KEYS

WARNING!

Key Fob

† Before exiting a vehicle, always shift the

automatic transmission into PARK or the

A code number is stamped on the plate and

manual transmission into FIRST gear or

attached to the key fob. Detach this plate

REVERSE, apply the parking brake, then

and store it in a safe place

(not in the

turn the engine OFF, remove the key fob

vehicle) in case you need to replace the

from the vehicle and lock your vehicle.

emergency key.

† Never leave children alone in a vehicle,

Also, write down the code number and keep

Key Fob

or with access to an unlocked vehicle.

it in a separate safe and convenient place.

† Allowing children to be in a vehicle unat-

Do not keep it in the vehicle.

1 — Emergency Key

tended is dangerous for a number of

2 — Key Fob

reasons. A child or others could be seri-

If the key fob is lost, contact an authorized

3 — Key Code Number Plate

ously or fatally injured. Children should

dealer.

be warned not to touch the parking

NOTE:

brake, brake pedal or the gear selector.

To use the emergency key, push the mechan-

Key fob configuration may vary with

ical latch on the back side of the key fob and

† Do not leave the key fob in or near the

equipped features. Please see the example

pull out the emergency key.

vehicle, or in a location accessible to

shown below:

children. A child could operate power

NOTE:

windows, other controls, or move the

† Always keep a spare key fob if one is lost.

vehicle.

If a key fob is lost, see an authorized

† Do not leave children or animals inside

dealer as soon as possible.

parked vehicles in hot weather. Interior

† The driver must carry the key fob to ensure

heat build-up may cause serious injury or

death.

the Keyless Entry System functions prop-

erly.

12

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The setting change can be completed by

Turning On The Alarm

Key Fob Antenna Location

doing any one of the following:

Pushing the panic button for one second or

† Placing the ignition in the ACC or ON posi-

more will trigger the alarm for about two

tion.

minutes and thirty seconds, and the

following will occur:

† Closing the driver’s door.

† The horn sounds intermittently.

† Opening the trunk lid.

† The hazard warning lights flash.

† Not operating the key fob for ten seconds.

Turning Off The Alarm

† Pushing any button except the unlock

button on the key fob.

The alarm will stop by pushing any button on

Key Fob Antenna Location

the key fob.

† Pushing a request switch on the exterior

door handle.

Operational Range

1 — Interior Antenna

2 — Operational Range

Trunk Button

The system operates only when the driver is

in the vehicle or within operational range,

To open the trunk lid, push and hold the

NOTE:

and the key fob is being carried.

trunk button until the trunk lid opens.

The engine may not start if the key fob is

Starting The Engine

placed in or around the following areas:

Panic Button

Starting the engine may be possible even if

† Around The Instrument Panel

To turn the Panic Alarm on or off, push and

the key fob is outside the vehicle and close

hold the panic button on the key fob and

† In The Storage Compartments

to a door or window. Always start the engine

release. When the Panic Alarm is on, the

from the driver's seat.

headlights will turn on, the park lights will

Key Fob Battery Replacement

flash, the horn will pulse on and off, and the

If the vehicle is started, and the key fob is

turn signal lights will flash.

If the key fob does not work, and the indi-

not in the vehicle, the vehicle will not restart

cator lights do not flash, the battery may be

after it is shut off. The ignition is placed in

NOTE:

low or depleted.

the OFF position.

The panic button will work if the doors or

trunk are opened or closed.

14

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replace with a new battery (CR2025 type)

Replacing The Key Fob Battery

before the key fob becomes unusable.

Proceed as follows:

The following conditions indicate that the

1.

Push the mechanical release button and

battery power is low:

remove the emergency key.

† Key indicator light (green) flashes in the

instrument cluster for about 30 seconds

after the ignition is placed in the OFF posi-

tion.

† The system does not operate, and the

Pry Case Left Side

operation indicator light on the key fob

does not flash when the buttons are

3.

Insert a coin, a flat blade screw driver, or

pushed.

the tip of your emergency key into the

side gap and carefully pry in the direction

† The system's operational range is reduced.

of the arrow to open the cover.

