Tesla Model X (2022 year). Manual in english - page 4





Tra…c-Aware Cruise Control
NOTE: Depending on market region, vehicle
detected ahead of you, you can initiate Tra…c-Aware
configuration, options purchased, and software version,
Cruise Control at any speed, even when stationary,
your vehicle may not be equipped with Tra„c-Aware
provided Model X is at least 5 feet (150 cm) behind the
Cruise Control, or the feature may not operate exactly as
detected vehicle and certain vehicle and environmental
described. If your vehicle is not equipped, refer to the
conditions are met.
owner's manual on your vehicle's touchscreen for
instructions on how to use Cruise Control.
NOTE: The maximum cruising speed is 90 mph (150
km/h). It is the driver's responsibility to cruise at a safe
NOTE: Tra…c-Aware Cruise Control is a BETA feature.
speed based on road conditions and speed limits.
Tra…c-Aware Cruise Control determines when there is a
When Tra…c-Aware Cruise Control is
vehicle in front of you in the same lane. If the area in
available but not engaged, the instrument
front of Model X is clear, Tra…c-Aware Cruise Control
panel displays the cruising speed in gray.
maintains a set driving speed. When a vehicle is
The number shown represents the cruising
detected, Tra…c-Aware Cruise Control is designed to
speed that will be set when you engage
slow down Model X as needed to maintain a selected
Tra…c-Aware Cruise Control.
time-based distance from the vehicle in front, up to the
set speed. Tra…c-Aware Cruise Control does not
When Tra…c-Aware Cruise Control is
eliminate the need to watch the road in front of you and
actively cruising at a set cruising speed,
to manually apply the brakes when needed.
the cruising speed is highlighted with blue
text.
Tra…c-Aware Cruise Control is primarily intended for
driving on dry, straight roads, such as highways.
1. Touch Controls > Autopilot > Autosteer Activation
CAUTION: Ensure all cameras and sensors are
and choose Double Click to allow you to use Tra…c-
clean before each drive. Dirty cameras and
Aware Cruise Control independently of Autosteer
sensors, as well as environmental conditions such
when you single press the right scroll wheel.
as rain and faded lane markings, can affect
Autopilot performance.
NOTE: If Autosteer Activation is set to single-click,
pressing the right scroll wheel once also activates
WARNING: Tra…c-Aware Cruise Control is
Autosteer (which includes Tra…c-Aware Cruise
designed for your driving comfort and
Control).
convenience and is not a collision warning or
avoidance system. It is your responsibility to stay
2. You can choose whether Tra…c-Aware Cruise Control
alert, drive safely, and be in control of the vehicle
engages at the currently detected speed limit or your
at all times. Never depend on Tra…c-Aware Cruise
current driving speed. Touch Controls > Autopilot >
Control to adequately slow down Model X. Always
Set Speed and choose either Speed Limit or Current
watch the road in front of you and be prepared to
Speed. If you choose to engage Tra…c-Aware Cruise
take corrective action at all times. Failure to do so
Control at the currently detected speed limit, you can
can result in serious injury or death.
specify an offset. Touch Set Speed Offset. You can
WARNING: Although Tra…c-Aware Cruise Control
choose a Fixed offset, in which the cruising speed
is capable of detecting pedestrians and cyclists,
adjusts by a specific number of mph (km/h) on all
never depend on Tra…c-Aware Cruise Control to
roads, or a Percentage offset, in which the cruising
adequately slow Model X down for them. Always
speed is adjusted as a percentage of the road's
watch the road in front of you and be prepared to
detected speed limit.
take corrective action at all times. Failure to do so
WARNING: When cruising at the speed limit,
can result in serious injury or death.
there may be situations where the cruising
WARNING: Do not use Tra…c-Aware Cruise
speed may not change when the speed limit
Control on winding roads with sharp curves, on icy
changes.
or slippery road surfaces, or when weather
WARNING: Do not rely on Tra…c-Aware Cruise
conditions (such as heavy rain, snow, fog, etc.)
Control or Speed Assist to determine an
make it inappropriate to drive at a consistent
accurate or appropriate cruising speed. It is the
speed. Tra…c-Aware Cruise Control does not
driver's responsibility to cruise at a safe speed
adapt driving speed based on road and driving
based on road conditions and applicable speed
conditions.
limits.
To Use Tra†c-Aware Cruise Control
3. To engage Tra…c-Aware Cruise Control, press the
right scroll wheel.
To initiate Tra…c-Aware Cruise Control when no vehicle
NOTE: If the setting for Autosteer Activation is set to
is detected ahead of you, you must be driving at least
Single Click (touch Controls > Autopilot > Autosteer
18 mph (30 km/h), unless certain vehicle and
Activation), Autosteer engages.
environmental conditions are met, in which case, you
may be able to initiate it at lower speeds. If a vehicle is
Autopilot
101
Tra…c-Aware Cruise Control
4. To change your speed while using Tra…c-Aware
You can manually accelerate at any time when cruising
Cruise Control, you can roll the right scroll wheel on
at a set speed, but when you release the accelerator,
the steering wheel up or down. For more details, see
Tra…c-Aware Cruise Control resumes cruising at the set
Changing the Cruising Speed on page 102.
speed.
5. To cancel Tra…c-Aware Cruise Control, press the right
NOTE: When Tra…c-Aware Cruise Control is actively
scroll wheel, or press the brake pedal. See Canceling
slowing down Model X to maintain the selected distance
and Resuming on page 104 for more information.
from the vehicle ahead, brake lights turn on to alert
other road users that you are slowing down. You may
notice slight movement of the brake pedal. However,
Set Tra†c-Aware Cruise Control
when Tra…c-Aware Cruise Control is accelerating
Chime
Model X, the accelerator pedal does not move.
WARNING: Tra…c-Aware Cruise Control may
If you want a chime to sound when you engage or
occasionally cause Model X to brake when not
cancel Tra…c-Aware Cruise Control, touch Controls >
required or when you are not expecting it. This can
Autopilot > Tra†c-Aware Cruise Control Chime.
be caused by closely following a vehicle ahead,
detecting vehicles or objects in adjacent lanes
NOTE: Model X must be in Park.
(especially on curves), etc.
WARNING: Due to limitations inherent in the
Changing the Cruising Speed
onboard GPS (Global Positioning System), you
may experience situations in which Model X slows
Roll the right scroll wheel up to increase, or down to
down, especially near exits or off-ramps where a
decrease, the set speed. Slowly rolling the scroll wheel
curve is detected and/or you are navigating to a
changes the set speed in 1 mph (1 km/h) increments and
destination and not following the route.
quickly rolling the scroll wheel changes the set speed to
WARNING: Tra…c-Aware Cruise Control may not
the closest 5 mph (5 km/h) increment.
detect all objects and, especially when cruising
over 50 mph (80 km/h), may not brake/decelerate
when a vehicle or object is only partially in the
driving lane or when a vehicle you are following
moves out of your driving path and a stationary or
slow-moving vehicle or object is in front of you.
Always pay attention to the road ahead and stay
prepared to take immediate corrective action.
Depending on Tra…c-Aware Cruise Control to
avoid a collision can result in serious injury or
death. In addition, Tra…c-Aware Cruise Control
may react to vehicles or objects that either do not
exist, or are not in your lane of travel, causing
Model X to slow down unnecessarily or
inappropriately.
NOTE: It may take a few seconds for Model X to reach
WARNING: Tra…c-Aware Cruise Control may be
the new cruising speed, assuming Model X is not
unable to provide adequate speed control because
cruising behind a vehicle that is driving slower than your
of limited braking capability and hills. It can also
set speed.
misjudge the distance from a vehicle ahead.
Driving downhill can increase driving speed,
causing Model X to exceed your set speed (and
Cruising at the Set Speed
potentially the road's speed limit). Never depend
on Tra…c-Aware Cruise Control to slow down
Tra…c-Aware Cruise Control maintains your set cruising
Model X enough to prevent a collision. Always
speed whenever a vehicle is not detected in front of
keep your eyes on the road when driving and be
Model X. When cruising behind a detected vehicle,
prepared to take corrective action as needed.
Tra…c-Aware Cruise Control accelerates and decelerates
Depending on Tra…c-Aware Cruise Control to
Model X as needed to maintain a chosen following
reduce your driving speed enough to prevent a
distance (see Adjust the Following Distance on page
collision can result in serious injury or death.
103), up to the set speed.
Tra…c-Aware Cruise Control also adjusts the cruising
speed when entering and exiting curves.
102
Tra…c-Aware Cruise Control
based on the new location. For example, if you merged
HOLD State
onto a different highway, the set cruising speed reverts
back to what it was before driving on the interchange.
When following a vehicle, Tra…c-Aware Cruise Control
remains active at low speeds, even when Model X comes
WARNING: In some cases (such as having
to a full stop. When the vehicle is moving again, Tra…c-
insu…cient data), Tra…c-Aware Cruise Control may
Aware Cruise Control resumes operating at the set
not automatically reduce the set speed on the
speed. However, under the following circumstances,
highway interchange or off-ramp. Do not rely on
Tra…c-Aware Cruise Control goes into a HOLD state, in
Tra…c-Aware Cruise Control to determine an
which case, you need to briefly press the accelerator
appropriate driving speed. Tesla recommends
pedal to resume cruising. When the HOLD status is
driving at a speed that is safe for road conditions
active, the instrument panel displays the HOLD icon and
and within posted speed limits.
a message that indicates that you need to resume cruise
control. The following circumstances can cause Tra…c-
Aware Cruise Control to go into the HOLD state:
Adjust the Following Distance
• Model X has been at a standstill for 5 minutes.
To adjust the following distance you want to maintain
between Model X and a vehicle traveling ahead of you,
• Model X detects a pedestrian (the HOLD state may
touch Controls > Autopilot > Cruise Follow Distance and
clear when the pedestrian is no longer detected).
choose a setting from 1 (the closest following distance)
• Model X suddenly loses visibility of the vehicle in
to 7 (the longest following distance). Each setting
front of you.
corresponds to a time-based distance that represents
how long it takes for Model X, from its current location,
• An obstacle is detected in front of Model X.
to reach the location of the rear bumper of the vehicle
ahead of you.
Cruising Near or On Exits
NOTE: Your setting is retained until you manually
change it.
When cruising near an exit on a controlled-access
highway and engaging the turn signal toward the off-
NOTE: For vehicles manufactured after approximately
ramp, Tra…c-Aware Cruise Control assumes you are
February 13, 2022, the closest following distance(s) may
exiting and begins to slow down Model X. If you do not
be unavailable.
drive onto the off-ramp, Tra…c-Aware Cruise Control
WARNING: It is the driver's responsibility to
resumes cruising at the set speed. In a region with right
determine and maintain a safe following distance
hand tra…c, this occurs only when you engage the right
at all times. Do not rely on Tra…c-Aware Cruise
turn signal when driving in the right-most lane within
Control to maintain an accurate or appropriate
164 feet (50 meters) of an exit. Likewise in regions with
following distance.
left hand tra…c; when engaging the left turn signal when
driving in the left-most lane within 164 feet (50 meters)
WARNING: Never depend on Tra…c-Aware Cruise
of an exit.
Control to adequately slow down Model X to avoid
a collision. Always watch the road in front of you
When cruising onto an on-ramp to a controlled-access
and stay prepared to take immediate corrective
highway, Tra…c-Aware Cruise Control automatically
action.
adjusts the set cruising speed to the speed limit of the
highway, plus any offset you have specified.
