CAUTION!

To prevent possible damage:
• Before closing hood, make sure the hood prop rod is

fully seated into its storage retaining clips.

• Do not slam the hood to close it. Use a firm down-

ward push at the center front edge of the hood to
ensure that both latches engage. Never drive your
vehicle unless the hood is fully closed, with both
latches engaged.

LIFTGATE

Opening

The liftgate can be unlocked or locked pushing the unlock
or lock button on the Remote Keyless Entry key fob, the
Keyless Enter-N-Go (Passive Entry) lock/unlock button
underneath the left side of the accent bar, which is located
on the liftgate below the glass or by activating the power
door lock switch located on either front door trim panel.

Refer to “Keyless Enter-N-Go” in “Getting To Know Your
Vehicle” for further information on Keyless Enter-N-Go
(Passive Entry).

NOTE:

The liftgate cannot be unlocked or locked with the

manual door lock plungers on the door trim panels or the
door lock cylinder on the driver’s door.

To open the unlocked liftgate, squeeze the handle and pull
the liftgate toward you. Gas props will raise and support
the liftgate in the open position.

NOTE:

Because the gas pressure drops with temperature, it

may be necessary to assist the props when opening the
liftgate in cold weather.

Liftgate Release

GETTING TO KNOW YOUR VEHICLE

109

WARNING!

• Driving with the liftgate open can allow poisonous

exhaust gases into your vehicle. You and your pas-
sengers could be injured by these fumes. Keep the
liftgate closed when you are operating the vehicle.

• If you are required to drive with the liftgate open,

make sure that all windows are closed, and the
climate control blower switch is set at high speed. Do
not use the recirculation mode.

Cargo Area Features

Cargo Management System

Five Passenger System Features
• A raised load floor that sits on top of a large built-in

storage bin.

• A tri-fold door built into the load floor that allows easy

access to items in the built-in storage bin.

• 60/40 split second-row passenger seats with fold flat

feature, which allows for extended cargo space. Refer to
“Seats” in “Getting To Know Your Vehicle” for further
information.

• An optional front passenger seat with fold flat feature,

which extends cargo space even further. Refer to “Seats” in
“Getting To Know Your Vehicle” for further information.

• Cargo tie-downs.
• A retractable cargo area cover (if equipped).

Seven Passenger System Features
• A large built-in storage bin with a hinged hardcover

located in the floor behind the third-row passenger seats.

• 60/40 split second-row passenger seats with fold flat

feature, which allows for extended cargo space. Refer to
“Seats” in “Getting To Know Your Vehicle” for further
information.

• 50/50 split third-row passenger seats with fold flat

feature, which allows for extended cargo space. Refer to
“Seats” in “Getting To Know Your Vehicle” for further
information.

• An optional front passenger seat with fold flat feature,

which extends cargo space even further. Refer to “Seats” in
“Getting To Know Your Vehicle” for further information.

• Cargo tie-downs.

110

GETTING TO KNOW YOUR VEHICLE

Retractable Cargo Area Cover (If Equipped) — Five
Passenger Models

NOTE:

The purpose of this cover is for privacy, not to

secure loads. It will not prevent cargo from shifting or
protect passengers from loose cargo.

The removable retractable cargo area cover mounts in the
cargo area behind the top of the rear seats.

The cover, when extended, covers the cargo area to keep
items out of sight. Notches in the trim panels near the
liftgate opening secure the extended cover in place.

The cover rolls away neatly inside its housing when not in
use. You can also remove the cover from the vehicle to
make more room in the cargo area.

To Install The Cover:

1. Position the cover in the vehicle so that the flat side of

the housing faces upward.

2. Insert either the left or the right spring-loaded post

(located on the ends of the cover housing) into the left
attachment point or the right attachment point (shown).

3. Insert the spring-loaded post on the opposite end of the

cover housing into the attachment point on the opposite
side of the vehicle.

Installing Retractable Cargo Area Cover

GETTING TO KNOW YOUR VEHICLE

111

4. Grab the cover handle and pull it toward you. As the

cover nears the liftgate opening, guide the rear attach-
ment posts (on both ends of the cover) into the notches
in the trim panels. Lower the cover to position the posts
into the bottom of the notches and release the handle.