NOTE:

Emergency Key Removed

Replacing the battery at an authorized dealer

1 — Emergency Key

is recommended to prevent damage to the

2 — Key Fob Case With Mechanical Re-

key fob. If replacing the battery alone, follow

lease Button

the instructions below.

2. Insert a coin, a flat blade screw driver, or

the tip of your emergency key into the

now exposed slot and carefully pry in the

direction of the arrows to open the cover

slightly.

Pry Case Right Side

15

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4. Separate the key fob case, then remove

Engine Start Function When Key Fob

the battery.

Battery Is Discharged

If a key fob has discharged or malfunctioned,

start the engine by holding the key fob over

the START/STOP ignition button. Be careful

to not allow the following because the signal

from the key fob will not be received

correctly, and the engine may not start:

† Contact with metal parts of other key fobs

Install New Battery

or metal objects

NOTE:

† Contact from key fobs from other vehicle’s

Remove Back Cover For Battery Replacement

Be careful not to allow the rubber ring to be

equipped with an immobilizer system

scratched or damaged. If the rubber ring

1 — Key Fob Battery

† Contact with devices for electronic

comes out, reinstall it before inserting a new

2 — Key Fob Case

battery.

purchases or security passage touch

Key Suspend Function

5. Insert a new battery with the positive pole

facing up. Then, cover the battery with

If a key fob is left in the vehicle, key fob

the battery cap.

functions are temporarily suspended to

prevent unlawful use of the vehicle.

6. Close the cover and reinsert the emer-

gency key.

To restore the functions, push the unlock

button on the functions-suspended key fob.

No Keys Touching The Key Fob

16

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5. Verify that the keyless ignition start indi-

In this case, the engine may start. However,

cator light (green) turns on.

contact an authorized dealer as soon as

possible.

6. Push the START/STOP ignition button to

start the engine.

If the keyless ignition start indicator light

(green) does not illuminate, perform the

operation from the beginning. If it does not

illuminate, contact an authorized dealer.

To change the ignition position without

starting the engine, perform the following

No Key Fob Touching The Key Fob

operations after the keyless ignition start

If the engine cannot be started due to a

indicator light (green) turns on:

discharged key fob battery, the engine can

1. Release the clutch pedal (manual trans-

be started using the following procedure:

mission) or brake pedal (automatic trans-

1. Continue to depress the brake pedal

mission).

Discharged Key Fob Battery Start Procedure

firmly until the engine has completely

2. Push the START/STOP ignition button to

started.

When touching the START/STOP ignition

change the ignition position. The ignition

button using the backside of the key fob,

2. Manual Transmission: Continue to

cycles in the order of ACC, ON, and OFF

touch the START/STOP ignition button with

depress the clutch pedal firmly until the

each time the START/STOP ignition

the key fob buttons facing up.

engine has completely started.

button is pushed.

The engine cannot be started unless the

3. Verify that the keyless ignition start indi-

NOTE:

clutch pedal is fully depressed

(manual

cator light (green) flashes.

To change the ignition position again,

transmission) or the brake pedal is fully

perform the operation from the beginning.

depressed (automatic transmission).

4. Touch the START/STOP ignition button

using the backside of the key fob while

If there is a malfunction with the START/

the keyless ignition start indicator light

STOP ignition button function, the keyless

(green) flashes.

ignition start indicator light (amber) flashes.

17

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

La operación de este equipo está sujeta a las

OFF

siguientes dos condiciones:

The power supply to electrical devices turns

1. es posible que este equipo o dispositivo

off, and the keyless ignition start indicator

no cause interferencia perjudicial y

light (amber) also turns off. In the OFF posi-

tion, the steering wheel is locked.

2. este equipo o dispositivo debe aceptar

cualquier interferencia, incluyendo la

ACC (Accessory)

que pueda causar su operación no

Some electrical accessories will operate and

deseada.

the indicator light

(amber) illuminates. In

Keyless START/STOP Ignition Button

the ACC position, the steering wheel is

NOTE:

Changes or modifications not expressly

unlocked.

NOTE:

approved by the party responsible for compli-

The Keyless Entry System does not function

ance could void the user’s authority to

† The engine starts by pushing the START/

while the keyless ignition has been placed in

operate the equipment.

