Lincoln MKZ (2020 year). Manual in english - page 24

Materials

Specification

Name

WSS-M2C953-B1

Engine Oil - SAE 0W-30

E240523

387

Capacities and Specifications

Fuel Tank

Capacities

Quantity

Variant

18.0 gal (68.1 L)

All.

Grease

Materials

Specification

Name

ESB-M1C93-B

Motorcraft® Multi-Purpose Grease Spray (U.S.)
Motorcraft® Multi-Purpose Grease Spray / Graisse tout usage en aérosol Motorcraft®
(Canada)
XL-5-A (U.S. & Canada)

388

Capacities and Specifications

Hydraulic Brake System

Note: We recommend using DOT 4 Low
Viscosity (LV) High Performance Brake Fluid
or equivalent meeting WSS-M6C65-A2. Use
of any fluid other than the recommended
fluid could cause reduced brake
performance and not meet our performance
standards. Keep brake fluid clean and dry.
Contamination with dirt, water, petroleum
products or other materials could result in
brake system damage and possible failure.

Materials

Specification

Name

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid (U.S.)
Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid / Liquide de
frein automobile haute performance DOT 4 LV Motorcraft® (Canada)
PM-20 (U.S. & Canada)

Locks

389

Capacities and Specifications

Materials

Specification

Name

-

Motorcraft® Penetrating and Lock Lubricant (U.S.)
Motorcraft® Penetrating Fluid / Liquide dégrippant Motorcraft® (Canada)
XL-1 (U.S.)
CXC-51-A (Canada)

Power Transfer Unit

Capacities

Quantity

Variant

23.7 fl oz (0.7 L)

All.

Materials

Specification

Name

WSL-M2C192-A

Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant (U.S.)
Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant / Lubrifiant synthétique
pour pont arrière SAE 75W-140 Motorcraft® (Canada)
XY-75W140-QL (U.S.)
CXY-75W140-1L (Canada)

390

Capacities and Specifications

Rear Axle

Capacities

Quantity

Variant

21.0 fl oz (0.62 L)

All.

Materials

Specification

Name

WSP-M2C197-A

Motorcraft® SAE 80W-90 Premium Rear Axle Lubricant (U.S.)
Motorcraft® SAE 80W-90 Premium Axle Lubricant / Lubrifiant pour essieux de très
haute qualité SAE 80W-90 Motorcraft® (Canada)
XY-80W90-QL (U.S.)
CXY-80W90-1L (Canada)

Washer Reservoir

Capacities

Quantity

Variant

Fill as required.

All.

391

Capacities and Specifications

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concentrate with Bitterant (U.S.)
Motorcraft® Premium Quality Windshield Washer Fluid / Liquide lave-glace de haute
qualité Motorcraft® (Canada)
ZC-32-B2 (U.S.)
CXC-37-A/B/D/F (Canada)

BULB SPECIFICATION CHART

Replacement bulbs are specified in the chart
below. Headlamp bulbs must be marked with
an authorized “D.O.T.” for North America to
make sure they have the proper lamp
performance, light brightness, light pattern,
and safe visibility. The correct bulbs will not
damage the lamp assembly or void the lamp
assembly warranty and will provide quality
bulb illumination time.

392

Capacities and Specifications

Trade name

Function

LED

Headlamp high beam - high series

HID

Headlamp high beam - low series

LED

Headlamp low beam - high series

HID

Headlamp low beam - low series

LED

Side marker lamp - front

LED

Park lamp - front

LED

Signature lamp

LED

Daytime running lamp

LED

Turn lamp - front

LED

Tail and brake lamp

LED

Reverse lamp

LED

Turn lamp - rear

LED

Side marker lamp - rear

LED

License plate lamp

LED

Trunk lamp

393

Capacities and Specifications

Trade name

Function

LED

High-mount brake lamp

LED

Side repeater lamp

LED

Glove compartment lamp

LED

Interior lamp

To replace any bulb, see your authorized dealer.

394

Capacities and Specifications

CONNECTED VEHICLE
REQUIREMENTS

Connected service and related feature
functionality requires a compatible vehicle
network.

