Potential causes

Condition

· There are no MyKeys programmed to the vehicle. See Creating a
MyKey
 (page 68).

· The key or transmitter used to start the vehicle does not have admin
privileges.

I cannot clear the MyKeys.

· No MyKeys are created.  See Creating a MyKey (page 68).

· Purchase a new key or transmitter from your authorized dealer.

I lost the only admin key.

· Program a spare key or transmitter. You may need to see your
authorized dealer. See Passive Anti-Theft System (page 83).

I lost a key.

· The MyKey user is not using the MyKey.

MyKey distances do not accumulate.

· An admin key holder cleared the MyKeys and created new MyKeys.
· The key system has been reset.

71

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

MyKey™

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKING AND UNLOCKING

You can use the power door lock control or
the remote control to lock and unlock your
vehicle.

Power Door Locks

The power door lock control is on the driver
and front passenger door panels.

E138628

Unlock.

A

Lock.

B

Door Lock Indicator

An LED on each door window trim illuminates
when you lock the door.  It remains on for
up to 10 minutes after you switch the ignition
off.

Door Lock Switch Inhibitor

When you electronically lock your vehicle,
the power door lock switch and interior trunk
release switch do not operate after 20
seconds.  You must unlock your vehicle with
the remote control or keyless keypad, or
switch the ignition on, to restore function to
these switches.  You can switch this feature
on or off in the information display.   See
General Information (page 120).

Note: Switch the ignition on and off after
changing the setting in the information
display.

Rear Door Unlocking and Opening

Pull the interior door handle twice to unlock
and open a rear door.  The first pull unlocks
the door and the second pull opens the door.

Remote Control

You can use the remote control at any time.
The liftgate release button only operates
when your vehicle's speed is less than 3 mph
(5 km/h).

Unlocking the Doors (Two-Stage Unlock)

E138629

Press the button to unlock the
driver door.

Press the button again within three seconds
to unlock all doors.  The direction indicators
will flash.

Note: If the system does not function, use
the key blade to lock and unlock your
vehicle.

Press and hold both the lock and unlock
buttons on the remote control for three
seconds to change between driver door or
all doors unlock mode.  The direction
indicators flash twice to confirm the change.
Driver door mode only unlocks the driver
door when you press the unlock button
once.  All door mode unlocks all doors when

72

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Doors and Locks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

you press the unlock button once.  The
unlocking mode applies to the remote
control, keyless entry keypad and intelligent
access.  You can also change between the
unlocking modes using the information
display.  See General Information (page 120).

Reprogramming the Unlocking Function

Note:  When you press the unlock button,
either all the doors are unlocked or only the
driver door is unlocked.  Pressing the unlock
button again unlocks all the doors.

Press and hold the unlock and lock buttons
on the remote control simultaneously for at
least four seconds with the ignition off.  The
direction indicators flash twice to confirm the
change.

To return to the original unlocking function,
repeat the process.

Locking the Doors

E138623

Press the button to lock all doors.
The direction indicators will flash.

Press the button again within three seconds
to confirm that all the doors are closed.  The
door lock again, the horn sounds and the
direction indicators flash if all the doors and
the liftgate are closed.

Note: If the system does not function, use
the key blade to lock and unlock your
vehicle.

Mislock

If any door or the liftgate is open, or if
the hood is open on vehicles with an
anti-theft alarm or remote start, the horn
sounds twice and the direction
indicators do not flash. You can switch
this feature on or off in the information
display.  See General Information (page
120).

Opening the Liftgate

E267940

Press twice within three seconds
to open the liftgate.

Activating Intelligent Access

General Information

You can unlock and lock the vehicle without
taking the keys out of your pocket or purse
when your intelligent access key is within
3 ft (1 m) of your vehicle. Intelligent access
uses a sensor on the back of the door handle
for unlocking and a separate sensor on the
face of each door handle for locking.

The system does not function if:

Your vehicle battery has no charge.

The key battery has no charge.

The key frequencies are jammed.

Note: The system may not function if the key
is close to metal objects or electronic
devices, for example keys or a cell phone.

