Door ajar indicator does not illuminate
with the driver door open.

•

Door ajar indicator illuminates with the
driver door closed.

•

Transmission not in park message
appears with the driver door closed, after
you shift out of park (P).

MANUAL PARK RELEASE

WHAT IS MANUAL PARK RELEASE

Manual park release allows you to move your
transmission out of the park (P) position in
the event of an electrical malfunction or
emergency.

MANUAL PARK RELEASE
PRECAUTIONS

WARNING: When doing this

procedure, you need to take the
transmission out of park (P) which means
your vehicle can roll freely. To avoid
unwanted vehicle movement, always fully
apply the parking brake prior to doing this
procedure. Use wheels chocks if
appropriate.

WARNING: If the parking brake is

fully released, but the brake warning lamp
remains illuminated, the brakes may not
be working properly. Have your vehicle
checked as soon as possible.

WARNING: Do not drive your vehicle

until you verify that the stoplamps are
working.

USING MANUAL PARK RELEASE

Activating the Manual Park Release
Cable

1. Apply the parking brake. See Electric

Parking Brake (page 223).

Note: If vehicle battery has run out of charge,
use an external power source to apply the
parking brake.

2. Remove the access cover. The cover is

located under the dash below the
steering wheel. Do not pull the tether.

214

Automatic Transmission

E307294

3. Sit in the drivers seat.

4. Switch the ignition on.

Note: Do not activate manual park release
when the engine is started.

5. Press and hold the brake pedal. Do not

release.

6. Pull the tether outward toward you. Move

the tether to the lower right-hand corner
and seat the metal bead in the pocket.

E307295

Note: A message appears in the information
display when your vehicle is out of park (P).
If you do not receive a message, release the
tether and start the procedure again.

7. Release the parking brake.   See Electric

Parking Brake (page 223).

Note: Your vehicle is free to roll.

8. Switch the ignition off.

9. Disconnect the negative battery cable

from the battery.

Note: If the vehicle detects wheel movement
before the battery is disconnected, the
electric parking brake could apply.

Returning Your Vehicle to Normal Mode

1. Reconnect the negative battery cable to

the battery.

2. Apply the parking brake.

Note: If the vehicle battery has run out of
charge, use an external power source to
apply the parking brake.

Note: If the vehicle detects wheel movement,
the electric parking brake could apply.

3. Sit in the drivers seat.

4. Press and hold the brake pedal. Do not

release.

215

Automatic Transmission

5. Pull the tether outward toward you. Move

tether left and into the stowed position.

6. Start your vehicle. Confirm the instrument

cluster displays park (P).

Note: If the instrument cluster does not
display park (P) or if Park Not Available,
Transmission Not In Park or Shift System
Fault message appears in the information
display, contact an authorized dealer for
service. Switch the ignition off and apply the
parking brake before you leave your vehicle.

7. Reinstall the access cover.

AUTOMATIC TRANSMISSION
AUDIBLE WARNINGS

Transmission Not In Park (P) Audible

Warning

Sounds if you open the driver door before
shifting into park (P).

Park (P) Selection Audible Warning

Sounds when you shift into park (P).

AUTOMATIC TRANSMISSION –
TROUBLESHOOTING

AUTOMATIC TRANSMISSION –
INFORMATION MESSAGES

You switched the

engine off and shift

select lever is in any

position other than

park (P).

Shift to Park

Transmission is too

cold. Wait for it to

warm up before you

drive.

Transmission

Warming Up Please

Wait

The transmission is

overheating and

needs to cool.  Stop

in a safe place as

soon as it’s possible.

Transmission Over

Temperature Stop

Safely

Have system

checked as soon as

possible.

Transmission

Service Required

The transmission is

overheating and

needs to cool.  Stop

in a safe place as

soon as it’s possible.

Transmission Too

Hot Press Brake

The transmission has
limited functionality.

Have system

checked as soon as

possible.

Transmission Limited
Function See Manual

A reminder to shift

into park. In addition,

this message is

typical after recon-

necting or rechar-

ging the battery until

you cycle the igni-

tion to the on mode.

See Changing the

12V Battery (page

353).