WARNING!

In a collision, a loose cargo cover in the vehicle could
cause injury. It could fly around in a sudden stop and
strike someone in the vehicle. Do not store the cargo
cover on the cargo floor or in the passenger compart-
ment. Remove the cover from the vehicle when taken
from its mounting. Do not store it in the vehicle.

Cargo Tie-Downs

WARNING!

Cargo tie-downs are not safe anchors for a child seat
tether strap. In a sudden stop or collision, a tie-down
could pull loose and allow the child seat to come loose.
A child could be badly injured. Use only the anchors
provided for child seat tethers.

Cargo tie-downs are located on both rear trim panels.
These tie-downs should be used to secure loads safely
when the vehicle is moving.

Positioning Retractable Cargo Area Cover

112

GETTING TO KNOW YOUR VEHICLE

WARNING!

The weight and position of cargo and passengers can
change the vehicle center of gravity and vehicle han-
dling. To avoid loss of control resulting in personal
injury, follow these guidelines for loading your ve-
hicle:
• Do not carry loads that exceed the load limits de-

scribed on the label attached to the left door or left
door center pillar.

(Continued)

WARNING! (Continued)

• Always place cargo evenly on the cargo floor. Put

heavier objects as low and as far forward as possible.

• Place as much cargo as possible in front of the rear

axle. Too much weight or improperly placed weight
over or behind the rear axle can cause the vehicle to
sway.

• Do not pile luggage or cargo higher than the top of

the seatback. This could impair visibility or become
a dangerous projectile in a sudden stop or collision.

• To help protect against personal injury, passengers

should not be seated in the rear cargo area. The rear
cargo space is intended for load carrying purposes
only, not for passengers, who should sit in seats and
use seat belts.

GARAGE DOOR OPENER — IF EQUIPPED

HomeLink replaces up to three remote controls (hand-held
transmitters) that operate devices such as garage door
openers, motorized gates, lighting or home security sys-
tems. The HomeLink unit operates off your vehicle’s
battery.

Cargo Tie-Downs

GETTING TO KNOW YOUR VEHICLE

113

The HomeLink buttons, located on either the overhead
console, headliner or sunvisor, designate the three different
HomeLink channels. The HomeLink indicator is located
above the center button.

NOTE:

HomeLink is disabled when the Vehicle Security

Alarm is active.

Before You Begin Programming HomeLink

Be sure that your vehicle is parked outside of the garage
before you begin programming.

For more efficient programming and accurate transmission
of the radio-frequency signal it is recommended that a new
battery be placed in the hand-held transmitter of the device
that is being programmed to the HomeLink system.

HomeLink Buttons/Overhead Consoles

HomeLink Buttons/Sunvisor/Headliner

114

GETTING TO KNOW YOUR VEHICLE

To erase the channels, place the ignition in the ON/RUN
position, and push and hold the two outside HomeLink
buttons (I and III) for up to 20 seconds or until the orange
indicator flashes.

NOTE:
• Erasing all channels should only be performed when

programming HomeLink for the first time. Do not erase
channels when programming additional buttons.

• If you have any problems, or require assistance, please

call toll-free 1-800-355-3515 or, on the Internet at
HomeLink.com for information or assistance.

Programming A Rolling Code

For programming garage door openers that were manufac-
tured after 1995:

These garage door openers can be identified by the
“LEARN” or “TRAIN” button located where the hanging
antenna is attached to the garage door opener. It is NOT the
button that is normally used to open and close the door.
The name and color of the button may vary by manufac-
turer.

1. Place the ignition in the ON/RUN position.

NOTE:

For vehicles equipped with Keyless Enter-N-Go,

place the ignition in the RUN position with the engine ON.
Make sure while programming HomeLink with the engine
ON that your vehicle is outside of your garage, or that the
garage door remains open at all times.