Overtake Acceleration
NOTE: The on-board Global Positioning System (GPS)
When following a vehicle with Tra…c-Aware Cruise
determines if you are driving in a region with right or left
Control active, engaging the turn signal (to indicate a
hand tra…c. In situations where GPS data is unavailable
move into the passing lane) accelerates Model X towards
(for example, if there is inadequate signal), engaging the
the vehicle ahead. By momentarily holding the turn
turn signal near an exit does not cause Tra…c-Aware
signal, you can quickly accelerate up to your set speed
Cruise Control to slow down Model X.
without having to press the accelerator pedal. The turn
When enabled while on a highway interchange or off-
signal causes acceleration only when all of the following
conditions are met:
ramp, Tra…c-Aware Cruise Control may reduce your set
speed in 5 mph (5 km/h) increments - to as slow as
25 mph (40 km/h) - to better match the reported
• Tra…c-Aware Cruise Control is operating and detects
speeds of other Tesla vehicles that have driven at that
a vehicle in front of you.
specific location. To override this and continue cruising
• No obstacles or vehicles are detected in the target
at your set speed, tap the accelerator pedal. The new set
lane.
speed is maintained for the duration of the interchange
or off-ramp (unless you override it or cancel Tra…c-
• Model X is traveling below the set speed, but over
45 mph (72 km/h).
Aware Cruise Control). After the interchange or off-
ramp, the set speed may revert or change as necessary
Autopilot
103
Tra…c-Aware Cruise Control
Overtake Acceleration is intended as an aid when
• A door is opened.
passing a vehicle ahead of you. When the turn signal is
• A camera or sensor is obstructed. This could be
engaged, Tra…c-Aware Cruise Control continues to
caused by dirt, mud, ice, snow, fog, etc.
maintain distance from the vehicle ahead, but allows you
to drive slightly closer than your selected distance.
• The traction control setting is manually disabled or is
repeatedly engaging to prevent wheels from slipping.
Acceleration cancels when one of the conditions
• The wheels are spinning while at a standstill.
happen:
• The Tra…c-Aware Cruise Control system is failing or
• You reach your set cruising speed.
requires service.
• Changing lanes takes too long.
When Tra…c-Aware Cruise Control is unavailable or
• Model X gets too close to the vehicle ahead.
cancels, Model X no longer drives consistently at a set
speed and no longer maintains a specified distance from
OR
the vehicle ahead.
• You disengage the turn signal.
WARNING: Tra…c-Aware Cruise Control can cancel
unexpectedly at any time for unforeseen reasons.
Always watch the road in front of you and stay
NOTE: Overtake Acceleration occurs when you fully
prepared to take appropriate action. It is the
press and hold the turn signal. When you release the
driver's responsibility to be in control of Model X at
turn signal, Model X stops accelerating (in the same way
all times.
as when you release the accelerator pedal) and resumes
the set speed.
Summary of Cruise Indicators
WARNING: Overtake Acceleration can cancel for
many unforeseen reasons in addition to those
listed above (for example, lack of GPS data). Stay
Tra…c-Aware Cruise Control is available
alert and never depend on Overtake Acceleration
but is not actively controlling your speed
to increase your driving speed.
until you activate it. The number shown in
gray is the cruising speed that will be set
WARNING: Overtake Acceleration increases your
when you engage Tra…c-Aware Cruise
driving speed whenever the appropriate turn
Control.
signal is engaged, and accelerates Model X closer
to the vehicle ahead. Although Tra…c-Aware
Tra…c-Aware Cruise Control is actively
Cruise Control continues to maintain distance from
cruising and is either maintaining the set
the vehicle ahead, it is important to be aware that
speed (no vehicle in front) or is
your selected following distance is reduced when
maintaining a chosen following distance
Overtake Acceleration is active, particularly in
from a vehicle ahead (up to the set speed).
cases where it may not be your intention to
overtake the vehicle you are following.
Model X has fully stopped but is in a HOLD
state. If safe, press the accelerator pedal to
resume cruising at the set speed.
Canceling and Resuming
To manually cancel Tra…c-Aware Cruise Control, press
the brake pedal or press the right scroll wheel on the
steering yoke.
Limitations
To resume cruising, press the right scroll button.
Tra…c-Aware Cruise Control is particularly unlikely to
operate as intended in the following types of situations:
NOTE: When Tra…c-Aware Cruise Control cancels,
Model X does not coast. Instead, regenerative braking
• The road has sharp curves.
slows down Model X in the same way as when you move
your foot off the accelerator when driving without
• Visibility is poor (due to heavy rain, snow, fog, etc.).
Tra…c-Aware Cruise Control (see Regenerative Braking
• Bright light (such as from oncoming headlights or
on page 75).
direct sunlight) is interfering with the view of the
WARNING: Tra…c-Aware Cruise Control cancels,
camera(s).
or may not be available, in the following situations:
• A camera or sensor is obstructed (fogged over, dirty,
covered by a sticker, etc.).
• You press the brake pedal.
• Your driving speed exceeds the maximum cruising
WARNING: The list above does not represent an
speed of 90 mph (150 km/h).
exhaustive list of situations that may interfere with
• You shift Model X.
proper operation of Tra…c-Aware Cruise Control.
104
Autosteer
NOTE: Depending on market region, vehicle
To indicate that Autosteer is now actively
configuration, options purchased, and software version,
steering Model X, the instrument panel
your vehicle may not be equipped with Autosteer, or the
displays the Autosteer icon in blue. When
feature may not operate exactly as described.
Autosteer is able to detect lane markings,
NOTE: Autosteer is a BETA feature.
it also displays the driving lane in blue.
Autosteer builds upon Tra…c-Aware Cruise Control (see
Autosteer briefly displays a message on the instrument
Tra…c-Aware Cruise Control on page 101), intelligently
panel reminding you to pay attention to the road and be
keeping Model X in its driving lane when cruising at a set
ready to take over at any time.
speed. Autosteer also allows you to use the turn signals
to move Model X into an adjacent lane (see Auto Lane
The speed at which you can initiate Autosteer can vary
Change on page 107). Autosteer detects lane markings
depending on various conditions and whether or not a
and the presence of vehicles and objects to steer
vehicle is detected ahead of you. When no vehicle is
Model X.
detected ahead of you, you must be driving at least
18 mph (30 km/h), unless certain vehicle and
NOTE: To display more details about the roadway and its
environmental conditions are met, in which case, you
surroundings, such as road markings, stop lights, objects
may be able to initiate it at lower speeds. When a
(such as trash cans and poles), etc., touch Controls >
vehicle is detected ahead of you, you can initiate
Autopilot > Full Self-Driving Visualization Preview (if
Autosteer at any speed, even when stationary, provided
equipped).
Model X is at least 5 feet (150 cm) behind the detected
CAUTION: Ensure all cameras and sensors are
vehicle.
clean. Dirty cameras and sensors, as well as
NOTE: The maximum cruising speed is 90 mph (150
environmental conditions such as rain and faded
km/h). It is the driver's responsibility to cruise at a safe
lane markings, affect performance.
speed based on road conditions and speed limits.
WARNING: Autosteer is a hands-on feature. You
NOTE: Auto High Beam is automatically enabled when
must keep your hands on the steering yoke at all
Autosteer is engaged and the maximum cruising speed
times.
may be limited to a lower speed for vehicles
WARNING: Autosteer is intended for use on
manufactured after approximately February 13, 2022.
controlled-access highways with a fully attentive
driver. When using Autosteer, hold the steering
CAUTION: If available in your market region,
Model X detects lights from an emergency vehicle
yoke and be mindful of road conditions and
when using Autosteer at night on a high speed
surrounding tra…c. Do not use Autosteer in
road, the driving speed is automatically reduced
construction zones, or in areas where bicyclists or
and the instrument panel displays a message
pedestrians may be present. Never depend on
Autosteer to determine an appropriate driving
informing you of the slowdown. You will also hear
a chime and see a reminder to keep your hands on
path. Always be prepared to take immediate
the steering yoke. When the light detections pass
action. Failure to follow these instructions could
by or cease to appear, Autopilot resumes your
cause damage, serious injury or death.
cruising speed. Alternatively, you may tap the
accelerator to resume your cruising speed.
Operating Autosteer
WARNING: Never depend on Autopilot features to
determine the presence of emergency vehicles.
Before you can operate Autosteer, you must enable it by
Model X may not detect lights from emergency
touching Controls > Autopilot > Autosteer (Beta).
vehicles in all situations. Keep your eyes on your
driving path and always be prepared to take
To indicate that Autosteer is available (but
immediate action.
not actively steering Model X), the
instrument panel displays a gray Autosteer
In situations where Autosteer is temporarily unavailable,
icon.
the Autosteer icon disappears. For example, your driving
speed is not within the speed required for Autosteer to
operate. Autosteer may also be unavailable if it is not
To initiate Autosteer, press the right scroll wheel.
receiving adequate data from the camera(s).
NOTE: If the setting for Autosteer Activation is set to
Single Click (touch Controls > Autopilot > Autosteer
If unable to detect lane markings, Autosteer may
Activation), Autosteer engages when you single-press
determine the driving lane based on a vehicle you are
the right scroll wheel. If set to Double Click, you must
following.
double-press the right scroll wheel to engage Autosteer.
In most cases, Autosteer attempts to center Model X in
the driving lane. However, there may be situations in
which Autosteer may steer Model X in a driving path
that is offset from the center of the lane (for example,
detection of guard rails).
Autopilot
105
Autosteer
WARNING: Autosteer is not designed to, and will
Autosteer requires that you pay attention to your
not, steer Model X around objects partially in a
surroundings and remain prepared to take control at any
driving lane and in some cases, may not stop for
time. If Autosteer still does not detect your hands on the
objects that are completely blocking the driving
steering yoke, the flashing light on the instrument panel
lane. Always watch the road in front of you and
increases in frequency and a chime sounds.
stay prepared to take immediate action. It is the
driver's responsibility to be in control of Model X at
If you repeatedly ignore Autosteer's prompts to apply
all times.
slight force to the steering yoke, Autosteer disables for
the rest of the drive and displays the following message
requesting you to drive manually. If you don't resume
Restricted Speed
manual steering, Autosteer sounds a continuous chime,
turns on the warning flashers, and slows the vehicle to a
On a controlled-access highway, the cruising speed
complete stop.
reflects the speed limit, taking into consideration any
offset you've specified using Speed Assist. However, if
Autosteer unavailable for the rest of this
you choose to use Autosteer on residential roads, a road
drive. Hold steering yoke to drive
without a center divider, or a road where access is not
manually.
limited, Autosteer may limit the maximum allowed
cruising speed and the instrument panel displays a
message indicating that speed is restricted. The
restricted speed will be the speed limit of the road plus
For the rest of the drive, you must steer manually.
5 mph (10 km/h).
Autosteer is available again on your next drive (after you
In situations where the speed limit cannot be detected
stop and shift Model X into Park).
when Autosteer is engaged, Autosteer reduces your
driving speed and limits the set cruising speed to 45
Take Over Immediately
mph (70 km/h). Although you can manually accelerate
to exceed the limited speed, Model X may not brake for
In situations where Autosteer is unable to steer Model X,
detected obstacles. Autosteer slows down to the limited
Autosteer sounds a warning chime and displays the
speed when you release the accelerator pedal. When
following message on the instrument panel:
you leave the road, or disengage Autosteer by using the
steering yoke, you can increase your set speed again, if
desired.
Take over immediately
Hold Steering Yoke
Autosteer determines how best to steer Model X. When
active, Autosteer requires you to hold the steering yoke.
When you see this message, TAKE OVER STEERING
If it does not detect your hands on the steering yoke for
IMMEDIATELY.
a period of time, a flashing light appears along the top
of the instrument panel and the following message
displays:
Canceling Autosteer
Apply slight turning force to steering yoke
Autosteer cancels when:
• You press the brake pedal.
• You start steering manually.
• You exceed the maximum speed at which Autosteer
operates - 90 mph (150 km/h).
Autosteer detects your hands by recognizing slight
resistance as the steering yoke turns, or from you
• You shift.
manually turning the steering yoke very lightly (without
• A door is opened.
enough force to take over steering). Autosteer also
qualifies your hands as being detected if you engage a
• An Automatic Emergency Braking event occurs (see
turn signal or use a button or scroll wheel on the
Collision Avoidance Assist on page 131).
steering yoke.
When Autosteer cancels, it sounds a chime and the
NOTE: When your hands are detected, the message
Autosteer icon either turns gray to indicate that
disappears and Autosteer resumes normal operation.