STOP ignition button while depressing the

the ACC position, and the doors will not lock/

clutch pedal (manual transmission) or the

unlock even if they have been locked manu-

IGNITION SWITCH

brake pedal (automatic transmission). To

ally.

change the ignition position, push the

Push Button Start Positions

START/STOP ignition button without

ON

depressing the clutch or brake pedal.

This is the normal running position after the

The system operates only when the key fob is

within operational range.

† Do not leave the ignition in the ON posi-

engine is started.

tion while the engine is not running. The

NOTE:

When the clutch pedal (manual transmission)

battery could discharge. If the ignition is

or brake pedal (automatic transmission) are

The indicator light

(amber) turns off

(the

left in the ACC position

(for automatic

indicator light [amber] illuminates when the

not depressed and the keyless ignition

transmission, the gear selector is in the

START/STOP ignition button is pushed, the

ignition has been placed in the ON position

PARK position, and the ignition is in ACC),

and the engine is not running).

ignition cycles in the order of OFF, ACC, and

the ignition cycles to the OFF position

ON. Pushing the START/STOP ignition button

automatically after about 25 minutes.

Some indicator lights/warning lights should

again from ON/RUN position, places the igni-

be inspected before the engine is started.

tion in the OFF position.

19

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When the keyless ignition has been placed in

ADVANCED KEYLESS

WARNING! (Continued)

the ON position, the sound of the fuel pump

ENTRY SYSTEM — IF

motor operating near the fuel tank can be

† Do not leave the key fob in or near the

heard. This does not indicate a problem.

vehicle, (or in a location accessible to

EQUIPPED

children), and do not leave the ignition

WARNING!

Advanced Keyless Entry System

in the ACC or ON/RUN mode. A child

† Never use the PARK position as a substi-

could operate power windows, other

The Advanced Keyless Entry System is an

controls, or move the vehicle.

tute for the parking brake. Always apply

enhancement that allows you to lock/unlock

the parking brake fully when exiting the

† Be sure the parking brake is fully disen-

the doors, trunk lid, and fuel filler door.

vehicle to guard against vehicle move-

gaged before driving; failure to do so can

ment and possible injury or damage.

The Advanced Keyless Entry System allows

lead to brake failure and a collision.

the driver to start the ignition with the push

† When exiting the vehicle, always make

† Always fully apply the parking brake

of a button as long as the key fob is in the

sure the ignition is in the OFF mode,

when leaving your vehicle, or it may roll

passenger compartment.

remove the key fob from the vehicle, and

and cause damage or injury. Also be

lock your vehicle.

certain to leave the transmission in

If equipped, the vehicle security alarm

PARK. Failure to do so may allow the

system may be armed/disarmed with the

† Never leave children alone in a vehicle,

vehicle to roll and cause damage or

push of the lock/unlock button located on

or with access to an unlocked vehicle.

injury.

the key fob.

Allowing children to be in a vehicle unat-

tended is dangerous for a number of

† Driving the vehicle with the parking

System Malfunctions/Warnings

reasons. A child or others could be seri-

brake engaged, or repeated use of the

ously or fatally injured. Children should

System malfunctions or warnings are indi-

parking brake to slow the vehicle may

be warned not to touch the parking

cause serious damage to the brake

cated by the following warning lights or

brake, brake pedal or the transmission

beeps (refer to “Getting To Know Your Instru-

system.

gear selector.

ment Panel” for further information):

(Continued)

† Key indicator light (red)

† Ignition ON warning beep

20

-------------------------------------------------------------------------------------------------------------------------------------------------------------

† Key fob removed from vehicle warning

† If the key fob does not operate when

WARNING!

beep

pushing a button, the operational range

becomes too small, or the warning light

Radio waves from the key fob may affect

† Request switch inoperable warning beep

does not illuminate or flash, the battery

medical devices such as pacemakers:

† Key fob left in trunk warning beep

may be weak or discharged. To install a

before using the key fob near people who

new battery, refer to “Keys” in this chapter

use medical devices, ask the medical

† Key fob left in vehicle warning beep

for further information.

device manufacturer or your physician if

radio waves from the key fob will affect the

If you have a problem with the key fob, or the

† Battery life is about one year. Replace the

device.

key fob is lost or stolen, contact an autho-

battery with a new one if the key indicator

rized dealer as soon as possible for a replace-

light

(green) flashes in the instrument

ment and to make the lost or stolen key fob

NOTE:

cluster. Replacing the battery about once

inoperative.