Training The Garage Door Opener

1 — Door Opener
2 — Training Button

GETTING TO KNOW YOUR VEHICLE

115

2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm)

away from the HomeLink button you wish to program
while keeping the HomeLink indicator light in view.

3. Push and hold the HomeLink button you want to

program while you push and hold the hand-held trans-
mitter button.

4. Continue to hold both buttons and observe the indicator

light. The HomeLink indicator will flash slowly and
then rapidly after HomeLink has received the frequency
signal from the hand-held transmitter. Release both
buttons after the indicator light changes from slow to
rapid.

5. At the garage door opener motor (in the garage), locate

the “LEARN” or “TRAINING” button. This can usually
be found where the hanging antenna wire is attached to
the garage door opener/device motor. Firmly push and
release the “LEARN” or “TRAINING” button. On some
garage door openers/devices there may be a light that
blinks when the garage door opener/device is in the
LEARN/TRAIN mode.

NOTE:

You have 30 seconds in which to initiate the next

step after the LEARN button has been pushed.

6. Return to the vehicle and push the programmed

HomeLink button twice (holding the button for two
seconds each time). If the garage door opener/device
activates, programming is complete.

NOTE:

If the garage door opener/device does not activate,

push the button a third time (for two seconds) to complete
the training.

To program the remaining two HomeLink buttons, repeat
each step for each remaining button. DO NOT erase the
channels.

Programming A Non-Rolling Code

For programming Garage Door Openers manufactured
before 1995:

1. Place the ignition in the ON/RUN position.

NOTE:

For vehicles equipped with Keyless Enter-N-Go,

2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm)

away from the HomeLink button you wish to program
while keeping the HomeLink indicator light in view.

116

GETTING TO KNOW YOUR VEHICLE

3. Push and hold the HomeLink button you want to

program while you push and hold the hand-held trans-
mitter button.

4. Continue to hold both buttons and observe the indicator

5. Push and hold the programmed HomeLink button and

observe the indicator light.

• If the indicator light stays on constantly, programming

is complete and the garage door/device should acti-
vate when the HomeLink button is pushed.

• To program the two remaining HomeLink buttons,

repeat each step for each remaining button. DO NOT
erase the channels.

Canadian/Gate Operator Programming

For programming transmitters in Canada/United States
that require the transmitter signals to “time-out” after
several seconds of transmission:

Canadian radio frequency laws require transmitter signals
to time-out (or quit) after several seconds of transmission,
which may not be long enough for HomeLink to pick up
the signal during programming. Similar to this Canadian
law, some U.S. gate operators are designed to time-out in
the same manner.

It may be helpful to unplug the device during the cycling
process to prevent possible overheating of the garage door
or gate motor.

1. Cycle the ignition to the ON/RUN position.

NOTE:

For vehicles equipped with Keyless Enter-N-Go,

2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm)

away from the HomeLink button you wish to program
while keeping the HomeLink indicator light in view.

3. Continue to push and hold the HomeLink button while

you push and release (“cycle”) your hand-held trans-
mitter every two seconds until HomeLink has success-
fully accepted the frequency signal. The indicator light
will flash slowly and then rapidly when fully trained.

GETTING TO KNOW YOUR VEHICLE

117

4. Watch for the HomeLink indicator to change flash rates.

When it changes, it is programmed. It may take up to 30
seconds or longer in rare cases. The garage door may
open and close while you are programming.

5. Push and hold the programmed HomeLink button and

observe the indicator light.

NOTE:

• If the indicator light stays on constantly, programming

is complete and the garage door/device should acti-
vate when the HomeLink button is pushed.

• To program the two remaining HomeLink buttons,

repeat each step for each remaining button. DO NOT
erase the channels.

If you unplugged the garage door opener/device for
programming, plug it back in at this time.

Using HomeLink

To operate, push and release the programmed HomeLink
button. Activation will now occur for the programmed
device (i.e. garage door opener, gate operator, security
system, entry door lock, home/office lighting, etc.) The
hand-held transmitter of the device may also be used at
any time.

Security

It is advised to erase all channels before you sell or turn in
your vehicle.