Some remote features require a subscription.
For additional information, see the FordPass
app. Some restrictions, third party terms and
message or data rates may apply.

CONNECTED VEHICLE
LIMITATIONS

Evolving technology or evolving cellular
networks could affect functionality and
availability, or continued provision of some
features. These changes could even stop
some features from functioning.

CONNECTING THE VEHICLE TO A
MOBILE NETWORK

What Is the Modem

The modem enables access to a
range of features built into your
vehicle.

Enabling and Disabling the Modem

1. Select Settings.
2. Select FordPass Connect.

3. Select Connectivity Settings.

4. Switch connectivity features on or off.

Connecting Lincoln Way to the Modem

1. Make sure that the modem is enabled

using the vehicle settings menu.

2. Open the Lincoln way app on your device

and log in.

3. Add your vehicle or select your vehicle

if already added.

4. Select the option for vehicle details.

5. Select the option to activate your vehicle.

6. Make sure that the name on the screen

matches the name shown in your Lincoln
Way account.

7. Confirm that your Lincoln Way account

is connected to the modem.

CONNECTING THE VEHICLE TO A
WI-FI NETWORK

1. Select Settings.
2. Select Wi-Fi.

3. Switch System Wi-Fi on.

4. Select View Available Networks.
5. Select an available Wi-Fi network.

Note: Enter the network password to
connect to a secure network.

395

Connected Vehicle

CONNECTED VEHICLE – TROUBLESHOOTING

Possible Cause and Resolution

Symptom

I cannot connect to a Wi-Fi network.

– Password error.

•

Enter the correct network password.

– Weak network signal.

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

– Multiple access points in range with the same SSID.

•

Use a unique name for your SSID. Do not use the default name unless it contains a
unique identifier, for example as part of the MAC address.

The Wi-Fi connection disconnects after
successful connection.

– Weak network signal.

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

I am close to a Wi-Fi hotspot but the network
signal strength is weak.

– Obstructed network signal.

•

If your vehicle has a heated windshield, position your vehicle so that the windshield
is not facing the Wi-Fi hotspot.

•

If your vehicle has metallic tinting on the windows but not on the windshield, position
your vehicle so that the windshield is facing the Wi-Fi hotspot or open the windows
that are facing the hotspot.

•

If your vehicle has metallic tinting on the windows and the windshield, open the
windows that are facing the hotspot.

396

Connected Vehicle

Possible Cause and Resolution

Symptom

If your vehicle is in a garage and you have the garage door closed, open the garage
door.

•

I cannot see a network in the list of available
networks that I expect to see.

– Hidden network.

•

Make the network visible and try again.

I cannot see the Wi-Fi hotspot name when I
search for Wi-Fi networks on my cell phone
or other device.

– System limitation.

•

Make sure Wi-Fi hotspot visibility is on.

•

The system does not provide a Wi-Fi hotspot at this time.

– Weak network signal

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

– Wi-Fi hotspot in high demand or has a slow Internet connection.

•

Use a more reliable Wi-Fi hotspot.

Software downloads take too long.

– No software update available.
– Wi-Fi network requires a subscription or acceptance of terms and conditions.

•

Test the connection using another device. If the network requires a subscription or
acceptance of terms and conditions, contact the network service provider.

The system seems to connect to a Wi-Fi
network and the signal strength is excellent
but the software does not update.

397

Connected Vehicle

CREATING A WI-FI HOTSPOT

You can create a Wi-Fi hotspot in your
vehicle and allow devices to connect to it for
access to the Internet.

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect.
2. Select Vehicle Hotspot.
Note: The vehicle hotspot default setting is
on.

Finding the Wi-Fi Hotspot Name and
Password

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect.

2. Select Vehicle Hotspot.

3. Select Settings.

Note: The SSID is the hotspot name.

4. Select View Password.

Connecting a Device to the Wi-Fi
Hotspot

1. On your device, turn on Wi-Fi and select

the hotspot from the list of available Wi-Fi
networks.

