360 DEGREE CAMERA SETTINGS

SWITCHING THE 360 DEGREE
CAMERA ON AND OFF

E205884

The 360 degree camera system
button is on the instrument panel
and allows you to toggle through

different camera views. The front and rear
cameras have multiple screens which consist
of:

•

Normal view

•

Normal view with 360

•

Split view

When in park (P), neutral (N) or drive (D), only
the front images display when you press the
button. When in reverse (R), only the rear
images display when you press the button.

Note: The 360 degree camera system turns
off when your vehicle is in motion at low
speed, except when in reverse (R).

SWITCHING THE 360 DEGREE
CAMERA VIEW

E224483

Press to access the different
camera views.

E224783

Normal + 360 view: Contains the
normal camera view next to a 360
degree camera view.

E224784

Normal view: Provides an image
of what is directly in front of or
behind your vehicle.

E224785

Split view: Provides an extended
view of what is in front of or behind
your vehicle.

E224485

Zooms in on the image.

296

360 Degree Camera

 (If Equipped)

WHAT IS ACTIVE PARK ASSIST

Assists you with parking in and out of parking
spaces.

SWITCHING ACTIVE PARK ASSIST
ON AND OFF

E326188

P

Press the parking aid button, then
press the active park assist icon
on the touchscreen to bring up full

screen notifications.

Press the soft keys on the touchscreen to
switch between the parallel park in,
perpendicular park in, or parallel park out
parking modes.

Cancelling Active Park Assist

To cancel parking assistance at any time,
shift out of neutral (N).

Pausing Active Park Assist

To pause parking assistance at any time,
release the parking aid button.

If you open the passenger or rear doors,
active park assist pauses.

To resume parking, press and hold the
parking aid button again.

ENTERING A PARALLEL PARKING
SPACE

1. Press the parking aid button.

Note: The system detects other vehicles and
curbs to find a parking space.

2. Press the active park assist icon on the

touchscreen.

3. Select parallel parking.

4. Use the turn signal lever to search for a

parking space on the driver or passenger
side of your vehicle.

Note: If you do not use the turn signal lever,
the system searches for a parking space on
the passenger side of your vehicle.

5. Drive your vehicle approximately 3 ft (1 m)

away from and parallel to the other
parked vehicles when searching for a
parking space.

Note: A tone sounds and a message
appears in the information and
entertainment display when active park
assist finds a suitable parking space.

6. Press and hold the brake pedal.

7. Release the steering wheel and shift into

neutral (N).

8. Press and hold the active park assist

button.

9. Release the brake pedal to allow your

vehicle to park.

Note: You can slow down your vehicle at
any time by pressing the brake pedal.

Note: When parallel parking between
objects, the system parks closer to the object
in front of your vehicle to allow easier access
to the luggage compartment.

Note: When parking is complete, your
vehicle shifts into park (P).

ENTERING A PERPENDICULAR
PARKING SPACE

1. Press the parking aid button.

297

Active Park Assist

 (If Equipped)

Note: Active park assist does not recognize
parking space lines and centers your vehicle
between objects.

2. Press the active park assist icon on the

touchscreen.

3. Select perpendicular parking.

4. Use the turn signal lever to search for a

parking space on the driver or passenger
side of your vehicle.

Note: If you do not use the turn signal lever,
the system searches for a parking space on
the passenger side of your vehicle.

5. Drive your vehicle approximately 3 ft (1 m)

away from and perpendicular to the other
parked vehicles when searching for a
parking space.

Note: A tone sounds and a message
appears in the information and
entertainment display when active park
assist finds a parking space.

6. Press and hold the brake pedal.

7. Release the steering wheel and shift into

neutral (N).

8. Press and hold the active park assist

button.

9. Release the brake pedal to allow the

vehicle to park.

Note: Active park assist backs your vehicle
into parking spaces.

Note: Active park assist aligns the front end
of your vehicle with the lane side of the
object next to it.

Note: When the system detects only one
object, it allows enough distance to open
the door on either side.

Note: You can slow down your vehicle at
any time by pressing the brake pedal.