Autosteer is no longer active, or disappears to indicate
that it is not currently available.
106
Autosteer
NOTE: If Autosteer Activation is set to Double Click and
3. If needed, cancel the turn signal once you are in the
Autosteer cancels because you started steering
target lane.
manually, Tra…c-Aware Cruise Control remains active. If
Autosteer Activation is set to Single Click and Autosteer
NOTE: The minimum speed at which Auto Lane Change
cancels because you started steering manually, Tra…c-
operates may vary depending on region, adjacent lane
Aware Cruise Control also cancels.
speeds, and other factors. Always be ready to manually
steer and change lanes as necessary.
To disable Autosteer so it is no longer available, touch
Controls > Autopilot > Autosteer (Beta).
Auto Lane Change moves Model X into the adjacent lane
in the direction indicated by the turn signal, provided
Auto Lane Change
the following conditions are met:
NOTE: Depending on market region, vehicle
• The turn signal is engaged.
configuration, options purchased, and software version,
• Model X does not detect a vehicle in its blind spot, or
your vehicle may not be equipped with Auto Lane
a vehicle or obstacle up to the center of the target
Change, or the feature may not operate exactly as
lane.
described.
• Lane markings indicate that a lane change is
When Autosteer is active, engage a turn signal to move
permitted.
Model X into an adjacent lane (moving the steering yoke
• Midway through the lane change, Model X must
would cancel Autosteer).
detect the target lane's outside lane marking. If this
lane marking is not detected, the lane change is
WARNING: It is the driver's responsibility to
aborted and Model X returns to its original driving
determine whether a lane change is safe and
lane.
appropriate. Therefore, before initiating a lane
change, always check blind spots, lane markings,
• The view of the camera(s) is not obstructed.
and the surrounding roadway to confirm it is safe
and appropriate to move into the target lane.
When an automatic lane change is in progress, Overtake
Acceleration is activated, allowing Model X to accelerate
WARNING: Never depend on Auto Lane Change to
closer to a vehicle in front (see Overtake Acceleration on
determine an appropriate driving path. Drive
page 103).
attentively by watching the road and tra…c ahead
of you, checking the surrounding area, and
NOTE: Auto Lane Change moves Model X one lane at a
monitoring the instrument panel for warnings.
time. Moving into an additional lane requires you to
Always be prepared to take immediate action.
engage the turn signal a second time after the first lane
WARNING: Do not use Auto Lane Change on roads
change is complete.
where tra…c conditions are constantly changing
and where bicycles and pedestrians are present.
When using Auto Lane Change, it is important to
monitor its performance by watching the driving path in
WARNING: The performance of Auto Lane Change
front of you and the surrounding area. Stay prepared to
depends on the ability of the camera(s) to
take over steering at any time. As you are crossing over
recognize lane markings.
into the adjacent lane, the instrument panel displays the
WARNING: Do not use Auto Lane Change on
location in the lane that Model X is moving into.
winding roads with sharp curves, on icy or slippery
roads, or when weather conditions (such as heavy
In situations where Auto Lane Change is unable to
rain, snow, fog, etc.) may be obstructing the view
operate at optimal performance, or cannot operate due
from the camera(s) or sensors.
to inadequate data, the instrument panel displays a
series of warnings. Therefore, when using Auto Lane
WARNING: Failure to follow all warnings and
Change, always pay attention to the instrument panel
instructions can result in property damage, serious
and be prepared to manually steer Model X.
injury or death.
Adjacent Lane Speed
Operating Auto Lane Change
NOTE: Depending on market region, vehicle
Auto Lane Change is available whenever Autosteer is
configuration, options purchased, and software version,
active. To change lanes using Auto Lane Change:
your vehicle may not be equipped with Adjacent Lane
Speed, or the feature may not operate exactly as
1. Perform visual checks to make sure it is safe and
described.
appropriate to move into the target lane.
2. Engage the appropriate turn signal, keeping your
hands on the steering yoke.
Autopilot
107
Autosteer
When moving significantly faster than vehicles in
WARNING: The Stop Light and Stop Sign Warning
adjacent lanes, Model X automatically reduces the
feature does not apply the brakes or decelerate
driving speed. This is especially helpful in heavy tra…c
Model X and may not detect all stop lights and
situations or when vehicles are constantly merging into
stop signs. Stop Light and Stop Sign Warning is
different lanes. When Model X detects other vehicles
designed for guidance purposes only and is not a
driving significantly slower, the instrument panel
substitute for attentive driving and sound
highlights the adjacent lanes with arrows and detected
judgment. Keep your eyes on the road when
vehicles in gray, and Model X reduces the driving speed
driving and never depend on Stop Light and Stop
as appropriate. To temporarily override this feature,
Sign Warning to warn you of a stop light or stop
press the accelerator pedal.
sign.
WARNING: Stop Light and Stop Sign Warning is
WARNING: Never depend on Autopilot to
designed to warn you only when approaching a
determine a safe driving speed; you are
visible red stop sign, solid red or later portion of a
responsible for driving safely and according to
yellow tra…c light. It may not warn you of
tra…c laws in your market region.
intersections with flashing lights and it does not
warn you of yield signs or temporary stop and
Stop Light and Stop Sign Warning
yield signs (such as those used in construction
areas). Additionally, Stop Light and Stop Sign
NOTE: Depending on market region, vehicle
Warning does not warn you of approaching stop
configuration, options purchased, and software version,
lights or stop signs when you are pressing the
your vehicle may not be equipped with Stop Light and
accelerator pedal or brake pedal (which disables
Stop Sign Warning, or the feature may not operate
Autosteer).
exactly as described.
Limitations
While Autosteer is in use, Model X displays a warning on
the instrument panel and sounds a chime if it detects
Autosteer and its associated functions are particularly
that you are likely to run through a red stop light or stop
unlikely to operate as intended when:
sign. If this happens, TAKE IMMEDIATE CORRECTIVE
ACTION!
• Autosteer is unable to accurately determine lane
The visual and audible warnings cancel after a few
markings. For example, lane markings are excessively
seconds, or when you press the brake pedal, whichever
worn, have visible previous markings, have been
adjusted due to road construction, are changing
comes first.
quickly (lanes branching off, crossing over, or
Stop Light and Stop Sign Warning provides warnings
merging), objects or landscape features are casting
only. It does not slow down or stop Model X at red tra…c
strong shadows on the lane markings, or the road
lights, stop signs, road markings, etc. If equipped with
surface contains pavement seams or other high-
Tra…c Light and Stop Sign Control, you can enable this
contrast lines.
feature to automatically stop Model X at tra…c lights
• Visibility is poor (heavy rain, snow, fog, etc.) or
and stop signs (see Tra…c Light and Stop Sign Control
weather conditions are interfering with sensor
on page 113).
operation.
NOTE: Touch Controls > Autopilot > Full Self-Driving
• A camera(s) or sensor(s) is obstructed, covered, or
Visualization Preview (if equipped) to display more
damaged.
details about the roadway and its surroundings, such as
• Driving on hills.
road markings, stop lights, objects (such as trash cans
and poles), etc.
• Approaching a toll booth.
CAUTION: Stop Light and Stop Sign Warning
• Driving on a road that has sharp curves or is
requires on-board maps to know that a particular
excessively rough.
stop light or stop sign exists at a location. In some
• Bright light (such as direct sunlight) is interfering
cases, map data is inaccurate or outdated and may
with the view of the camera(s).
not include all stop lights or stop signs. Therefore,
• The sensors are affected by other electrical
Stop Light and Stop Sign Warning may not detect
equipment or devices that generate ultrasonic waves.
all stop lights and stop signs.
• A vehicle is detected in your blind spot when you
engage the turn signal.
• Model X is being driven very close to a vehicle in
front of it, which is blocking the view of the
camera(s).
108
Autosteer
WARNING: Many unforeseen circumstances can
impair the operation of Autosteer. Always keep this
in mind and remember that as a result, Autosteer
may not steer Model X appropriately. Always drive
attentively and be prepared to take immediate
action.
Autopilot
109
Navigate on Autopilot
NOTE: Depending on market region, vehicle
change lanes to achieve the set cruising speed. The
configuration, options purchased, and software version,
Mild setting is more conservative about lane changes
your vehicle may not be equipped with Navigate on
and may result in a slightly longer driving time
Autopilot, or the feature may not operate exactly as
whereas Mad Max is designed to allow you to reach
described.
your destination in the shortest driving time possible,
but changes lanes only when safe to do so.
NOTE: Navigate on Autopilot is a BETA feature.
Exit Passing Lane: Choose whether you want
When using Autosteer on a controlled-access highway
Navigate on Autopilot to maneuver out of a passing
(a main highway on which road users enter and exit
lane when navigating to a destination.
using on-ramps and off-ramps). Navigate on Autopilot
NOTE: In addition to route-based and speed-based
guides Model X to off-ramps and interchanges based on
lane changes, Navigate on Autopilot requests a lane
your navigation route. Along the highway portion of a
change out of a passing lane as a reminder to stay in
navigation route, Navigate on Autopilot also changes
a slower lane when you are not passing other
lanes to prepare for exits (route-based lane changes)
vehicles. Choose NO to disable this and keep Model X
and to minimize the driving time to your destination
in a passing lane except when needed to stay on the
(speed-based lane changes).
navigation route.
WARNING: Navigate on Autopilot does not make
Require Lane Change Confirmation (if equipped): By
driving autonomous. You must pay attention to the
default, Navigate on Autopilot requires your
road, keep your hands on the steering yoke at all
confirmation before proceeding with a lane change
times, and remain aware of your navigation route.
by pressing the appropriate turn signal. However, if
WARNING: As is the case with normal driving, be
you want Navigate on Autopilot to change lanes
extra careful around blind corners, interchanges,
without requiring this confirmation, turn this setting
and on-ramps and off-ramps - obstacles can
off. When you turn the setting off, you can specify if
appear quickly and at any time.
or how you want to be notified of lane changes (Off,
Chime, Vibrate, or Both).
WARNING: Navigate on Autopilot may not
recognize or detect oncoming vehicles, stationary
WARNING: If you turn off Require Lane Change
objects, and special-use lanes such as those used
Confirmation, Navigate on Autopilot notifies
exclusively for bikes, carpools, emergency vehicles,
you of upcoming lane changes and off-ramps,
etc. Remain alert at all times and be prepared to
but it remains your responsibility to monitor the
take immediate action. Failure to do so can cause
environment and maintain control of Model X at
damage, injury or death.
all times. Lane changes can occur quickly and
suddenly. Always keep your hands on the wheel
and your eyes on the driving path in front of
Enabling and Customizing Navigate
you.
on Autopilot
NOTE: The touchscreen displays route-based lane
To enable Navigate on Autopilot, touch Controls >
changes at the top of the map's turn-by-turn direction
Autopilot > Navigate on Autopilot (Beta). Then, to
list to notify you that an upcoming lane change is
customize how you want Navigate on Autopilot to
needed to stay on the navigation route.
operate, touch Customize Navigate on Autopilot:
Enable At Start Of Every Trip: Choose whether or not
Operating Navigate on Autopilot
you want to automatically enable Navigate on
Autopilot for every navigation route. When enabled,
Once enabled, the Navigate on Autopilot button appears
the Navigate on Autopilot button on the turn-by-turn
on the map’s turn-by-turn direction list whenever a
direction list is already enabled at the start of every
navigation route is active and the route includes at least
trip.
one controlled-access highway. When enabled, the
Navigate on Autopilot button is blue and the turn-by-
Speed Based Lane Changes: Navigate on Autopilot is
turn direction displays the Autosteer icon next to the
designed to perform both route-based and speed-
maneuvers (such as off-ramps) that Navigate on
based lane changes. Route-based lane changes are
Autopilot will handle.
designed to keep you on your navigation route (for
example, moving you into an adjacent lane to prepare
NOTE: If Enable At Start Of Every Trip is turned off, you
for an upcoming off-ramp) whereas speed-based
must touch the Navigate on Autopilot button to enable
lane changes are designed to maintain a driving
it for each navigation route.
speed (not to exceed your cruising speed) that allows
you to minimize the time it takes to reach your
destination (for example, moving into an adjacent
lane to pass a vehicle in front of you). Speed-based
lanes changes are optional. You can use this setting
to disable speed-based lane changes or to specify
how aggressively you want Navigate on Autopilot to
110
Navigate on Autopilot
Navigate on Autopilot activates and deactivates as
WARNING: Navigate on Autopilot may not always
appropriate, based on the type of road you are driving
attempt to exit at an off-ramp or change lanes,
on. For example, if Autosteer is active and Navigate on
even when an exit or lane change is determined by
Autopilot is enabled, Navigate on Autopilot
the navigation route. Always remain alert and be
automatically becomes active when you reach a
prepared to manually steer onto an off-ramp, or
controlled-access highway on your navigation route.
make a lane change to prepare for, or to exit at, an
off-ramp or interchange.