The Advanced Keyless Entry System func-

a year is recommended because the key

tions can be deactivated to prevent any

indicator light may not illuminate or flash

NOTE:

possible adverse effect on a user wearing a

if the battery is low or depleted.

Changes or modifications not approved by

pacemaker or other medical device. If the

the party responsible for compliance could

† Additional key fobs may be obtained at an

system is deactivated, you will be unable to

void the user's authority to operate the

authorized dealer. Up to six key fobs may

start the engine by carrying the key fob.

equipment.

be used with the Advanced Keyless Entry

Contact an authorized dealer for details. If

System per vehicle. Bring all key fobs to

the Advanced Keyless Entry System has

† The Advanced Keyless Entry System oper-

an authorized dealer when additional keys

been deactivated, you can start the engine by

ational range may vary due to local

are required.

following the procedure indicated when the

weather conditions.

key fob battery becomes discharged.

The Advanced Keyless Entry function allows

† The Advanced Keyless Entry System is

you to lock/unlock the door, trunk lid, and

fully operational (door/trunk lid/fuel filler

fuel filler door, or open the trunk lid while

door lock/unlock) when the ignition is

carrying the key fob.

placed in the OFF position. The Advanced

Keyless Entry System does not operate if

the ignition is placed in any position other

than the OFF position.

21

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operational Range

Locking/Unlocking The Doors And The Trunk

Opening The Trunk Lid

Lid

The system operates only when the driver is

in or around the vehicle while the key fob is

being carried.

Electronic Trunk Release

Request Switch Door Functions

1 — Exterior Antenna

1 — Exterior Antenna

2 — Operational Range

Advanced Keyless Entry Sensors

2 — Operational Range

3 — Distance (31 inches)

3 — Distance (31 inches)

1 — Operational Range

2 — Interior Antennas

NOTE:

The system may not operate if you are too

NOTE:

close to the windows or door handles.

When the battery power is low, or in places

where there are high-intensity radio waves or

noise, the operational range may reduce, or

the system may not operate.

22

-------------------------------------------------------------------------------------------------------------------------------------------------------------

General Information

La operación de este equipo está sujeta a las

Immobilizer System

siguientes dos condiciones:

The following regulatory statement applies to

The immobilizer system allows the engine to

all Radio Frequency (RF) devices equipped

1. es posible que este equipo o dispositivo

start only with a recognized key fob.

in this vehicle:

no cause interferencia perjudicial y

If someone attempts to start the engine with

This device complies with Part 15 of the FCC

2. este equipo o dispositivo debe aceptar

an unrecognized key fob, the engine will not

Rules and with Innovation, Science and

cualquier interferencia, incluyendo la

start, preventing unlawful vehicle use.

Economic

Development

Canada

que pueda causar su operación no

If you have a problem with the immobilizer

license-exempt RSS standard(s). Operation

deseada.

system or the key fob, contact an authorized

is subject to the following two conditions:

NOTE:

dealer.

1. This device may not cause harmful inter-

Changes or modifications not expressly

To avoid damage to the key fob, DO NOT:

ference, and

approved by the party responsible for compli-

ance could void the user’s authority to

† Drop the key fob

2. This device must accept any interference

operate the equipment.

received, including interference that may

† Get the key fob wet

cause undesired operation.

VEHICLE SECURITY ALARM

† Expose the key fob to any kind of magnetic

field

Le présent appareil est conforme aux CNR

SYSTEM — IF EQUIPPED

d`Innovation, Science and Economic Devel-

† Expose the key fob to high temperatures

opment applicables aux appareils radio

Modifications And Add-On Equipment

such as direct sunlight

exempts de licence. L'exploitation est

autorisée aux deux conditions suivantes:

FCA cannot guarantee the immobilizer and

NOTE:

security alarm system operation if the system

1. l'appareil ne doit pas produire de brouil-

† Changes or modifications not expressly

has been modified or if any add-on equip-

lage, et

approved by the party responsible for

ment has been installed.

compliance could void the user's authority

2. l'utilisateur de l'appareil doit accepter

NOTE:

to operate the equipment.

tout brouillage radioélectrique subi,

To avoid damage to the vehicle, do not

même si le brouillage est susceptible

† If the engine does not start with the

modify the system or install any add-on

d'en compromettre le fonctionnement.

correct key fob, and the

warning light

equipment to the immobilizer, the security

keeps illuminating or flashing, the system

alarm system, or the vehicle.

