling —

R–1234yf

R–1234yf Air Conditioning Refrigerant is a

hydrofluoroolefin (HFO) that is endorsed by the

Environmental Protection Agency and is an

ozone-friendly substance with a low

global-warming potential. The manufacturer

recommends that air conditioning service be

performed by an authorized dealer using recovery

and recycling equipment.

NOTE:

Use only manufacturer approved A/C system PAG

compressor oil, and refrigerants.

Cabin Air Filter

See an authorized dealer for service.

ODY

UBRICATION

Locks and all body pivot points, including such

items as seat tracks, door hinge pivot points and

rollers, liftgate, tailgate, decklid, sliding doors and

hood hinges, should be lubricated periodically with

WARNING!



Use only refrigerants and compressor lubri

cants approved by the manufacturer for your

air conditioning system. Some unapproved

refrigerants are flammable and can explode,

injuring you. Other unapproved refrigerants or

lubricants can cause the system to fail,

requiring costly repairs. Refer to Warranty

Information Book, located in your owner’s

information kit, for further warranty informa

tion.



The air conditioning system contains refrig

erant under high pressure. To avoid risk of

personal injury or damage to the system,

adding refrigerant or any repair requiring lines

to be disconnected should be done by an

experienced technician.

CAUTION!

Do not use chemical flushes in your air

conditioning system as the chemicals can

damage your air conditioning components. Such

damage is not covered by the New Vehicle

Limited Warranty.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SERVICING AND MAINTENANCE

245

a lithium based grease, such as Mopar® Spray

White Lube to ensure quiet, easy operation and to

protect against rust and wear. Prior to the

application of any lubricant, the parts concerned

should be wiped clean to remove dust and grit;

after lubricating excess oil and grease should be

removed. Particular attention should also be given

to hood latching components to ensure proper

function. When performing other underhood

services, the hood latch, release mechanism and

safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated

twice a year, preferably in the Autumn and Spring.

Apply a small amount of a high quality lubricant,

such as Mopar® Lock Cylinder Lubricant directly

into the lock cylinder.

INDSHIELD

IPER

LADES

Clean the rubber edges of the wiper blades and the

windshield periodically with a sponge or soft cloth

and a mild nonabrasive cleaner. This will remove

accumulations of salt or road film.
Operation of the wipers on dry glass for long

periods may cause deterioration of the wiper

blades. Always use washer fluid when using the

wipers to remove salt or dirt from a dry windshield.
Avoid using the wiper blades to remove frost or ice

from the windshield. Keep the blade rubber out of

contact with petroleum products such as engine

oil, gasoline, etc.

NOTE:

Life expectancy of wiper blades varies depending

on geographical area and frequency of use. Poor

performance of blades may be present with chat

tering, marks, water lines or wet spots. If any of

these conditions are present, clean the wiper

blades or replace as necessary.
The wiper blades and wiper arms should be

inspected periodically, not just when wiper

performance problems are experienced. This

inspection should include the following points:



Wear or uneven edges



Foreign material



Hardening or cracking



Deformation or fatigue

If a wiper blade or wiper arm is damaged, replace

the affected wiper arm or blade with a new unit. Do

not attempt to repair a wiper arm or blade that is

damaged.

Service Position Strategy

The service position allows the wiper blades to be

placed in a position that allows the wiper blades to

be easily changed.
To enable the Service Position Strategy, the wipers

must be in the Park position before placing the

ignition in the OFF position.

Service Mode must be activated within two

minutes after the ignition is placed in the OFF

position.
To have a correct activation of strategy, the Service

Position command (anti-panic) must be active for

at least half a second.
At every valid activation of Service Position

command, the wiper blades are activated for

250 ms.
The Service Position command can be repeated

several times to bring the blades into the desired

position, up to a maximum of three times.
After three subsequent activations the strategy is

disabled.
Function Deactivation:
The functionality is reset if:



The ignition is turned to the RUN position.



Number of subsequent activations is three.



Two minute timer has expired after placing the

ignition OFF.

NOTE:

When turning the ignition ON, the blades will go

into the parking position.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

246

SERVICING AND MAINTENANCE

(Continued)

Front Wiper Blade Removal/Installation

1. Lift the front wiper arm upward to raise the

wiper blade off of the windshield.

2. Push the release button on the arm of the

wiper blade.

3. Push the wiper blade up and remove it.

4. Install the wiper blade and firmly push the

wiper blade until it snaps into place.

Rear Wiper Blade Removal/Installation

1. Carefully lift the rear wiper arm upward to

raise the wiper blade off of the liftgate glass.

2. Grab and hold the wiper arm closest to the

wiper blade end while pushing the wiper blade

towards the liftgate glass to unsnap the blade

pivot pin from the wiper blade holder on the

wiper arm.

3. Install the wiper blade pivot pin into the wiper

blade holder at the end of the wiper arm, and

firmly push the wiper blade until it snaps into

place.

XHAUST

YSTEM

The best protection against carbon monoxide entry

into the vehicle body is a properly maintained

engine exhaust system.
If you notice a change in the sound of the exhaust

system; or if the exhaust fumes can be detected

inside the vehicle; or when the underside or rear of

the vehicle is damaged; have an authorized

technician inspect the complete exhaust system

and adjacent body areas for broken, damaged,

deteriorated, or mispositioned parts. Open seams

or loose connections could permit exhaust fumes

to seep into the passenger compartment. In

addition, have the exhaust system inspected each

time the vehicle is raised for lubrication or oil

change. Replace as required.

1 — Wiper Blade
2 — Release Button
3 — Wiper Arm

WARNING!



Exhaust gases can injure or kill. They contain

carbon monoxide (CO), which is colorless and

odorless. Breathing it can make you uncon

scious and can eventually poison you. To

avoid breathing CO

page 216.



A hot exhaust system can start a fire if you

park over materials that can burn. Such mate

rials might be grass or leaves coming into

contact with your exhaust system. Do not park

or operate your vehicle in areas where your

exhaust system can contact anything that can

burn.

CAUTION!



The catalytic converter requires the use of

unleaded fuel only. Leaded gasoline will

destroy the effectiveness of the catalyst as an

emissions control device and may seriously

reduce engine performance and cause

serious damage to the engine.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fiat 500X (2022 year). Manual in english - page 15
