24

GETTING TO KNOW YOUR VEHICLE



Le présent appareil est conforme aux CNR

d`Innovation, Science and Economic Develop-

ment applicables aux appareils radio exempts

de licence. L'exploitation est autorisée aux deux

conditions suivantes:

1. l'appareil ne doit pas produire de brouil-

lage, et

2. l'utilisateur de l'appareil doit accepter tout

brouillage radioélectrique subi, même si le

brouillage est susceptible d'en comprom-

ettre le fonctionnement.

La operación de este equipo está sujeta a las

siguientes dos condiciones:

1. es posible que este equipo o dispositivo no

cause interferencia perjudicial y

2. este equipo o dispositivo debe aceptar cual-

quier interferencia, incluyendo la que

pueda causar su operación no deseada.

NOTE:

Changes or modifications not expressly

approved by the party responsible for compli-

ance could void the user’s authority to operate

the equipment.

Child-Protection Door Lock System — Rear

Doors

To Engage The Child-Protection Door Lock

System
To provide a safer environment for small chil-

dren riding in the rear seats, the rear doors are

equipped with a Child-Protection Door Lock

system.

1. Open the rear door.

2. Insert the tip of the emergency key (or alike)

into the child lock control and rotate it to the

lock position.

Child-Protection Door Lock Location

Child-Protection Door Lock Function

3. Repeat steps 1 and 2 for the opposite rear

door.

NOTE:

When the Child-Protection Door lock system is

engaged, the door can be opened only by using

the outside door handle even though the inside

door lock is in the unlocked position.

GETTING TO KNOW YOUR VEHICLE

25

NOTE:

After engaging the Child-Protection Door

Lock system, always test the door from the

inside to make certain it is in the desired

position.

For emergency exit with the system

engaged, move the lock knob up to the

unlock position, open the window, and

open the door with the outside door

handle.

To Disengage The Child-Protection Door Lock

System

1. Open the rear door.

2. Insert the tip of the emergency key (or alike)

into the child lock control and rotate it to the

unlock position.

Child-Protection Door Lock Function

3. Repeat steps 1 and 2 for the opposite rear

door.

NOTE:

After disengaging the Child-Protection Door

Lock system, always test the door from the

inside to make certain it is in the desired

position.

SEATS

Seats are a part of the Occupant Restraint

System of the vehicle.

WARNING!

Avoid trapping anyone in a vehicle in a

collision. Remember that the rear doors can

only be opened from the outside when the

Child-Protection locks are engaged. Failure to

follow this warning may result in serious injury

or death.

WARNING!

It is dangerous to ride in a cargo area,

inside or outside of a vehicle. In a collision,

people riding in these areas are more likely

to be seriously injured or killed.

Do not allow people to ride in any area of

your vehicle that is not equipped with seats

and seat belts. In a collision, people riding

in these areas are more likely to be seri-

ously injured or killed.

Be sure everyone in your vehicle is in a seat

and using a seat belt properly.

2

26

GETTING TO KNOW YOUR VEHICLE



Manual Adjustment (Front Seats)

Forward/Rearward Adjustment

For models equipped with manual seats, the

driver and passenger seats can be adjusted

forward or rearward by using a bar located by

the front of the seat cushion, near the floor.

Forward/Rearward Seat Adjustment Bar

While sitting in the seat, lift up on the bar and

move the seat forward or rearward. Release the

bar once the desired position has been

reached. Then, using body pressure, move

forward and rearward on the seat to be sure

that the seat adjusters have latched.

Driver's Seat Height Adjustment

— If Equipped

The seat height control lever is located on the

outboard side of the seat. Raise the lever to

raise the seat. Lower the lever to lower the seat.

The total seat travel is approximately 2.5 inches

(64 mm).

Seat Height Adjustment Lever

WARNING!

Adjusting a seat while the vehicle is moving

is dangerous. The sudden movement of the

seat could cause you to lose control. The

seat belt might not be adjusted properly

and you could be injured. Adjust the seat

only while the vehicle is parked.

Do not ride with the seatback reclined so

that the shoulder belt is no longer resting

against your chest. In a collision you could

slide under the seat belt and be seriously or

even fatally injured. Use the recliner only

when the vehicle is parked.

WARNING!

Adjusting a seat while driving may be

dangerous. Moving a seat while driving

could result in loss of control which could

cause a collision and serious injury or

death.