To do this, push and hold the two outside buttons for 20
seconds until the red indicator flashes.

NOTE:

All channels will be erased. Individual channels

cannot be erased.

The HomeLink Universal Transceiver is disabled when the
Vehicle Security Alarm is active.

Troubleshooting Tips

If you are having trouble programming HomeLink, here
are some of the most common solutions:
• Replace the battery in the Garage Door Opener hand-

held transmitter.

• Push the LEARN button on the Garage Door Opener to

complete the training for a Rolling Code.

• Did you unplug the device for programming and re-

member to plug it back in?

118

GETTING TO KNOW YOUR VEHICLE

If you have any problems, or require assistance, please call
toll-free

1-800-355-3515

or,

the

Internet

HomeLink.com for information or assistance.

WARNING!

• Vehicle exhaust contains carbon monoxide, a danger-

ous gas. Do not run your vehicle in the garage while
programming the transceiver. Exhaust gas can cause
serious injury or death.

• Your motorized door or gate will open and close

while you are programming the universal trans-
ceiver. Do not program the transceiver if people, pets
or other objects are in the path of the door or gate.
Only use this transceiver with a garage door opener
that has a “stop and reverse” feature as required by
Federal safety standards. This includes most garage
door opener models manufactured after 1982. Do not
use a garage door opener without these safety fea-
tures. Call toll-free 1-800-355-3515 or, on the Internet
at HomeLink.com for safety information or assis-
tance.

General Information

The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:

This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, in-

cluding interference that may cause undesired opera-
tion.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

GETTING TO KNOW YOUR VEHICLE

119

INTERNAL EQUIPMENT

Storage

Glove Compartment

The glove compartment is located on the passenger side of
the instrument panel.

To open the glove compartment, pull the release handle.

In-Floor Storage Bin With Removable Liner

NOTE:

Position the front seat to at least a mid-track

position to provide easier access to the storage bin.

An in-floor storage bin is located behind each front seat.
Each 1.6 gal (5.9L) bin can hold up to 12, 12 oz (0.35L) cans,
plus ice, or other items. The removable bin liner allows for
easy filling, emptying, and cleaning.

To access the bin, position the floor mat aside (if equipped).
Pull the door latch release-loop upward to release the latch
and then forward to open the bin door.

Glove Compartment

In-Floor Storage

120

GETTING TO KNOW YOUR VEHICLE

The liner can be removed for easy cleaning.

Second-Row Map Pocket And Grocery Retainers —
If Equipped

A map storage pocket and grocery retainers are located on
the back of the driver’s and passenger’s seatbacks.

Removable Liner

Seat Storage And Grocery Retainers

GETTING TO KNOW YOUR VEHICLE

121

Floor Console Storage

An open storage area, or cubby bin, is located in the floor
console.

Center Console Storage

There is a storage tray and storage compartment located
under the center console armrest.

Floor Console Cubby Bin

Center Console

122

GETTING TO KNOW YOUR VEHICLE

Pull upward on the release handle, located on the front of
the lid, to gain access to the storage tray and storage
compartment.

The storage tray can be slid forward and rearward or
removed to access the center console storage compartment.

WARNING!

Do not operate this vehicle with a console compart-
ment lid in the open position. Driving with the console
compartment lid open may result in injury in a colli-
sion.

Center Console Storage Tray

Center Console Storage Compartment

GETTING TO KNOW YOUR VEHICLE

123

Sliding Armrest

The center console armrest can also slide rearward for easy
access to the storage area.

WARNING!

Do not operate this vehicle with a console compart-
ment lid in the open position. Driving with the console
compartment lid open may result in injury in a colli-
sion.

Cupholders

There are two cupholders, located in the center floor
console, for the front passengers.

For passengers in the second row there are two cupholders,
located in the center armrest between the two seats.

When the armrest is folded flat the cupholders are in the
back of the Head Restraint. The Head Restraint can be
adjusted to better position the cupholders.

Sliding Armrest

Floor Console Cupholders

124

GETTING TO KNOW YOUR VEHICLE

Content .. 5 6 7 8 ..
