ADJUSTING THE HEADLAMPS Vertical Aim Adjustment The headlamps on your vehicle are properly Headlamp Aiming Target E142592 8 feet (2.4 meters) A Center height of lamp to ground B 25 feet (7.6 meters) C Horizontal reference line D Vertical Aim Adjustment Procedure 1. Park the vehicle directly in front of a wall or screen on a level surface, 2. Measure the height of the headlamp bulb center from the ground and mark an 8 ft Note: To see a clearer light pattern for 3. Turn on the low beam headlamps to illuminate the wall or screen and open E142465 4. On the wall or screen you will observe a flat zone of high intensity light located at 311 MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing Maintenance |