23

-------------------------------------------------------------------------------------------------------------------------------------------------------------

may have a malfunction. Contact an

NOTE:

NOTE:

authorized dealer.

Signals from a TV, radio station, transceiver,

† If the

warning light flashes continu-

or mobile telephone could interfere with your

† The key fobs carry a unique electronic

ously while you are driving, do not turn the

immobilizer system. If you are using the

code. For this reason, and to assure your

engine off. Contact an authorized dealer

proper key fob and the engine fails to start,

safety, obtaining a replacement key fob

and have it checked. If the engine is shut

check the

warning light.

can only be done through an authorized

off while the

warning light is flashing,

dealer, and will require some waiting time.

Arming

it will not be able to be restarted.

† Always keep a spare key fob in case one is

The system is armed when the ignition is

† Because the electronic codes are reset

lost. If a key fob is lost, contact an autho-

cycled from the ON to OFF position. The

when the immobilizer system is repaired,

rized dealer as soon as possible.

warning light in the instrument cluster

the keys are needed. Make sure to bring all

flashes every two seconds until the system is

the key fobs to an authorized dealer so

† If you lose a key fob, an authorized dealer

disarmed.

that they can be programmed.

will reset the electronic codes of your

remaining key fobs and immobilizer

Disarming

Vehicle Security Alarm System — If

system. Bring all the remaining key fobs to

Equipped

The system is disarmed when the ignition is

an authorized dealer to reset. Starting the

placed in the ON position with the correct

vehicle with a key fob that has not been

If the security alarm system detects an inap-

programmed key fob. The

warning light

reset is not possible.

propriate entry into the vehicle, or the intru-

illuminates for about three seconds and then

sion sensor detects movement in the vehicle,

Operation

turns off. If the engine does not start with the

which could result in the vehicle or its

correct key fob, and the

warning light

contents being stolen, the alarm alerts the

The engine may not start and

warning

remains illuminated or flashing, try the

surrounding area by sounding the siren/horn

light may illuminate or flash if the key fob is

following:

and flashing the hazard warning lights.

placed in an area difficult for the system to

† Make sure the key fob is within the opera-

detect the signal, such as on the instrument

The system will not function unless it is

tional range for signal transmission.

panel. Move the key fob to a location within

properly armed. Follow the arming procedure

the signal range, place the ignition in the

† Place the ignition in the OFF position, and

correctly.

OFF position, and restart the engine.

then restart the engine. If the engine does

not start after three or more tries, contact

an authorized dealer.

24

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Siren/Horn Triggering Conditions

How To Arm The System

† Opening the engine compartment

The siren/horn sounds intermittently, and

1. Close the windows and the convertible top.

† Placing the ignition in the ON position

the hazard warning lights flash for about

2. Place the ignition in the OFF position.

When the doors are locked by pushing the

30 seconds when the system is triggered

lock button on the key fob, or using the emer-

by any one of the following:

3. Make sure the engine compartment,

gency key, the hazard warning lights will

† Unlocking a door with an inside door lock

convertible top, doors, and trunk lid are

flash once to indicate that the vehicle secu-

knob

closed.

rity alarm system is armed.

† Forcing open a door, the engine compart-

4. Push the lock button on the key fob, or

NOTE:

ment, or the trunk lid

lock the driver's door from the outside

† If any door or trunk lid remains closed for

with the emergency key. The hazard

† Opening the hood by operating the hood

30 seconds, the doors, and trunk lid auto-

warning lights will flash once. With The

release handle

matically re-lock, and the vehicle security

Advanced Keyless Entry function: push a

alarm system arms even if a window opens

† Placing the ignition in the ON position

request switch. The

warning light in

or the convertible top is left down.

without starting the engine

the instrument cluster display flashes

twice per second for 20 seconds. After

† To reactivate the intrusion sensor, turn off

† With the intrusion sensor: the intrusion

20 seconds the system is fully armed.

the armed vehicle security alarm system

sensor detects a movement in the vehicle

and then rearm it.