Transmission Not in

Park

216

Automatic Transmission

Displays when the

system requires

service. Have your

vehicle checked as

soon as possible.

SHIFT SYS FAULT

Confirm Park Brake

Apply Before Exiting

the Vehicle

Have system

checked as soon as

possible.

SHIFT SYS FAULT

Service Required

Displays when the

system requires

service. Have your

vehicle checked as

soon as possible.

SHIFT SYS FAULT

Vehicle is Shifting to

Park

Displays when the

system requires

service. Have your

vehicle checked as

soon as possible.

SHIFT SYS FAULT

Reverse Unavailable

Service Required

Have system

checked as soon as

possible.

SHIFT SYS FAULT

Drive Unavailable

Select S for Drive

Service Required

Have system

checked as soon as

possible.

SHIFT SYS FAULT

Neutral Unavailable

Service Required

Have system

checked as soon as

possible.

SHIFT SYS FAULT
Sport Unavailable

Service Required

Displays when an

invalid gear has

been selected.

Invalid Gear Selec-

tion

Displays when the

brake pedal needs

to be depressed to

enable the transmis-

sion to shift from

park.

Depress Brake to

Shift from Park

Displays when

neutral hold is

active.

Stay in Neutral Mode

Engaged

Displays when the

neutral button N

needs to be pressed

again to enter

neutral hold.

To Stay in Neutral

When Exiting

Vehicle Select N

Again

217

Automatic Transmission

HOW DOES ALL-WHEEL DRIVE
WORK

All-wheel drive uses all four wheels to power
the vehicle. This increases traction, enabling
you to drive over terrain and road conditions
that a conventional two-wheel drive vehicle
cannot. The AWD system turns on when
needed and does not require input from you.

There is further information on driving in
unique driving conditions. See Driving Hints
(page 310).

ALL-WHEEL DRIVE PRECAUTIONS

WARNING: Do not become

overconfident in the ability of all-wheel
drive vehicles. Although an all-wheel drive
vehicle may accelerate better than a
two-wheel drive vehicle in low traction
situations, it won't stop any faster than
two-wheel drive vehicles. Always drive at
a safe speed.

ALL-WHEEL DRIVE LIMITATIONS

Using different size tires other than the
provided spare could cause system damage
or disable the all-wheel drive system.

218

All-Wheel Drive

 (If Equipped)

ALL-WHEEL DRIVE – TROUBLESHOOTING

ALL-WHEEL DRIVE – INFORMATION MESSAGES

Action

Message

The all-wheel drive system temporarily turns off to protect itself from overheating.

AWD Temporarily Disabled

The all-wheel drive system will resume normal function and clear this message after driving a

short distance with the road tire re-installed or after the system cools.

AWD Restored

The all-wheel drive system temporarily turns off to protect itself from overheating or if you are

using the temporary spare tire.

AWD OFF

The all-wheel drive system is not operating properly. If the warning stays on or continues to

come on, contact an authorized dealer.

AWD Malfunction Service Required

219

All-Wheel Drive

 (If Equipped)

BRAKE PRECAUTIONS

WARNING: Driving your vehicle with

the warning lamp on is dangerous. A
significant decrease in braking
performance may occur. It may take you
longer to stop your vehicle. Have your
vehicle checked as soon as possible.
Driving extended distances with the
parking brake engaged can cause brake
failure and the risk of personal injury.

Wet brakes result in reduced braking
efficiency.  Gently press the brake pedal a
few times when leaving a car wash or driving
from standing water to dry the brakes.

Note: Depending on applicable laws and
regulations in the country for which your
vehicle was originally built, the stoplamps
could flash during heavy braking. Following
this the hazard warning flashers could also
turn on when your vehicle comes to a stop.

ANTI-LOCK BRAKING SYSTEM

ANTI-LOCK BRAKING SYSTEM
LIMITATIONS

The anti-lock braking system does not
eliminate the risk of crash when:
•

You drive too closely to the vehicle in
front of you.

•

Your vehicle is hydroplaning.

•

You take corners too fast.

•

The road surface is poor.

Note:  If the system activates, the brake
pedal could pulse and travel further.
Maintain pressure on the brake pedal.