Note: If the system does not function, use
the key blade to lock and unlock your
vehicle.  See Remote Control (page 62).

73

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Doors and Locks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking Using Intelligent Access

E248553

With your intelligent access key within 3 ft
(1 m) of your vehicle, touch the unlock sensor
on the back of the door handle for a brief
period and then pull on the door handle to
unlock, being careful to not touch the lock
sensor at the same time or pulling the door
handle too quickly. The intelligent access
system requires a brief delay to authenticate
your intelligent access key fob.

Locking Using Intelligent Access

E248554

With your intelligent access key within 3 ft
(1 m) of your vehicle, touch the outer door
handle lock sensor for approximately one
second to lock, being careful to not touch
the unlock sensor on the back of the door
handle at the same time. After locking, you
can immediately pull on the door handle to
confirm locking occurred without
inadvertently unlocking.

At the Luggage Compartment

E247050

With your intelligent access key within 3 ft
(1 m) of your vehicle, press the exterior
release button.

74

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Doors and Locks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking and Unlocking the Doors with
the Key Blade

A key cylinder is located under the driver
side door handle. You can use your key
blade to manually lock and unlock the driver
side door.  See Remote Control (page 62).

Smart Unlocks for Intelligent Access
Keys

This helps to prevent you from locking your
key inside the passenger compartment or
rear cargo area.

When you electronically lock your vehicle
with any door open, the transmission is in
park (P) and the ignition is off, the system
searches for an intelligent access key inside
your vehicle after you close the last door.  If
the system finds a key, all the doors
immediately unlock and the horn sounds
twice, indicating that a key is inside.

You can override the smart unlock feature
and intentionally lock the intelligent access
key inside your vehicle.

To do this, lock your vehicle after you have
closed all the doors by:

Using the keyless entry keypad.

Pressing the lock button on another
intelligent access key.

When you open one of the front doors and
lock your vehicle using the power door lock
control, all doors will lock then unlock if:

The ignition is on.

The ignition is off and the transmission
is not in park (P).

Autolock

 (If Equipped)

Autolock locks all the doors when:

All doors are closed.

The ignition is on.

You shift into any gear putting your
vehicle in motion.

Your vehicle reaches a speed greater
than 12 mph (20 km/h).

Autolock repeats when:

You open then close any door while the
ignition is on and your vehicle speed is
9 mph (15 km/h) or lower.

Your vehicle reaches a speed greater
than 12 mph (20 km/h).

Autounlock

Autounlock unlocks all the doors when:

The ignition is on, all the doors are
closed, and your vehicle has been
moving at a speed greater than 12 mph
(20 km/h).

Your vehicle comes to a stop and you
switch the ignition off, or to the accessory
position.

You open the driver door within 10
minutes of switching the ignition off or to
accessory.

Note: The doors do not autounlock if you
electronically lock your vehicle after you
switch the ignition off and before you open
the driver door.

75

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Doors and Locks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Enabling or Disabling Autounlock

You can enable or disable the autounlock
feature in the information display or an
authorized dealer can do it for you.  See
General Information (page 120).

Illuminated Entry

The interior lamps and some exterior lamps
illuminate when you unlock the doors with
the remote control.

The lamps turn off if:

The ignition is on.

You press the remote control lock button.

25 seconds have elapsed.

The lamps do not turn off if:

You turn them on with the lamp control.

Any door is open.

Illuminated Exit

The interior lamps and some exterior lamps
illuminate when all doors are closed and you
switch the ignition off.

The lamps turn off if all the doors remain
closed and:

25 seconds have elapsed.

You press the push button ignition
switch.

Approach Detection Illumination

When you approach your vehicle and a valid
key is detected, the exterior door handles
and some exterior lamps illuminate.

Battery Saver

If you leave the courtesy lamps, interior
lamps or headlamps on, the battery saver
shuts them off 10 minutes after you switch
the ignition off.

Battery Saver for Intelligent Access Keys

If you leave the ignition switched on, it shuts
off when it detects a certain amount of
battery drain, or after 45 minutes.