The vehicle security alarm system can also

The system will be triggered again (up to

be armed by activating the auto re-lock func-

† The intrusion sensor is operational when

10 times) if one of the above conditions

tion with all the doors, the trunk lid and the

the vehicle security alarm system is

remains.

engine compartment closed.

armed. To cancel the intrusion sensor,

The trunk lid will not open when the vehicle

push the intrusion sensor cancel button

The system will disarm if one of the following

security alarm system is activated.

each time the vehicle security alarm

operations takes place within

20 seconds

system is armed.

If the battery becomes depleted while the

after pushing the lock button: To rearm the

vehicle security alarm system is armed, the

system, perform the arming procedure again:

siren will activate, and the hazard warning

† Unlocking any door

lights will flash during the battery charging

or replacement process.

† Opening any door

25

-------------------------------------------------------------------------------------------------------------------------------------------------------------

To Turn Off An Armed System

DOORS

Manual Lock/Unlock Knob

An armed system can be turned off using any

Operation From Inside

Lock/Unlock With Emergency Key

one of the following methods:

To lock any door from the inside, push the

† Pushing the unlock button on the key fob.

The doors, trunk lid, and fuel door lock auto-

door lock knob. To unlock, pull it outward.

matically when the driver's door is locked

† Starting the engine with the START/STOP

This does not operate the other door locks.

using the emergency key.

ignition button.

† Lock With Emergency Key: Insert key into

† With The Advanced Keyless Entry function:

driver’s door and turn to the left (toward

pushing a request switch on the exterior

front of car).

door handles.

† Unlock With Emergency Key: Insert key into

NOTE:

driver’s door and turn to the right (toward

When the doors are unlocked by pushing the

back of car).

unlock button on the key fob, the hazard

warning lights will flash twice to indicate

Both doors unlock when the driver's door is

that the system is turned off.

unlocked using the emergency key.

To Stop The Alarm

Interior Door Lock Knob

Turn the emergency key toward the front to

A triggered alarm can be turned off using any

lock, toward the back to unlock.

1 — Door Lock Knob Position (Red Indica-

one of the following methods:

tor Not Seen When Locked)

CAUTION!

† Pushing the unlock button on the key fob.

2 — Door Unlock Knob Position (Red Indi-

An unlocked vehicle is an invitation for

cator Seen When Unlocked)

† Starting the engine with the START/STOP

thieves. Always remove key fob from the

ignition button.

vehicle and lock all doors when leaving the

† With The Advanced Keyless Entry function:

vehicle unattended.

NOTE:

The red indication can be seen when the

pushing a request switch on the exterior

door handles or the electric trunk release

door lock knob is unlocked.

while the key fob is being carried.

The hazard warning lights will flash twice.

26

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operation From Outside

NOTE:

WARNING! (Continued)

To lock the passenger door with the door lock

† The doors, trunk lid, and the fuel filler

† Never leave children alone in a vehicle,

knob from the outside, push the door lock

door cannot be locked while any other door

or with access to an unlocked vehicle.

knob to the lock position and close the door

is open.

Allowing children to be in a vehicle unat-

(holding the door handle in the open position

tended is dangerous for a number of

† The key fob may not be able to be detected

is not required).

reasons. A child or others could be seri-

by the vehicle keyless-go system if it is

NOTE:

ously or fatally injured. Children should

located next to a mobile phone, laptop or

When locking the door this way, be careful

be warned not to touch the parking

other electronic device; these devices may

not to leave the key fob inside the vehicle.

brake, brake pedal or the gear selector.

block the key fob’s wireless signal and

The driver's door lock knob cannot be used

prevent the keyless-go system

from

† Do not leave the key fob in or near the

while the driver's door is open.

starting the vehicle.

vehicle, or in a location accessible to

children, and do not leave the ignition of

WARNING!

a vehicle equipped with Advanced

Keyless Entry in the ACC or ON/RUN

† For personal security and safety in the

positions. A child could operate power

event of a collision, lock the vehicle

windows, other controls, or move the

doors before you drive as well as when

vehicle.

you park and leave the vehicle.