Whenever Navigate on Autopilot is active, the
instrument panel displays the driving lane as a single
You can cancel Navigate on Autopilot at any time by
blue line in front of Model X:
touching Navigate on Autopilot on the map’s turn-by-
turn direction list (Model X reverts back to Autosteer), or
by canceling Autosteer entirely (see Canceling
Autosteer on page 106).
Lane Changes
Navigate on Autopilot changes lanes to either prepare
Model X for an upcoming off-ramp, to increase your
driving speed (not to exceed your set cruising speed), or
to move Model X out of a passing lane when you are not
actively passing other road users. A message displays at
the top of the map's turn-by-turn direction list to notify
you when an upcoming lane change is required to stay
on your navigation route. The instrument panel displays
the upcoming driving path:
When Navigate on Autopilot is active and you approach
an off-ramp or interchange along your navigation route,
the appropriate turn signal engages and Autosteer
maneuvers Model X onto the off-ramp or interchange.
WARNING: Never depend on Navigate on
Autopilot to determine an appropriate lane at an
off-ramp. Stay alert and perform visual checks to
ensure that the driving lane is safe and
appropriate.
When you leave a controlled-access highway (for
If Require Lane Change Confirmation is turned off,
example, you take an exit or you enter a section of the
Navigate on Autopilot engages the appropriate turn
navigation route that is no longer supported), Navigate
signal, checks for vehicles and objects, and when
on Autopilot reverts back to Autosteer— a chime sounds
appropriate, maneuvers Model X into the adjacent lane.
and the instrument panel displays the driving lane lines
in blue (instead of the single blue in front of Model X).
If Require Lane Change Confirmation is turned on, you
must engage the appropriate turn signal to confirm that
NOTE: When determining navigation routes, and
you want Navigate on Autopilot to proceed with the
maneuvers at interchanges, Navigate on Autopilot
lane change. If you do not confirm the lane change
considers whether or not you want to use High
within three seconds, a chime sounds to remind you that
Occupancy Vehicle (HOV) lanes. Therefore, ensure the
Navigate on Autopilot requires your confirmation to
Use HOV Lanes setting is appropriate for your
change lanes.
circumstances (see Maps and Navigation on page 148).
If the setting is off, Navigate on Autopilot never uses a
NOTE: If you ignore a route-based lane change
HOV lane, regardless of time of day. If the setting is on,
suggestion (for example, you are driving in the left lane
Navigate on Autopilot uses HOV lanes, whenever
while approaching an off-ramp on the right side of the
applicable.
highway), Navigate on Autopilot is unable to maneuver
onto the off-ramp and as a result, you are re-routed to
WARNING: When Navigate on Autopilot
your destination.
deactivates, Autosteer remains active. Always be
prepared to take appropriate action.
Autopilot
111
Navigate on Autopilot
WARNING: Navigate on Autopilot may not always
attempt to exit at an off-ramp or change lanes,
even when an exit or lane change is determined by
the navigation route. Always remain alert and be
prepared to manually steer onto an off-ramp, or
make a lane change to prepare for, or to exit at, an
off-ramp or interchange.
Be Ready to Assist
When attempting to change lanes or maneuver Model X,
or when approaching construction zones, Navigate on
Autopilot may be unable to determine the appropriate
driving lane (for example, complex clover leafs and
multi-lane off-ramps) and the instrument panel displays
an alert indicating that Navigate on Autopilot is trying to
maneuver and may require assistance. When you see the
message, be prepared to take immediate action to
ensure that it is safe and appropriate to complete the
lane change or maneuver.
112
Tra…c Light and Stop Sign Control
NOTE: Depending on market region, vehicle
• Enable the feature. With the vehicle in Park, touch
configuration, options purchased, and software version,
Controls > Autopilot > Tra†c Light and Stop Sign
your vehicle may not be equipped with Tra„c Light and
Control. Once enabled, Tra…c Light and Stop Sign
Stop Sign Control, or the feature may not operate
Control operates whenever Tra…c-Aware Cruise
exactly as described.
Control or Autosteer is active.
NOTE: Traffic Light and Stop Sign Control is a BETA
feature and works best on roads that are frequently
How it Works
driven by Tesla vehicles. Traffic Light and Stop Sign
Control attempts to stop at all traffic lights and may
When Tra…c Light and Stop Sign Control is enabled and
also stop at green lights.
you are using Autosteer or Tra…c-Aware Cruise Control,
the instrument panel displays a popup message to
Tra…c Light and Stop Sign Control is designed to
recognize and respond to tra…c lights and stop signs,
inform you that an upcoming tra…c light, stop sign, or
slowing Model X to a stop when using Tra…c-Aware
road marking has been detected. As it approaches the
cruise control or Autosteer. This feature uses the
stop location, even at an intersection where the tra†c
light is green, Model X slows down and displays a red
vehicle's forward-facing cameras, in addition to GPS
line to indicate where Model X will stop. To continue
data, and slows the car for all detected tra…c lights,
including green, blinking yellow, and off lights in addition
through the intersection—even if the tra…c light is green
to stop signs and some road markings. As Model X
—you must briefly press the accelerator pedal to give
approaches an intersection, the instrument panel
the vehicle permission to proceed. When you've
confirmed that you want to proceed, the red stop line
displays a notification indicating the intention to slow
turns gray and Model X continues through the
down. You must confirm that you want to continue or
Model X stops at the red line displayed on the
intersection and resumes your set cruising speed.
instrument panel's driving visualization.
NOTE: If Model X is approaching a green light and
WARNING: NEVER make assumptions and predict
detects that a vehicle in front of you is continuing
when and where Tra…c Light and Stop Sign
through the intersection, Model X continues through the
intersection without requiring your confirmation,
Control will stop or continue through an
provided you are not in a turning lane and your hands
intersection or road marking. From a driver's
perspective, the behavior of Tra…c Light and Stop
are detected on the steering yoke.
Sign Control may appear inconsistent. Always pay
NOTE: If, after you briefly press the accelerator pedal to
attention to the roadway and be prepared to take
confirm that you want to continue through the
immediate action. It is the driver's responsibility to
intersection, the tra…c signal changes before you enter
determine whether to stop or continue through an
the intersection (for example, the light changes from
intersection. Never depend on Tra…c Light and
green to yellow or from yellow to red), Model X may
Stop Sign Control to determine when it is safe
determine that it is not appropriate to proceed.
and/or appropriate to stop or continue through an
Therefore, Model X stops and you must press the
intersection.
accelerator to proceed. At all times, it is your
responsibility to ensure the vehicle stops or accelerates
appropriately and safely.
Before Using
WARNING: Tra…c Light and Stop Sign Control
Before using Tra…c Light and Stop Sign Control, you
DOES NOT turn Model X through an intersection.
must:
When in a turning lane, Model X stops at the red
stop line. To proceed, briefly press the accelerator
• Ensure that forward-facing cameras are unobstructed
pedal—Model X continues straight through the
(see Cleaning Cameras and Sensors on page 100)
intersection (even when in a turning lane), so you
and calibrated (see Drive to Calibrate Cameras on
MUST manually steer Model X through the
page 99). Tra…c Light and Stop Sign Control
intersection (which cancels Autosteer).
depends on the ability of the cameras to detect
tra…c lights, stop signs, and road markings.
Tra…c Light and Stop Sign Control is designed to
operate as described only when the following conditions
• Ensure that the latest version of maps has been
are met:
downloaded to Model X. Although Tra…c Light and
Stop Sign Control primarily uses visual data received
• Autosteer or Tra…c-Aware Cruise Control is engaged.
from the vehicle's cameras, greater accuracy is
achieved when using the most recent map data. To
• The cameras can detect an upcoming tra…c light,
check which version of maps is currently
stop sign or road marking (for example, cameras are
downloaded, touch Controls > Software > Additional
unobstructed and have a clear line-of-sight to the
vehicle information. You must connect to a Wi-Fi
tra…c light, stop sign, or road marking).
network to receive updated maps (see Map Updates
on page 153).
Autopilot
113
Tra…c Light and Stop Sign Control
• The instrument panel on Model X is displaying an
WARNING: Tra…c Light and Stop Sign Control is
upcoming tra…c light in "bold" format. Model X does
not a substitute for attentive driving and sound
not acknowledge tra…c lights that the instrument
judgment.
panel shows as faded. If a tra…c light is not directly
ahead of the camera (for example, it is located at an
angle of the camera's view, or located in an adjacent
lane) the instrument panel displays it as faded and
Model X does not slow down and stop for it.
WARNING: If the instrument panel is not
displaying a red stop line at an upcoming
intersection, Model X does not slow down or stop.
It is the driver's responsibility to pay attention to
upcoming intersections and monitor tra…c
conditions to determine when and if the vehicle
should stop and then to take appropriate action as
needed.
WARNING: Never depend on Tra…c Light and
Stop Sign Control to determine whether to stop at,
or proceed through, an intersection. Drive
attentively by watching the road and paying
attention to the roadway, upcoming intersections,
tra…c conditions, crosswalks, and other road users.
It is always the driver's responsibility to determine
whether to stop or proceed. Be prepared to take
immediate action. Failure to do so can result in
injury or death.
WARNING: In some situations, Tra…c Light and
Stop Sign Control may inaccurately detect a tra…c
light or stop sign, causing Model X to slow down
unexpectedly. Be prepared to take immediate
action at all times.
WARNING: You must briefly press the accelerator
pedal to confirm that you want to proceed through
an intersection, regardless of the status of the
tra…c light. If you do not confirm, Model X stops at
the red stop line displayed on the instrument
panel, even if stopping may be inappropriate.
Stopping at a green light may confuse other
drivers and may result in a collision, injury or
death. Therefore, always pay attention to
upcoming intersections and be prepared to
manually brake or accelerate in response to
surroundings.
WARNING: Never assume that your ability to see a
tra…c light, stop sign, or road marking (especially
at a complex intersection, or an intersection in
which a tra…c light or sign is partially obstructed,
etc.) means that Model X can also see it and
respond appropriately.
WARNING: Even the most recent map data does
not include all tra…c lights and stop signs.
Therefore, Tra…c Light and Stop Sign Control
relies heavily on the ability of the cameras to
detect tra…c lights, stop signs, road markings, etc.
As a result, Model X may ignore an intersection
that is blocked from the camera's view (for
example, obstructed by a tree or a large vehicle or
object, or located near a steep hill or sharp curve).
114
Tra…c Light and Stop Sign Control
Tra†c Lights
When driving with Autosteer or Tra…c-Aware Cruise Control engaged, and Tra…c Light and Stop Sign Control
enabled, Model X is designed to respond as follows when approaching intersections controlled by a tra…c light:
Type of Tra…c Light
Vehicle Intended Response
At a solid green tra…c light, or at a tra…c light that is currently off (not
illuminated), Model X slows down.
If you are following a car in front of you that continues through the intersection,
the instrument panel displays a green stop line and provided your hands are
detected on the steering yoke, Model X also continues. If a car is not in front of
you, the instrument panel displays a red stop line and you must confirm that you
want to continue through the intersection by briefly pressing the accelerator pedal.