KEYLESS ENTRY

SECURICODE™ KEYLESS ENTRY
KEYPAD

The keypad is near the driver window.  It
illuminates when touched.

Note:  If you enter your entry code too fast
on the keypad, the unlock function may not
work.  Enter your entry code again more
slowly.

E138637

76

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Doors and Locks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

You can use the keypad to:

Lock or unlock the doors.

Unlock the liftgate glass.

Program and erase user codes.

Arm and disarm the anti-theft alarm.

You can operate the keypad with the
factory-set five-digit entry code.  The code
is on the owner's wallet card in the glove box
and is available from an authorized dealer.
You can also program up to five of your own
five-digit personal entry codes.

Programming a Personal Entry Code

To create your own personal entry code:

1. Enter the factory-set five-digit code.

2. Press 1·2 on the keypad within five

seconds.

3. Enter your personal five-digit code.  You

must press each number within five
seconds of each other.

4. Press 1·2 on the keypad to save personal

code 1.

The doors lock then unlock to confirm that
programming was successful.

To program additional personal entry codes,
repeat Steps 1-3, then for Step 4:

Press 3·4 to save personal code 2

Press 5·6 to save personal code 3

Press 7·8 to save personal code 4

Press 9·0 to save personal code 5.

You may also program a personal entry code
through the information display.

Tips:

Do not set a code that uses five of the
same number.

Do not use five numbers in sequential
order.

The factory-set code works even if you
have set your own personal code.

Erasing a Personal Code

1. Enter the factory-set 5-digit code.

2. Press and release 1·2 on the keypad

within five seconds.

3. Press and hold 1·2 for two seconds. You

must do this within five seconds of
completing Step 2.

All personal codes erase and only the
factory-set 5-digit code works.

Anti-Scan Feature

The keypad goes into an anti-scan mode if
you enter the wrong code seven times.  This
mode turns off the keypad for one minute
and the keypad lamp flashes.

The anti-scan feature turns off after:

One minute of keypad inactivity.

Pressing the unlock button on the remote
control.

Switching the ignition on.

Locking and Unlocking

To Unlock All Doors

Enter the factory-set 5-digit code or your
personal code to unlock all doors.

To Lock All Doors

Press and hold 7·8 and 9·0 at the same time
with the driver door closed to lock all doors.
You do not need to enter the keypad code
first.

77

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Doors and Locks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

To Unlock the Liftgate Glass

Enter the factory-set 5-digit code or your
personal code, then press 5·6 to unlock the
liftgate glass.

Displaying the Factory-Set Code

Note: Two programmed intelligent access
keys are required for this procedure.

1. Open the floor console storage

compartment lid.

2. With the buttons facing the rear of your

vehicle and the key ring facing upward,
place the first intelligent access key into
the backup slot inside the center console.

3. Press the push button ignition switch

once and wait for a few seconds.

4. Press the push button ignition switch

again and remove the intelligent access
key from the center console.

5. Insert the second programmed key into

the backup slot in the center console,
then press the push button ignition
switch.

The factory-set code appears in the
information display for a few seconds.

Note: The code may not display until after
any other warning messages first display.

78

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Doors and Locks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

POWER LIFTGATE

WARNING: It is extremely dangerous

to ride in a cargo area, inside or outside of
a vehicle. In a crash, people riding in these
areas are more likely to be seriously
injured or killed. Do not allow people to
ride in any area of your vehicle that is not
equipped with seats and seatbelts. Make
sure everyone in your vehicle is in a seat
and properly using a seatbelt. Failure to
follow this warning could result in serious
personal injury or death.

WARNING: Make sure that you fully

close the liftgate to prevent exhaust fumes
from entering your vehicle. If you are
unable to fully close the tailgate, open the
air vents or the windows to allow fresh air
to enter your vehicle. Failure to follow this
instruction could result in personal injury
or death.

WARNING: Make sure that you fully

close the liftgate to prevent passengers
and cargo from falling out. Failure to follow
this instruction could result in personal
injury or death.

WARNING: Keep keys out of reach

of children. Do not allow children to
operate or play near an open or moving
power liftgate. You should supervise the
operation of the power liftgate at all times.