Seats should be adjusted before fastening

the seat belts and while the vehicle is

parked. Serious injury or death could result

from a poorly adjusted seat belt.

GETTING TO KNOW YOUR VEHICLE

27

(Continued)

Recliner Adjustment

The recline lever is located on the outboard side

of the seat. To recline the seat, lean forward

slightly, lift the lever, lean back to the desired

position and release the lever. To return the

seatback to its normal upright position, lean

forward and lift the lever. Release the lever

once the seatback is in the upright position.

Recline Lever

Manual Adjustment (Rear Seats)

To provide additional storage area, each

second-row passenger seat can be folded flat.

This allows for extended cargo space and still

maintains some seating room if needed.

NOTE:

Prior to folding the second-row passenger seat,

make sure the front seatback is not in a reclined

position. This will allow the second-row seat to

fold easily.

WARNING!

Adjusting a seat while the vehicle is moving

is dangerous. The sudden movement of the

seat could cause you to lose control. The

seat belt might not be adjusted properly

and you could be injured. Adjust the seat

only while the vehicle is parked.

Do not ride with the seatback reclined so

that the shoulder belt is no longer resting

against your chest. In a collision you could

slide under the seat belt and be seriously or

even fatally injured. Use the recliner only

when the vehicle is parked.

WARNING!

Do not pile luggage or cargo higher than the

top of the seatback. This could impair

visibility or become a dangerous projectile in

a sudden stop or collision.

WARNING!

 (Continued)

WARNING!

It is extremely dangerous to ride in a cargo

area, inside or outside of a vehicle. In a

collision, people riding in these areas are

more likely to be seriously injured or killed.

Do not allow people to ride in any area of

your vehicle that is not equipped with seats

and seat belts.

Be sure everyone in your vehicle is in a seat

and using a seat belt properly.

On seven passenger models, do not allow a

passenger to sit in a third row seat with the

second row seatback(s) folded flat. In a

collision, the passenger could slide under-

neath the seat belt and be seriously or even

fatally injured.

2

28

GETTING TO KNOW YOUR VEHICLE



(Continued)

Forward And Rearward Adjustment

The control lever is on the outboard side of the

seat. Lift the lever to move the seat forward or

rearward. Release the lever once the seat is in

the desired position. Then, using body pressure,

move forward and rearward on the seat to be

sure that the seat adjusters have latched.

Manual Seat Adjustment

Recliner Adjustment

The recline lever is on the outboard side of the

seat. To recline the seatback, lean back, lift the

lever, position the seatback as desired, and

then release the lever. To return the seatback to

its normal upright position, lean back, lift the

lever, lean forward, and then release the lever

once the seatback is in the upright position.

Recline Lever

Stadium Tip 'n Slide (Easy Entry/Exit Seat) —

Seven Passenger Models

This feature allows passengers to easily enter or

exit the third-row passenger seats from either

side of the vehicle.
To Move The Second-Row Passenger Seat

Forward

NOTE:

Raise the seatback/armrest before moving the

seat to allow for full seat travel.

WARNING!

Adjusting a seat while the vehicle is moving is

dangerous. The sudden movement of the

seat could cause you to lose control. The seat

belt might not be adjusted properly and you

could be injured. Adjust any seat only while

the vehicle is parked.

WARNING!

Adjusting a seat while the vehicle is moving

is dangerous. The sudden movement of the

seat could cause you to lose control. The

seat belt might not be adjusted properly

and you could be injured. Adjust the seat

only while the vehicle is parked.

Do not ride with the seatback reclined so

that the shoulder belt is no longer resting

against your chest. In a collision you could

slide under the seat belt and be seriously or

even fatally injured. Use the recliner only

when the vehicle is parked.

WARNING!

 (Continued)

GETTING TO KNOW YOUR VEHICLE

29

Move the control lever on the upper outboard

side of the seatback forward. Then, in one fluid

motion, the seat cushion flips upward and the

seat moves forward on its tracks.

Tip 'n Slide Control Lever

Tip 'n Slide Seat

NOTE:

A hand-grip is molded into the front of each

quarter trim panel near the door opening to

assist entry and exit from the third-row

passenger seats.