Note: When parking is complete, your
vehicle shifts into park (P).

EXITING A PARKING SPACE

Active park assist only assists leaving parallel
parking spaces.

1. Press the parking aid button.

2. Press the active park assist icon on the

touchscreen.

3. Select parallel park exit.

4. Use the turn signal to choose the

direction to exit the parking space.

5. Press and hold the brake pedal.

6. Release the steering wheel and shift into

neutral (N).

7. Release the parking brake.

8. Press and hold the active park assist

button.

9. Release the brake pedal to allow your

vehicle to move.

Note: After active park assist drives your
vehicle to a position where you can exit the
parking space in a forward movement, a
message appears instructing you to take full
control of your vehicle.

10.

Take control of your vehicle.

Note: You can slow down your vehicle at
any time by pressing the brake pedal.

298

Active Park Assist

 (If Equipped)

ACTIVE PARK ASSIST –
TROUBLESHOOTING

ACTIVE PARK ASSIST – INFORMATION
MESSAGES

Action

Message

The system requires

service. Have your

vehicle checked as

soon as possible.

Active Park Fault

ACTIVE PARK ASSIST – FREQUENTLY
ASKED QUESTIONS

Why does active park assist not operate
correctly?

The system is unable to detect a vehicle,
curb or object to park next to or in
between. The system needs boundary
objects to operate correctly.

Why does active park assist not search for
a parking space?

You have switched traction control off.

Why does active park assist not search for
a parking space?

The transmission is in reverse (R). Your
vehicle must be moving forward to be
able to detect a parking space.

Why does active park assist not offer a
parking space?

The sensors could be blocked. For
example, snow, ice or large
accumulations of dirt. Blocked sensors
can affect how the system functions.

Why does active park assist not offer a
parking space?

The sensors in the front or rear bumper
could be damaged.

Why does active park assist not offer a
parking space?

There is not enough room in the parking
space for your vehicle to safely park.

Why does active park assist not offer a
parking space?

There is not enough space for the
parking maneuver on the opposite side
of the parking space.

Why does active park assist not offer a
parking space?

The parking space is more than 5 ft
(1.5 m) or less than 2 ft (0.5 m) away from
your vehicle.

Why does active park assist not offer a
parking space?

Your vehicle's speed is greater than
22 mph (35 km/h) for parallel parking or
greater than 19 mph (30 km/h) for
perpendicular parking.

Why does active park assist not offer a
parking space?

You recently disconnected or replaced
the battery. After you reconnect the
battery you must drive your vehicle on
a straight road for a short period of time.

Why does active park assist not correctly
position the vehicle into a parking space?

An irregular curb along the parking
space prevents the system from
correctly aligning your vehicle.

299

Active Park Assist

 (If Equipped)

Why does active park assist not correctly
position the vehicle into a parking space?

Vehicles or objects bordering the space
could not be correctly parked.

Why does active park assist not correctly
position the vehicle into a parking space?

Your vehicle stopped too far past the
parking space.

Why does active park assist not correctly
position the vehicle into a parking space?

The tires are not correctly installed or
maintained. For example, using a spare
tire, not inflated correctly, improper size,
or of different sizes.

Why does active park assist not correctly
position the vehicle into a parking space?

A repair or alteration changed the
detection capabilities.

Why does active park assist not correctly
position the vehicle into a parking space?

A parked vehicle has a high attachment.
For example, a salt sprayer, snowplow
or moving truck bed.

Why does active park assist not correctly
position the vehicle into a parking space?

The parking space length, or position of
parked objects, changes after your
vehicle passes the space.

Why does active park assist not correctly
position the vehicle into a parking space?

The temperature around your vehicle
quickly changes. For example, driving
from a heated garage into a cold outside
temperature, or after leaving a car wash.

300

Active Park Assist

 (If Equipped)

WHAT IS CRUISE CONTROL

Cruise control lets you maintain a set speed
without keeping your foot on the accelerator
pedal.

Requirements

Use cruise control when the vehicle speed
is greater than 20 mph (30 km/h).