If you don’t confirm, Model X stops at the red stop line.
NOTE: Model X resumes the set cruising speed when it continues through the
intersection, taking into consideration the speed of a vehicle in front of you.
Model X slows down and comes to a complete stop at the red stop line displayed
on the instrument panel. When you want to continue through the intersection (for
example, the light turns green again, or once Model X has come to a complete
stop), you must briefly press the accelerator pedal.
Model X slows down and comes to a complete stop at the red stop line displayed
on the instrument panel. When you want to proceed through the intersection (for
example, the light turns green again), you must briefly press the accelerator pedal.
NOTE: If the tra…c light changes after you've confirmed that you want to proceed
(for example, a green tra…c light turns yellow), Model X may stop instead of
continuing, especially if Model X determines that it can safely stop before entering
the intersection.
NOTE: Model X is not designed to proceed through an intersection when the tra…c
light is red or if the light turns yellow in situations when there is adequate distance
to safely stop before entering the intersection.
NOTE: You can take over driving at any time by manually braking to cancel
Autosteer or Tra…c-aware Cruise Control.
Autopilot
115
Tra…c Light and Stop Sign Control
Type of Tra…c Light
Vehicle Intended Response
Model X slows down. To proceed, you must briefly press the accelerator pedal. If
you don’t, Model X stops at the red stop line displayed on the instrument panel.
NOTE: To prevent Model X from stopping, and to minimize how much it slows
down as it approaches, you can confirm that you want to proceed by briefly
pressing the accelerator pedal at any time after the instrument panel displays the
red stop line. Model X resumes your set cruising speed immediately after you
confirm (taking into consideration the speed of a vehicle in front of you).
WARNING: Approach attentively and be prepared to press the brake pedal to
slow down or stop.
Model X slows down and comes to a complete stop at the red stop line displayed
on the instrument panel. When you want to proceed through the intersection (for
example, tra…c laws and conditions indicate it is safe and legal to proceed), you
must briefly press the accelerator pedal.
116
Tra…c Light and Stop Sign Control
Stop Signs and Road Markings
When driving with Autosteer or Tra…c-aware Cruise Control engaged, and Tra…c Light and Stop Sign Control
enabled, Model X is designed to respond as follows when approaching intersections controlled by stop signs, stop
lines, or road markings:
Type of Intersection
Vehicle Intended Response
Model X assumes the right of way and continues straight without slowing down or
stopping.
No Tra…c Control
Arm of T-junction
If Model X detects a T-junction based on the map data, Model X slows down and
comes to a complete stop at the red stop line displayed on the instrument panel.
When you want to proceed, you must take over steering and acceleration.
WARNING: Model X may not stop at a T-junction that does not have a stop
sign or stop line, or if the T-junction is not included in the map data. Drive
attentively and be prepared to stop (when necessary and/or appropriate).
End of T-junction
Model X slows down and comes to a complete stop at the red stop line displayed on
the instrument panel. When you want to proceed through the intersection, you must
briefly press the accelerator pedal.
NOTE: If you confirm that you want to proceed through an intersection controlled by
a stop sign by briefly pressing the accelerator pedal before Model X has stopped,
your confirmation is ignored. Model X is not designed to proceed through a stop
sign without stopping.
NOTE: Even when using Autosteer, and even if you have engaged a turn signal, you
must turn the steering yoke yourself (which cancels Autosteer) to complete a turn at
an intersection.
Stop Sign
Autopilot
117
Tra…c Light and Stop Sign Control
Type of Intersection
Vehicle Intended Response
Stop Sign and Road Marking
Road Marking
WARNING: Model X also slows down and stops at a roundabout. You must take over steering (which cancels
Autosteer) and briefly press the accelerator pedal to confirm that you want to continue through the
roundabout.
WARNING: At crosswalks, Model X may slow down and may stop, depending on whether the crosswalk is
controlled by a tra…c light and whether the cameras detect pedestrians, bicyclists, etc. in the crosswalk. Pay
particular attention at crosswalks and be prepared to take over at any time. Failure to do so can result in injury
or death.
Limitations
Depending on many different circumstances and environmental conditions, Tra…c Light and Stop Sign Control may
or may not stop at:
• Railroad crossings.
• Keep-out zones.
• Toll booths.
• Crosswalk systems.
• Yield signs or temporary tra…c lights and stop signs (such as at construction areas).
• Miscellaneous tra…c U-turn lights, bicycle and pedestrian crossing lights, lane availability lights, etc.
In addition, Tra…c Light and Stop Sign Control is particularly unlikely to operate as intended, can disengage, or may
not operate, when one or more of the following conditions are present:
• Driving through consecutive light-controlled intersections that are very close to each other.
• Visibility is poor (heavy rain, snow, fog, etc.) or weather conditions are interfering with camera or sensor
operation.
118
Tra…c Light and Stop Sign Control
• Bright light (such as direct sunlight) is interfering with the view of the camera(s).
• A camera is obstructed, covered, damaged, or not properly calibrated.
• Driving on a hill or on a road that has sharp curves on which the cameras are unable to see upcoming tra…c lights
or stop signs.
• A tra…c light, stop sign, or road marking is obstructed (for example, a tree, a large vehicle, etc.).
• Model X is being driven very close to a vehicle in front of it, which is blocking the view of a camera.
WARNING: The limitations listed above are not an exhaustive list of reasons why Model X may not operate as
expected. Many unforeseen circumstances can adversely impact the accurate operation of Tra…c Light and
Stop Sign Control. Using this feature does not reduce or eliminate the need to drive attentively and
responsibly. You must be prepared to take appropriate and immediate action at all times.
Autopilot
119
Autopark
NOTE: Depending on market region, vehicle
1. While driving slowly on a public road, monitor the
configuration, options purchased, and software version,
instrument panel to determine when Autopark has
your vehicle may not be equipped with Autopark.
detected a parking space. The instrument panel will
display a parking icon if the vehicle detects a
Autopark uses data to simplify parking on public roads
potential parking spot.
by maneuvering Model X into parallel and perpendicular
parking spaces.
CAUTION: Ensure all cameras and sensors are
clean. Dirty cameras and sensors, as well as
environmental conditions such as rain and faded
lane markings, can affect Autopilot performance.
WARNING: Autopark's performance depends on
the ability of the cameras and ultrasonic sensors to
determine the vehicle's proximity to curbs, objects,
and other vehicles.
WARNING: Do not use Autopark if anything, such
as a ball hitch, bike rack, or trailer, is attached to
NOTE: The parking icon appears only if the vehicle's
the tow hitch. Autopark may not stop for hitches
when parking between or in front of other vehicles.
position and/or the circumstances of the surrounding
area are such that Autopark can determine an
appropriate driving path. If Autopark cannot
Parameters
determine an appropriate path (for example, when
driving on a narrow street where moving into the
Autopark detects potential parking spaces based on the
parking space causes the front of the vehicle to
following parameters:
extend into the adjacent lane), you can either
reposition the vehicle, find a different parking space,
Perpendicular Parking
or park manually.
• Your driving speed must be below 8 mph (13 km/h). If
2. Check to determine if the detected parking space is
driving too fast, Autopark may not be able to
appropriate and safe. If so, pull forward and stop
accurately detect your desired parking space.
approximately one car length ahead of the parking
space (as you normally would when parallel parking
• The parking space must be at least 7.2 feet (2.2
or when backing into a perpendicular parking space).
meters) wide.
3. Release the steering yoke, shift Model X into Reverse,
• The parking space must have at least three visible
then touch Start Autopark on the touchscreen.
lines for the vehicle to park into, such as parking lines,
road markings, or distinct curbs. Autopark may not
4. Release the steering yoke, then touch and hold
work in a garage, for example, without three visible
Autopark in the drive mode strip on the touchscreen.
parking lines.
You can release the button once Autopark engages.
• Autopark may not work with textured road surfaces
5. Autopark displays a message when parking is
such as cobblestone or brick.
complete.
Parallel Parking
NOTE: If you press the brake pedal when Autopark is
actively parking Model X, the parking process pauses
• Your driving speed must be below 13 mph (21 km/h).
until you touch Resume on the touchscreen.
If driving too fast, Autopark may not be able to
WARNING: Never depend on Autopark to find a
accurately detect your desired parking space.
parking space that is legal, suitable, and safe.
• There must be a vehicle in front of the space you
Autopark may not always detect objects in the
want to park in.
parking space. Always perform visual checks to
confirm that a parking space is appropriate and
• A distinct curb or edge must be visible. Autopark
safe.
may not correctly identify the parking space if the
curb is not distinct, such as grass or dirt.
WARNING: When Autopark is actively steering
Model X, the steering yoke moves in accordance
with Autopark's adjustments. Do not interfere with
NOTE: Autopark does not operate on angled parking
the movement of the steering yoke. Doing so
spaces.
cancels Autopark.
WARNING: During the parking sequence,
To Use Autopark
continually check your surroundings. Be prepared
to apply the brakes to avoid vehicles, pedestrians,
When driving, follow these steps to allow Autopark to
or objects.
maneuver Model X into a parking space:
120
Autopark
WARNING: When Autopark is active, monitor the
touchscreen and instrument panel to ensure that
you are aware of the instructions that Autopark is
providing.
To Pause Parking
To pause Autopark, press the brake pedal once. Model X
stops and remains stopped until you touch Resume on
the touchscreen.
To Cancel Parking
Autopark cancels the parking sequence when you
manually move the steering yoke, shift, or touch Cancel
on the touchscreen. Autopark also cancels parking
when:
• The parking sequence exceeds seven moves.
• Model X detects that the driver is exiting the vehicle.
• A door is opened.
• You press the accelerator pedal.
• You press the brake pedal while Autopark is paused.
• An Automatic Emergency Braking event occurs (see
Collision Avoidance Assist on page 131).
Limitations
Autopark is particularly unlikely to operate as intended
in these situations:
• The road is sloped. Autopark is designed to operate
on flat roads only.
• Visibility is poor (due to heavy rain, snow, fog, etc.).
• The curb is constructed of material other than stone,
or the curb cannot be detected.
• The target parking space is directly adjacent to a wall
or pillar (for example, the last parking space of a row
in an underground parking structure).
• One or more of the ultrasonic sensors or cameras is
damaged, dirty, or obstructed (such as by mud, ice,
or snow, or by a vehicle bra, excessive paint, or
adhesive products such as wraps, stickers, rubber
coating, etc.).
• Weather conditions (heavy rain, snow, fog, or
extremely hot or cold temperatures) are interfering
with sensor operation.
• The sensors are affected by other electrical
equipment or devices that generate ultrasonic waves.
WARNING: Many unforeseen circumstances can
impair Autopark's ability to park Model X. Keep
this in mind and remember that as a result,
Autopark may not steer Model X appropriately. Pay
attention when parking Model X and stay prepared
to immediately take control.
Autopilot
121
Summon
NOTE: Depending on market region, vehicle
WARNING: Parking in a narrow space limits the
configuration, options purchased, and software version,
ability of the sensors to accurately detect the
your vehicle may not be equipped with Summon, or the
location of obstacles, increasing the risk of
feature may not operate exactly as described.
damage to Model X and/or surrounding
objects.
Summon allows you to automatically park and retrieve
Model X while you are standing outside the vehicle.
Require Continuous Press: By default, Summon
Summon moves Model X forward and reverse up to 39
requires that you press and hold a button on the
feet (12 meters) in, or out of, a parking space.
mobile app to move Model X during the parking
process. When Require Continuous Press is set to No,
To move Model X a longer distance while steering
you can press and release the button—you don't need
around objects, you can use Smart Summon (if
to hold it down to keep the vehicle moving. Also,
equipped) and your mobile phone. Smart Summon
when Require Continuous Press is set to No, you can
allows your vehicle to find you (or you can send your
operate Summon using the key fob instead of the
vehicle to a chosen location). See Smart Summon on
mobile app (see Operating Summon with the Key
page 125.