To Unfold And Move The Second-Row

Passenger Seat Rearward
Move the seatback rearward until it locks in

place and then continue sliding the seat rear-

ward on its tracks until it locks in place.
Push the seat cushion downward to lock it in

place.
Adjust the seat track position as desired. Using

body pressure, move forward and rearward on

the seat to be sure that the seat adjusters have

latched.

Manual Folding Second Row Seat

To Fold The Seat

1. Locate the control lever on the lower

outboard side of the seat.

Seatback Release

WARNING!

Do not drive the vehicle with the seat in this

position, as it is only intended for entering

and exiting the third row seats. Failure to

follow this warning may result in personal

injury.

WARNING!

Be certain that the seatback is securely

locked into position. If the seatback is not

securely locked into position the seat will not

provide the proper stability for child seats

and/or passengers. An improperly latched

seat could cause serious injury.

2

30

GETTING TO KNOW YOUR VEHICLE



2. Place one hand on the seatback and apply

a gentle pressure.

3. Lift the control lever with the other hand,

allow the seatback to move forward slightly,

and then release the lever.

4. Gently guide the seatback into the folded

position.

NOTE:

You may experience deformation in the seat

cushion from the seat belt buckles if the seats

are left folded for an extended period of time.

This is normal and by simply opening the seats

to the open position, over time the seat cushion

will return to its normal shape.

To Unfold The Seat
Raise the seatback and lock it in place.

Manual Folding Third Row Seats

To provide additional storage area, each

third-row passenger seatback can be folded

flat. This allows for extended cargo space and

still maintains some rear seating room if

needed.

NOTE:

Prior to folding the third-row passenger seat-

back, make sure the second-row passenger

seatback is not in a reclined position. This will

allow the seatback to fold easily.

To Fold The Seatback
Pull the latch release-loop located at the top of

the seatback upward, push the seatback

forward slightly, and release the release-loop.

Then, continue to push the seatback forward.

The head restraints will fold automatically as

the seatback moves forward.

Seatback Release

NOTE:

You may experience deformation in the seat

cushion from the seat belt buckles if the seats

are left folded for an extended period of time.

This is normal and by simply opening the seats

to the open position, over time the seat cushion

will return to its normal shape.

WARNING!

To prevent personal injury or damage to

objects, keep your head, arms, and objects

out of the folding path of the seatback.

WARNING!

Be certain that the seatback is securely

locked into position. If the seatback is not

securely locked into position the seat will not

provide the proper stability for child seats

and/or passengers. An improperly latched

seat could cause serious injury.

GETTING TO KNOW YOUR VEHICLE

31

To Unfold The Seatback
Grasp the assist strap loop on the seatback and

pull it toward you to raise the seatback.

Continue to raise the seatback until it locks in

place. Raise the head restraint to lock it in

place.

Assist Strap

The seatback can also be locked in the reclined

position. To do so, pull the latch release-loop

located at the top of the seatback upward, allow

the seatback to recline, and release the

release-loop.

Power Adjustment (Front Seat)

The power seat switch is on the outboard side of

the seat near the floor. Use this switch to move

the seat up, down, forward, rearward or to tilt

the seat.

Power Seat Switch

Adjusting The Seat Forward Or Rearward

The seat can be adjusted both forward and rear-

ward. Push the seat switch forward or rearward,

and the seat will move in the direction of the

switch. Release the switch when the desired

position has been reached.

WARNING!

Be certain that the seatback is locked

securely into position. Otherwise, the seat

will not provide the proper stability for

passengers. An improperly latched seat

could cause serious injury.

Do not allow a passenger to sit in a third

row seat without having the head restraint

unfolded and locked in place. Failure to

follow this warning may result in personal

injury to the passenger in the event of a

collision.

Do not allow a passenger to sit in a third

row seat with the second row seatback(s)

folded flat. In a collision, the passenger

could slide underneath the seat belt and be

seriously or even fatally injured.

2

32

GETTING TO KNOW YOUR VEHICLE



(Continued)

Adjusting The Seat Up Or Down

The height of the seats can be adjusted up or

down. Pull upward or push downward on the

rear of seat switch, the seat will move in the

direction of the switch. Release the switch when

the desired position has been reached.

Tilting The Seat Up Or Down

The angle of the seat cushion can be adjusted

in four directions. Pull upward or push down-

ward on the front or rear of the seat switch; the

front or rear of the seat cushion will move in the

direction of the switch. Release the switch when

the desired position is reached.