SWITCHING CRUISE CONTROL ON
AND OFF

WARNING: Do not use cruise control

on winding roads, in heavy traffic or when
the road surface is slippery. This could
result in loss of vehicle control, serious
injury or death.

The cruise controls are on the steering
wheel.

Switching Cruise Control On

E71340

Press the button to put the system
in standby mode.

Switching Cruise Control Off

E71340

Press the button when in standby
mode or switch the ignition off.

Note: When you switch cruise control off the
set speed clears.

SETTING THE CRUISE CONTROL
SPEED

WARNING: When you are going

downhill, your vehicle speed could
increase above the set speed. The system
does not apply the brakes.

Drive to the speed you prefer.

Press either button to set the
current speed.

Take your foot off the accelerator pedal.

Note: The indicator changes color in the
information display.

Changing the Set Speed

Press and release the button to
increase the set speed in small
increments.

Press and hold the button to accelerate.
Release the button when you reach your
preferred speed.

Press and release the button to
decrease the set speed in small
increments.

Press and hold the button to decelerate.
Release the button when you reach your
preferred speed.

301

Cruise Control

Note:  If you accelerate by pressing the
accelerator pedal, the set speed does not
change. When you release the accelerator
pedal, your vehicle returns to the speed that
you previously set.

CANCELING THE SET SPEED

E281471

Press the button, or tap the brake
pedal to cancel the set speed.

Note: The system remembers the set speed.

Note: The system cancels if the vehicle
speed drops below 10 mph (16 km/h) under
the set speed when driving uphill.

RESUMING THE SET SPEED

E281472

Press the button.

CRUISE CONTROL INDICATORS

E71340

Illuminates when you switch the
system on.

302

Cruise Control

HOW DOES ADAPTIVE CRUISE
CONTROL WITH STOP AND GO
WORK

Adaptive cruise control with stop and go
uses radar and camera sensors to adjust the
speed of your vehicle to maintain a set gap
from the vehicle in front of you in the same
lane while following it to a complete stop.
You can also engage the system to follow a
vehicle in front of you and adjust set speed
while stopped.

WHAT IS ADAPTIVE CRUISE
CONTROL WITH LANE CENTERING

Adaptive cruise control with lane centering
uses radar and camera sensors to help keep
your vehicle in the lane by applying
continuous assistance steering torque input
toward the lane center on highways.

Note: The adaptive cruise control gap setting
operates normally.

WHAT IS INTELLIGENT ADAPTIVE
CRUISE CONTROL

Intelligent adaptive cruise control combines
speed sign recognition with adaptive cruise
control to adjust the cruise set speed to the
speed limit detected by the speed sign
recognition system. For example, if the speed
sign recognition system detects a 50 mph
(80 km/h) speed limit, the cruise set speed
is updated to 50 mph (80 km/h) +/- the
driver's selected speed offset.

Note: The adaptive cruise control gap setting
operates normally.

ADAPTIVE CRUISE CONTROL
PRECAUTIONS - VEHICLES WITH:
ADAPTIVE CRUISE CONTROL
WITH LANE CENTERING

Adaptive cruise control precautions apply to
lane centering unless stated otherwise or
contradicted by a lane centering precaution.
See Adaptive Cruise Control Precautions
(page 304).

WARNING: Do not use the system

when towing a trailer. Failure to follow this
instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING: Do not use the system if

any changes or modifications to the
steering wheel have been made. Any
changes or modifications to the steering
wheel could affect the functionality or
performance of the system. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

303

Adaptive Cruise Control

 (If Equipped)

ADAPTIVE CRUISE CONTROL
PRECAUTIONS - VEHICLES WITH:
ADAPTIVE CRUISE CONTROL
WITH STOP AND GO

WARNING: You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

WARNING: Pay close attention to

changing road conditions such as entering
or leaving a highway, on roads with
intersections or roundabouts, roads
without visible lanes of travel, roads that
are winding, slippery, unpaved, or steep
slopes.

WARNING: The system does not

control speed in low traction conditions or
extremely steep slopes. The system is
designed to be an aid and does not relieve
you of your responsibility to drive with due
care and attention. Failure to follow this
instruction could result in personal injury.