BRAKE OVER ACCELERATOR

In the event the accelerator pedal becomes
stuck or entrapped, apply steady and firm
pressure to the brake pedal to slow the
vehicle and reduce engine power. If you
experience this condition, apply the brakes
and bring your vehicle to a safe stop. Move

the transmission to park (P), switch the
engine off and apply the parking brake.
Inspect the accelerator pedal for any
interference. If none are found and the
condition persists, have your vehicle towed
to the nearest authorized dealer.

LOCATING THE BRAKE FLUID
RESERVOIR

See Under Hood Overview (page 341).

CHECKING THE BRAKE FLUID

WARNING: Do not use any fluid other

than the recommended brake fluid as this
will reduce brake efficiency. Use of
incorrect fluid could result in the loss of
vehicle control, serious personal injury or
death.

220

Brakes

WARNING: Only use brake fluid from

a sealed container. Contamination with dirt,
water, petroleum products or other
materials may result in brake system
damage or failure. Failure to adhere to this
warning could result in the loss of vehicle
control, serious personal injury or death.

WARNING: Do not allow the fluid to

touch your skin or eyes. If this happens,
rinse the affected areas immediately with
plenty of water and contact your physician.

WARNING: The brake system could

be affected if the brake fluid level is below
the MIN mark or above the MAX mark on
the brake fluid reservoir.

E170684

1. Park your vehicle on a level surface.

2. Look at the brake fluid reservoir to see

where the brake fluid level is relative to
the MIN and the MAX marks on the
reservoir.

Note: To avoid fluid contamination, the
reservoir cap must remain in place and fully
tight, unless you are adding fluid.

Only use fluid that meets our specifications.
See Capacities and Specifications (page
404).

BRAKE FLUID SPECIFICATION

See Brake Fluid Specification (page 420).

BRAKES – TROUBLESHOOTING

BRAKES – WARNING LAMPS

If the ABS indicator illuminates
when you are driving, this indicates
a malfunction. Your vehicle

continues to have normal braking without
the anti-lock braking system function. See
an authorized dealer.

It also momentarily illuminates when you
switch the ignition on to confirm the lamp is
functional. If it does not illuminate when you
switch the ignition on, or begins to flash at
any time, have the system checked by an
authorized dealer.

221

Brakes

E270480

The brake indicator momentarily
illuminates when you switch the
ignition on to confirm the lamp is

functional.  It may also illuminate when you
apply the parking brake and the ignition is
on.  If it illuminates when your vehicle is
moving, make sure the parking brake is
disengaged.  If the parking brake is
disengaged, this indicates low brake fluid
level or a brake system fault.  See an
authorized dealer.

BRAKES – INFORMATION MESSAGES

The brake fluid level
is low and the brake

system should be

inspected immedi-

ately.  See Checking

the Brake Fluid

(page 220).

Brake Fluid Level

Low

The brake system

needs servicing.

Stop the vehicle in a

safe place. Contact

an authorized

dealer.

Check Brake System

BRAKES – FREQUENTLY ASKED
QUESTIONS

Is brake dust on the wheels normal?

Brake dust could accumulate on the
wheels, even under normal driving
conditions. Some dust is inevitable as
the brakes wear and does not contribute
to brake noise. See Cleaning Wheels
(page 364).

Will wet driving conditions effect my
braking abilities?

Wet brakes result in reduced braking
efficiency. Gently press the brake pedal
a few times when driving from a car
wash or standing water to dry the
brakes.

Is brake noise considered normal?

Occasional brake noise is normal. If a
metal-to-metal, continuous grinding or
continuous squeal sound is present, the
brake linings may be worn-out and an
authorized dealer should check them.
If the vehicle has continuous vibration
or shudder in the steering wheel while
braking, an authorized dealer should
check your vehicle.

When should you replace the brake fluid?

Brake fluid absorbs water over time
which degrades the effectiveness of the
brake fluid. Change the brake fluid at
the specified intervals to prevent
degraded braking performance. See
Normal Scheduled Maintenance (page
467).