† When leaving the vehicle, always remove

Central Lock/Unlock

the key fob from the vehicle and lock

your vehicle. If equipped with Advanced

The doors, trunk lid, and fuel door lock auto-

Keyless Entry, always make sure the

matically when the lock rocker switch is

Central/Power Door Lock Switch

keyless ignition is in OFF position,

pushed with both doors closed. Both unlock

remove the key fob from the vehicle and

when the unlock rocker switch is pushed.

lock the vehicle. Unsupervised use of

vehicle equipment may cause severe

personal injuries or death.

(Continued)

27

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Double Locking System — If Equipped

Lock/Unlock With Advanced Keyless

Entry Function — If Equipped

The double locking system is designed to

prevent someone who has broken into your

The doors, trunk lid, and fuel filler door can

vehicle from opening the door from the

be locked/unlocked by pushing the request

inside. If you have any problems with the

switch on the exterior door handle while the

double locking system, contact an autho-

key fob is being carried.

rized dealer.

System Activation

Emergency Key Lock Procedure

Proceed as follows:

1.

Close both the windows and the convert-

The system can be activated by pushing the

ible top.

lock button on the key fob twice within three

seconds.

2.

Place the ignition in the OFF position,

and take the key fob with you.

With The Advanced Keyless Function: the

system can be activated by pushing the

3.

Close both doors and trunk lid.

request switch on the exterior door handle

Request Switch On Exterior Door Handle

twice within three seconds.

4.

Insert the emergency key in the driver's

To Lock

door, turn the emergency key to the lock

NOTE:

position

(counter clockwise/left), and

The system cannot be activated when any

To lock the doors, trunk lid, and fuel filler

return it to the center position. Then turn

door is open.

door, push the button on the exterior door

it to the lock position (counter clockwise/

handle; the hazard warning lights will flash

System Deactivation

left) again within three seconds.

once.

Unlock the driver's door, or place the ignition

A beep will sound once.

5.

The

indicator light illuminates for

in the ON position. If the power supply is

about three seconds to indicate that the

interrupted

(fuse blows or the battery is

system has been activated.

disconnected), the system can only be deac-

tivated by unlocking a door with the emer-

gency key.

28

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Function Number

Function (*)

1

The auto door-lock function is disabled.

2

The doors and the fuel filler door lock automatically when the vehicle speed is about 12 mph

(20 km/h) or more.

3

The doors and the fuel filler door lock automatically when the vehicle speed is about 12 mph

(20 km/h) or more. The doors, trunk lid, and fuel filler door unlock when the ignition is cycled from

the ON to OFF position.

4

Automatic Transmission Vehicles Only: when the ignition is placed in the ON position, and the gear

selector is shifted from PARK to any other gear position, the doors, and fuel filler door lock

automatically.

5

Automatic Transmission Vehicles Only: when the ignition is placed in the ON position, and the gear

selector is shifted from PARK to any other gear position, the doors and the fuel filler door lock

automatically. When the dear selector is shifted to PARK while the ignition is placed in the ON

position, the doors and the fuel filler door unlock automatically.

6

Automatic Transmission Vehicles Only: the doors and the fuel filler door lock automatically when the

vehicle speed is about 12 mph (20 km/h) or more. When the gear selector is shifted to PARK while

the ignition is placed in the ON position, the doors and the fuel filler door unlock automatically.

(*) For other settings for the auto door lock function contact an authorized dealer.

NOTE:

Settings Changing

3. Push and hold the lock side of the driver's

Function number 3 is the factory setting for

door-lock switch within

20 seconds of

Settings can be changed using the following

your vehicle.

placing the ignition in the ON position,

procedure:

and make sure a beep is heard about eight

1. Safely park the vehicle. Both doors must

seconds afterwards.

remain closed.

2. Place the ignition in the ON position.

31

Content      ..      1       2         ..

///////////////////////////////////////