Note:  Make sure that you close the liftgate
before operating or moving your vehicle,
especially in an enclosure, like a garage or
a parking structure.  This could damage the
liftgate and its components.

Note:  Do not hang anything, for example a
bike rack, from the glass or liftgate.  This
could damage the liftgate and its
components.

The liftgate only operates with the
transmission in park (P).

Three warning tones sound as the liftgate
begins to power close. If there is a problem
with the open or close request, one of the
following may occur:

One tone sounds if the ignition is on and
the transmission is not in park (P).

Three tones sound if the battery voltage
is below the minimum operating voltage.

One tone sounds if the vehicle speed is
at or above 3 mph (5 km/h)

If the liftgate starts to close after it has fully
opened, this indicates there may be
excessive weight on the liftgate or a possible
strut failure.  A repetitive tone sounds and
the liftgate closes under control.  Remove
any excessive weight from the liftgate.  If the
liftgate continues to close after opening,
have the system checked as soon as
possible.

Opening and Closing the Liftgate

WARNING: Make sure all persons

are clear of the power liftgate area before
using the power liftgate control.

79

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Liftgate

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Note:  Objects too close to your vehicle, for
example a wall, garage door or another
vehicle may come into contact with the
moving liftgate.  Make sure the area behind
your vehicle is free from obstruction and that
there is enough room for you to operate the
liftgate.  This could damage the liftgate and
its components.

Note: Be careful when opening or closing
the liftgate in a garage or other enclosed
area to avoid damaging the liftgate.

Note:  Do not leave the liftgate open when
driving.  This could damage the liftgate and
its components.

From the Instrument Panel

With the transmission in park (P),
press the button on the instrument
panel.

Remote Control

E138630

Press the button twice within a few
seconds.

Outside Control

E247048

Liftgate window.  See Liftgate
Window
 (page 111).

A

Liftgate.

B

Opening the Liftgate

1. Unlock the liftgate with the remote

control or power door unlock control.  If
an intelligent access key is within 3 ft
(1 m) of the liftgate, the liftgate unlocks
when you press the liftgate release
button.

2. Press button B.

Note: Allow the power system to open the
liftgate. Manually pushing or pulling the
liftgate may activate the system’s obstacle
detection and stop the power operation or
reverse its direction, replicate a strut failure
or damage mechanical components.

Stopping the Liftgate Movement

Note:  Do not apply sudden excessive force
to the liftgate when it is in motion.  This could
damage the power liftgate and its
components.

80

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Liftgate

-------------------------------------------------------------------------------------------------------------------------------------------------------------

You can stop the liftgate movement by doing
any of the following:

Pressing the liftgate control button.

Pressing the liftgate button on the remote
control twice.

Pressing the liftgate button on the
instrument panel.

Setting the Liftgate Open Height

1. Open the liftgate.

2. Stop the liftgate movement by pressing

the control button on the liftgate when it
reaches the desired height.

Note: Once the liftgate has stopped moving,
you can also manually move it to the desired
height.

3. Press and hold the liftgate control button

on the liftgate until a tone sounds,
indicating programming is complete.

Note: You can only use the liftgate control
button to program the height.

Note: You cannot program the height if the
liftgate position is too low.

The new open liftgate height is recalled
when the power liftgate is opened.  To
change the programmed height, repeat the
above procedure.  Once you open the power
liftgate, you can manually move it to a
different height.

Note: The system recalls the new
programmed height, even if you disconnect
the battery.

When operating the power liftgate after you
have programmed a lower height than fully
open, you can fully open the liftgate by
manually pushing it upward to the maximum
open position.

Obstacle Detection

When Closing

The system stops when it detects an
obstacle.  Three tones sound and the system
reverses to open.  When you remove the
obstacle, you can power close the liftgate.

Note: Entering your vehicle when the liftgate
is closing can cause your vehicle to bounce
and activate obstacle detection. To prevent
this, let the power liftgate close completely
before you enter your vehicle. Before driving
off, check the instrument cluster for a liftgate
or door ajar message or warning indicator.
Failure to do this could result in
unintentionally leaving the liftgate open
when driving.