Power Lumbar — If Equipped

The Power Lumbar switch is located on the

outboard side of the driver's seat. Push the

switch forward to increase the lumbar support.

Push the switch rearward to decrease the

lumbar support. Pushing upward or downward

on the switch will raise or lower the position of

the support.

Power Lumbar Switch

Front Heated Seats — If Equipped

The front heated seats control buttons are

located within the Uconnect system. You can

gain access to the control buttons through the

climate screen or the controls screen.

Press the heated seat button   once to turn

the HI setting on.

Press the heated seat button   a second

time to turn the LO setting on.

Press the heated seat button   a third time

to turn the heating elements off.

WARNING!

Adjusting a seat while driving may be

dangerous. Moving a seat while driving

could result in loss of control which could

cause a collision and serious injury or

death.

Seats should be adjusted before fastening

the seat belts and while the vehicle is

parked. Serious injury or death could result

from a poorly adjusted seat belt.

Do not ride with the seatback reclined so

that the shoulder belt is no longer resting

against your chest. In a collision you could

slide under the seat belt, which could result

in serious injury or death.

CAUTION!

Do not place any article under a power seat

or impede its ability to move as it may cause

damage to the seat controls. Seat travel may

become limited if movement is stopped by an

obstruction in the seat's path.

WARNING!

 (Continued)

GETTING TO KNOW YOUR VEHICLE

33

If the HI-level setting is selected, the system will

automatically switch to LO-level after approxi-

mately 60 minutes of continuous operation. At

that time, the display will change from HI to LO,

indicating the change. The LO-level setting will

turn off automatically after approximately

45 minutes.

NOTE:

The engine must be running for the heated

seats to operate.

Vehicles Equipped With Remote Start
On models that are equipped with remote start,

the heated seats can be programmed to come

on during a remote start.
This feature can be programmed through the

Uconnect system. Refer to “Uconnect Settings”

in “Multimedia” for further information.

Seatback/Armrest — Second Row

Passenger Seat

The latch release-loop is located at the top of

the seatback/armrest. Pull the release-loop

forward to release the latch and then downward

to lower the seatback/armrest.

Seatback/Armrest

Raise the seatback/armrest and lock it in place

when not in use, or when additional seating

area is required.

WARNING!

Persons who are unable to feel pain to the

skin because of advanced age, chronic

illness, diabetes, spinal cord injury, medica-

tion, alcohol use, exhaustion or other phys-

ical condition must exercise care when

using the seat heater. It may cause burns

even at low temperatures, especially if

used for long periods of time.

Do not place anything on the seat or seat-

back that insulates against heat, such as a

blanket or cushion. This may cause the seat

heater to overheat. Sitting in a seat that has

been overheated could cause serious

burns due to the increased surface

temperature of the seat.

WARNING!

Keep the latch clean and free of objects and

be certain that the seatback/armrest is

locked securely into position. Otherwise, the

seat will not provide the proper stability for

child seats and/or passengers. An improperly

latched seat could cause serious injury.

2

34

GETTING TO KNOW YOUR VEHICLE



HEAD RESTRAINTS

Head restraints are designed to reduce the risk

of injury by restricting head movement in the

event of a rear impact. Head restraints should

be adjusted so that the top of the head restraint

is located above the top of your ear.

Supplemental Active Head Restraints (AHR)

— Front Seats

Supplemental Active Head Restraints (AHR) are

passive, deployable components, and vehicles

with this equipment can not be readily identified

by any markings, only through visual inspection

of the head restraint. The head restraint will be

split in two halves, with the front half being soft

foam and trim, the back half being decorative

plastic.
When AHRs deploy during a rear impact, the

front half of the head restraint extends forward

to minimize the gap between the back of the

occupant’s head and the AHR. This system is

designed to help prevent or reduce the extent of

injuries to the driver and front passenger in

certain types of rear impacts. Refer to “Occu-

pant Restraint Systems” in “Safety” for further

information.
To raise the head restraint, pull upward on the

head restraint. To lower the head restraint,

push the adjustment button, located at the

base of the head restraint, and push downward

on the head restraint.

Adjustment Button

For comfort, the Active Head Restraints can be

tilted forward and backward. To tilt the head

restraint closer to the back of your head, pull

forward on the bottom of the head restraint.

Push rearward on the bottom of the head

restraint to move the head restraint away from

your head.

Active Head Restraint (Normal Position)

WARNING!