Fob on page 123) and you can start a parking
sequence from inside the vehicle (see Starting
CAUTION: Ensure all cameras and sensors are
Summon Before Exiting the Vehicle on page 123).
clean. Dirty cameras and sensors, as well as
Use Auto HomeLink (if equipped): Set to ON if you
environmental conditions such as rain and faded
want to activate HomeLink to open/close a
lane markings, can affect Autopilot performance.
programmed HomeLink device (such as a gate or a
WARNING: Summon is designed and intended for
garage door) during the parking process when using
use only on parking lots and driveways on private
Summon. If enabled, the device automatically opens
property where the surrounding area is familiar
and closes when Model X enters or exits during a
and predictable.
Summon session. In a Smart Summon session (if
equipped), the device automatically opens when, at
WARNING: Summon is a BETA feature. You must
the beginning of a session, Smart Summon detects
continually monitor the vehicle and its
that Model X is parked in a garage.
surroundings and stay prepared to take immediate
action at any time. It is the driver's responsibility to
WARNING: Always ensure that Model X is fully
use Summon safely, responsibly, and as intended.
in or out of a garage before HomeLink lowers
the garage door. Summon and Smart Summon
WARNING: Summon's performance depends on
(if equipped) cannot detect where an overhead
the ability of the ultrasonic sensors to determine
door will lower.
the vehicle's proximity to objects, people, animals,
and other vehicles.
NOTE: When enabled, the HomeLink device
automatically opens and closes when using Summon,
and automatically opens as needed when using
Before Using Summon
Smart Summon (if equipped). To automate HomeLink
in other situations (such as normal driving), you must
Before operating Summon, use the touchscreen to
adjust the HomeLink device's main settings by
enable it and customize how you want it to work. Touch
touching the HomeLink icon at the top of the
Controls > Autopilot > Customize Summon and adjust
Controls screen (see HomeLink Universal Transceiver
the following settings to suit your preferences:
on page 172).
Bumper Clearance: Set the distance that you want
Summon to stop from a detected object (for
NOTE: The above settings, with the exception of
example, you may want Summon to stop within just a
HomeLink, apply only to Summon—not Smart Summon
few inches of a garage wall). Note that this distance
(if equipped) (see Before Using Smart Summon on page
applies only to objects that Summon detects directly
125). You cannot customize Smart Summon's bumper
in front of Model X when moving forward, or directly
clearance, distance, and side clearance. And when using
behind Model X when reversing.
Smart Summon, you must always hold down the button
on the mobile app to keep Model X moving. Also, Smart
Summon Distance: Set a maximum distance that
Summon operates with the mobile app only—not the key
Model X can travel when entering or exiting a parking
fob.
space.
NOTE: All settings are retained until you manually
Side Clearance: Choose an option to specify how
change them.
much side clearance you want to allow. Tight allows
Model X to enter and exit very narrow parking
spaces.
Using Summon to Park and Retrieve
your Vehicle
Follow these steps to use Summon to park your
Model X:
122
Summon
• Align Model X within 39 feet (12 meters) of the
WARNING: Model X cannot detect obstacles that
parking space so Model X can follow a straight path
are located lower than the bumper, are very
into or out of the space in either Drive or Reverse.
narrow, or are hanging from a ceiling (for example,
bicycles). In addition, many unforeseen
• From outside the vehicle, initiate the parking
circumstances can impair Summon's ability to
maneuver by touching Summon on the mobile app,
move in or out of a parking space and, as a result,
then holding down the Forward or Reverse button.
Summon may not move Model X appropriately.
NOTE: If the Require Continuous Press setting is No,
Therefore, you must continually monitor the
you do not need to hold down the button, just press
vehicle's movement and its surroundings and
and release.
remain prepared to stop Model X at any time.
NOTE: You can also initiate the parking maneuver
from inside the vehicle (see Starting Summon Before
Operating Summon with the Key Fob
Exiting the Vehicle on page 123).
NOTE: Summon may not operate if the battery is low on
the key fob.
Summon shifts Model X into Drive or Reverse (based on
the direction you specified) and drives into or out of the
Follow these steps to park Model X from outside the
parking space. When parking is complete, or if an
vehicle using the key fob:
obstacle is detected, Summon shifts Model X into Park.
Summon shifts Model X into Park when:
1. On the touchscreen, ensure that Require Continuous
Press is disabled (touch Controls > Autopilot >
• Model X detects an obstacle in its driving path
Customize Summon > Require Continuous Press).
(within the Bumper Clearance setting that you
specified).
2. With Model X in Park, stand within 10 feet (three
meters) and press and hold the top center button on
• Summon has moved Model X the maximum distance
the key fob (Lock/Unlock All button) until the hazard
of 39 feet (12 meters).
lights blink continuously.
• You release the Forward or Reverse button (when
NOTE: The hazard lights flash once as Model X locks,
Require Continuous Press is turned on).
then within five seconds, Model X powers on and the
• You press any button to manually stop Summon.
hazard lights flash continuously. Do not proceed to
the next step until the hazard lights are flashing. If,
If you used Summon to park Model X, you can then use
after five seconds, the hazard lights are not flashing,
Summon to return Model X back to its original position
release the button on the key fob, move closer to
(provided Model X has remained in Park), or to the
Model X, and try again. If Summon receives no further
maximum Summon Distance that you have specified
input within ten seconds, Summon cancels.
(whichever comes first). Simply specify the opposite
3. Press the Front Trunk button on the key fob to move
direction on the mobile app and Summon moves
Model X forward into the parking space, or press the
Model X along the original path, provided no
obstructions have been introduced. If an obstacle is
Rear Trunk button to reverse Model X into the
detected, Model X attempts to avoid the obstacle while
parking space.
staying very close to its original path (Summon does not
steer around obstacles).
Starting Summon Before Exiting the
NOTE: To use Summon to move Model X multiple times
Vehicle
in the same direction (not to exceed the maximum of 39
feet (12 meters), cancel Summon and then restart the
To start a Summon parking sequence before exiting
parking process using the same direction.
Model X:
NOTE: Although Summon can move Model X a short
distance laterally to avoid an obstacle, it does not
1. On the touchscreen, ensure that Require Continuous
attempt to steer around an obstacle to return Model X
Press is disabled (touch Controls > Autopilot >
to its original driving path. Only Smart Summon (if
Customize Summon > Require Continuous Press).
equipped) can steer Model X around objects.
2. Close all doors and trunks.
NOTE: Summon requires that Model X can detect a valid
3. With Model X powered on and Park engaged, double
key nearby.
press the scroll button on the right side of the
steering yoke. The touchscreen displays a popup
screen.
4. On the touchscreen, choose the direction of travel.
5. Exit Model X and close the driver's door.
Autopilot
123
Summon
Summon now moves Model X according to the direction
WARNING: The list above does not represent an
you specified on the touchscreen.
exhaustive list of situations that may interfere with
proper operation of Summon. It is the driver's
NOTE: To cancel the parking maneuver before exiting
responsibility to remain in control of Model X at all
the vehicle, touch Cancel on the popup screen.
times. Pay close attention whenever Summon is
actively moving Model X and stay prepared to take
NOTE: If you do not choose a direction of travel on the
immediate action. Failure to do so can result in
touchscreen, Summon does not start a parking
serious property damage, injury or death.
maneuver when you exit.
Stopping or Canceling Summon
Stop Model X at any time while Summon is active by
using the mobile app or by pressing any button on the
key fob. Summon also cancels when:
• A door handle is engaged or a door is opened.
• You interact with the steering yoke, brake pedal,
accelerator pedal, or shift.
• Model X detects an obstacle.
• Summon has moved Model X the maximum distance
of approximately 39 feet (12 meters).
• Your phone enters sleep mode or loses connectivity
to Model X.
Limitations
Summon is unlikely to operate as intended in the
following types of situations:
• The driving path is sloped. Summon is designed to
operate on flat roads only (up to 10% grade).
• A raised concrete edge is detected. Summon does
not move Model X over an edge that is higher than
approximately 1 in (2.5 cm).
• One or more of the ultrasonic sensors or cameras is
damaged, dirty, or obstructed (such as by mud, ice,
or snow, or by a vehicle bra, excessive paint, or
adhesive products such as wraps, stickers, rubber
coating, etc.).
• Weather conditions (heavy rain, snow, fog, or
extremely hot or cold temperatures) are interfering
with sensor operation.
• The sensors are affected by other electrical
equipment or devices that generate ultrasonic waves.
• Model X is in Trailer Mode or an accessory is
attached.
NOTE: Summon is disabled if Model X is in Valet mode
(see Valet Mode on page 55).
124
Smart Summon
NOTE: Depending on market region, vehicle
• Your phone must be connected to Model X and
configuration, options purchased, and software version,
located within approximately 213 feet (65 meters).
your vehicle may not be equipped with Smart Summon,
• The vehicle's cameras must be fully calibrated (see
or the feature may not operate exactly as described.
Drive to Calibrate Cameras on page 99).
Smart Summon is designed to allow you to move
• You must have a clear line of sight to Model X.
Model X to your location (using your phone's GPS as a
• Model X must be in Park, not charging, and all doors
target destination) or to a location of your choice,
and trunks must be closed.
maneuvering around and stopping for objects as
necessary. Smart Summon works with the Tesla mobile
app when your phone is located within approximately
Using Smart Summon
213 feet (65 meters) of Model X. Smart Summon
maneuvers Model X out of parking spaces and around
corners. This is useful for moving Model X out of a tight
1. Open the Tesla mobile app, and press Summon.
parking spot, through puddles, or helping you retrieve
2. Press the Smart Summon icon located in the center
your car while carrying packages. You must maintain a
of the image of your Model X. It may take several
clear line of sight between you and Model X and closely
seconds for Smart Summon to start up.
monitor the vehicle and its surroundings at all times.
NOTE: You can use Standby Mode to eliminate the
CAUTION: Ensure all cameras and sensors are
delay that occurs when Smart Summon is starting up
clean. Dirty cameras and sensors, as well as
(see Standby Mode on page 126).
environmental conditions such as rain and faded
The mobile app displays a map with a blue circle,
lane markings, can affect Autopilot performance.
which represents the maximum proximity of 213 feet
WARNING: Smart Summon is designed and
(65 meters) that you must maintain between your
intended for use only on parking lots and
phone and Model X. The blue dot on the map
driveways located on private property where the
represents your location, and the red arrow
surrounding area is familiar and predictable. Do
represents the location of Model X.
not use Smart Summon on public roads.
WARNING: Smart Summon must only be used on
3. Position yourself anywhere within the blue circle
paved surfaces.
where you have a clear line of sight to Model X.
WARNING: Smart Summon is a BETA feature. You
4. You can now operate Smart Summon using either of
must continually monitor the vehicle and its
these modes:
surroundings and stay prepared to take immediate
Come to Me mode: Press and hold the Come to
action at any time. It is the driver's responsibility to
Me button. Model X moves to your GPS location.
use Smart Summon safely, responsibly, and as
As you move, Model X follows you. When Model X
intended.
reaches you, it stops and shifts into park.
WARNING: Smart Summon may not stop for all
Go to Target mode: Touch the crosshair icon then
objects (especially very low objects such as some
drag the map to position the pin on a chosen
curbs, or very high objects such as a shelf) and
destination. Press and hold the Go to Target
may not react to all tra…c. Smart Summon does
button. Model X moves to the destination. When
not recognize the direction of tra…c, does not
reaching the location, Model X stops and shifts
navigate around empty parking spaces, and may
into Park and the mobile app displays a message
not anticipate crossing tra…c.
indicating that Summon has completed.
WARNING: Smart Summon's performance
NOTE: To subsequently change the location, lift
depends on the ultrasonic sensors , the visibility of
your finger, reposition the map, then press and
the cameras, and the availability of an adequate
hold Go to Target again.
cellular signal and GPS data.
To stop Model X at any time, simply release the Come
WARNING: When using Smart Summon, you must
to Me or Go to Target button.
maintain a clear line of sight between you and
Model X and stay prepared to stop the vehicle at
any time by releasing the button on the mobile
The map's crosshair icon toggles between
app.