When Opening

The system stops when it detects an
obstacle and two short tones sound.
Remove the obstacle to operate the liftgate.

Using the Hands-Free Liftgate

 (If Equipped)

Make sure you have an intelligent access
key within 3 ft (1 m) of the liftgate.

1. Stand behind your vehicle, and face the

liftgate.

2. Move your foot, in a single-kick motion,

without pausing, under and away from
the rear bumper detection area.

3. The liftgate power opens or closes.

81

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Liftgate

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicles Without a Trailer Hitch

E253664

The detection area is in the center of the rear
bumper.

Vehicles With a Trailer Hitch

E253799

The detection area is on the left-hand side
and right-hand side of the hitch, between the
exhaust and the hitch.

Avoid the following actions when using
hands-free opening:

Making physical contact with the bumper.

Holding your foot under the bumper.

Sweeping your foot from side to side, or
kicking at an odd angle.

Note: Allow the power system to open the
liftgate. Manually pushing or pulling the
liftgate may activate the system’s obstacle
detection and stop the power operation or
reverse its direction, replicate a strut failure,
or damage mechanical components.

Note:  Splashing water may cause the
hands-free liftgate to open.  Keep the
intelligent access key away from the rear
bumper detection area when you wash your
vehicle.

82

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Liftgate

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PASSIVE ANTI-THEFT SYSTEM

Note:  The system is not compatible with
aftermarket remote start systems.  Use of
these systems may result in vehicle starting
problems and a loss of security protection.

Note: Metallic objects, electronic devices or
a second coded key on the same key chain
may cause vehicle starting problems if they
are too close to the key when starting the
engine. Prevent these objects from touching
the coded key while starting the engine.
Switch the ignition off, move all objects on
the key chain away from the coded key and
restart the engine if a problem occurs.

Note: Do not leave a duplicate coded key
in the vehicle. Always take your keys and
lock all doors when leaving the vehicle.

SecuriLock™

The system is an engine immobilization
system.  The intended design is to help
prevent the engine from starting unless a
coded key programmed to your vehicle is
used.  Using the wrong key may prevent the
engine from starting.  A message may appear
in the information display.

If you are unable to start the engine with a
correctly coded key, a malfunction has
happened and a message may appear in the
information display.

Automatic Arming

The vehicle arms immediately after you
switch the ignition off.

Automatic Disarming

If you switch the ignition on with a coded key
you disarm the vehicle. If you unlock the
doors with the touch handle you disarm the
alarm.

Replacement Keys

Note: Your vehicle comes equipped with two
intelligent access keys.

The intelligent access key functions as a
programmed key that operates the driver
door lock and activates the intelligent access
with push button start system, as well as a
remote control.

If your programmed transmitters are lost or
stolen and you do not have an extra coded
key, you will need to have your vehicle
towed to an authorized dealer.  You need to
erase the key codes from your vehicle and
program new coded keys.

Store an extra programmed key away from
the vehicle in a safe place to help prevent
any inconveniences. See your authorized
dealer to purchase additional spare or
replacement keys.

Programming a Spare Intelligent Access
Key

Note: Do not place the device on the
wireless accessory charging area when
programming intelligent access keys.

83

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Security

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Note: You can program a maximum of four
keys to your vehicle.

You must have two previously programmed
intelligent access keys inside your vehicle
and the new unprogrammed intelligent
access key readily accessible.  You can
purchase replacement keys or remote
controls from an authorized dealer.

Make sure that the ignition is switched off
before beginning this procedure.  Make sure
that you close all the doors before beginning
and that they remain closed throughout the
procedure.  Carry out all steps within 30
seconds of starting the sequence.  Stop and
wait for at least one minute before starting
again if you carry out any steps out of
sequence.

Read and understand the entire procedure
before you begin.

1. Remove the key blade from the

transmitter.

E247437

2. Open the center console storage

compartment lid.

3. Insert the first programmed key in the

backup slot.

4. Press the push button ignition switch.

5. Wait five seconds and then press the

push button ignition switch again.