All occupants, including the driver, should

not operate a vehicle or sit in a vehicle’s

seat until the head restraints are placed in

their proper positions in order to minimize

the risk of neck injury in the event of a

crash.

Head restraints should never be adjusted

while the vehicle is in motion. Driving a

vehicle with the head restraints improperly

adjusted or removed could cause serious

injury or death in the event of a collision.

GETTING TO KNOW YOUR VEHICLE

35

Active Head Restraint (Tilted)

NOTE:

The head restraints should only be removed

by qualified technicians, for service purposes

only. If either of the head restraints require

removal, see an authorized dealer.

In the event of deployment of an Active Head

Restraint, refer to “Occupant Restraints

/Supplemental Active Head Restraints

(AHR)/Resetting Active Head Restraints

(AHR)” in “Safety” for further information.

Rear Head Restraint Adjustment

The second row seats are equipped with adjust-

able and removable head restraints. To raise

the head restraint, pull upward on the head

restraint. To lower the head restraint, push the

adjustment button located on the base of the

head restraint, and push downward on the head

restraint.

Rear Head Restraint

WARNING!

All occupants, including the driver, should

not operate a vehicle or sit in a vehicle’s

seat until the head restraints are placed in

their proper positions in order to minimize

the risk of neck injury in the event of a

collision.

Do not place items over the top of the

Active Head Restraint, such as coats, seat

covers or portable DVD players. These

items may interfere with the operation of

the Active Head Restraint in the event of a

collision and could result in serious injury or

death.

Active Head Restraints may be deployed if

they are struck by an object such as a hand,

foot or loose cargo. To avoid accidental

deployment of the Active Head Restraint

ensure that all cargo is secured, as loose

cargo could contact the Active Head

Restraint during sudden stops. Failure to

follow this warning could cause personal

injury if the Active Head Restraint is

deployed.

1 — Release Button
2 — Adjustment Button

2

36

GETTING TO KNOW YOUR VEHICLE



Rear Head Restraint Removal

To remove the head restraint, push the adjust-

ment and the release buttons while pulling

upward on the whole assembly and raise it up

as far as it can go. To reinstall the headrest, put

the headrest posts into the holes while pushing

the release buttons. Then adjust it to the appro-

priate height.

NOTE:

For proper routing of a Child Seat Tether, refer

to “Occupant Restraint Systems” in “Safety”.

STEERING WHEEL

Tilt/Telescoping Steering Column

This feature allows you to tilt the steering

column upward or downward. It also allows you

to lengthen or shorten the steering column. The

tilt/telescoping control handle is located below

the steering wheel at the end of the steering

column.

Tilt/Telescoping Steering Control Handle

To unlock the steering column, push the control

handle downward. To tilt the steering column,

move the steering wheel upward or downward

as desired. To lengthen or shorten the steering

column, pull the steering wheel outward or push

it inward as desired. To lock the steering column

in position, pull the control handle upward until

fully engaged.

WARNING!

A loose head restraint thrown forward in a

collision or hard stop could cause serious

injury or death to occupants of the vehicle.

Always securely stow removed head

restraints in a location outside the occupant

compartment.

WARNING!

ALL the head restraints MUST be reinstalled

in the vehicle to properly protect the

occupants. Follow the re-installation

instructions above prior to operating the

vehicle or occupying a seat.

WARNING!

Driving a vehicle with the head restraints

removed or improperly adjusted could cause

serious injury or death in the event of a

collision. The head restraints should be

checked prior to operating the vehicle and

never adjusted while the vehicle is in motion.

WARNING!

Do not adjust the steering column while

driving. Adjusting the steering column while

driving or driving with the steering column

unlocked, could cause the driver to lose

control of the vehicle. Failure to follow this

warning may result in serious injury or death.

GETTING TO KNOW YOUR VEHICLE

37

(Continued)

Heated Steering Wheel — If Equipped

The steering wheel contains a heating element

that helps warm your hands in cold weather.

The heated steering wheel has only one

temperature setting. Once the heated steering

wheel has been turned on, it will stay on for an

average of 80 minutes before automatically

shutting off. This time will vary based on envi-

ronmental temperatures. The heated steering

wheel can shut off early or may not turn on

when the steering wheel is already warm.
The heated steering wheel control button is

located within the Uconnect system. You can

gain access to the control button through the

climate screen or the controls screen.