222

Brakes

WHAT IS THE ELECTRIC PARKING
BRAKE

The electric parking brake is used to hold
your vehicle on slopes and flat roads.

APPLYING THE ELECTRIC
PARKING BRAKE

WARNING: Always fully apply the

parking brake and make sure you shift into
park (P). Failure to follow this instruction
could result in personal injury or death.

WARNING: If you drive extended

distances with the parking brake applied,
you could cause damage to the brake
system.

E267156

The switch is on the lower part of
the instrument panel.

1. Pull the switch up.

The red warning lamp flashes during
operation and illuminates when the parking
brake is applied.

Note: You can apply the electric parking
brake when the ignition is off.

Note: The electric parking brake could apply
when the transmission selector is in park (P).
See Park (P) (page 210).

APPLYING THE ELECTRIC
PARKING BRAKE IN AN
EMERGENCY

You can use the electric parking brake to
slow or stop your vehicle in an emergency.

1. Pull the switch up and hold it.

The electric parking brake continues to slow
your vehicle down unless you release the
switch.

The red warning lamp illuminates, a tone
sounds and the stoplamps turn on when you
use the electric parking brake in an
emergency.

Note: Do not apply the electric parking brake
when your vehicle is moving, except in an
emergency. If you repeatedly use the electric
parking brake to slow or stop your vehicle,
you could cause damage to the brake
system.

MANUALLY RELEASING THE
ELECTRIC PARKING BRAKE

1. Switch the ignition on.

2. Press and hold the brake pedal.

3. Push the switch down.

The red warning lamp turns off.

Pulling Away on a Hill When Towing a
Trailer

1. Press and hold the brake pedal.

2. Pull the switch upward and hold it.

3. Shift into gear.

4. Press the accelerator pedal until engine

has developed sufficient torque to
prevent your vehicle from rolling down
the hill.

223

Electric Parking Brake

5. Release the switch and pull away in a

normal manner.

AUTOMATICALLY RELEASING THE
ELECTRIC PARKING BRAKE

1. Close the driver door.

2. Shift into gear.

3. Press the accelerator pedal and pull away

in a normal manner.

ELECTRIC PARKING BRAKE
AUDIBLE WARNING

Sounds when the parking brake is on and
your vehicle is moving. If the warning tone
continues after you have released the
parking brake, this indicates a malfunction.
Have your vehicle checked as soon as
possible.

RELEASING THE ELECTRIC
PARKING BRAKE IF THE VEHICLE
BATTERY HAS RUN OUT OF
CHARGE

WARNING: The electric parking

brake does not operate if the vehicle
battery has run out of charge.

Connect a booster battery to the vehicle
battery to release the electric parking brake
if the vehicle battery has run out of charge.
See Jump Starting the Vehicle (page 317).

ELECTRIC PARKING BRAKE –
TROUBLESHOOTING

ELECTRIC PARKING BRAKE –
WARNING LAMPS

Brake System

E270480

It illuminates red when you apply
the parking brake and your vehicle
is on.  If the lamp flashes when the
parking brake has been released,
this indicates the parking brake
system requires service.   Have

your vehicle checked as soon as possible.

Note: Lamps may vary depending on region.

Electric Parking Brake

E146190

When the lamp illuminates yellow,
it indicates a malfunction in the
electric parking brake.  Have your

vehicle checked as soon as possible.

224

Electric Parking Brake

ELECTRIC PARKING BRAKE – INFORMATION MESSAGES

Park Brake

Action

Message

The parking brake is set, the engine is running and you drive your vehicle more than 3 mph

(5 km/h). If the warning stays on after the parking brake is released, contact an authorized dealer

as soon as possible.

Park Brake Engaged

The electric parking brake is set and a manual release is attempted without the brake pedal

being pressed.

To Release: Press Brake and Switch

The electric parking brake is set and an automatic release is attempted but cannot be performed.

Perform a manual release.

Park Brake Use Switch to Release

The electric parking brake is set and your vehicle speed exceeds 3 mph (5 km/h). Release park

brake before continued driving.

Release Park Brake

The electric parking brake is not fully applied.

Park Brake Not Applied

The electric parking brake is not fully released.