WARNING: The system is not a crash

warning or avoidance system.

WARNING: Do not use the system

when towing a trailer that has aftermarket
electronic trailer brake controls. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

WARNING: Do not use tire sizes

other than those recommended because
this can affect the normal operation of the
system. Failure to do so may result in a loss
of vehicle control, which could result in
serious injury.

WARNING: Do not use the system

with a snow plow blade installed.

WARNING: Do not use the system in

poor visibility, for example fog, heavy rain,
spray or snow.

When Following a Vehicle

WARNING: When following a vehicle

that is braking, your vehicle does not
always decelerate quickly enough to avoid
a crash without driver intervention. Apply
the brakes when necessary. Failure to
follow this instruction could result in
personal injury or death.

304

Adaptive Cruise Control

 (If Equipped)

Hilly Condition Usage

You should select a lower gear when the
system is active in situations such as
prolonged downhill driving on steep grades,
for example in mountainous areas. The
system needs additional engine braking in
these situations to reduce the load on the
vehicle’s regular brake system to prevent it
from overheating.

Note: An audible alarm sounds and the
system shuts down if it applies brakes for an
extended period of time. This allows the
brakes to cool. The system functions
normally again after the brakes cool.

ADAPTIVE CRUISE CONTROL
LIMITATIONS - VEHICLES WITH:
ADAPTIVE CRUISE CONTROL
WITH LANE CENTERING

Adaptive cruise control limitations apply to
lane centering unless stated otherwise or
contradicted by a lane centering limitation.
See Adaptive Cruise Control Limitations
(page 305).

The system may not correctly operate in any
of the following conditions:
•

The lane is too narrow or wide.

•

The system does not detect at least one
lane marking or when lanes merge or
split.

•

Limited steering torque input is applied.

•

Areas under construction or new
infrastructure.

•

When modifications to the steering
system have been made.

•

When using a spare tire.

Note: The driving assistance torque is limited
and may not be sufficient for all driving
situations such as driving through tight
curves or driving through curves at high
speeds.

Note: In exceptional conditions, the system
may deviate from the center line.

ADAPTIVE CRUISE CONTROL
LIMITATIONS - VEHICLES WITH:
ADAPTIVE CRUISE CONTROL
WITH STOP AND GO

Sensor Limitations

WARNING: On rare occasions,

detection issues can occur due to the road
infrastructures, for example bridges,
tunnels and safety barriers. In these cases,
the system may brake late or
unexpectedly. At all times, you are
responsible for controlling your vehicle,
supervising the system and intervening, if
required.

WARNING: If the system

malfunctions, have your vehicle checked
as soon as possible.

WARNING: Large contrasts in outside

lighting can limit sensor performance.

305

Adaptive Cruise Control

 (If Equipped)

WARNING: The system only warns

of vehicles detected by the radar sensor.
In some cases there may be no warning
or a delayed warning. Apply the brakes
when necessary. Failure to follow this
instruction could result in personal injury
or death.

WARNING: The system may not

detect stationary or slow moving vehicles
below 6 mph (10 km/h).

WARNING: The system does not

detect pedestrians or objects in the road.

WARNING: The system does not

detect oncoming vehicles in the same lane.

WARNING: The system may not

operate properly if the sensor is blocked.
Keep the windshield free from obstruction.

WARNING: The sensor may

incorrectly track lane markings as other
structures or objects. This can result in a
false or missed warning.

E307893

The camera is mounted on the windshield
behind the interior mirror.

E307892

The radar sensor is in the lower grille.

Note: You cannot see the sensor. It is behind
a fascia panel.

Note: Keep the front of your vehicle free of
dirt, metal badges or objects. Vehicle front
protectors, aftermarket lights, additional
paint or plastic coatings could also degrade
sensor performance.

A message displays if something obstructs
the camera or the sensor. When something
blocks the sensor, the system cannot detect
a vehicle ahead and does not function.  See
Adaptive Cruise Control – Information
Messages (page 314).