2. When prompted, enter the password.

Purchasing a Data Plan

1. Connect a device to the hotspot.
Note: The vehicle network carrier’s portal
opens on your device.

2. If the portal does not open on your

device, open a website and it redirects
to the vehicle network carrier’s portal.

Note: Secure websites do not redirect.

3. Follow the instructions on the carrier

portal to purchase a plan.

Note: If you have an active plan, the system
does not redirect to the vehicle network
carrier’s portal when you connect a device.
Visit the vehicle network carrier’s website to
purchase more data.

Note: If data usage information is available
in the vehicle hotspot menu, it is
approximate.

Note: If you carry out a master reset, the
system does not remove your vehicle from
your vehicle network carrier’s account. To
remove your vehicle from the account,
contact your vehicle network carrier.

Note: The vehicle network carrier provides
Vehicle Hotspot services, subject to your
vehicle network carrier agreement, coverage
and availability.

CHANGING THE WI-FI HOTSPOT
NAME OR PASSWORD

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect .

2. Select Vehicle Hotspot.

3. Select Settings.

4. Select Edit .

5. Select Change SSID Name.

398

Wi-Fi Hotspot

6. Enter your required SSID.

7. Select Done.
8. Select Change Password .

9. Enter your required password.

10.

Select Done.

399

Wi-Fi Hotspot

GENERAL INFORMATION

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the

road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Radio Frequencies and Reception
Factors

Note: Listening to loud audio for long
periods of time could damage your hearing.

Radio Reception Factors

The further you travel from an AM or FM station, the weaker the signal and the weaker the reception.

Distance and strength

Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and
thunderstorms can interfere with the reception.

Terrain

When you pass a ground-based broadcast repeating tower, a stronger signal may overtake a weaker one and
result in the audio system muting.

Station overload

400

Audio System

AUDIO UNIT

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

E287755

Note: Depending on your vehicle option
package, the controls may look different
from what you see here.

Note: Some features, such as satellite radio,
may not be available in your location. Check
with an authorized dealer.

Note:  The touchscreen system controls most
of the audio features.

Adjusting the Volume

E265373

Turn to adjust the volume.

Changing Radio Stations

E265696

In radio mode, turn to search through the
radio frequency band.

In satellite radio mode, turn to find the
previous or next available satellite radio
station.

Ejecting the CD

 (If Equipped)

E265032

Press and release the button to
eject a CD.

401

Audio System

Inserting a CD

 (If Equipped)

Insert a CD into the CD slot.

Playing or Pausing Media

 (If Equipped)

Press and release the button to
either play or pause the audio.

Selecting the Audio Modes

E265276

Press and release the button to
access different audio modes, for
example AM, FM and CD.

Switching the Audio Unit On and Off

Press and release the button.

Using Seek, Fast Forward and Reverse

In radio mode, select a frequency band and
press and release either button. The system
stops at the first station it finds in that
direction.

In CD mode, press and release to select the
next or previous track. Press and hold to
move quickly forward or backward through
the current track.

In satellite radio mode, press and release to
select the next or previous satellite radio
station. If you select a specific category, such
as jazz, rock or news, press to find the next
or previous station in the category you select.

DIGITAL RADIO

 (IF EQUIPPED)

Note: HD Radio broadcasts are not available
in all markets.

HD Radio technology is the digital evolution
of analog AM/FM radio. Your system has a
special receiver that allows it to receive
digital broadcasts, where available, in
addition to the analog broadcasts, it already
receives. Digital broadcasts provide a better
sound quality than analog broadcasts with
free, crystal-clear audio and no static or
distortion. For more information, and a guide
to available stations and programming,
please visit www.hdradio.com.

When HD Radio is on and you tune to a
station broadcasting HD Radio technology,
you may notice the HD Radio logo on your
screen. When this logo is available, you may
also see Title and Artist fields on-screen.

The multicast indicator appears in FM mode,
only, if the current station is broadcasting
multiple digital broadcasts. The highlighted
numbers signify available digital channels
where new or different content is available.
HD1 signifies the main programming status
and is available in analog and digital
broadcasts. Other multicast stations, HD2
through HD7, are only available digitally.

402

Audio System