Park Brake Not Released

The electric parking brake system has been put into a special mode that is used to allow service

of the rear brakes. Contact an authorized dealer.

Park Brake Maintenance Mode

The electric park brake system has detected a condition that requires service. Some functionality

may still be available. Contact your authorized dealer.

Park Brake Limited Function Service

Required

The electric parking brake system has detected a condition that requires service. Contact your

authorized dealer.

Park Brake Malfunction Service Now

225

Electric Parking Brake

Action

Message

Numerous park brake applies have overheated the system. Wait 2 minutes before attempting

to apply again.

Park Brake System Overheated

226

Electric Parking Brake

WHAT IS HILL START ASSIST

Hill Start Assist makes it easier for you to pull
away when your vehicle is on a slope without
using the parking brake.

HOW DOES HILL START ASSIST
WORK

When the system activates, your vehicle
remains stationary for a few seconds after
you release the brake pedal.  This gives you
time to move your foot from the brake pedal
to the accelerator pedal.  The brakes release
when the engine has developed sufficient
torque to prevent your vehicle from rolling
down the slope.

HILL START ASSIST PRECAUTIONS

WARNING: The system does not

replace the parking brake. When you leave
your vehicle, always apply the parking
brake.

WARNING: You must remain in your

vehicle when the system turns on. At all
times, you are responsible for controlling
your vehicle, supervising the system and
intervening, if required. Failure to take care
may result in the loss of control of your
vehicle, serious personal injury or death.

WARNING: The system will turn off

if a malfunction is apparent. Failure to take
care may result in the loss of control of
your vehicle, serious personal injury or
death.

HILL START ASSIST –
TROUBLESHOOTING

HILL START ASSIST – INFORMATION
MESSAGES

Action

Message

Displays when

system is not avail-

able.  Have your

vehicle checked as

soon as possible.

Hill Start Assist Not

Available

227

Hill Start Assist

HOW DOES AUTO HOLD WORK

Auto Hold applies the brakes to hold your
vehicle after you stop it and release the
brake pedal. This can help when waiting on
a hill or in traffic.

SWITCHING AUTO HOLD ON AND
OFF

WARNING: The system does not

replace the parking brake. When you leave
your vehicle, always apply the parking
brake.

WARNING: You must remain in your

vehicle when the system turns on. At all
times, you are responsible for controlling
your vehicle, supervising the system and
intervening, if required. Failure to take care
may result in the loss of control of your
vehicle, serious personal injury or death.

WARNING: The system will turn off

if a malfunction is apparent. Failure to take
care may result in the loss of control of
your vehicle, serious personal injury or
death.

Select the drive assist menu in the center
display screen to switch auto hold on and
off.

Note: You can only switch the system on
after you close the driver door, fasten your
seatbelt and start the engine.

Note: The system remembers the last setting
when you start your vehicle.

Make sure you switch the system off before
towing with your vehicle or before using an
automatic car wash.

USING AUTO HOLD

1. Bring your vehicle to a complete stop.

The auto hold active indicator illuminates
in the information display.

2. Release the brake pedal. The system

holds your vehicle at a standstill. The
auto hold active indicator remains
illuminated in the information display.

3. Pull away in the normal manner.  The

system releases the brakes and the auto
hold active indicator switches off.

Note: The system only activates if you apply
enough brake pressure on the brake pedal.

Note: Under certain conditions, the system
could apply the electric parking brake. The
brake system warning lamp illuminates. The
electric parking brake releases when you
press the accelerator pedal.  See
Automatically Releasing the Electric
Parking Brake (page 224).

Note: The system switches off if you shift
into reverse (R) and press the brake pedal.

There could be actions that can cause the
auto hold system not to work when the
following occur:
•

When you use active park assist.

•

Your vehicle is in stay in neutral mode.

•

The driver door is open.

228

Auto Hold

•

You have not fastened your seatbelt.

•

You shift into reverse (R) before the
system is active.

AUTO HOLD INDICATORS

E197933

Illuminates when the system is
active.

E197934

Illuminates when the system is on
but cannot hold your vehicle at a
standstill at this particular time.

229

Auto Hold