The radar sensor has a limited field of view.
It may not detect vehicles at all or detect a
vehicle later than expected in some
situations. The lead vehicle image does not
illuminate if the system does not detect a
vehicle in front of you.

306

Adaptive Cruise Control

 (If Equipped)

Detection issues can occur:

E71621

When driving on a different line
than the vehicle in front.

A

B

With vehicles that edge into your
lane. The system can only detect
these vehicles once they move
fully into your lane.

There may be issues with the
detection of vehicles in front when
driving into and coming out of a
bend or curve in the road.

C

In these cases, the system may brake late or
unexpectedly.

If something hits the front end of your vehicle
or damage occurs, the radar-sensing zone
may change. This could cause missed or
false vehicle detection.

Optimal system performance requires a clear
view of the road by the windshield-mounted
camera.

Optimal performance may not occur if:

•

The camera is blocked.

•

There is poor visibility or lighting
conditions.

•

There are bad weather conditions.

SWITCHING ADAPTIVE CRUISE
CONTROL ON AND OFF

The cruise controls are on the steering
wheel.

Switching Adaptive Cruise Control On

E144529

Press the button to set the system
in standby mode.

The indicator, current gap setting and set
speed appear in the information display.

Switching Adaptive Cruise Control Off

E144529

Press the button when the system
is in standby mode, or switch the
ignition off.

Note: You erase the set speed when you
switch the system off.

Automatic Cancellation or Deactivation

The system may cancel if:
•

The tires lose traction.

•

You apply the parking brake.

307

Adaptive Cruise Control

 (If Equipped)

The system may cancel and set the parking
brake if:
•

You unbuckle the seatbelt and open the
driver door after you stop your vehicle.

•

Your vehicle is at a stop continuously for
more than three minutes.

The system may turn off or prevent activating
when requested if:
•

The vehicle has a blocked sensor.

•

The brake temperature is too high.

•

There is a failure in the system or a
related system.

SETTING THE ADAPTIVE CRUISE
CONTROL SPEED

Drive to the speed you prefer.

Press either button to set the
current speed.

Take your foot off the accelerator pedal.

The indicator, current gap setting and set
speed appear in the information display.

E255686

A vehicle image illuminates if there is a
vehicle detected in front of you.

Note: When adaptive cruise control is active,
the speedometer may vary slightly from the
set speed displayed in the information
display.

Setting the Adaptive Cruise Speed
from a Complete Stop

Press and release either button
while keeping the brake pedal fully
pressed.

The set speed adjusts to 20 mph (30 km/h).

The indicator, current gap setting and set
speed appear in the information display.

Note: The system activates from a complete
stop only when it detects a lead vehicle in
close proximity.

Manually Changing the Set Speed

Press and release to increase the
set speed in small increments.

Press and release to decrease the
set speed in small increments.

Press and hold either button to change the
set speed in large increments. Release the
button when the set speed shown is equal
to the speed you prefer.

Press the accelerator or brake pedal until
you reach the speed you prefer. Press either
button to select the current speed as the set
speed.

The system may apply the brakes to slow
the vehicle to the new set speed.  The set
speed displays continuously in the
information display when the system is
active.

308

Adaptive Cruise Control

 (If Equipped)

SETTING THE ADAPTIVE CRUISE
CONTROL GAP

Press the button to cycle through
the four gap settings.

E255686

The selected gap appears in the instrument
cluster display as shown by the bars in the
image.

Note: The gap setting is time dependent and
therefore, the distance adjusts with your
vehicle speed.

Note: It is your responsibility to select a gap
appropriate to the driving conditions.

Adaptive Cruise Control Gap Settings

Dynamic

Behavior

Gap Distance

Graphic
Display,

Bars Indic-

ated

Between

Vehicles

Sport.

Closest.

1

Normal.

Close.

2

Normal.

Medium.

3

Comfort.

Far.

4

Each time you switch the system on, it
selects the last chosen gap setting.

Following a Vehicle

When a vehicle ahead of you enters the
same lane or a slower vehicle is ahead in the
same lane, the vehicle speed adjusts to
maintain the gap setting.