Go to Target and Come to Me modes.
When Come to Me mode is selected, the
icon is blue.
Before Using Smart Summon
NOTE: The map also has an icon that
allows you to display/hide satellite imagery.
• Download the latest version of the Tesla mobile app
to your phone, and ensure your phone has cellular
service and GPS enabled.
Autopilot
125
Smart Summon
Immediately after initiating Smart Summon in either
Standby Mode
mode, hazard lights briefly flash, mirrors fold, and
Model X shifts into Drive or Reverse. Model X then slowly
To keep Model X ready to Summon and reduce the time
moves to within 3 feet (1 meter) of you (COME TO ME)
it takes to warm up, turn on Standby Mode. Touch
or your chosen destination (GO TO TARGET), navigating
Controls > Autopilot > Standby Mode. When Standby
obstacles as needed. As Model X moves, the
Mode is turned on, you can conserve Battery energy by
corresponding red arrow on the map also moves to
disabling Standby Mode at these locations:
show the vehicle’s location. As you move, the
corresponding blue dot also moves to show your
Exclude Home - Disables Standby Mode at the
location.
location you set as Home in your Favorites list.
In either mode, Model X stops moving and shifts into
Exclude Work - Disables Standby Mode at the
park when:
location you set as Work in your Favorites list.
Exclude Favorites - Disables Standby Mode at any
• You release the button on the mobile app.
location in your Favorites list.
• The maximum proximity of 213 feet (65 meters)
between your phone and Model X is exceeded (if
NOTE: To conserve energy, Smart Summon
moving Model X to a destination away from you, you
automatically exits Standby mode from midnight to
may need to follow the car to maintain this distance).
6:00 am. During these hours, a delay occurs as Smart
• The driving path is blocked.
Summon starts up.
• Model X has moved the maximum distance of 475
NOTE: Additional battery power may be consumed
feet (145 meters) since the start of the Smart
while Standby Mode is active.
Summon session, or has moved 492 feet (150 meters)
NOTE: For details on how to designate a location as
away from the location from which the vehicle was
Home, Work, or Favorites, see Home, Work, and Favorite
last driven manually.
Destinations on page 150.
NOTE: If Smart Summon moves Model X forward
three feet and then backwards two feet, this is
Stopping or Canceling Smart
considered five feet of travel.
Summon
NOTE: There is no need to look at the mobile app—just
Smart Summon stops Model X whenever you release the
hold down the button while keeping your eye on
button on the mobile app. To resume the Smart
Model X and its driving path at all times, remaining
Summon session, simply press the Come to Me or Go to
ready to release the button to stop the vehicle if needed.
Target button again.
If equipped and Auto HomeLink is enabled for Summon
WARNING: Always anticipate when you need to
(touch Controls > Autopilot > Customize Summon > Use
stop Model X. Depending on the quality of the
Auto HomeLink), Smart Summon automatically opens a
connectivity between the phone and Model X,
HomeLink device if you start the Smart Summon
there may be a slight delay between when you
maneuver when Model X is located inside a garage. The
release the button and when the car stops.
mobile app informs you that the door has opened.
Smart Summon cancels, and requires you to restart it,
WARNING: When you release the button to stop
when:
Model X, a slight delay occurs before the vehicle
stops. Therefore, it is critical that you pay close
• You press any button on the key fob.
attention to the vehicle’s driving path at all times
and proactively anticipate obstacles that the
• A door handle is engaged or a door is opened.
vehicle may be unable to detect.
• You interact with the steering yoke, brake pedal,
WARNING: Use extreme caution when using Smart
accelerator pedal, or shift.
Summon in environments where movement of
• Model X is blocked by an obstacle.
obstacles can be unpredictable. For example,
where people, children or animals are present.
• Smart Summon has moved Model X the maximum
distance of approximately 475 feet (145 meters)
WARNING: Smart Summon may not stop for all
within a 213 foot (65 meter) radius of the phone's
objects (especially very low objects such as some
location. To move further than this distance, you must
curbs, or very high objects such as a shelf) and
shift Model X into Drive or Reverse and then re-
may not react to all oncoming or side tra…c. Pay
initiate an Smart Summon session.
attention and be ready to stop Model X at all times
by releasing the button on the mobile app.
• Your phone enters sleep mode or loses connectivity
to Model X.
126
Smart Summon
Limitations
Smart Summon is unlikely to operate as intended in the
following types of situations:
• GPS data is unavailable due to poor cellular coverage.
• The driving path is sloped. Smart Summon is
designed to operate on flat roads only (up to 10%
grade).
• A raised concrete edge is detected. Depending on
the height of the concrete edge, Smart Summon may
not move Model X over it.
• One or more of the ultrasonic sensors or cameras is
damaged, dirty, or obstructed (such as by mud, ice,
or snow, or by a vehicle bra, excessive paint, or
adhesive products such as wraps, stickers, rubber
coating, etc.).
• Weather conditions (heavy rain, snow, fog, or
extremely hot or cold temperatures) are interfering
with sensor or camera operation.
• The sensors are affected by other electrical
equipment or devices that generate ultrasonic waves.
• Model X is in Trailer Mode or an accessory is
attached.
NOTE: Smart Summon is disabled if Model X is in Valet
mode (see Valet Mode on page 55).
WARNING: The list above does not represent an
exhaustive list of situations that may interfere with
proper operation of Smart Summon. It is the
driver's responsibility to remain in control of
Model X at all times. Pay close attention whenever
Smart Summon is actively moving Model X and
stay prepared to take immediate action. Failure to
do so can result in serious property damage, injury
or death.
Autopilot
127
Lane Assist
Model X monitors the markers on the lane you are
is traveling between 30 and 85 mph (48 and 140 km/h)
driving in as well as the surrounding areas for the
on major roads with clearly visible lane markings. When
presence of vehicles or other objects.
a steering intervention is applied, the instrument panel
briefly displays a warning message.
When an object is detected in your blind spot or near
the side of Model X (such as a vehicle, guard rail, etc.),
Lane Departure Avoidance
the instrument panel displays colored lines radiating
from the image of your vehicle. The location of the lines
correspond to the location of the detected object. The
Lane Departure Avoidance is designed to warn you if
color of the lines (white, yellow, orange, or red)
Model X is drifting out of, or nears the edge of, your
driving lane.
represent the object's proximity to Model X, with white
being the farthest and red being the closest and
Lane Departure Avoidance operates when driving
requiring your immediate attention. These colored lines
between 40 and 90 mph (64 and 145 km/h) on roads
only display when driving between approximately 7 and
with clearly visible lane markings. You can choose if and
85 mph (12 and 140 km/h). When Autosteer is active,
how you want Lane Departure Warning to operate by
these colored lines also display if driving slower than 7
touching Controls > Autopilot > Lane Departure
mph (12 km/h). However, the colored lines do not display
Avoidance and selecting between these options:
if Model X is at a standstill (for example, in heavy tra…c).
Off: You are not warned of lane departures or
potential collisions with a vehicle in an adjacent lane.
Warning: If a front wheel passes over a lane marking,
the steering yoke vibrates.
Assist: Corrective steering is applied to keep Model X
in a safe position if Model X drifts into an adjacent
lane or near the edge of the road.
When Lane Departure Avoidance is enabled and Tra…c-
Aware Cruise Control is active, if Model X drifts out of
the driving lane when the associated turn signal is off,
Lane Assist also checks to see whether your hands are
on the steering yoke. If hands are not detected, the
instrument panel displays a series of alerts, similar to
CAUTION: Ensure all cameras and sensors are
those that are used when driving with Autosteer. If
clean. Dirty cameras and sensors, as well as
hands are repeatedly not detected Model X gradually
environmental conditions such as rain and faded
slows down to 15 mph (25 km/h) below the detected
lane markings, can affect Autopilot performance.
speed limit, or below the set cruising speed, and the
hazard lights start flashing.
WARNING: Lane Assist features are for guidance
purposes only and is not intended to replace your
NOTE: Lane Departure Avoidance does not warn you of
own direct visual checks. Before changing lanes,
lane departures, or provide steering interventions, if the
always use side mirrors and perform the
associated turn signal is on, which indicates an
appropriate shoulder checks to visually determine
intentional lane change.
if it is safe and appropriate to change lanes.
WARNING: Lane Departure Avoidance is intended
WARNING: Never depend on Lane Assist to inform
to help keep you safe, but it does not work in
you if you unintentionally drive outside of the
every situation and does not replace the need to
driving lane, or to inform you that there is a vehicle
remain attentive and in control.
beside you or in your blind spot. Several external
factors can reduce the performance of Lane Assist
WARNING: Keep your hands on the steering yoke
(see Limitations and Inaccuracies on page 129). It
and drive attentively at all times.
is the driver's responsibility to stay alert and pay
WARNING: Steering interventions are minimal and
attention to the driving lane and other road users.
are not designed to move Model X out of its
Failure to do so can result in serious injury or
driving lane. Do not rely on steering interventions
death.
to avoid side collisions.
Steering Interventions
Emergency Lane Departure
Avoidance
Lane Assist provides steering interventions if Model X
drifts into (or close to) an adjacent lane in which an
object, such as a vehicle, is detected. In these situations,
Emergency Lane Departure Avoidance automatically
Model X automatically steers to a safer position in the
applies steering to avoid a potential collision in
driving lane. This steering is applied only when Model X
situations where:
128
Lane Assist
• Model X is departing a lane and may collide with a
• Visibility is poor and lane markings are not clearly
vehicle traveling in the same direction in the adjacent
visible (due to heavy rain, snow, fog, etc.). The exact
lane (regardless of the status of the turn signal).
detection zone of the ultrasonic sensors varies
depending on environmental conditions.
• Model X is departing a lane into an oncoming lane,
the turn signal is off, and an oncoming vehicle is
• Bright light (such as from oncoming headlights or
detected.
direct sunlight) is interfering with the view of the
camera(s).
• Model X is departing the road and the turn signal is
off (for example, very close to the edge of the road
• A vehicle in front of Model X is blocking the view of
and a collision may occur).
the camera(s).
• The windshield is obstructing the view of the
To turn this feature on or off, touch Controls > Autopilot
camera(s) (fogged over, dirty, covered by a sticker,
> Emergency Lane Departure Avoidance.
etc.).
• Lane markings are excessively worn, have visible
When Emergency Lane Departure Avoidance applies
steering, a chime sounds and the instrument panel
previous markings, have been adjusted due to road
displays a warning and highlights the lane marking in
construction, or are changing quickly (for example,
red.
lanes branching off, crossing over, or merging).
• The road is narrow or winding.
Emergency Lane Departure Avoidance operates when
• Objects or landscape features are casting strong
Model X is traveling between 40 and 90 mph (64 and
145 km/h) on a road with clearly visible lane markings,
shadows on lane markers.
curbs, etc.
Lane Assist may not provide warnings, or may apply
WARNING: Emergency Lane Departure Avoidance
inappropriate warnings, in these situations:
is not a substitute for attentive driving and sound
judgment. Keep your eyes on the road when
• One or more of the ultrasonic sensors or cameras is
driving and never depend on Emergency Lane
damaged, dirty, or obstructed (by mud, ice, or snow,
Departure Avoidance to prevent a collision. Several
or by a vehicle bra, excessive paint, or adhesive
factors can reduce or impair performance.
products such as wraps, stickers, rubber coatings,
Depending on Emergency Lane Departure
etc.).
Avoidance to prevent a potential collision can
• Weather conditions (heavy rain, snow, fog, or
result in serious injury or death.
extremely hot or cold temperatures) are interfering
with sensor operation.
Blind Spot Camera and Collision
• The sensors are affected by other electrical
Warning Chime
equipment or devices that generate ultrasonic waves.
• An object that is mounted to Model X is interfering
To display the image from the corresponding side
with and/or obstructing a sensor (such as a bike rack
repeater camera whenever you engage a turn signal to
or a bumper sticker).
change lanes, touch Controls > Autopilot > Blind Spot
Camera.