Press the heated steering wheel button

once to turn the heating element on.

Press the heated steering wheel button   a

second time to turn the heating element off.

NOTE:

The engine must be running for the heated

steering wheel to operate.

Vehicles Equipped With Remote Start
On models that are equipped with remote start,

the heated steering wheel can be programmed

to come on during a remote start through the

Uconnect system. Refer to “Uconnect Settings”

in “Multimedia” for further information.

MIRRORS

Inside Day/Night Mirror — If Equipped

The mirror head can be adjusted up, down, left,

and right for various drivers. The mirror should

be adjusted to center on the view through the

rear window.
Headlight glare from vehicles behind you can be

reduced by moving the small control under the

mirror to the night position (toward the rear of

the vehicle). The mirror should be adjusted

while set in the day position (toward the

windshield).

WARNING!

Persons who are unable to feel pain to the

skin because of advanced age, chronic

illness, diabetes, spinal cord injury, medica-

tion, alcohol use, exhaustion, or other phys-

ical conditions must exercise care when

using the steering wheel heater. It may

cause burns even at low temperatures,

especially if used for long periods.

Do not place anything on the steering wheel

that insulates against heat, such as a

blanket or steering wheel covers of any type

and material. This may cause the steering

wheel heater to overheat.

WARNING!

 (Continued)

2

38

GETTING TO KNOW YOUR VEHICLE



NOTE:

A single ball joint mirror is provided in the

vehicle. It is a twist on mirror that has a fixed

position at the windshield. The mirror installs on

the windshield button with a counterclockwise

rotation and requires no tools for mounting. The

mirror head can be adjusted left and right and

tilted up and down for various drivers. The

mirror should be adjusted to center on the view

through the rear window.

Adjusting Rearview Mirror

Automatic Dimming Mirror — If Equipped

A single ball joint mirror is provided in the

vehicle. It is a twist on mirror that has a fixed

position at the windshield. The mirror installs on

the windshield button with a counterclockwise

rotation and requires no tools for mounting. The

mirror head can be adjusted up, down, left, and

right for various drivers. The mirror should be

adjusted to center on the view through the rear

window.
This mirror automatically adjusts for headlight

glare from vehicles behind you.

NOTE:

The Automatic Dimming Mirror feature is

disabled when the vehicle is in REVERSE to

improve rear view viewing.

The Automatic Dimming Mirror feature can

be turned on or off using the Uconnect

System. Refer to “Uconnect Settings” in

“Multimedia” for further information.

Automatic Dimming Mirror

CAUTION!

To avoid damage to the mirror during

cleaning, never spray any cleaning solution

directly onto the mirror. Apply the solution

onto a clean cloth and wipe the mirror clean.

GETTING TO KNOW YOUR VEHICLE

39

Automatic Dimming Mirror With Rear View

Camera Display — If Equipped

A single ball joint mirror is provided in the

vehicle. It is a twist on mirror that has a fixed

position at the windshield. The mirror installs on

the windshield button with a counterclockwise

rotation and requires no tools for mounting. The

mirror head can be adjusted up, down, left, and

right for various drivers. The mirror should be

adjusted to center on the view through the rear

window.
This mirror automatically adjusts for headlight

glare from vehicles behind you.
When the vehicle is placed in REVERSE, a video

display illuminates to display the image gener-

ated by the rear view camera located on the lift-

gate handle. The auto dimming feature is also

disabled to improve rear view viewing.

Automatic Dimming Mirror With Rear View Camera

Outside Mirrors

To receive maximum benefit, adjust the outside

mirrors to center on the adjacent lane of traffic

and a slight overlap of the view obtained from

the inside mirror.

NOTE:

The passenger side convex outside mirror will

give a much wider view to the rear, and espe-

cially of the lane next to your vehicle.

Outside Mirrors Folding Feature

All outside mirrors are hinged and may be

moved either forward or rearward to resist

damage. The hinges have three detent posi-

tions:

Full forward position

Full rearward position

Normal position

WARNING!

Vehicles and other objects seen in the

passenger side convex mirror will look smaller

and farther away than they really are. Relying

too much on your passenger side convex

mirror could cause you to collide with another

vehicle or other object. Use your inside mirror

when judging the size or distance of a vehicle

seen in the passenger side convex mirror.

2















Content      ..      1      2      3      ..