6. Remove the intelligent access key.

7. Within 10 seconds, place a second

programmed intelligent access key in the
backup slot and press the push button
ignition switch.

8. Wait five seconds and then press the

push button ignition switch again.

9. Remove the intelligent access key.

10.

Wait five seconds, then place the
unprogrammed intelligent access key
in the backup slot and press the push
button ignition switch.

11.

Once complete, the information cluster
displays a message confirming the key
has been programmed. The direction
indicators flash and the horn sounds.

Programming is now complete.  Check that
the remote control functions operate and
your vehicle starts with the new intelligent
access key.

If programming was unsuccessful, wait 10
seconds and repeat steps 1 through 7.  If it
still does not work, take your vehicle to an
authorized dealer.

84

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Security

-------------------------------------------------------------------------------------------------------------------------------------------------------------

ANTI-THEFT ALARM - VEHICLES
WITH: INTERIOR SENSOR

Alarm System

Perimeter Alarm

The perimeter alarm is a deterrent against
unauthorized access to your vehicle through
the doors and the hood.

Interior Sensors

Note: Do not cover up the interior lamp unit
sensors.

The interior lamp unit sensors are in the
overhead console. The sensors act as a
deterrent against unauthorized intrusion by
sensing any movement inside your vehicle.

Inclination Sensors

When you lock your vehicle and arm the
alarm, the sensors are designed to detect
an attempt to raise your vehicle, for example
to remove a wheel or to tow it away.

Alarm Settings

ALL SENSORS ACTIVE is the standard
setting. In this mode, the interior sensors are
on when you arm the alarm.

In PERIMETER SENSING mode, the interior
sensors are off when you arm the alarm.

You can change the setting through the
information display. See General Information
(page 120).

Ask on Exit

 (If Equipped)

You can set the information display to ask
you each time which level of guard you wish
to set.

Triggering the Alarm

Once armed, the alarm triggers in any of the
following ways:

If someone opens a door, the liftgate or
the hood without a valid key or remote
control.

If you switch your vehicle on without a
correctly coded key.

If the interior sensors detect movement
within your vehicle.

If the alarm triggers, the alarm horn sounds
for 30 seconds and the hazard flashers turn
on for five minutes.

Any further attempts to perform one of the
above triggers the alarm again.

Arming the Alarm

To arm the alarm, lock your vehicle. See
Doors and Locks (page 72).

85

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Security

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Disarming the Alarm

Vehicles Without Keyless Entry

Disarm and silence the alarm by unlocking
the doors with the key and switching your
vehicle on with a correctly coded key, or by
unlocking the doors with the remote control.

Vehicles with Keyless Entry

Note: A valid remote control must be located
within the detection range of that door for
keyless entry. See Keyless Entry (page 76).

Disarm and silence the alarm by unlocking
the doors and switching your vehicle on, or
by unlocking the doors with the remote
control.

ANTI-THEFT ALARM - VEHICLES
WITH: ANTI-THEFT ALARM
SYSTEM

The system will warn you of an unauthorized
entry to your vehicle. It will be triggered if
any door, the luggage compartment or the
hood is opened without using the key,
remote control or keyless entry keypad.

The direction indicators will flash and the
horn will sound if unauthorized entry is
attempted while the alarm is armed.

Take all remote controls to an authorized
dealer if there is any potential alarm problem
with your vehicle.

Arming the Alarm

The alarm is ready to arm when there is not
a key in your vehicle. Electronically lock your
vehicle to arm the alarm.

Disarming the Alarm

Disarm the alarm by any of the following
actions:

Unlock the doors or luggage
compartment with the remote control or
keyless entry keypad.

Switch your vehicle on or start your
vehicle.

Use a key in the driver door to unlock
your vehicle, then switch your vehicle on
within 12 seconds.

Note: Pressing the panic button on the
remote control will stop the horn and signal
indicators, but will not disarm the system.

86

Navigator (TB9) Canada/United States of America, enUSA, Edition date: 201808, First-Printing

Security

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     3      4      5      6     ..