In addition, Lane Assist may not steer Model X away
from an adjacent vehicle, or may apply unnecessary or
If you want a chime to sound when a vehicle is in your
inappropriate steering, in these situations:
blind spot and a possible collision is detected, touch
Controls > Autopilot > Blind Spot Collision Warning
• You are driving Model X on sharp corners or on a
Chime.
curve at a relatively high speed.
WARNING: Blind Spot Camera does not eliminate
• Bright light (such as from oncoming headlights or
the need to drive attentively and manually perform
direct sunlight) is interfering with the view of the
shoulder checks when changing lanes.
camera(s).
WARNING: Blind Spot Collision Warning Chime
• You are drifting into another lane but an object (such
cannot detect every collision. It is the driver's
as a vehicle) is not present.
responsibility to remain alert and perform the
• A vehicle in another lane cuts in front of you or drifts
appropriate shoulder checks when changing lanes.
into your driving lane.
• Model X is not traveling within the speeds at which
Limitations and Inaccuracies
the Lane Assist feature is designed to operate.
Lane Assist features cannot always detect lane markings
and you may experience unnecessary or invalid warnings
in these situations:
Active Safety Features
129
Lane Assist
• One or more of the ultrasonic sensors is damaged,
dirty, or obstructed (such as by mud, ice, or snow, or
by a vehicle bra, excessive paint, or adhesive
products such as wraps, stickers, rubber coating,
etc.).
• Weather conditions (heavy rain, snow, fog, or
extremely hot or cold temperatures) are interfering
with sensor operation.
• The sensors are affected by other electrical
equipment or devices that generate ultrasonic waves.
• An object mounted to Model X (such as a bike rack or
a bumper sticker) is interfering with or obstructing a
sensor.
• Visibility is poor and lane markings are not clearly
visible (due to heavy rain, snow, fog, etc.).
• Lane markings are excessively worn, have visible
previous markings, have been adjusted due to road
construction or are changing quickly (for example,
lanes branching off, crossing over, or merging).
WARNING: The lists above do not represent every
possible situation that may interfere with Lane
Assist features. There are many reasons why Lane
Assist may not operate as intended. To avoid a
collision, stay alert and always pay attention to the
road so you can anticipate the need to take
corrective action as early as possible.
130
Collision Avoidance Assist
The following collision avoidance features are designed
to increase the safety of you and your passengers:
Forward Collision Warning - provides visual and
audible warnings in situations when Model X detects
that there is a high risk of a frontal collision (see
Forward Collision Warning on page 131).
Automatic Emergency Braking - automatically
applies braking to reduce the impact of a frontal
collision (see Automatic Emergency Braking on page
132).
Obstacle-Aware Acceleration - reduces acceleration
if Model X detects an object in its immediate driving
path (see Obstacle-Aware Acceleration on page
132).
CAUTION: Ensure all cameras and sensors are
clean. Dirty cameras and sensors, as well as
Warnings cancel automatically when the risk of a
environmental conditions such as rain and faded
collision has been reduced (for example, you have
lane markings, can affect performance.
decelerated or stopped Model X, or the object in front of
WARNING: Forward Collision Warning is for
your vehicle has moved out of your driving path).
guidance purposes only and is not a substitute for
attentive driving and sound judgment. Keep your
If immediate action is not taken when Model X issues a
eyes on the road when driving and never depend
Forward Collision Warning, Automatic Emergency
on Forward Collision Warning to warn you of a
Braking (if enabled) may automatically apply the brakes
potential collision. Several factors can reduce or
if a collision is considered imminent (see Automatic
impair performance, causing either unnecessary,
Emergency Braking on page 132).
invalid, inaccurate, or missed warnings. Depending
on Forward Collision Warning to warn you of a
By default, Forward Collision Warning is turned on. To
potential collision can result in serious injury or
turn it off or adjust its sensitivity, touch Controls >
death.
Autopilot > Forward Collision Warning. Instead of the
default warning level of Medium, you can turn the
WARNING: Automatic Emergency Braking is not
warning Off, or you can choose to be warned Late or
designed to prevent all collisions. In certain
Early.
situations, it can minimize the impact of a frontal
collision by attempting to reduce your driving
NOTE: Forward Collision Warning automatically resets to
speed. Depending on Automatic Emergency
Medium at the beginning of each drive.
Braking to avoid a collision can result in serious
injury or death.
WARNING: The camera(s) and sensors associated
with Forward Collision Warning are designed to
WARNING: Obstacle-Aware Acceleration is not
monitor an approximate area of up to 525 feet
designed to prevent a collision. In certain
(160 meters) in your driving path. The area being
situations, it can minimize the impact of a collision.
monitored by Forward Collision Warning can be
Depending on Obstacle-Aware Acceleration to
adversely affected by road and weather
avoid a collision can result in serious injury or
conditions. Use appropriate caution when driving.
death.
WARNING: Forward Collision Warning is designed
only to provide visual and audible alerts. It does
Forward Collision Warning
not attempt to apply the brakes or decelerate
Model X. When seeing and/or hearing a warning, it
Model X monitors the area in front of it for the presence
is the driver's responsibility to take immediate
of an object such as a vehicle, motorcycle, bicycle, or
corrective action.
pedestrian. If a collision is considered likely unless you
WARNING: Forward Collision Warning may
take immediate corrective action, Forward Collision
provide a warning in situations where the
Warning is designed to sound a chime and highlight the
likelihood of collision may not exist. Stay alert and
vehicle in front of you in red on the instrument panel. If
always pay attention to the area in front of
this happens, TAKE IMMEDIATE CORRECTIVE ACTION!
Model X so you can anticipate whether any action
is required.
Forward Collision Warning operates only when driving
between approximately 3 mph (5 km/h) and 90 mph
(150 km/h).
Active Safety Features
131
Collision Avoidance Assist
WARNING: Forward Collision Warning does not
WARNING: Several factors can affect the
provide a warning when the driver is already
performance of Automatic Emergency Braking,
applying the brake.
causing either no braking or inappropriate or
untimely braking, such as when a vehicle is
partially in the path of travel or there is road
Automatic Emergency Braking
debris. It is the driver’s responsibility to drive
safely and remain in control of the vehicle at all
Model X is designed to determine the distance from a
times. Never depend on Automatic Emergency
detected object traveling in front of it. When a frontal
Braking to avoid or reduce the impact of a
collision is considered unavoidable, Automatic
collision.
Emergency Braking is designed to apply the brakes to
reduce the vehicle's speed and therefore, the severity of
WARNING: Automatic Emergency Braking is
designed to reduce the impact of frontal collisions
the impact. The amount of speed that is reduced
only and does not function when Model X is in
depends on many factors, including driving speed and
Reverse.
environment.
WARNING: Automatic Emergency Braking is not a
When Automatic Emergency Braking applies the brakes,
substitute for maintaining a safe traveling distance
the instrument panel displays a visual warning and
between you and the vehicle in front of you.
sounds a chime. You may also notice abrupt downward
WARNING: The brake pedal moves downward
movement of the brake pedal. The brake lights turn on
abruptly during automatic braking events. Always
to alert other road users that you are slowing down.
ensure that the brake pedal can move freely. Do
not place material under or on top of the driver’s
Emergency braking in progress
floor mat (including an additional mat) and always
ensure that the driver’s floor mat is properly
secured. Failure to do so can impede the ability of
the brake pedal to move freely.
Multi-Collision Braking
Automatic Emergency Braking operates only when
driving between approximately 3 mph (5 km/h) and 90
mph (150 km/h).
In addition to Automatic Emergency Braking, your
vehicle may apply the brakes to prevent or mitigate a
Automatic Emergency Braking does not apply the
subsequent impact after an initial collision if airbag
brakes, or stops applying the brakes, when:
deployment is detected. The brakes may be applied
regardless of driving speed.
• You turn the steering yoke sharply.
• You press and release the brake pedal while
Obstacle-Aware Acceleration
Automatic Emergency Braking is applying the brakes.
Obstacle-Aware Acceleration is designed to reduce the
• You accelerate hard while Automatic Emergency
impact of a collision by reducing motor torque and in
Braking is applying the brakes.
some cases applying the brakes, if Model X detects an
• The vehicle, motorcycle, bicycle, or pedestrian is no
object in its driving path. The instrument panel displays
longer detected ahead.
a visual warning and sounds a chime when the brakes
are automatically applied. For example, Model X, while
Automatic Emergency Braking is always enabled when
parked in front of a closed garage door with Drive
you start Model X. To disable it for your current drive,
engaged, detects that you have pressed hard on the
touch Controls > Autopilot > Automatic Emergency
accelerator pedal. Although Model X still accelerates and
Braking. Even if you disable Automatic Emergency
hits the garage door, the reduced torque may result in
Braking, your vehicle may still apply the brakes after
less damage.
detecting an initial collision to reduce further impact
(see Multi-Collision Braking on page 132).
Obstacle-Aware Acceleration is designed to operate
only when all of these conditions are simultaneously
WARNING: It is strongly recommended that you
met:
do not disable Automatic Emergency Braking. If
you disable it, Model X does not automatically
• Drive or Reverse is engaged.
apply the brakes in situations where a collision is
• Model X is stopped or traveling less than 10 mph (16
considered likely.
km/h).
WARNING: Automatic Emergency Braking is
• Model X detects an object in its immediate driving
designed to reduce the severity of an impact. It is
path.
not designed to avoid a collision.
To disable Obstacle-Aware Acceleration, touch Controls
> Autopilot > Obstacle-Aware Acceleration.
132
Collision Avoidance Assist
WARNING: Obstacle-Aware Acceleration is
CAUTION: If a fault occurs with a Collision
designed to reduce the severity of an impact. It is
Avoidance Assist feature, Model X displays an
not designed to avoid a collision.
alert. Contact Tesla Service.
WARNING: Obstacle-Aware Acceleration may not
limit torque in all situations. Several factors,
including environmental conditions, distance from
an obstacle, and a driver's actions, can limit, delay,
or inhibit Obstacle-Aware Acceleration.
WARNING: Obstacle-Aware Acceleration may not
limit torque when performing a sharp turn, such as
into a parking space.
WARNING: Do not rely on Obstacle-Aware
Acceleration to control acceleration or to avoid, or
limit, the severity of a collision, and do not attempt
to test Obstacle-Aware Acceleration. Doing so can
result in serious property damage, injury, or death.
WARNING: Several factors can affect the
performance of Obstacle-Aware Acceleration,
causing an inappropriate or untimely reduction in
motor torque and/or undesired braking. It is the
driver's responsibility to drive safely and remain in
control of Model X at all times.
Limitations and Inaccuracies
Collision Avoidance features cannot always detect all
objects, vehicles, bikes, or pedestrians, and you may
experience unnecessary, inaccurate, invalid, or missed
warnings for many reasons, particularly if:
• The road has sharp curves.
• Visibility is poor (due to heavy rain, snow, fog, etc.).
• Bright light (such as from oncoming headlights or
direct sunlight) is interfering with the view of the
camera(s).
• A camera or sensor is obstructed (dirty, covered,
fogged over, covered by a sticker, etc.).
• One or more of the ultrasonic sensors is damaged,
dirty, or obstructed (such as by mud, ice, or snow, or
by a vehicle bra, excessive paint, or adhesive
products such as wraps, stickers, rubber coating,
etc.).
• Weather conditions (heavy rain, snow, fog, or
extremely hot or cold temperatures) are interfering
with sensor operation.
• The sensors are affected by other electrical
equipment or devices that generate ultrasonic waves.
WARNING: The limitations previously described do
not represent an exhaustive list of situations that
may interfere with proper operation of Collision
Avoidance Assist features. These features may fail
to provide their intended function for many other
reasons. It is the driver’s responsibility to avoid
collisions by staying alert, paying attention, and
taking corrective action as early as possible.
Active Safety Features
133















Content      ..     2      3      4      5     ..