Note: When you are following a vehicle and
you switch on a turn signal lamp, adaptive
cruise control may provide a small,
temporary acceleration to help you pass.

Your vehicle maintains a consistent gap from
the vehicle ahead until:
•

The vehicle in front of you accelerates to
a speed above the set speed.

•

The vehicle in front of you moves out of
the lane you are in.

•

You set a new gap distance.

The system applies the brakes to slow down
your vehicle to maintain a safe gap distance
from the vehicle in front of you.  The system
only applies limited braking.  You can
override the system by applying the brakes.

Note: The brakes may emit noise when
applied by the system.

If the system determines that its maximum
braking level is not sufficient, an audible
warning sounds, a message appears in the
instrument cluster display and an indicator
flashes when the system continues to brake.
Take immediate action.

309

Adaptive Cruise Control

 (If Equipped)

CANCELING THE SET SPEED

E281471

Press the button or tap the brake
pedal.

The set speed does not erase.

RESUMING THE SET SPEED

E281472

Press the button.

Your vehicle speed returns to the previously
set speed and gap setting.  The set speed
displays continuously in the information
display when the system is active.

Note: Only use resume if you are aware of
the set speed and intend to return to it.

Resuming the Set Speed from a
Complete Stop

If your vehicle follows a vehicle to a complete
stop and remains stationary for less than
three seconds, your vehicle accelerates from
a stationary position to follow the vehicle
ahead.

E281472

If your vehicle follows a vehicle to
a complete stop and remains
stationary for more than three

seconds, press and release the button or
press the accelerator pedal to follow the
vehicle ahead.

OVERRIDING THE SET SPEED

WARNING: If you override the system

by pressing the accelerator pedal, it does
not automatically apply the brakes to
maintain a gap from any vehicle ahead.

When you press the accelerator pedal, you
override the set speed and gap distance.

Use the accelerator pedal to intentionally
exceed the set speed limit.

When you override the system, the green
indicator illuminates and the vehicle icon
does not appear in the instrument cluster
display.

The system resumes operation when you
release the accelerator pedal. The vehicle
speed decreases to the set speed, or a lower
speed if following a slower vehicle.

ADAPTIVE CRUISE CONTROL
INDICATORS - VEHICLES WITH:
ADAPTIVE CRUISE CONTROL
WITH LANE CENTERING

E262175

Illuminates when you switch lane
centering on. The color of the
indicator changes to indicate the

system status.

Gray indicates the system is on but inactive.

Green indicates the system is active and
applying assistance steering torque input to
keep your vehicle in the center of the lane.

Amber with an audible tone and then gray
indicates a system auto-cancellation.

310

Adaptive Cruise Control

 (If Equipped)

ADAPTIVE CRUISE CONTROL
INDICATORS - VEHICLES WITH:
ADAPTIVE CRUISE CONTROL
WITH STOP AND GO

E144529

Illuminates when you switch
adaptive cruise control on. The
color of the indicator changes to

indicate the system status.

White indicates the system is on but inactive.

Green indicates that you set the speed and
the system is active.

ADAPTIVE CRUISE CONTROL
INDICATORS - VEHICLES WITH:
INTELLIGENT ADAPTIVE CRUISE
CONTROL

E292490

A bracket appears around the set speed and
the detected speed limit sign in the
information display.

System Warnings

If the set speed is increased beyond the
speed limit or speed limit plus a positive
tolerance value, the set speed indicator
flashes.

The warning does not occur if:
•

You override the set speed using the
accelerator pedal.

•

The vehicle speed exceeds the set speed
due to being on a downhill slope.

SWITCHING FROM ADAPTIVE
CRUISE CONTROL TO CRUISE
CONTROL

WARNING: Normal cruise control will

not brake when your vehicle is
approaching slower vehicles. Always be
aware of which mode you have selected
and apply the brakes when necessary.

Use the touchscreen to select the following:

1. Select Settings.

2. Select Driver Assist.

3. Select Cruise Control.

4. Select Normal.

311

Adaptive Cruise Control

 (If Equipped)
